PL3-100BPEBBLE SMART DOGGIE DOORBELL

User Manual 1, Humanized design, simple installation without help professionals or people, completely remove the decoration expenses, free of noises, install a suitable cell can be used, can be moved optionally installation position. 2, The radio frequency emission technology, innovation of the same frequency and different code and dialing function, the error rate is low; effectively avoids the mutual interference between the neighborhood and false ringing annoyance. 3, The open line remote control distance through rigorous testing of not less than 100 meters, obstacle effect is far better than similar products industry, can meet the needs of different family environment, the general family 50 meters enough. 4, A host of music using humanized design, computer optional 36 piece and fixed tone through the switch can be converted. 5, Remote control transmitter button long life design, work up to 100000 times. 6, The bell receiver standby power is less than 0.3W. The transmitter uses 12V V 23A not to press the button battery, no power consumption, the normal use of up to one year (laboratory test, one day in 20 use ). 7, Electromagnetic interference, mounted in a closed metal gate above, a shielding phenomenon, dry weather, humidity conditions, the battery is exhausted without timely replacement of such environmental factors will affect the use of wireless doorbell. 8, A wide range of uses, in addition to ordinary doorbell, but also as a contact, paging, patient care, emergency notification and other special purposes. Product specifications: ●type: 1 to 1 -- transmitter (remote control )× 1+ receiver ( audible ) x 1 The remote power: <10mw ●receiver rated voltage: DC 3V ( AA1.5V × 2 ) ●receiver standby current: <0.1mA The operating frequency: 433MHz ±0.5MHz ●attachment : a transmitter built in 12V 23A alkaline battery 1 ●packing: color card double-sided two-purpose plastic hanging FCC Statemet: This device complies with part 15 of the FCC Rules. Operation is subject to the fol-lowing two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference re-ceived, including interference that may cause undesired operation. NOTE: The manufacturer is not responsible for ANY interference, for example RADIO or TV interference, caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.

433.92M Crystal RF RF MODULATOR IC ENCODER DC 12V POWER SUPPLY Antenna Block Diagram square graph for receiver DC 3V POWER SUPPLY 433.92MHz RECEIVER CIR2272AN-L4 DECODING SIGNAL PROCESSING Warning tone Indicator light

深圳市华标检测技术服务有限公司 Bontek Compliance Testing Laboratory Co., Ltd DATE: August 23, 2012 Dear TCB Section of Timco Engineering, Inc., Thank you for cooperation. I would like to submit FCC application of Pebble Smart LLC./FCC ID: PL3-100B by your TCB Approval today. Best Regards, Bontek Compliance Testing Laboratory Co., Ltd. Tony Wu/General Manager

Pebble Smart LLC FCC ID: PL3-100B POWER OF ATTORNEY August23, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Bontek Compliance Testing Laboratory Co., Ltd.(Tony Wu) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Bontek Compliance Testing Laboratory Co., Ltd. (Tony Wu) on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, Pebble Smart LLC are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuantto that section. Sincerely, Pebble Smart LLC Keith Jin (Owner)

External Photographs EUT –Front View （transmitter） EUT – Rear View（transmitter） EUT – Side View（transmitter） EUT –Front View（receiver） EUT – Rear View（receiver） EUT – Side View（receiver）

FCC ID Label Sample for FCC ID: PL3-100B Pebble Smart LLC Smart Doggie Doorbell Model: 100B FCC ID: PL3-100B

FCC ID Location FCC ID Location

Internal Photographs EUT - Open View （transmitter） EUT - PCB View （transmitter） Antenna Location EUT - Open View （receiver） EUT - PCB View （receiver）

Circuit Description The transmitter through the button switch to the power circuit, a coding circuit through level connected to control address bits and data bits set of information, through the coding circuit codes and address bits and data bits are converted into a pulse signal, sent to the transmitting circuit; the transmitting circuit through the 433.92MHz oscillator filter are obtained after 433.92MHz frequency carrier, after high frequency power amplifier through the antenna after the pulse signal transmission. The Antenna is printed in the PCB The tramsmitter is powered by the 12V battery.

1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:12-Jul-2012Sheet of File:E:\我的设计PCB\MyDesign10.ddbDrawn By: R2 47K Q1 R25 C3 222 C5 22P BAT1 12V B(SCH) transmitter FR:433.92MHz K1 SW1 R4 680R C4 4P R1 2.4M C1 222 1 910 2 3 4 5 6 7 811 12 13 14 15 16 17 18 IC1 CS5211DGO SAW1 T1 R3 6.8K C2 104 L2 47N C6 1.5P L1 22N L3 22N L4 18N A B C DD C B A Title NumberRevisionSize A4 Date:12-Jul-2012Sheet of File:E:\我的设计PCB\MyDesign10.ddbDrawn By: Q1 9018 L1 10uH R4 680RC7 222 R3 4.7K R1 47K R2 7.5K R5 10KC43.6P 7*7*1.5T WL1 D1 4148 C6 222 C9 680P C8 2.5P R7 120K C3 222 A0 1 A1 2 A2 3 A3 4 A4 5 A5 6 A6 7 A7 8 D1 10 D2 11 D3 12 D4 13 DIN 14 OSC 15 OSC 16 OUT 17 VCC 18 VSS 9 IC1 CIR2272AN-L4 C5 39P R8 820K C1 220uF/16V C10105 308DC(SCH) RECEPTION R9 220R T1 SPK/16R 13 2 K1SK-13D01 D2 LED1 C13 222 BT1 AA1.5V*2 Q2 9013 R6 10M C2 222 C12 100P C11 105 Input Voltage:DC3V Frequency:433.92MHZ 1 2 3 4 5 6 7 8 9 IC2 1832

Test Report of FCC Part 15 C for FCC Certificate On Behalf of Pebble Smart LLC Product description: Pebble Smart Doggie Doorbell Model No.: 100B FCC ID: PL3-100B Prepared for: Pebble Smart LLC 3917 Brae Burn Dr. Eugene, OR 97405, USA Prepared by: Bontek Compliance Testing Laboratory Ltd 1/F, Block East H-3, OCT Eastern Ind. Zone, Qiaocheng East Road, Nanshan, Shenzhen, China Tel: 86-755-86337020 Fax: 86-755-86337028 Report No.: BCT12GR-1039E Issue Date: August 29, 2012 Test Date: August 1~29, 2012 Test by: Reviewed By: Vincent Jiang Kevin Chi TABLE OF CONTENTS 1．GENERAL INFORMATION........................................................................................................................................ 4 1.1 Product Description for Equipment Under Test (EUT) ............................................................ 4 1.2 Test Standards........................................................................................................................ 4 1.3 Test Facility............................................................................................................................. 4 2. SYSTEM TEST CONFIGURATION.............................................................................................................................. 6 2.1 EUT Configuration.................................................................................................................. 6 2.2 EUT Exercise.......................................................................................................................... 6 2.3 General Test Procedures........................................................................................................ 6 2.4 Measurement Uncertainty....................................................................................................... 6 2.5 Test Equipment List and Details............................................................................................. 7 3. SUMMARY OF TEST RESULTS.................................................................................................................................. 9 4．DISTURBANCE VOLTAGE AT THE MAINS TERMINALS...................................................................................... 10 4.1 Measurement Uncertainty..................................................................................................... 10 4.2 Applicable Standard.............................................................................................................. 10 4.3 Test Description.................................................................................................................... 10 5. RADIATED DISTURBANCES.................................................................................................................................... 11 5.1 Measurement Uncertainty..................................................................................................... 11 5.2 Limit of Radiated Disturbances............................................................................................. 11 5.3 EUT Setup............................................................................................................................ 11 5.4 Test Receiver Setup ............................................................................................................. 12 5.5 Test Procedure..................................................................................................................... 12 5.6 Corrected Amplitude & Margin Calculation ........................................................................... 13 5.7 Radiated Emissions Test Result........................................................................................... 13 6. 20DB BANDWIDTH.................................................................................................................................................... 16 6.1 Measurement Uncertainty..................................................................................................... 16 6.2 Limit of 20dB Bandwidth ....................................................................................................... 16 6.3 EUT Setup............................................................................................................................ 16 6.4 Test Procedure..................................................................................................................... 16 6.5 Emissions within Band Edges Test Result............................................................................ 17 7. DUTY CYCLE............................................................................................................................................................. 18 7.1 Measurement Uncertainty..................................................................................................... 18 7.2 EUT Setup............................................................................................................................ 18 7.3 Test Procedure..................................................................................................................... 18 7.4 Measurement Result............................................................................................................. 18 8. TRANSMISSION TIME............................................................................................................................................... 21 8.1 Measurement Uncertainty..................................................................................................... 21 8.2 EUT Setup............................................................................................................................ 21 Report No.: BCT12GR-1039E Page 2 of 23 FCC ID:PL3-100B 8.3 Test Procedure..................................................................................................................... 21 8.4 Limit of Transmission time ...............…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS Radiated Emission (transmitter) Radiated Emission (receiver)
