PM5T55800-01

© Nokia Networks Oy1 (2) Nokia MetroHopper Radio with FC RRI/ FXC RRI User Manual B0 Binder 1/1 C33512.22 2 (2)© Nokia Networks Oy The information in this document is subject to change without notice and describes only the product defined in the introduction of this documentation. This document is intended for the use of Nokia Networks' customers only for the purposes of the agreement under which the document is submitted, and no part of it may be reproduced or transmitted in any form or means without the prior written permission of Nokia Networks. The document has been prepared to be used by professional and properly trained personnel, and the customer assumes full responsibility when using it. Nokia Networks welcomes customer comments as part of the process of continuous development and improvement of the documentation. The information or statements given in this document concerning the suitability, capacity, or performance of the mentioned hardware or software products cannot be considered binding but shall be defined in the agreement made between Nokia Networks and the customer. However, Nokia Networks has made all reasonable efforts to ensure that the instructions contained in the document are adequate and free of material errors and omissions. Nokia Networks will, if necessary, explain issues which may not be covered by the document. Nokia Networks' liability for any errors in the document is limited to the documentary correction of errors. Nokia Networks WILL NOT BE RESPONSIBLE IN ANY EVENT FOR ERRORS IN THIS DOCUMENT OR FOR ANY DAMAGES, INCIDENTAL OR CONSEQUENTIAL (INCLUDING MONETARY LOSSES), that might arise from the use of this document or the information in it. This document and the product it describes are considered protected by copyright according to the applicable laws. NOKIA logo is a registered trademark of Nokia Corporation. Other product names mentioned in this document may be trademarks of their respective companies, and they are mentioned for identification purposes only. Copyright © Nokia Networks Oy 2000. All rights reserved. User Manual B0 NOKIA / C33512.22© Nokia Networks Oy1 (2) M = Missing Document P = Preliminary Contents Binder 1/1 TitleDocument IdentifierDiv.Rem 1 Document NoteDN99617961 Issue 2-0 en1.0 2 Guide to DocumentationDN99611449 Issue 2-0 en2.0 3 Installation OverviewDN99611437 Issue 2-0 en3.0 4 InstallationDN99592289 Issue 2-1 en4.0 5 Commissioning and MaintenanceDN99611394 Issue 2-0 en5.0 6 Product DescriptionDN99592717 Issue 2-2 en6.0 7 GlossaryDN99593058 Issue 2-1 en7.0 2 (2)© Nokia Networks OyNOKIA / C33512.22 M = Missing Document P = Preliminary C33512.20 D0 Nokia MetroHopper Radio User Manual DN99592241© Nokia Networks OyDraft1 (11) Issue 3-0 enNokia Proprietary and Confidential Document Note Document Note 2 (11)© Nokia Networks OyDraftDN99592241 Nokia Proprietary and ConfidentialIssue 3-0 en The information in this document is subject to change without notice and describes only the product defined in the introduction of this documentation. This document is intended for the use of Nokia Networks' customers only for the purposes of the agreement under which the document is submitted, and no part of it may be reproduced or transmitted in any form or means without the prior written permission of Nokia Networks. The document has been prepared to be used by professional and properly trained personnel, and the customer assumes full responsibility when using it. Nokia Networks welcomes customer comments as part of the process of continuous development and improvement of the documentation. The information or statements given in this document concerning the suitability, capacity, or performance of the mentioned hardware or software products cannot be considered binding but shall be defined in the agreement made between Nokia Networks and the customer. However, Nokia Networks has made all reasonable efforts to ensure that the instructions contained in the document are adequate and free of material errors and omissions. Nokia Networks will, if necessary, explain issues which may not be covered by the document. Nokia Networks' liability for any errors in the document is limited to the documentary correction of errors. Nokia Networks WILL NOT BE RESPONSIBLE IN ANY EVENT FOR ERRORS IN THIS DOCUMENT OR FOR ANY DAMAGES, INCIDENTAL OR CONSEQUENTIAL (INCLUDING MONETARY LOSSES), that might arise from the use of this document or the information in it. This document and the product it describes are considered protected by copyright according to the applicable laws. NOKIA logo is a registered trademark of Nokia Corporation. Other product names mentioned in this document may be trademarks of their respective companies, and they are mentioned for identification purposes only. Copyright © Nokia Networks Oy 2001. All rights reserved. Nokia Citytalk, Nokia Extratalk, Nokia FlexiHopper, Nokia Flexitalk, Nokia Hopper Manager, Nokia Intratalk, Nokia MetroHopper, Nokia MetroHub, and Nokia MetroSite are trademarks of Nokia Networks Oy. Hereby, Nokia Corporation, declares that this Nokia MetroHopper radio is in compliance with the essential requirements and other relevant provisions of Directive: 1999/5/EC. FCC ID:PM5T55800–01 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The product is marked with the CE marking and Notified Body number according to the Directive 1999/5/EC 0889 DN99592241© Nokia Networks OyDraft3 (11) Issue 3-0 enNokia Proprietary and Confidential Summary of changes DocumentDateComment C33512002PE_0024 Jun 1999 C33512002PE_A006 Sep 1999 C33512002PE_B026 Oct 1999 C33512009XE_A029 Oct 1999 DN99592241 Issue 1-0 en01 Nov 1999New document numbering scheme adopted. DN99592241 Issue 2-0 en11 Feb 2000 DN99592241 Issue 2-1 en16 Mar 2000 DN9…

Text truncated - open the document above for the full version.

Product Description 60 (82)© Nokia Networks OyDraftDN99592717 Nokia Proprietary and ConfidentialIssue 4-0 en Caution Note 8.1.2Environment Changes or modifications not expressly approved by the party responsible for compliance may void the user's authority to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna -Increase the separation between the equipment and receiver -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected -Consult the dealer or an experienced radio/TV technician for help. Table 5.EMC ETS 300 385, EMC standard for digital fixed radio links and ancillary equipment Emissions Radiated emissionEN 55022 Class B CISPRS 22 Conducted emissionEN 55022 0.15 - 0.5 MHz: 66 dBμV, average 0.5 - 30 MHz: 60 dBμV, average Immunities RF EM fieldEN 61000 -4 -3 80 - 1000 MHz, 3 V/m: no errors

Marianne Bosley From:Aird Anthony (NET-RD/Dallas) [[email protected]] Sent:Wednesday, October 03, 2001 10:22 AM To:'ext Marianne Bosley' Cc:Mitchell Steve.1 (NET/Dallas); Hull Charles (NET/Dallas) Subject:RE: Type Approvals of Nokia MetroHopper & MetroHub Marianne, Attached is the revised page from the user manual with the 15.105 statement included. Thanks, Ant hony. -----Original Message----- From: ext Marianne Bosley [mailto:[email protected]] Sent: Friday, September 28, 2001 11:29 AM To: Aird Ant hony ( NET-RD/Dallas) Subject: RE: Type Approvals of Nokia MetroHopper & MetroHub Thank you, I'll wait to hear. Marianne T. Bosley EMC Administrator 410-354-3300, ext. 412 > -----Original Message----- > From: Aird Anthony (NET-RD/Dallas) [SMTP:[email protected]] > Sent: Friday, September 28, 2001 11:26 AM > To:'ext Marianne Bosley ' > Subject:RE: Type Approvals of Nokia MetroHopper & MetroHub > > Marianne, > > Thanks, the FCC 15.105 statement page is being worked on. I will sent it > to you as soon as I get the corrected version. > > Thanks, > Anthony. > > -----Original Message----- > From: ext Marianne Bosley > To: Aird Anthony ( NET- RD/Dallas) > Cc: Joyce Holton > Sent: 9/28/01 9:38 AM > Subject: RE: Type Approvals of Nokia MetroHopper & MetroHub > > Good morning, > > Ok, I have renamed those documents as layouts so that there is not any > confusion any further. They, however, are not submitted as exhibits to > the > FCC. The ones that are, block diagram (out of tech des), tech des, and > schematics, will be kept confidential. > > The only issue left now is the 15.105 statement page. Are there any > questions regarding that? > > Marianne > > Marianne T. Bosley > EMC Administrator > 410-354-3300, ext. 412 > > > -----Original Message----- > > From:Aird Anthony (NET-RD/Dallas) [SMTP:Ant [email protected]] > > Sent:Thursday, September 27, 2001 4:43 PM > > To: 'ext Marianne Bosley' > > Subject:RE: Type Approvals of Nokia MetroHopper & MetroHub > > > > Marianne, > > > > The attachment which you sent are not block diagrams. They are circuit > > board layouts. I don't think we want any technical information about > our > > product accessible to the public. They are all confidential > information. > > It's all stated in the confidentiality letter. > > > > Anthony. > > > > -----Original Message----- > > From: ext Marianne Bosley [mailto:[email protected]] > > Sent: Thursday, September 27, 2001 2:01 PM > > To: Aird Anthony ( NET-RD/Dallas) > > Subject: RE: Type Approvals of Nokia MetroHopper & MetroHub > > > > > > Hello > > > > Someone had submitted two block diagrams by themselves (not as part of > > the > > manual, or any other document) besides the blocks that are in the tech > > description that you submitted. If the blocks within the tech des are > > sufficient, you can send me a request to disregard the previous blocks > > and > > only send the ones in the latest tech description, or you canadd block > > diagrams to the letter of confidentiality and I can submit the whole > > package. I have attached the blocks that I am talking about so that > you > > can > > see for yourself which ones they are. Please let me know. > > > > <<block diagrams E10012268cx_00.pdf>> <<diagrams > E10012269cx_00.pdf>> > > > > Marianne T. Bosley > > EMC Administrator > > 410-354-3300, ext. 412 > > > > > -----Original Message----- > > > From:Aird Anthony (NET-RD/Dallas) > [SMTP:[email protected]] > > > Sent:Thursday, September 27, 2001 2:30 PM > > > To:'ext Marianne Bosley' > > > Subject: RE: Type Approvals of Nokia MetroHopper & MetroHub > > > > > > Marianne, > > > > > > Regarding the confidentiality letter, in our opinion "technical > > > descriptions" includes block diagrams. > > > > > > Anthony. > > > > > > -----Original Message----- > > > From: ext Marianne Bosley [mailto:[email protected]] > > > Sent: Thursday, September 27, 2001 11:56 AM > > > To: Aird Anthony (NET-RD/Dallas) > > > Subject: RE: Type Approvals of Nokia MetroHopper & MetroHub > > > > > > > > > Ok, > > > > > > I converted it through adobe photoshop and it's ok now. The problem > > > before, > > > in jpeg, was it was 8 pages worth of one picture. However, we got > it > > > now. > > > So, the only two things are the clarification of the block diagram > > being > > > held confidential, and the revised page with the 105 statement. > > Thanks. > > > > > > > > > Mariannne > > > > > > Marianne T. Bosley > > > EMC Administrator > > > 410-354-3300, ext. 412 > > > > > > > -----Original Message----- > > > > From:Aird Anthony (NET-RD/Dallas) > > [SMTP:[email protected]] > > > > Sent:Thursday, September 27, 2001 12:41 PM > > > > To:'ext Marianne Bosley' > > > > Subject: RE: Type Approvals of Nokia MetroHopper & MetroHub > > > > > > > > Marianne, > > > > > > > > The label should be located to the right of the photo. > > > > > > > > Anthony. > > > > > > > > > > > > -----Original Message----- > > > > From: ext Marianne Bosley [mailto:[email protected]] > > > > Sent: Thursday, September 27, 2001 10:55 AM > > > > To: Aird Anthony (NET-RD/Dallas) > > > > Cc: Mitchell Steve.1 (NET/Dallas); Joyce Holton > > > > Subject: RE: Type Approvals of Nokia MetroHopper & MetroHub > > > > > > > > > > > > Hello Mr. Aird. > > > > > > > > I have reviewed the documentation that you sent to me, and that > > which > > > we > > > > already had on file. Unfortunately, we have two small issues > still. > > > > > > > > 1. The photo of the label location that you sent to us does not > > show > > > > the > > > > label on the device; it just shows the device itself. Please > > resubmit > > > > with > > > > the label (or facsimile of) on the device showing the location > upon > > > > marketing; final location. > > > > > > > > 2. The 15.105 statement that you have in the manual is a > > combination > > > > wording of the Class A and the Class B statement. Please see the > > > > attached > > > > and resubmit the revised page. Thank you, and if any questions, > > > p…

Text truncated - open the document above for the full version.

October 26, 2001 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: Confidentiality Request for FCC ID: PM5T55800-01 Dear Sir/Madam, Nokia Networks hereby request that the internal photographs, schematic diagrams, block diagrams, and technical descriptions be held as confidential items per Section 0.459 of the Commission Rules. This request is based on the following reasons: The market we are serving with our MetroHopper Microwave Radio is new and technically very advanced, and hence competition between manufacturers is extremely high. We believe that our MetroHopper microwave Radio contains equipment that some competitors would be extremely keen to get information on. This would provide an unfair advantage to our competitors. When a MetroHopper Microwave Radio is installed into a network it is usually placed in the mast, roof, wall, brick etc., with access only available to authorized personnel and most places are securely locked. This means the only way a competitor could get hold of technical information on the MetreHopper Radio is from FCC records. We are concerned that if a competitor is able to get hold of sensitive information on the Nokia MetroHopper Microwave Radio, our position as a market leader could be seriously compromised. It is for these reasons that we would like to file all the internal photographs, schematic diagrams, block diagrams, and technical descriptions for confidentiality. Systems Department Manager Nokia IMN/NET

FCC ID: PM5T55800-01 October 8, 2001 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attention:Applications Examiner Applicant:Nokia Networks 6000 Connection Dr.; Irving, TX 75039 Equipment:MetroHopper FCC ID: PM5T55800-01 Specification:for a 47 CFR 15.255 Certification Dear Examiner: The following application for Grant of Equipment Authorization is presented on behalf of Nokia Networks, Inc. for the Certification of their MetroHopper. Enclosed, please find a complete data and documentation package demonstrating that this device complies with the technical requirements of 47 CFR 15.255 and FCC Report & Order 99-261, for millimeter wave device operating between 57.2 - 58.2 GHz.. If you have any questions, please contact the undersigned, who is authorized to act as Agent. Sincerely, Chris Harvey, Director EMC Laboratory MET Laboratories, Inc. FCC ID: PM5T55800-01 EMI9754A- 2 -October 8, 2001 MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE !! BALTIMORE, MARYLAND 21230-3432 !! PHONE (410) 354-3300 !! FAX (410) 354-3313 ENGINEERING TEST REPORT in support of the Application for Grant of Equipment Authorization EQUIPMENT:Model: MetroHopper FCC ID:PM5T55800-01 Specification:47 CFR 15.255 On Behalf of the Applicant:Nokia Networks. 6000 Connection Dr. Irving, TX 75039 Manufacturer:Nokia Networks. 6000 Connection Dr. Irving, TX 75039 Manufacturer’s Mr. Anthony Aird Representative Test Date(s):June 21 thru June 23, 2000 ENGINEERING STATEMENT I ATTEST: the measurements shown in this report were made in accordance with the procedures indicated, and that the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements. On the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 15.255 of the FCC Rules under normal use and maintenance. _____________________________ Liming Xu EMC Engineer, MET Laboratories FCC ID: PM5T55800-01 EMI9754A- 3 -October 8, 2001 1.0INTRODUCTION The following data is presented on behalf of the Applicant, Nokia Networks, as verification of the compliance of the Nokia MetroHopper to the requirements of 47 CFR 15.255 2.0TEST SITE All testing was conducted at MET Laboratories, Inc., 914 West Patapsco Avenue, Baltimore, Maryland 21230-3493. Radiated emissions measurements were performed on a three-meter test site. A complete site description is on file with the FCC Laboratory Division as 31040/SIT/MET. 3.0TEST EQUIPMENT USED ManufacturerEquipmentCalibration Due Date @ time of testing Cal. Interval Hewlett Packard8563A Spectrum Analyzer6/14/01annual EMCOBiconical Antenna 31044/10/01annual EMCOEMCO Log Periodic Antenna4/10/01annual EMCODouble Ridge Guided Horn2/17/01annual Hewlett Packard8594EM Analyzer11/20/00annual Hewlett Packard8591E Analyzer8/12/00annual SolarLISN8/27/00annual 4.0EQUIPMENT UNDER TEST CONFIGURATION The MetroHopper was configured with MetroHub providing DC power to MetroHopper via the FXC, RRI card. The MetroHub required AC power as input. An external PC was used to program the EUT to output a RF signal. The EUT with host external computer was configured for maximum signal gain and bandwidth. The EUT was operated in a manner representative of the typical usage of the equipment. During all testing, system components were manipulated within the confines of typical usage to maximize each emission. 5.0TEST TYPE(S) 5.1Radiated Emissions: 47 CFR2.1053, , 15.255 5.2Occupied Bandwidth: 47 CFR2.1049 5.3RF Power Output: 47 CFR 2.1046, 15.255 5.4Frequency Stability over temperature variations: 47 CFR 15.255 (f) 5.5Frequency Stability over variations in supply voltage: 47 CFR 15.255 (f) 5.6AC Line Conducted Emissions: 47 CFR 15.107 FCC ID: PM5T55800-01 EMI9754A- 4 -October 8, 2001 6.0TEST RESULTS 6.1TEST TYPE: Radiated Emissions 6.1.1TECHNICAL SPECIFICATION:2.1053; 15.209 6.1.2TEST DATE(S):6/12/00 6.1.3MEASUREMENT PROCEDURES: As required by §2.1053, field strength of spurious radiation measurements were made in accordance with the general procedures of ANSI C63.4-1992 "Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz". Preliminary radiated emission measurements were performed inside a shielded chamber. The frequency list from the preliminary measurements was used as a guide for making final measurements for frequencies below 1GHz on a 3 meter Open Area Test Site. Emissions above 1GHz were performed in an open area of the laboratory. The unit was scanned over the frequency range 30MHz to 200GHz The photograph of the EUT test configuration FCC ID: PM5T55800-01 EMI9754A- 5 -October 8, 2001 6.1.4RESULTS: Frequency (MHz) Azimuth (EECCW- OEE=EUT facing ant.) Pola- rity Height (m) Raw Amplitude (dBuV) Ant.Cor. Factor (db) Cable Loss (db) Distance Corr. 3m to 1m Corrected Amplitude (dBuV/m) Limit (dBuV/m) at 3 meters * 40.500 270 H1.5 13.25 11.19 1.17 0 25.61 40 * 40.500 270 V1 15.52 10.09 1.17 0 26.78 40 * 74.620 270 H1.5 13.54 7.0216 1.55 0 22.11 40 * 74.620 270 V1 15.14 7.1456 1.55 0 23.84 40 * 159.500 270 H1.5 13.29 14.93 2.359 0 30.58 43.5 * 159.500 270 V1 13.17 15.27 2.359 0 30.80 43.5 * 394.000 270 H1.5 13.15 16.58 3.884 0 33.61 46 * 394.000 270 V1.2 13.24 16.28 3.884 0 33.40 46 * 413.500 270 H1.5 13.63 17.14 3.99 0 34.76 46 * 413.500 270 V1 13.51 17.215 3.99 0 34.72 46 * 566.000 270 H1.5 13.61 19.12 4.903 0 37.63 46 * 566.000 279 V1 13.64 18.58 4.903 0 37.12 46 4.96GHz0H14433.3359.5432.7654 9.517GHz0H149378359.5442.2654 Equipment meets the specifications of 2.10532; 15.209 *— These emissions were related to the digital electronics, and thus are measured against the 47 CFR 15 Class B limit. These emissions are significantly below the limit for spurious emissions. ** There is no detectable emissions betwe…

Text truncated - open the document above for the full version.

The Nation's First Licensed Nationally Recognized Testing Laboratory MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE • BALTIMORE, MARYLAND 21230-3432 • PHONE (410) 354-3300 • FAX (410) 354-3313 16 November 2001 Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Re:Request for Certification of Nokia Networks, 15.255 Transmitter, EA102731, FCC ID: PM5T55800-01 Application Receipt Date: October 12, 2001 Dear Reviewing Engineer: There were several revisions made on the test report for this project. Please only review and consider the last submitted test report on November 13, 2001. This revision includes many improvements and inclusions. If you have any questions concerning this matter, please call me at 410-354-3300, ext. 412, or email to [email protected]. Regards, Marianne Bosley EMC Administrator

FCC ID: PM5T55800-01 October 8, 2001 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attention:Applications Examiner Applicant:Nokia Networks 6000 Connection Dr.; Irving, TX 75039 Equipment:MetroHopper FCC ID: PM5T55800-01 Specification:for a 47 CFR 15.255 Certification Dear Examiner: The following application for Grant of Equipment Authorization is presented on behalf of Nokia Networks, Inc. for the Certification of their MetroHopper. Enclosed, please find a complete data and documentation package demonstrating that this device complies with the technical requirements of 47 CFR 15.255 and FCC Report & Order 99-261, for millimeter wave device operating between 57.2 - 58.2 GHz.. If you have any questions, please contact the undersigned, who is authorized to act as Agent. Sincerely, Chris Harvey, Director EMC Laboratory MET Laboratories, Inc. FCC ID: PM5T55800-01 EMI9754A- 2 -October 8, 2001 MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE !! BALTIMORE, MARYLAND 21230-3432 !! PHONE (410) 354-3300 !! FAX (410) 354-3313 ENGINEERING TEST REPORT in support of the Application for Grant of Equipment Authorization EQUIPMENT:Model: MetroHopper FCC ID:PM5T55800-01 Specification:47 CFR 15.255 On Behalf of the Applicant:Nokia Networks. 6000 Connection Dr. Irving, TX 75039 Manufacturer:Nokia Networks. 6000 Connection Dr. Irving, TX 75039 Manufacturer’s Mr. Anthony Aird Representative Test Date(s):June 21 thru June 23, 2000 ENGINEERING STATEMENT I ATTEST: the measurements shown in this report were made in accordance with the procedures indicated, and that the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements. On the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 15.255 of the FCC Rules under normal use and maintenance. _________ ____________________ Liming Xu EMC Engineer, MET Laboratories FCC ID: PM5T55800-01 EMI9754A- 3 -October 8, 2001 1.0INTRODUCTION The following data is presented on behalf of the Applicant, Nokia Networks, as verification of the compliance of the Nokia MetroHopper to the requirements of 47 CFR 15.255 2.0TEST SITE All testing was conducted at MET Laboratories, Inc., 914 West Patapsco Avenue, Baltimore, Maryland 21230-3493. Radiated emissions measurements were performed on a three-meter test site. A complete site description is on file with the FCC Laboratory Division as 31040/SIT/MET. 3.0TEST EQUIPMENT USED ManufacturerEquipmentCalibration Due Date @ time of testing Cal. Interval Hewlett Packard8563A Spectrum Analyzer6/14/01annual EMCOBiconical Antenna 31044/10/01annual EMCOEMCO Log Periodic Antenna4/10/01annual EMCODouble Ridge Guided Horn2/17/01annual Hewlett Packard8594EM Analyzer11/20/00annual Hewlett Packard8591E Analyzer8/12/00annual SolarLISN8/27/00annual 4.0EQUIPMENT UNDER TEST CONFIGURATION The MetroHopper was configured with MetroHub providing DC power to MetroHopper via the FXC, RRI card. The MetroHub required AC power as input. An external PC was used to program the EUT to output a RF signal. The EUT with host external computer was configured for maximum signal gain and bandwidth. The EUT was operated in a manner representative of the typical usage of the equipment. During all testing, system components were manipulated within the confines of typical usage to maximize each emission. 5.0TEST TYPE(S) 5.1Radiated Emissions: 47 CFR2.1053, , 15.255 5.2Occupied Bandwidth: 47 CFR2.1049 5.3RF Power Output: 47 CFR 2.1046, 15.255 5.4Frequency Stability over temperature variations: 47 CFR 15.255 (f) 5.5Frequency Stability over variations in supply voltage: 47 CFR 15.255 (f) 5.6AC Line Conducted Emissions: 47 CFR 15.107 FCC ID: PM5T55800-01 EMI9754A- 4 -October 8, 2001 6.0TEST RESULTS 6.1TEST TYPE: Radiated Emissions 6.1.1TECHNICAL SPECIFICATION:2.1053; 15.209 6.1.2TEST DATE(S):6/12/00 6.1.3MEASUREMENT PROCEDURES: As required by §2.1053, field strength of spurious radiation measurements were made in accordance with the general procedures of ANSI C63.4-1992 "Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz". Preliminary radiated emission measurements were performed inside a shielded chamber. The frequency list from the preliminary measurements was used as a guide for making final measurements for frequencies below 1GHz on a 3 meter Open Area Test Site. Emissions above 1GHz were performed in an open area of the laboratory. The unit was scanned over the frequency range 30MHz to 200GHz The photograph of the EUT test configuration FCC ID: PM5T55800-01 EMI9754A- 5 -October 8, 2001 6.1.4RESULTS: Frequency (MHz) Azimuth (EECCW- OEE=EUT facing ant.) Pola- rity Height (m) Raw Amplitude (dBuV) Ant.Cor. Factor (db) Cable Loss (db) Distance Corr. 3m to 1m Corrected Amplitude (dBuV/m) Limit (dBuV/m) at 3 meters * 40.500 270 H1.5 13.25 11.19 1.17 0 25.61 40 * 40.500 270 V1 15.52 10.09 1.17 0 26.78 40 * 74.620 270 H1.5 13.54 7.0216 1.55 0 22.11 40 * 74.620 270 V1 15.14 7.1456 1.55 0 23.84 40 * 159.500 270 H1.5 13.29 14.93 2.359 0 30.58 43.5 * 159.500 270 V1 13.17 15.27 2.359 0 30.80 43.5 * 394.000 270 H1.5 13.15 16.58 3.884 0 33.61 46 * 394.000 270 V1.2 13.24 16.28 3.884 0 33.40 46 * 413.500 270 H1.5 13.63 17.14 3.99 0 34.76 46 * 413.500 270 V1 13.51 17.215 3.99 0 34.72 46 * 566.000 270 H1.5 13.61 19.12 4.903 0 37.63 46 * 566.000 279 V1 13.64 18.58 4.903 0 37.12 46 4.96GHz0H14433.3359.5432.7654 9.517GH z 0H149378359.5442.2654 Equipment meets the specifications of 2.10532; 15.209 *— These emissions were related to the digital electronics, and thus are measured against the 47 CFR 15 Class B limit. These emissions are significantly below the limit for spurious emissions. ** There is no detectable emissions be…

Text truncated - open the document above for the full version.
