Ray101 Handheld VHF Radio Owner’s Handbook Document number: 81229_1 Date: November 2003 81229_1.book Page i Wednesday, November 12, 2003 2:39 PM 81229_1.book Page ii Wednesday, November 12, 2003 2:39 PM iii About this Handbook Introduction This handbook describes the Ray101 portable VHF marine radio. The Ray101 provides two-way communications on all US, Canadian and International marine channels and ten weather channels. Conventions Used Throughout this handbook, the dedicated (labelled) keys are shown in bold capitals (for example: SCAN/SAVE). The LCD indicators and functions are shown in normal capitals (for example: TX). ➤Operating procedures, which may consist of a single key-press or a sequence of numbered steps, are indicated by an arrow icon shown in the margin. Technical Accuracy To the best of our knowledge, the information in this handbook was correct as it went to press. However, our policy of continuous product improvement and updating may change specifications without prior notice. As a result, unavoidable differences between the product and handbook may occur from time to time. Raymarine cannot accept liability for any inaccuracies or omissions it may contain. For the latest product information visit our website: www.raymarine.com Warranty To register your new Raymarine product, please take a few minutes to fill out the warranty registration card found at the end of this handbook. It is very important that you complete the owner information and return the card to the factory in order to receive full warranty benefits. 81229_1.book Page iii Wednesday, November 12, 2003 2:39 PM ivRay101 Handheld VHF Radio Important Information Safety Warnings WARNING: Navigation Aid Although we have designed this product to be accurate and reliable, many factors can affect its performance. As a result, it should only be used as an aid to navigation and should never replace common sense and navigational judgement. Always maintain a permanent watch so you can respond to situations as they develop. WARNING: Battery and Battery Charger Safety Do not short the terminals in the charger base that recharge the batteries. Do not put the charger in water. Do not charge the batteries with + and – terminals reversed. Do not use charger if power plug or cable is damaged. Do not recharge batteries if physically deformed or leaking. EMC Conformance All Raymarine equipment and accessories are designed to the best industry standards for use in the recreational marine environment. Their design and manufacture conform to the appropriate Electromagnetic Compatibility (EMC) standards but correct installation and use is required to ensure that performance is not compromised. 81229_1.book Page iv Wednesday, November 12, 2003 2:39 PM v Raymarine Products and Services Raymarine products are supported by a network of Authorized Service Representatives. Raymarine’s Technical Services representatives or your local dealer will be available to answer any questions you may have. For information on Raymarine products and services, contact either of the following: United StatesRaymarine, Inc. 22 Cotton Road, Unit D Nashua, NH 03063-4219 USA Telephone:1-603-881-5200 1-800-539-5539 Fax: 1-603-864-4756 EuropeRaymarine Ltd Anchorage Park Portsmouth, Hampshire England PO3 5TD Telephone: +44 (0) 23 9269 3611 Fax: +44 (0) 23 9269 4642 Or, you may contact us on the World Wide Web at: www.raymarine.com Raymarine is a registered trademark of Raymarine Limited. © Raymarine Limited 2003 81229_1.book Page v Wednesday, November 12, 2003 2:39 PM viRay101 Handheld VHF Radio 81229_1.book Page vi Wednesday, November 12, 2003 2:39 PM vii Contents Safety Warnings ....................................................................................... iv EMC Conformance ................................................................................. iv Chapter 1: General Information .........................................................................1 1.1 Introduction ...................................................................................... 1 1.2 Features ............................................................................................ 1 1.3 Licensing Requirements ................................................................... 2 Chapter 2: Installation .........................................................................................5 2.1 Unpacking and Inspection ................................................................ 5 Equipment Supplied ..................................................................... 5 2.2 Attaching the Antenna ...................................................................... 5 2.3 Attaching the Belt Clip ..................................................................... 6 2.4 Attaching the Wrist Strap ................................................................. 6 2.5 Battery Usage ................................................................................... 6 Battery Tray .................................................................................. 6 Charging Rechargeable NiMH Cells ........................................... 8 Chapter 3: Getting Started ..................................................................................9 3.1 Keypad and Rotary Knobs ............................................................... 9 Rotary Keys .......................................................................... 10 Push Keys ............................................................................. 10 Description ................................................................................. 10 1. PWR/VOL ........................................................................ 10 2. SQ ..................................................................................... 10 3. PTT .................................................................................... 10 4. UP/DOWN ..................................................................…
Text truncated - open the document above for the full version.
Raymarine, Inc. 22 Cotton Road, Unit D Nashua NH 03063 4219 USA 603 881-5200 800-539-5539 (Fax) www.raymarine.com Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: PJ5RAY101 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: • Schematics • Block Diagrams • Bill of Materials The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Keith Wansley Raymarine, Inc. VP of Sales Telp: 603-846-4831 [email protected] Rev. 1/1/03
Raymarine, Inc. 22 Cotton Road, Unit D Nashua NH 03063 4219 USA 603 881-5200 800-539-5539 (Fax) www.raymarine.com Label for Raymarine Ray101 December 12, 2003 Label: 38.8mm x 31.8mm with 2.9x 1r corners Colors: print black on white label stock Raymarine, Inc. 22 Cotton Road, Unit D Nashua NH 03063 4219 USA 603 881-5200 800-539-5539 (Fax) www.raymarine.com Label Placement on the Ray101
RAY101 THEORY OF OPERATIO, Ver 1.0 z z z z! ! ! ! z " " " " # $ %& # $ %& # $ %& # $ %& z' ( $ ' ( $' ( $ ' ( $ z $ ')& (* * +)&, '-./#/0/%+)&,#-0/% ( )&,#.0/% 1 - * 2 ( + (&"+ #34% &" (5-+5/ 5. (567+ 5.8 $ -++&67+ &76+&74 + +36+3. ( &6+&/+&9+&66+&6+6+. ( &44+39+/, + * #*&% )&6+5+57+6+ 9 ! + :&" 34 34 ; z 2 ( ( ) 2 (#)%.6/ '< /98$< ( + $&6+&/+&9+&68+ &66+&6+6+.+9 + 36 =*! /* ( 59 =*! 9 ; 2 (( ; 564 * )#) 2 (%.6/'< ) ( 6#60.%+.#.0.% ) (56 ) )&-#>*/66% )&- + + ; +2 + .6/'<) ; ; . ) 2 (#)%/98 $< . ) - 9 )&/ #>*/66% ) * 7 )&-#>*/66% ((* )&.#?@'.8,8% $ 2 ( )&- #>*/66% ) )&- #>*/66% 2 66/+ &6/+ &69 2 2 # % 6/ )&- 2 &A $ 6. )&- ==) &A z 3 3 3 3 ( +(.6 .. )&9 /6 z! ! ! ! )&4#>+&+3%'-./+ ()&4*'-./+ + ()&9A3,47/8, z# $ %& # $ %& # $ %& # $ %& # $ %& 2 ( 2 ( :6.879'< )&/ #B>44.9% * $ #% )&/ #B>44.9%+ : &" 56, : &" 56 2 ( 2 ( ( )&/ .9 $< ! &" 2 ( 2 (()&/ 2 ( .9$<+ BLOCK DIAGRAMBLOCK DIAGRAM &" ! 2 + $&" 2 ( $ &A 2 ( $ z' (> $ ' (> $' (> $ ' (> $ )&68 CC"'*./&6 ( $ $ ( C ( + &A ( + *'+ ( CC"' *' '&A
© 2003 Celltech Labs Inc. 1 of 20 Test Report S/N: 120303-448PJ5 Test Date(s): December 09, 2003 Test Type: FCC/IC SAR Evaluation Celltech Labs Inc. declares under its sole responsibility that this wireless portable device has demonstrated compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada’s Safety Code 6. The device was tested in accordance with the measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01) and Industry Canada RSS-102 Issue 1 (Provisional) for the General Population / Uncontrolled Exposure environment. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Russell W. Pipe Senior Compliance Technologist Celltech Labs Inc. DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION Test Lab CELLTECH LABS INC. Testing and Engineering Services 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250-448-7047 Fax: 250-448-7046 e-mail: [email protected] web site: www.celltechlabs.com Applicant Information RAYMARINE INC. 22 Cotton Road, Unit D Nashua, NH 03063 Rule Part(s): FCC 47 CFR §2.1093; IC RSS-102 Issue 1 (Provisional) Test Procedure(s): FCC OET Bulletin 65, Supplement C (01-01) Device Classification: GHH - Part 80 VHF Hand Held Transmitter (GMDSS) FCC ID: PJ5RAY101 Model: RAY101 DUT Type: Portable VHF PTT Marine Radio Transceiver Modulation: FM (VHF) Tx Frequency Range: 156.025 - 157.425 MHz Max. RF Output Power Tested: 5.41 Watts Conducted (156.800 MHz) Antenna Type(s): Monopole Battery Type(s): 1.5 V AA Alkaline (x6) / 1.2 V AA NiMH (x6) Body-worn Accessories Tested: n/a (radio does not have provision for body-worn transmit operation) Max. SAR Measured: 0.310 W/kg - Face-held (50% Duty Cycle) © 2003 Celltech Labs Inc. 2 of 20 Test Report S/N: 120303-448PJ5 Test Date(s): December 09, 2003 Test Type: FCC/IC SAR Evaluation TABLE OF CONTENTS 1.0INTRODUCTION.....................................................................3 2.0DESCRIPTION OF DUT............................................................ 3 3.0SAR MEASUREMENT SYSTEM................................................ 4 4.0MEASUREMENT SUMMARY..................................................... 5 5.0 DETAILS OF SAR EVALUATION............................................... 6 6.0EVALUATION PROCEDURES................................................... 6 7.0SYSTEM PERFORMANCE CHECK............................................. 7 8.0SIMULATED EQUIVALENT TISSUES......................................... 8 9.0SAR SAFETY LIMITS.............................................................. 8 10.0ROBOT SYSTEM SPECIFICATIONS.......................................... 9 11.0PROBE SPECIFICATION......................................................... 10 12.0PLANAR PHANTOM................................................................ 10 13.0VALIDATION PHANTOM........................................................... 10 14.0DEVICE HOLDER.................................................................... 10 15.0TEST EQUIPMENT LIST........................................................... 11 16.0MEASUREMENT UNCERTAINTIES............................................ 12-13 17.0REFERENCES........................................................................14 APPENDIX A - SAR MEASUREMENT DATA............................................. 15 APPENDIX B - SYSTEM PERFORMANCE CHECK DATA........................... 16 APPENDIX C - SYSTEM VALIDATION PROCEDURES............................... 17 APPENDIX D - PROBE CALIBRATION................................................... 18 APPENDIX E - MEASURED FLUID DIELECTRIC PARAMETERS................ 19 APPENDIX F - SAR TEST SETUP & DUT PHOTOGRAPHS........................ 20 © 2003 Celltech Labs Inc. RAYMARINE INC. FCC ID: PJ5RAY101 (Model: RAY101) 3 of 20 Portable VHF PTT Marine Radio Transceiver (156.025-157.425 MHz) Test Report S/N: 120303-448PJ5 Test Date(s): December 09, 2003 Test Type: FCC/IC SAR Evaluation This measurement report demonstrates compliance of the RAYMARINE INC. Model: RAY101 Portable VHF PTT Marine Radio Transceiver FCC ID: PJ5RAY101 with the SAR (Specific Absorption Rate) RF exposure requirements specified in FCC 47 CFR §2.1093 (see reference [1]) and Health Canada Safety Code 6 (see reference [2]) for the General Population / Uncontrolled Exposure environment. The test procedures described in FCC OET Bulletin 65, Supplement C (Edition 01- 01) (see reference [3]) and IC RSS-102 Issue 1 (Provisional) (see reference [4]), were employed. A description of the product and operating configuration, detailed summary of the test results, methodology and procedures used in the evaluation, equipment used, and the various provisions of the rules are included within this test report. FCC Rule Part(s) FCC 47 CFR §2.1093 IC Rule Part(s) RSS-102 Issue 1 (Provisional) Test Procedure(s) FCC OET Bulletin 65, Supplement C (01-01) Device Type Portable VHF PTT Marine Radio Transceiver FCC ID PJ5RAY101 Model No. RAY101 Serial No. SR-161/03 (Identical Prototype) Modulation FM (VHF) Tx Frequency Range 156.025 - 157.425 MHz Max. RF Output Power Tested 5.41 Watts Conducted (156.800 MHz) Battery Type(s) 1.5 V AA Alkaline (x6) 1.2 V AA NiMH (x6) Antenna Type(s) Monopole (Length: 138 mm) Body-worn Accessories Tested n/a (radio does not have provision for body-worn transmit operation) 1.0 INTRODUCTION 2.0 DESCRIPTION OF DEVICE UNDER TEST (DUT) © 2003 …
Text truncated - open the document above for the full version.
TIMCOTIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: RAYMARINE, INC. FCC ID: PJ5RAY101 REPORT #: R\RAYMAR\1594AUT3\1594AUT3TestReport.doc TITLE PAGE Test Report Product Name: HANDHELD MARINE TRANSCEIVER – TRANSMITTER PORTION FCC ID: PJ5RAY101 Applicant: RAYMARINE, INC. 22 COTTON ROAD UNIT D NASHUA, NH 03063-4219 Date Receipt: DECEMBER 1, 2003 Date Tested: DECEMBER 11, 2003 TIMCOTIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: RAYMARINE, INC. FCC ID: PJ5RAY101 REPORT #: R\RAYMAR\1594AUT3\1594AUT3TestReport.doc TABLE OF CONTENTS TABLE OF CONTENTS LIST APPLICANT: RAYMARINE, INC. FCC ID: PJ5RAY101 TEST REPORT: PAGE 1...........GENERAL INFORMATION & TECHNICAL DESCRIPTION PAGE 2...........TECHNICAL DESCRIPTION CONTINUED RF POWER OUTPUT PAGE 3...........VOICE MODULATION CHARACTERISTICS AUDIO FREQUENCY RESPONSE AUDIO LOW PASS FILTER PAGE 4...........MODULATION LIMITING CHARACTERISTICS PAGE 5...........OCCUPIED BANDWIDTH PAGE 6...........OCCUPIED BANDWIDTH PLOT PAGE 7...........SPURIOUS EMISSIONS AT ANTENNA TERMINALS PAGE 8...........METHOD OF MEASURING CONDUCTED SPURIOUS EMISSIONS PAGE 9-10........FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 11..........METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 12..........FREQUENCY STABILITY PAGE 13..........LIST OF TEST EQUIPMENT EXHIBIT CONTAINING: EXHIBIT 1.........CONFIDENTIALITY LETTER EXHIBIT 2.........BLOCK DIAGRAM EXHIBIT 3.........SCHEMATIC EXHIBIT 4.........PARTS LIST EXHIBIT 5.........USERS MANUAL EXHIBIT 6.........LABEL SAMPLE AND LOCATION EXHIBIT 7.........EXTERNAL PHOTOGRAPHS EXHIBIT 8.........INTERNAL PHOTOGRAPHS EXHIBIT 9.........ALIGNMENT PROCEDURE EXHIBIT 10........THEORY OF OPERATION EXHIBIT 11........TEST SET UP PHOTOGRAPHS EXHIBIT 12........SAR TEST REPORT TIMCOTIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: RAYMARINE, INC. FCC ID: PJ5RAY101 REPORT #: R\RAYMAR\1594AUT3\1594AUT3TestReport.doc Page 1 of 13 GENERAL_INFORMATION_REQUIRED FOR_TYPE_ACCEPTANCE 2.1033(c) RAYMARINE, INC. will sell the FCC ID: PJ5RAY101 VHF Marine transmitter in quantity, for use under FCC RULES PART 80. 2.1033(c) TECHNICAL_DESCRIPTION (4) Type of Emission: 16K0G3E/16K0F3E For 20KHz Bn = 2M + 2DK M = 3000 D = 4.6KHz (Peak Deviation) K = 1 Bn = 2(3.0K) + 2(4.6K)(1) = 6.0K + 10.0 = 16.0K 80.205 (A) ALLOWED AUTHORIZED BANDWIDTH = 20.00KHz. 2.1033(c)(5) Frequency Range: 156.025-157.425 MHz 2.1033(c)(6) Power Range and Controls: There is a user Power switch for High/Low Power. 2.1033(c)(8) DC Voltages and Current into Final Amplifier: POWER INPUT - FINAL AMPLIFIER ONLY WITH ALKALINE BATTERIES High Low Vce = 9 VDC Vce = 9 VDC Ice = 1.65 A. Ice = 0.67 A. Pin = 14.85 Watts Pin = 6.03 Watts WITH NiMH BATTIERES High Low Vce = 7.2 VDC Vce = 7.2 VDC Ice = 1.65 A. Ice = 0.67 A. Pin = 11.88 Watts Pin = 4.83 Watts Function of each electron tube or semiconductor device or other active circuit device: - EXHIBIT #4. 2.1033(c)(10) Complete Circuit Diagrams: The circuit diagram is included as EXHIBIT 3. The block diagram is included as EXHIBIT 2. 2.1033(c)(3) Instruction book. The instruction manual is included as EXHIBIT #5. TIMCOTIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: RAYMARINE, INC. FCC ID: PJ5RAY101 REPORT #: R\RAYMAR\1594AUT3\1594AUT3TestReport.doc Page 2 of 13 2.1033(c)(9) Tune-up procedure. The tune-up procedure is given in EXHIBIT #9. Description of all circuitry and devices provided for determining and stabilizing frequency is included in the circuit description in EXHIBIT #10. 2.1033(c)(13) Digital modulation. This unit does NOT use digital modulation. The data required by 2.1046 through 2.1055 is submitted below. 2.1046(a) RF_power_output. 80.215(e)(1) RF power is measured by connecting a 50 ohm, resistive wattmeter to the RF output connector. With a nominal battery voltage of 9 V, and the transmitter properly adjusted the RF output measures: POWER OUTPUT OUTPUT POWER: HIGH: 5.3 W CONDUCTED LOW: 1.0 W CONDUCTED METHOD OF MEASURING RF POWER OUTPUT Transmitter 50 ohm under test Resistive Wattmeter Power Supply TIMCOTIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: RAYMARINE, INC. FCC ID: PJ5RAY101 REPORT #: R\RAYMAR\1594AUT3\1594AUT3TestReport.doc Page 3 of 13 2.1047(a) Voice Modulation_characteristics: Audio Frequency Response -20 +10 -17.5 -15 -12.5 -10 -7.5 -5 -2.5 +0 +2.5 +5 +7.5 d B 100 5k 200 300 400 500 600 800 1k 2k 3k 4k Hz 2.1047(a) AUDIO_LOW_PASS_FILTER The audio low pass filter is included. Rules 80.213(e) for ship stations with a low pass filter. AUDIO LOWPASS FILTER GRAPH -17.5 +12.5 -15 -12.5 -10 -7.5 -5 -2.5 +0 +2.5 +5 +7.5 +10 d B 2k 20k 3k 4k 5k 6k 7k 8k 9k 10k Hz TIMCOTIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: RAYMARINE, INC. FCC ID: PJ5RAY101 REPORT #: R\RAYMAR\1594AUT3\1594AUT3TestReport.doc Page 4 of 13 2.1047(b) Audio_input_versus_modulation 80.213 (d) A plot of the audio input versus deviation is shown below. MODULATION LIMITING GRAPH 3.0KHz (Green), 1.0KHz (Blue), and 300Hz (Yellow) 0 5 4.5 k H z -60 +0 -50 -40 -30 -20 -10 dBu TIMCOTIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: RAYMARINE, INC. FCC ID: PJ5RAY101 REPORT #: R\RAYMAR\1594AUT3\1594AUT3TestReport.doc Page 5 of 13 2.1049(c) Occupied bandwidth: 80.213 (b) Data in the plots shows that on any frequency removed from the assigned fr…
Text truncated - open the document above for the full version.
849 NW State Road 45 · Newberry, Florida · United States
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 4 | 80.1101(c)(7) | 156.025 MHz - 157.425 MHz | 1 W | 16K0F3E | 10 ppm |
