PIYW5734-12A4RRC HW CARS2 EZ DRIVER FRANCESCO

1 1 2 2 3 3 4 4 5 5 6 6 DD CC BB AA Distributed to SMT: No Yes Rev.: on demand. Ltd./Radica Games Ltd., and must be returned detrimental to the interest of Radica China covenants it will not be used in any manner Games Ltd. This print is loaned and recipient express consent of Radica China Ltd./Radica others, in part or in whole, without the reproduced, revealed to or appropriated by confidence and is not to be copied, Games Ltd. This information is disclosed in is the property of Radica China Ltd./Radica pertaining to the article shown on this sheet All design, operative and process data Description: Model No.: Drawn by: Checked by: Approved by: Drawing No.: Date: Date: Date: INNOVATIONS RADICA: A MEMBER OF RADICA GAMES GROUP Sheet of Changed byDateDescriptionRev. A W5734 Aug-20-2011 A11 761D0310 IN1 11 OUT1 12 IN2 13 OUT2 14 D00 5 D01 6 D02 8 D03 9 D04 10 ROSC 2 VDD 7 DIN 4 VSS 1 U1 GPRC206A 4.5V BATT 3*2A SW1 M M1Motor L/R Q5 8550 Q4 8550 Q6 8050 Q8 8050 Q9 8050 Q7 8050 R14 47 R11 47 GND VDD M M2 Motor F/B M_C2 104 Q11 1300_2A Q10 1300_2A Q12 8050 Q13 3279_2A Q15 3279_2A Q14 8050 R27 47 R26 47 GND VDD R18 4.7K R10 2.2K PTC-0075 GND GND VDD R15 4.7K GND R9 2.2K Q2 9012 R3 4.7K GND VDD R12 120R R8 200K R5 6.8K R202.2K R132.2K R6 3.3M R7 2.2K R1 470R R4 3.3M R2 150K C13 104 C15 103 C14 104 C9 102 C12100P C7104 C10 103 C16 12P C11 100uF C8 100uF GND GND GND Z1 3.3V GNDGND GND GNDGND R16 4.7K R28 2.2K GND R17 4.7K R29 2.2K GND L4 7KB-2431-00-LF 6.5T C20 332 C18 103 C17 18P C19 4.7uF L3 3.3uH GNDGNDGNDGND ANTENNA Q1 2SC2712 C21 5P LIZHU RC CAR RX 49MHz M_CAP 104 0603 0603 0603 0603 0603 0603 0603 0603 0603 0603 SOD-80 DIP 5*8 0603 0603 0603 0603 0603 0603 0603 0603 0603 0603 0603 DIP5*8 0603 0603 0603 0603 0603 0603 0603 0603 DIP 0603 06030603 0603 0603 0603 0805 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 SOT-23 TO-92 TO-92 TO-92 TO-92 DIP DIP DIP Initial Release 8/20/11LIZHU

TEST REPORT Report No. : AN0051788(7) Date : 20 Sep 2011 For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : Page 1 of 11 Mr. WONG Lap-pong, Andrew Assistant Manager Electrical Division FCC ID: PIYW5734-12A4R Application No. : LN026720(6) Applicant : Mattel Asia Pacific Sourcing Ltd. 1301, South Tower, World Finance Center, Harbour City, Tsimshatsui, Hong Kong Sample Description : One(1) item of submitted sample stated to be RC HW CARS2 EZ DRIVER FRANCESCO of Model No. W5734 Radio Frequency : 49.860MHz Receiver Rating : 3 x 1.5V AA size batteries No. of submitted sample : Two (2) piece (s) Date Received : 17 Aug 2011. Test Period : 25 Aug 2011 to 14 Sep 2011. Test Requested : FCC Part 15 Certification. Test Method : 47 CFR Part 15 (10-1-09 Edition) ANSI C63.4 – 2009 Test Result : See attached sheet(s) from page 2 to 11. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart B. TEST REPORT Report No. : AN0051788(7) Date : 20 Sep 2011 Page 2 of 11 FCC ID: PIYW5734-12A4R Table of Contents 1 General Information ................................................................................................................................... 3 1.1 General Description ............................................................................................................................ 3 1.2 Location of the test site ....................................................................................................................... 4 1.3 List of measuring equipment............................................................................................................... 5 1.4 Measurement Uncertainty ................................................................................................................... 5 2 Description of the radiated emission test ................................................................................................... 6 2.1 Test Procedure .................................................................................................................................... 6 2.2 Test Result .......................................................................................................................................... 6 2.3 Radiated Emission Measurement Data ............................................................................................... 7 3 Description of the Line-conducted Test ..................................................................................................... 8 3.1 Test Procedure .................................................................................................................................... 8 3.2 Test Result .......................................................................................................................................... 8 3.3 Graph and Table of Conducted Emission Measurement Data ............................................................ 8 4 Photograph ................................................................................................................................................. 9 4.1 Photographs of the Test Setup for Radiated Emission and Conducted Emission ............................... 9 4.2 Photographs of the External and Internal Configurations of the EUT................................................ 9 5 Supplementary document ......................................................................................................................... 10 5.1 Bandwidth ......................................................................................................................................... 10 5.2 Duty cycle ......................................................................................................................................... 10 5.3 Transmission time ............................................................................................................................. 10 6 Appendices...............................................................................................................................................11 TEST REPORT Report No. : AN0051788(7) Date : 20 Sep 2011 Page 3 of 11 FCC ID: PIYW5734-12A4R 1 General Information 1.1 General Description The equipment under test (EUT) is a receiver for RC HW CARS2 EZ DRIVER FRANCESCO. It operates at 49.860MHz and the oscillation of radio control is generated by a LRC circuit. The EUT is powered by 3 x 1..5V AA size batteries. When the EUT switched "ON" and received radio control signal, it will take the corresponding action. The brief circuit description is listed as follows: - Q1 and its associated circuit act as a receiver. - Q2, Z1 and its associated circuit act as a voltage regulator. - Q4, Q5, Q6, Q7, Q8, Q9 and its associated circuit act as motor M1 driver. - Q10, Q11, Q12, Q13, Q14, Q15 and its associated circuit act as motor M2 driver. - U1 and its associated circuit act as a decoder. TEST REPORT Report No. : AN0051788(7) Date : 20 Sep 2011 Page 4 of 11 FCC ID: PIYW5734-12A4R 1.2 Location of the test site Radiated emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2009. A Semi-Anechoic Chamber Testing Site is set up for investigation and located at: Ground Floor, Yan Hing Centre, 9 – 13 Wong Chuk Yeung Street, Fo Tan, Shatin, New Territories, Hong Kong. Conducted emissions measurements are investigated and also taken pursuant to the procedures of ANSI C63.4 – 2009. A shielded room is located at : Ground Floor, Yan Hing Centre, 9 – 13 Wong Chuk Yeung Street, Fo Tan, Shatin, New Territories, Hong Kong. TEST REPORT Report No. : AN0051788(7) Date : 20 Sep 2011 Page 5 of 11 FCC ID: PIYW5734-12A4R 1.3 List of measuring equipment Equipment Manufacturer Model No. Serial No. Calibration Due Date EMI Test Receiver R&S ESCI 100152 16 Mar 2012 Broadband Antenna Schaffner CBL6112B 2718 31 Oct 2012 Coaxial Cable Schaffner RG 213/U N…
