PKSQMTQMODEM800PCellular CDMA Data Modem Module

USER’S MANUAL Q-modem 800P Palm V series (V/Vx) attachable CDMA modem Document number: Q-modem 800P010317 Revised: March 17, 2001 CONFIDENTIALITY AND PROPRIETARY INFORMATION Do not duplicate or distribute without express permission from QMtel Co., Ltd. FCC RF EXPOSURE COMPLIANCE In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. This CDMA modem module has been tested for FCC RF exposure hand and body SAR compliance with the Palm V/Vx handheld organizer. In order to comply with FCC RF exposure requirements, the CDMA modem module must be operated with the Palm V/Vx handheld organizer. The use of this device in any other type of host configuration may not comply with FCC RF exposure requirements and should be avoided. During operation, a 0.5cm separation distance should be maintained between the antenna, whether extended or retracted, and the user’s/bystander’s body (excluding hands, wrists, feet, and ankles) to ensure FCC RF exposure compliance. CAUTION Changes or modifications without the express consent of QMtel Co., Ltd. voids the user’s authority to use the equipment. This equipment has been tested and found to comply with the limits pursuant to Part 22of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not used in accordance with instructions, can cause harmful radiation to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If the equipment does cause harmful interference in radio and television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: l Reorient or relocate the receiving antenna l Increase the separation distance between the equipment and the receiver l Contact QMtel Co., Ltd. Technical Support for assistance. Please read this information before use Introduction Q-modem 800P is Palm attachable modem based on CDMA technology. Q-modem 800P supports wireless data transaction with attachment to Palm V series (Palm V/Vx) on CDMA coverage territory. General Features l Ultra compact design & size l High capable li-ion rechargeable battery pack l 64kbps data transfer rate support-up to CDMA coverage l IS-95A/B CDMA Protocol Support l Wireless e-mail sending & receiving anywhere & anytime l Wireless Internet access & surfing anywhere & anytime l Standard RS-232 Interface l TIA/EIA IS-95A/B(Common Air interface) compatible: Protocol between MS and BTS l TIA/EIA IS-98A compatible: Minimum Performance Requirements for MS l IS-707 compatible: Async Data Service l IS-637 compatible: Short Message Services Unpacking 1. Q-modem 800P 2. Adaptor 3. Rechargeable battery Description Getting ready 1. Open the battery cover and install rechargeable li-ion battery pack into battery compart. 2. Connect adaptor to DC jack to recharge. Upon delivery, Battery is not fully charged. Please recharge before initial use till the power LED indicator turns green. 3. Connect Q-modem 800P with Palm V/Vx. And the following is configuration & setup instruction to connect your WISP/Carrier. Configuration & Setup Instruction 1. Click “Prefs”. 2. Click “Connection” at the right upper menu. Then click “New” out of the left bottom menu. 3. Enter the name, whatever you want at “Name”. Ex) qmodem 800p. And choose “Serial to Modem” at “Connection Method”. And choose “TouchTone” at “Dialing” and choose whatever you want at “Volume”. Then click “Details” out of the right bottom menu. 4. Adjust 115,200bps at “Speed”. And set “On” or “Automatic” at “Flow Ctl”. Then set “at+crm=129” for 9.6kbps Internet access or “at+crm=131” for 14.4kbps Internet access or “at+crm=135” for 64kbps Internet access at “Init String”. And click “OK” out of the left bottom menu. 5. Return “preferences” mode. And choose “Network”. 6. Enter “sktelecom” at “User Name” and choose “Prompt” at “Password”. 7. Choose the above name you made already at “Connection” and enter “1501” at “Phone”. Then, click “Connect” at the left bottom of menu. 8. You can access Internet once connected. Power and Display Specifications The modem has power function with external 4.5V AC/DC adaptor and internal Li-ion Cell battery. The adaptor must supply 4.5V± 5% power to the modem. The nominal voltage of internal single Li- ion battery is 3.7V. The modem turns on by two methods, applying EXT_PWR_ON to the modem and pressing the side switch on the modem for 1 second. Palm V attached with Qmodem-800P sends EXT_PWR_ON signal when the HOT SYNC button on the modem is pressed for 1 second. The modem turned on by 1 st method, pressing HOT SYNC button, is turned off when the Palm V is detached. The modem turned on by 2 nd method, turns off by pressing the side switch one more time for 1 second. *The modem also has power on/off button. Modem power is controlled by power on/off button. Display specification is to be changed in the future. LEDs status and their meanings Status RSSI LED Power LED Incoming Call LED Remark Green Steady During power-on AC used One time blink during power-on Green Blinking Indicate strong signal area Battery good Red Steady Battery low Battery mode LED Off No service area Battery cut-off Specifications Mech…

Text truncated - open the document above for the full version.

Celltech Research Inc. 1955 Moss Court, Kelowna, B.C. Canada V1Y 9L3 Tel. 250-860-3130 •• Fax. 250-860-3110 •• [email protected] www.globuswireless.com/celltech/celltech.htm April 2, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: QMTEL CO., LTD. FCC ID: PKSQMTQMODEM800P Part 22 Certification Gentlemen: On behalf of QMtel Co., Ltd., we hereby submit an application for Part 22 Certification of a Cellular CDMA Data Modem Module as follows: FCC ID: PKSQMTQMODEM800P Model(s): Q-MODEM 800P Equipment Class: Licensed Non-Broadcast Station Transmitter (TNB) Equipment Type: Cellular CDMA Data Modem Module for Palm V/Vx PDA Tx Freq. Range: 824.70 - 848.31 MHz Rx Freq. Range: 869.70 - 893.31 MHz Max. RF Output Power: 0.264 Watts (ERP) Emission Designator: 1M25F9W Attached is the Letter of Authorization, Confidentiality Request, ESN Affidavit, measurement report data and test plots, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), circuit diagrams and description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), user's manual with RF exposure warning statement, and RF exposure measurement report data & photographs. If you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Shawn McMillen General Manager Celltech Research Inc. Testing & Engineering Lab cc: QMtel Co., Ltd. QMtel Co., Ltd. 14’h FL., Dongwha B/D 58-7, Seosomun-Dong, Choong-Ku ljeoul Korea Zip: 100110 Tel: +82 2 7508744 I Fax: +82 2 7508799 VRL: www.qmtel.com E-mail: [email protected] DATE/y+iy/%P ./ -/ Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Re: QMtel Co., Ltd. FCC ID: PKSQMTQMODEM800P FCC Part 22 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, QMtel Co., Ltd. hereby requests confidentiality of the Block Diagrams, Circuit Diagrams, Circuit Description, Parts List, Tune-up Procedure, and Operational Description Attachments for the subject application. These documents contain detailed system and equipment description and related information about the product in which QMtel Co., Ltd. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, QMtel Co., Ltd. considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, SIGNATURE . NAME: YH Kim TITLE: CT0 COMPANY NAME: QMtel Co., Ltd.

CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 © 2001 Celltech Research Inc. QMtel Co., Ltd. FCC ID: PKSQMTQMODEM800P CDMA Modem Module for Palm V/Vx (824-849MHz) EXTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 © 2001 Celltech Research Inc. QMtel Co., Ltd. FCC ID: PKSQMTQMODEM800P CDMA Modem Module for Palm V/Vx (824-849MHz) EXTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 © 2001 Celltech Research Inc. QMtel Co., Ltd. FCC ID: PKSQMTQMODEM800P CDMA Modem Module for Palm V/Vx (824-849MHz) EXTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 © 2001 Celltech Research Inc. QMtel Co., Ltd. FCC ID: PKSQMTQMODEM800P CDMA Modem Module for Palm V/Vx (824-849MHz) EXTERNAL EUT PHOTOGRAPHS

CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 © 2001 Celltech Research Inc. QMtel Co., Ltd. FCC ID: PKSQMTQMODEM800P CDMA Modem Module for Palm V/Vx (824-849MHz) FCC ID LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. CDMA MODEM MODULE MODEL: QMODEM 800P FCC ID: PKSQMTQMODEM800P SERIAL NO.: MADE IN KOREA

CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 © 2001 Celltech Research Inc. QMtel Co., Ltd. FCC ID: PKSQMTQMODEM800P CDMA Modem Module for Palm V/Vx (824-849MHz) INTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 © 2001 Celltech Research Inc. QMtel Co., Ltd. FCC ID: PKSQMTQMODEM800P CDMA Modem Module for Palm V/Vx (824-849MHz) INTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 © 2001 Celltech Research Inc. QMtel Co., Ltd. FCC ID: PKSQMTQMODEM800P CDMA Modem Module for Palm V/Vx (824-849MHz) INTERNAL EUT PHOTOGRAPHS CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 © 2001 Celltech Research Inc. QMtel Co., Ltd. FCC ID: PKSQMTQMODEM800P CDMA Modem Module for Palm V/Vx (824-849MHz) INTERNAL EUT PHOTOGRAPHS

CELLTECH RESEARCH INC. Test Report S/N: 032101-78PKS 1955 Moss Court, Kelowna, Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. CERTIFICATE OF COMPLIANCE SAR EVALUATION This wireless portable device has been shown to be compliant for localized Specific Absorption Rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and has been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1999. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Celltech Research Inc. certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Shawn McMillen General Manager Celltech Research Inc. Test Lab: CELLTECH RESEARCH INC. Testing and Engineering Lab 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250 - 860-3130 Fax: 250 - 860-3110 Toll Free: 1-877-545-6287 e-mail: [email protected] web site: www.globuswireless.com Applicant Information: QMTEL CO., LTD. 14 th Fl., Dongwha B/D 58-7 Seosomun-Dong, Chung-Ku Seoul 100-110 Korea Attn: Mr. Zen Lee Sales & Marketing Manager FCC ID: PKSQMTQMODEM800P Model: Q-modem 800P Equipment Type: Cellular CDMA Data Modem Module for Palm V/Vx Equipment Class: Licensed Non-Broadcast Station Transmitter (TNB) Modulation(s): CDMA Tx Frequency Range: 824.70 - 848.31 MHz Rx Frequency Range: 869.70 - 893.31 MHz Max. RF Output Power: 0.264 Watts (ERP) FCC Rule Part(s): 2.1093; ET Docket 96.326 CELLTECH RESEARCH INC. Test Report S/N: 032101-78PKS 1955 Moss Court, Kelowna, Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. TABLE OF CONTENTS 1.0 INTRODUCTION.................................................................. 1 2.0 DESCRIPTION OF EUT.......................................................... 1 3.0 SAR MEASUREMENT SYSTEM ............................................. 2 4.0 MEASUREMENT SUMMARY.................................................. 3-6 5.0 SAR LIMITS........................................................................ 7 6.0 DETAILS OF SAR EVALUATION........................................... 7 7.0 EVALUATION PROCEDURES................................................. 8 8.0 SYSTEM VALIDATION.......................................................... 8 9.0 SIMULATED EQUIVALENT TISSUES...................................... 9 10.0 TISSUE PARAMETERS......................................................... 9 11.0 SYSTEM SPECIFICATIONS.................................................... 10 12.0 TEST EQUIPMENT LIST........................................................ 11 13.0 MEASUREMENT UNCERTAINTIES........................................ 12 14.0 REFERENCES...................................................................... 13 APPENDIX A - SAR MEASUREMENT DATA........................................ 14 APPENDIX B - DIPOLE VALIDATION................................................ 15 APPENDIX C - PROBE CALIBRATION............................................... 16 APPENDIX D - SAR TEST SETUP PHOTOGRAPHS............................... 17 CELLTECH RESEARCH INC. Test Report S/N: 032101-78PKS 1955 Moss Court, Kelowna, Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. QMTEL CO., LTD. FCC ID: PKSQMTQMODEM800P 1 CDMA Data Modem Module for Palm V/Vx (824-849MHz) 1.0 INTRODUCTION This measurement report shows that the QMTEL CO., LTD. Model: Q-MODEM 800P Cellular CDMA Data Modem Module for Palm V/Vx Handheld Organizer is in compliance with FCC Part 2.1093, ET Docket 96-326 Rules for mobile and portable devices. The test procedures, as described in American National Standards Institute C95.1-1992 (1), FCC OET Bulletin 65-1997 were employed. A description of the product and operating configuration, detailed summary of the test results, methodology and procedures used in the evaluation, equipment used, and the various provisions of the rules are included within this test report. 2.0 DESCRIPTION of Equipment Under Test (EUT) EUT Type Cellular CDMA Data Modem Module for Palm V/Vx Handheld Organizer Equipment Class Licensed Non-Broadcast Station Transmitter (TNB) FCC ID PKSQMTQMODEM800P Model No. Q-MODEM 800P Tx Frequency Range (MHz) 824.70 – 848.31 S/N No. Pre-production Rx Frequency Range (MHz) 869.70 – 893.31 Max. RF Output Power 0.264 Watts Power Supply 3.7V 650mAh Li-ion Battery Modulation CDMA Antenna Type Retractable Whip Antenna Length 100 mm CELLTECH RESEARCH INC. Test Report S/N: 032101-78PKS 1955 Moss Court, Kelowna, Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 _________________________________________________________________________________________________________ © 2001 Celltech Research Inc. QMTEL CO., LTD. FCC ID: PKSQMTQMODEM800P 2 CDMA Data Modem Module for Palm V/Vx (824-849MHz) 3.0 SAR MEASUREMENT SYSTEM Celltech Research SAR measurement facility utilizes the Dosimetric Assessment System (DASY™) manufactured by Schmid & Partner Engineering AG (SPEAG™) of Zurich, Switzerland. The DASY system is comprised of the robot controller, computer, near-field probe, probe alignment sensor, and the generic twin phantom containing brain or muscle equivalent material. The robot is a six-axis industrial robot performing precise movements to position the probe to the location (points) of maximum electromagnetic field (EMF). A cell contr…

Text truncated - open the document above for the full version.

QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (10g): 1.05 mW/g Hand SAR at 0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna In Low Channel 1013 [824.70MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 1.64E-1 6.55E-1 1.15E+0 1.64E+0 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (10g): 0.657 mW/g Hand SAR at 0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna Out Low Channel 1013 [824.70MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 1.08E-1 4.30E-1 7.52E-1 1.08E+0 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (10g): 0.797 mW/g Hand SAR at 0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna In Mid Channel 363 [835.89MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 1.36E-1 5.43E-1 9.51E-1 1.36E+0 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (10g): 0.613 mW/g Hand SAR at 0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna Out Mid Channel 363 [835.89MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 1.03E-1 4.10E-1 7.18E-1 1.03E+0 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (10g): 0.907 mW/g Hand SAR at 0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna In High Channel 777 [848.31MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 1.47E-1 5.86E-1 1.03E+0 1.47E+0 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (90°,90°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (10g): 0.661 mW/g Hand SAR at 0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna Out High Channel 777 [848.31MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 1.01E-1 4.03E-1 7.05E-1 1.01E+0 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (1g): 0.615 mW/g, SAR (10g): 0.423 mW/g Face of Unit 0.0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna In Low Channel 1013 [824.70MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 6.45E-2 2.58E-1 4.52E-1 6.45E-1 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (1g): 0.528 mW/g, SAR (10g): 0.324 mW/g Face of Unit 0.0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna Out Low Channel 1013 [824.70MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 5.68E-2 2.27E-1 3.98E-1 5.68E-1 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (1g): 0.669 mW/g, SAR (10g): 0.456 mW/g Face of Unit 0.0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna In Mid Channel 363 [835.89MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 6.97E-2 2.79E-1 4.88E-1 6.97E-1 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (1g): 0.524 mW/g, SAR (10g): 0.315 mW/g Face of Unit 0.0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna Out Mid Channel 363 [835.89MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 5.50E-2 2.20E-1 3.85E-1 5.50E-1 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Generic Twin Phantom; Flat Section; Position: (270°,270°) Probe: ET3DV6 - SN1387; ConvF(6.43,6.43,6.43); Crest factor: 1.0 Muscle 835 MHz: σ = 0.95 mho/m ε r = 56.1 ρ = 1.00 g/cm 3 Coarse: Dx = 20.0, Dy = 20.0, Dz = 10.0 Cube 5x5x7: SAR (1g): 0.617 mW/g, SAR (10g): 0.420 mW/g Face of Unit 0.0cm Separation Model: Q-Modem 800P CDMA Mode - Antenna In High Channel 777 [848.31MHz] Conducted Power: 24.8 dBm Date Tested: March 29, 2001 SAR Tot [mW/g] 6.52E-2 2.61E-1 4.56E-1 6.52E-1 Celltech Research Inc. Celltech Research Inc. QMTEL FCC ID: PKSQMTQMODEM800P Gene…

Text truncated - open the document above for the full version.

FCC RF EXPOSURE COMPLIANCE In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. This CDMA modem module has been tested for FCC RF exposure hand and body SAR compliance with the Palm V/Vx handheld organizer. In order to comply with FCC RF exposure requirements, the CDMA modem module must be operated with the Palm V/Vx handheld organizer. The use of this device in any other type of host configuration may not comply with FCC RF exposure requirements and should be avoided. During operation, a 0.5cm separation distance should be maintained between the antenna, whether extended or retracted, and the user’s/bystander’s body (excluding hands, wrists, feet, and ankles) to ensure FCC RF exposure compliance. CAUTION Changes or modifications without the express consent of QMtel Co., Ltd. voids the user’s authority to use the equipment. This equipment has been tested and found to comply with the limits pursuant to Part 22of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not used in accordance with instructions, can cause harmful radiation to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If the equipment does cause harmful interference in radio and television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference by one or more of the following measures: l Reorient or relocate the receiving antenna l Increase the separation distance between the equipment and the receiver l Contact QMtel Co., Ltd. Technical Support for assistance. Please read this information before use

CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 ____________________________________________________________________________________________________________________ © 2001 Celltech Research Inc. CERTIFICATE OF COMPLIANCE FCC PART 22 CERTIFICATION This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Celltech Research Inc. certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Shawn McMillen General Manager Celltech Research Inc. Test Lab: CELLTECH RESEARCH INC. Testing and Engineering Services 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250 - 860-3130 Fax: 250 - 860-3110 Toll Free: 1-877-545-6287 e-mail: [email protected] web site: www.globuswireless.com Applicant Information: QMTEL CO., LTD. 14 th FL., Dongwha B/D 58-7, Seosomun-Dong Choong-Ku, Seoul, Korea 100-110 Attn: Zen Lee, Sales & Marketing Manager FCC Classification: Licensed Non-Broadcast Station Transmitter (TNB) FCC Rule Part(s): §22.901(d), §2 FCC ID: PKSQMTQMODEM800P Model(s): Q-MODEM 800P Equipment Type: Cellular CDMA Data Modem Module for Palm V/Vx Tx Frequency Range: 824.70 - 848.31 MHz Rx Frequency Range: 869.70 - 893.31 MHz Max. RF Output Power: 0.264 Watts (ERP) Frequency Tolerance: 2.5 PPM Emission Designator: 1M25F9W CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 ____________________________________________________________________________________________________________ © 2001 Celltech Research Inc. TABLE OF CONTENTS 1.1 GENERAL INFORMATION 1 2.1 MEASUREMENT PROCEDURES 2 Occupied Bandwidth (2.1049) 2 Spurious/Harmonic Emissions at Antenna Terminal (2.1051) 2 Radiated Spurious & Harmonic Emissions (2.1053) 2 Frequency Stability/Temperature Variation (2.1055) 3 3.1 TEST DATA 4 Effective Radiated Power Output 4 Field Strength of Spurious Radiation 5-7 Frequency Stability 8-9 4.1 LIST OF TEST EQUIPMENT 10 5.1 CONCLUSION 11 ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL EUT PHOTOGRAPHS ATTACHMENT H: INTERNAL EUT PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: CIRCUIT DIAGRAMS / DESCRIPTION ATTACHMENT K: PARTS LIST / TUNE UP PROCEDURE ATTACHMENT L: OPERATIONAL DESCRIPTION ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT CELLTECH RESEARCH INC. Test Report S/N: 032101-77PKS 1955 Moss Court, Kelowna Dates of Tests: March 26-29, 2001 B.C. CANADA V1Y 9L3 ____________________________________________________________________________________________________________ © 2001 Celltech Research Inc. QMTEL CO., LTD. FCC ID: PKSQMTQMODEM800P 1 CDMA Data Modem Module for Palm V/Vx (824-849MHz) APPLICANT: QMTEL CO., LTD. 14 th FL., Dongwha B/D 58-7, Seosomun-Dong Choong-Ku, Seoul, Korea 100-110 Attn: Zen Lee, Sales & Marketing Manager MEASUREMENT REPORT - FCC PART 22.901(d) 1.1 SCOPE Measurement and determination of electromagnetic emissions (EME) from radio frequency devices for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033(a) General Information FCC ID PKSQMTQMODEM800P Model(s) Q-MODEM 800P EUT Type Cellular CDMA Data Modem Module for Palm V/Vx Handheld Organizer FCC Classification Licensed Non-Broadcast Station Transmitter (TNB) FCC Rule Part(s) §2…

Text truncated - open the document above for the full version.
