CAGE Code 07KA5 Copyright©2013 Raytheon Company Unpublished Work. All rights reserved. Highway Transportation Management System Roadside Reader User’s Manual Version: 1.0 23 April 2013 Prepared by: Raytheon Company 1801 Hughes Drive Fullerton, CA 92833 22 April 2013 Roadside Reader User’s Manual Version 1.0 Page i Version Change History Revision Paragraph Explanation 1.0 All Initial release 22 April 2013 Roadside Reader User’s Manual Version 1.0 Page ii Table Of Contents 1 INTRODUCTION .............................................................................................................................................. 1 1.1 SAFETY CONSIDERATIONS ................................................................................................................................ 2 2 APPLICABLE DOCUMENTS ......................................................................................................................... 2 3 SETUP AND INSTALLATION ........................................................................................................................ 2 4 ROADSIDE READER OPERATION .............................................................................................................. 2 4.1 READER POWER INDICATOR ............................................................................................................................. 2 4.2 READER POWER SWITCH .................................................................................................................................. 2 4.3 STARTUP .......................................................................................................................................................... 3 4.4 FCC TWO PART WARNING: 15.19(A)(3) .......................................................................................................... 3 APPENDIX A. ACRONYMS AND DEFINITION OF TERMS ...................................................................... 5 22 April 2013 Roadside Reader User’s Manual Version 1.0 Page iii List of Figures Figure 1.1-1 DSRC Reader Unit .............................................................................................................. 1 Figure 4.3-1 Roadside Reader Menu Screen ........................................................................................... 3 22 April 2013 Roadside Reader User’s Manual Version 1.0 Page 1 1 Introduction The Reader is part of an automatic vehicle identification system that transmits and receives radio frequency (RF) data to/from transponder-equipped vehicles or assemblies. The Reader works in conjunction with a host computer system to identify a passing transponder, verify its operating credentials (if applicable), communicate to the driver whether the vehicle is cleared or not (if applicable), and transmit the transponder’s data package to the next appropriate station (dependent of the type of system connected to the Reader). The Reader is a part of the electronic toll collection system that may reside inside a cabinet adjacent to the toll road, or inside a vehicle for mobile operation. Figure 1.1-1 DSRC Reader Unit 22 April 2013 Roadside Reader User’s Manual Version 1.0 Page 2 1.1 Safety Considerations Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. 2 Applicable Documents The following documents apply to the extent specified herein: DSRC Reader Description and Operational Procedure Version 3.0 3 Setup and Installation The unit requires a 12VDC (9-18VDC) source capable of supplying up to 2.5A via a mating power connector (Hirose HR10-73P-4S) shown in Fig 1.1-1. Only antennas which have been approved for use with this Reader (see table 3.1-1) and professionally installed by Raytheon or its designated installer shall be connected to the unit. Changes or modifications not expressly approved by Raytheon could void the user's authority to operate the equipment. Manufacturer Model No. Gain (dB) Sirit ANTENNA-024 15 Transcore AA3152 14 Table 3.1-1 Approved antennas for Roadside Reader 4 Roadside Reader Operation 4.1 Reader Power Indicator A green LED on the front panel of the Reader is lit when the Reader is powered ON. A red LED on the front panel briefly lights up when the Reader is first turned on, and will turn off if the Reader is functioning properly. 4.2 Reader Power Switch A push button switch on the front panel of the Reader is used to power the Reader ON and OFF. 22 April 2013 Roadside Reader User’s Manual Version 1.0 Page 3 4.3 Startup To turn on the Roadside Reader, press the power switch on the front panel after verifying that a proper antenna or termination has been connected to the antenna port/s. After booting up the Reader should request a configuration command from the Host computer connected to either the Host Data port or the Test Port. Depending on internal jumper settings either of these ports are active. Refer to Reader Description and Operation Procedure document for specific configuration settings. The Host Data port is an RS-422 interface while the Test Port is an RS- 232 interface. Once a valid configuration command is received by the Roadside Reader, it will begin transmitting from any one of four antenna ports and at power levels ranging from 20 to 30 dBm depending on configuration settings. Transmissions occur at approximately 9.8 msec intervals and have durations of approx. 1 msec. There is…

Text truncated - open the document above for the full version.

4/24/2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Permanent Confidentiality To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459 pertaining to confidential material, we hereby request to hold permanently confidential all information contained within the below identified exhibits/document categories submitted pursuant to radio equipment certification requirements for FCC ID: PJL6156388. 1. Block Diagram 2. Operational Description 3. Schematics 4. Parts List / Tune-Up Procedure The above material contains trade secrets and proprietary information as specified by 47CFR 0.457(d) and technical data, which would customarily be guarded from competitors. The public disclosure of this information might be harmful to our company and provide unjustified benefits to our competitors. Sincerely, _________________________________________ Michael Mikasa Principal Electrical Engineer Raytheon – Network Centric Systems 1801 W. Hughes Drive M/S 675/K124 Fullerton, CA 92834 Filename: FCC Confidentiality Request (Permanent)revised.doc Directory: C:\BFR\REX-TPQ37\CCA SPECS Template: C:\Documents and Settings\00a2885\Application Data\Microsoft\Templates\Normal.dotm Title: Subject: Author: jessina.hunter Keywords: Comments: Creation Date: 4/24/2013 8:44:00 AM Change Number: 4 Last Saved On: 4/24/2013 8:45:00 AM Last Saved By: Raytheon Total Editing Time: 1 Minute Last Printed On: 4/24/2013 3:26:00 PM As of Last Complete Printing Number of Pages: 1 Number of Words: 161 (approx.) Number of Characters: 922 (approx.)

DSRC Reader V2- FCC 15.19 Label PlacementPlace Label on left side of housing as shown.

RAYTHEON COMPANY PROPRIETARY Copyright 2013 © Raytheon Company Unpublished Work-All Rights Reserved PROPRIETARY: This document or software contains Proprietary Information furnished for use in connection with Highway 407 and may be used, disclosed, or copied only in accordance with the Proprietary Information Disclosure Agreement, or other similar or related agreements, to one of which you work, must be a signatory, and, except with written permission of Raytheon Company or Raytheon Systems Canada Ltd., such information may not be published, disclosed or used for any other purpose, or duplicated in whole or in part. This document (or software if applicable) contains data whose export/transfer/disclosure is restricted by U.S. law. Dissemination to non-U.S. persons whether in the United States or abroad requires an export license or other authorization. 1. A NUMBER WITHIN A SQUARE SYMBOL MEANS: SEE NOTE NUMBER INDICATED. 2. MATERIAL: 3M-7860 4 MIL. WHITE POLYESTER, WITH 300 PRESSURE SENSITIVE ADHESIVE AND LAMINATE AFTER PRINTING. USE CSA APPROVED LABEL PROCESS HW332MT. 3. LOGO AND TEXT SHALL BE BLACK IN COLOR. 4. MANUFACTURER CAGE CODE SHALL BE 5 DIGITS. CAGE CODE NUMBER SHALL BE DEFINED PER INSTRUCTIONS PROVIDED WITH EACH PURCHASE ORDER. 5. SERIAL NUMBER SHALL BE 5 DIGITS. SERIALIZATION RANGE SHALL BE DEFINED PER INSTRUCTIONS PROVIDED WITH EACH PURCHASE ORDER. 6. ARTWORK SHALL BE PROVIDED IN DXF FORMAT 7. ALL TEXT SHALL BE ARIAL FONT, BOLD, TEXT HEIGHT .080 INCH. 8. RAYTHEON SHALL REVIEW AND APPROVE ARTWORK PRIOR TO MANUFACTURE. 9. AREA RESERVED FOR CSA “C/US” MARKING. MARKING APPROXIMATE SIZE AND LOCATION SHOWN. MARKING SHALL BE BLACK IN COLOR. 10. NAMEPLATE MANUFACTURER’S MARK SHALL BE PRINTED. NOT TO EXCEED 0.08” HEIGHT OR DIAMETER. STANDARD RELEASE APVD fl.rkL-_- M. MIKASA 8 7 + AZl>i 6t799I9 2 6 5 Ilc I flN AAfl REVISIONS AUTHORITY REV. DESCRIPTION DATE APPROVED B4359 - STANDARD RELEASE 3/05/13 ‘\-. __ 3.500±.020 1 .200±.020 50 .680 186387 ©© fi©© CC O ©za©j ©© .480 .280 © 7c C zL J NOTE: UNLESS OTHERWISE SPECIFIED 1 SHOWN R.063 4 PLACES 10 COLOR REFERENCE D C 1— B A 186387 rmJIbeo. DSRC READER M215-A2A CAGE CODE 07KM C US PART NUMBER 6156388-100 FCC ID: PJLSI 56388 SERIAL NUMBER XXXXX MFG CAGE CODE XXXXX 9-18 VDC 2A MAX. 8 EXCEPT AS NOTED DIM ARE IN INCHES & PER ANSI Y14.5 XXX XX ANGLES ±01 ±03 ±5° CONTRACT: L5252-4O7ETR-08 7 DWNC JOHNSON MATERIAL SEE NOTES CHK G. TESTA 3/05/13 RAYTHEON COMPANY FULLERTON, CALIFORNIA LABEL, FCC ID - DSRC READER V2 6 4 I 2 SIZE CAGECODE DWGNO REV B 07KA5 6156429 - SCALE 2:1 SHEET 1 OF 1

Page 1 of 8 Report No: 93870-12 RADIO FREQUENCY EXPOSURE REPORT FOR THE Device: DSRC Reader Model: M215-A2A Report No.: 93870-12 Date of issue: March 25, 2013 PREPARED FOR: Raytheon Company Bldg 675-D241 Dist. Center 1801 Hughes Drive Fullerton CA 92834-3310 PREPARED BY: EDDIE WONG CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 2 of 8 Report No: 93870-12 Purpose: To demonstrate compliance with United States, Canada and/or European Union RF Exposure requirements for Portable equipment (devices used ≤20cm from the body) or Mobile equipment (devices used >20cm from the body) with power output below exemption levels and Mobile equipment, where Maximum Permissible Exposure (MPE) Calculations apply. United States Compliance Requirements (1.1310): RF Exposure Evaluation Limits Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-3.0 614 1.63 *(100) 6 3.0-30 1842/f 4.89/f *(900/f 2 ) 6 30-300 61.4 0.163 1 6 300-1500 --- --- f/300 6 1500-100,000 --- --- 5.0 6 RF Exposure Evaluation Limits General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 --- --- f/1500 30 1500-100,000 --- --- 1.0 30 * Plane wave equivalent power density Limit is calculated based on the mid-band frequency used in the operating frequency range. Exemption Level: Power output <60/f GHz (mW) Page 3 of 8 Report No: 93870-12 Canadian Compliance Requirements (RSS-102): RF Exposure Evaluation Limits Occupational / Controlled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.003-1.0 600 4.9 --- 6 1.0-10 600/f 4.9/f --- 6 10-30 60 4.9/f --- 6 30-300 60 0.163 10 6 300-1500 3.54 f 0.5 0.0094*f 0.5 f/3 6 1500-15,000 137 0.364 50 6 15,000-150,000 137 0.364 50 616000/f 1.2 RF Exposure Evaluation Limits General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.003-1.0 280 2.19 --- 6 1.0-10 280/f 2.19/f --- 6 10-30 28 2.19/f --- 6 30-300 28 0.073 2 6 300-1500 1.585 * f 0.5 0.0042 * f 0.5 f/150 6 1500-15,000 61.4 0.163 10 6 15,000-150,000 61.4 0.163 10 616000/f 1.2 *Power density limit applicable >100MHz Exemption Level: Frequency Range (MHz) Maximum Output Power (Conducted or EIRP) 0.003-1000 ≤ 200 mW 1000-2200 ≤ 100 mW 2200-3000 ≤ 20 mW 3000-6000 ≤ 10 mW Page 4 of 8 Report No: 93870-12 European Union Compliance Requirements (ICNIRP): RF Exposure Evaluation Limits Occupational / Controlled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.00082-0.065 610 24.4 --- 6 0.065-1.0 610 1.6/f --- 1.0-10 610/f 1.6/f --- 6 10-400 61 0.16 10 6 400-2000 3.0 * f 0.5 0.008 * f 0.5 f/40 6 2000-300,000 137 0.36 50 6 RF Exposure Evaluation Limits General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.003-0.150 87 5.0 --- 6 0.150-1.0 87 0.73/f -- 6 1.0-10 87/f 0.5 0.73/f --- 6 10-400 28 0.073 2 6 400-2000 1.375 f 0.5 0.0037*f 0.5 f/200 6 2000-300,000 61 0.16 10 6 *Power density limit applicable >100MHz Exemption Level: Power output < 20mW 1 1 May vary by product type Page 5 of 8 Report No: 93870-12 Device and Antenna Operating Configuration: The EUT is placed on the test bench. RS232 port is connected to a support laptop. All other ports are left unpopulated for evaluation of RF signal at the antenna port. The spectrum analyzer is connected to Port 1 of the EUT. Port 1 thru Port 4 utilizes the same RF circuit. Digital attenuator set to : 9 Freq: 905MHz, 915MHz, 925MHz Modulation: OOK. Measured Peak Power= 29.04dBm, 29.92dBm, 29.18dBm (0.80 W, 0.98W, 0.83W) Antenna to be used with this product: Sirit, single-element patch antenna , ANTENNA-024 Gain: 15dBi Transcore, Universal Toll Antenna , AA3152 Gain: 14dBi Frequency range of measurement = Fundamental Test environment conditions: 25°C, 45% Relative Humidity, 100kPa The EUT obtains 12V DC power from a support DC Power supply. Modification: 0.1uF capacitor added to the T/R control line C196. Center frequency was set to 905MHz, 915MHz and 925MHz. The licensee will adjust the transmit frequency according to appropriate frequency plan at the time of licensing. Test Procedure: This equipment is evaluated in accordance with the guidelines set forth in OET Guide 65 & ANSI C95.1 for the US and Health Canada Safety Code 6 & RSS 102 for Canada. Other Considerations: Page 6 of 8 Report No: 93870-12 MPE Calculations Applicability: Limit Used X General Population / Uncontrolled Exposure Occupational / Controlled Exposure RF Exposure Exemption Yes United States No Canada No Europe Equipment operational details: Config # Operating Frequency (MHz) Measured Output Power (dBm) Antenna Gain (dBi) Antenna Type / Configuration EIRP (dBm) 1 915 29.92 14 Outdoor 43.92 Measurements based from EMC Test Report(s): 93870-7 MPE Calculation: 2 4d EIRP DensityPower   Given: EIRP in mW or W and d in cm or m Config …

Text truncated - open the document above for the full version.

This report contains a total of 29 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Raytheon Company TEST REPORT FOR DSRC Reader Model: M215-A2A Tested To The Following Standards: FCC Part 90I Report No.: 93870-7 Date of issue: March 25, 2013 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 29 Report No.: 93870-7 TABLE OF CONTENTS Administrative Information ........................................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 90I ................................................................................................................................................................... 7 RF Power Output ....................................................................................................................................................... 7 Occupied Bandwidth................................................................................................................................................ 11 Bandedge ................................................................................................................................................................. 14 Conducted Spurious Emissions ................................................................................................................................ 17 Radiated Spurious Emissions ................................................................................................................................... 20 Emissions Mask ........................................................................................................................................................ 23 Supplemental Information .......................................................................................................................................... 29 Measurement Uncertainty ...................................................................................................................................... 29 Emissions Test Details .............................................................................................................................................. 29 Page 3 of 29 Report No.: 93870-7 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Raytheon Company 1801 Hughes Drive Bldg. 675 -D241 Dist. Center Fullerton, CA 92834-3310 Dianne Dudley CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Mike Mikasa Project Number: 93870 Customer Reference Number: 4200632228 DATE OF EQUIPMENT RECEIPT: March 12, 2013 DATE(S) OF TESTING: March 12-14, 2013 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 29 Report No.: 93870-7 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.00.14 Immunity 5.00.07 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Bothell US0081 SL2-IN-E-1145R 3082C-1 318736 A-0148 Page 5 of 29 Report No.: 93870-7 SUMMARY OF RESULTS Standard / Specification: FCC Part 90I Description Test Pro…
