PMWBATXMTRD1Blink A Tag Transmitter

EXHIBIT 1 (Para. 2.1033(b)(1)) FULL NAME & MAILING ADDRESS OF MANUFACTURER & APPLICANT APPLICANT NAME: PHYSIO SYSTEMS, INCORPORATED STREET ADDRESS: 37053 CHERRY STREET CITY, STATE AND ZIP: NEWARK, CALIFORNIA 94560 TELEPHONE NUMBER: 510-796-3901 FAX NUMBER: 510-796-2649 MANUFACTURER NAME: DAVID E. LIEBERMAN STREET ADDRESS: 37053 CHERRY STREET CITY, STATE AND ZIP: NEWARK, CALIFORNIA 94560 TELEPHONE NUMBER: 510-796-3901 FAX NUMBER: 510-796-2649 E-MAIL: [email protected]

EXHIBIT 2 (Para. 2.1033(b)(2)) FCC IDENTIFICATION NUMBER PMWBATXMTRD1

(Para. 2.1033(b)(8)) EXHIBIT 8 BRIEF DESCRIP TION OF PERIPHERALS REQUIRED TO TEST There were no external peripherals required to exercise the Equipment Under Test.

(Para. 2.1033(b)(9)) EXHIBIT 9 INDICATE IF TRANSITION PROVISIONS ARE NECESSARY Transition Provisions of Part 15 are not applicable to this application.

(Para. 2.1033(b)(8)) EXHIBIT 8 BRIEF DESCRIP TION OF PERIPHERALS REQUIRED TO TEST There were no external peripherals required to exercise the Equipment Under Test.

(Para. 2.1033(b)(9)) EXHIBIT 9 INDICATE IF TRANSITION PROVISIONS ARE NECESSARY Transition Provisions of Part 15 are not applicable to this application.

Physio Systems, Inc. Transmitter Field Strengths 1 299.74 56.2 14.2 6 27 -8.9 40.5 46 5.5 2 599.48 35.7 19.7 8.6 27 -8.9 28.1 46 17.9 3 899.22 26.6 23.9 9.2 27 -8.9 22.4 46 23.6 4 1198.96 20.4 22.5 9.0 27 -8.9 16.0 54 38.0 5 1498.70 20.4 22.5 9.7 27 -8.9 16.7 54 37.3 6 1798.44 18.9 22.6 10.3 28 -8.9 14.9 54 39.1 7 2098.18 19.4 22.3 10.8 28 -8.9 15.6 54 38.4 8 2397.92 19.5 22.3 11.2 28 -8.9 16.1 54 37.9 9 2697.66 20.7 22.3 11.5 28 -8.9 17.6 54 36.4 10 2997.40 20.9 22.3 11.8 28 -8.9 18.1 54 35.9 Test Date: 14 November 2001Harmonic Numbers 1, 2 & 3 measured with Quasi-Peak detector. All other harmonics measured with Average detector.Duty Cycle = 20*LOG(T on /T tot ) = 20*LOG(5.4 mS/15mS) = -8.9 dB Figure 15. Corrected Values of Horizontal E-Field Strength Versus FCC Limit. Duty Cycle dB Corrected Reading dBuV/m Specification Limit dBuV/m HORIZONTAL POLARITY Margin dB Harmonic Number Frequency MHz Spectrum Analyzer Reading Antenna Factors dB/m Cable Loss dB Pre- Amp Gain

1 299.75 53.7 14.2 6 27 -8.9 38.0 46 8.0 2 599.50 44.9 19.7 8.6 27 -8.9 37.3 46 8.7 3 899.25 28.5 23.9 9.2 27 -8.9 24.3 46 21.7 4 1199.00 20.4 22.5 9.0 27 -8.9 16.0 54 38.0 5 1498.75 20.4 22.5 9.7 27 -8.9 16.7 54 37.3 6 1798.50 18.9 22.6 10.3 28 -8.9 14.9 54 39.1 7 2098.25 19.4 22.3 10.8 28 -8.9 15.6 54 38.4 8 2398.00 19.5 22.3 11.2 28 -8.9 16.1 54 37.9 9 2697.75 20.9 22.3 11.5 28 -8.9 17.8 54 36.2 10 2997.50 20.8 22.3 11.8 28 -8.9 18.0 54 36.0 Test Date: 14 November 2001Harmonic numbers 1, 2 and 3 are measured with a Quasi-peak detector. All other harmonics measured with Average Detector. Duty Cycle = 20*LOG(Ton/Ttot) = 20*LOG(5.4 mS/15 mS) = -8.9 dB Figure 16. Corrected Values of Vertical E-Field Strength Versus FCC Limit. Pre- Amp Gain Duty C y cle dB Corrected Reading dBuV/m Specification Limit dBuV/m Vertical Polarization Values. Physio Systems, Inc. Transmitter Field Strengths Mar g in dB Harmonic Number Frequency MHz Spectrum Analyzer Reading Antenna Factors dB/m Cable Loss dB

44366 S. Grimmer Boulevard, Fremont, CA 94538 CERTIFICATE OF COMPLIANCE APPLICABLE SPECIFICATION: 47 CFR PART 2, SUBPART J, PARAGRAPH 2.906 Declaration of Conformity Equipment Authorization Part 15, Subpart C – Intentional Radiators Paragraph 15.201(b) Certification of Transmitter Report Number: PSI0003 Date of Report: 14 November 2001 I hereby certify that the measurements shown on this report were made in accordance with the procedures of American National Standards Institute (ANSI) Specification C63.4-1992. The electric fields radiated by the equipment listed below meets the Commissions Limits for ‘other Receiver’ devices. No conducted tests were performed because the EUT is battery powered with no provision for re-charging the battery. Tests were performed on 14 November 2001 . Company: Physio Systems, Inc. Street Address: 37053 Cherry Street, Suite 202 City, State & ZIP Newark, CA 94560 Equipment under Test: BLINK-A-TAG XMTR Model Number: BAT-T Serial Number: 1002 EMCE Engineering, Inc has been place on the Federal Communications Commission’s list of recognized facilities for Parts 15 and 18 DoC approvals. Per the request of EMCE Engineering, the facility has been added to the list of those who perform Measurement Services for the public on a fee basis. This list is published periodically and is also available on the FCC World Wide Web. Additionally, EMCE Engineering has been approved by the National Institute for Standards and Technology (NIST) under the NVLAP program. EMCE Engineering, assumes no responsibility for the continuing validity of test data when the Equipment under Test (EUT) is not under the continuous physical control of EMCE. The signature below attests to the fact that all measurements reported herein were performed by myself or were made under my supervision, and are correct to the best of my knowledge and belief as of the date specified. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Tests were conducted by qualified EMCE Engineering personnel utilizing test equipment maintained in a “current” state of calibration with traceability to NIST. Note • This report or certificate does not represent endorsement by NVLAP or any agency of the US Government. • This report or certificate shall not be reproduced except in full without the written approval of the issuer. Certified by: EMCE Engineering, Inc. Stephen A. Sawyer, NCE President Report Number: PSI0003 Date: 14 November 2001 Page 2 of 53 Page: ELECTROMAGNETIC INTERFERENCE TEST REPORT Report Number: PSI0003 Report Date: 14 November 2001 Applicable Specification: 47 CFR Part 15, Subpart C, Certification of Intentional Radiator Equipment under Test: BLINK-A-TAG XMTR Model Number: BAT-T Serial Number: 1002 Prepared for: Physio Systems, Inc. 37053 Cherry Street, Suite 202 Newark, CA 94560 Prepared by: Stephen A. Sawyer, NCE EMCE Engineering, Inc. 44366 S. Grimmer Blvd. Fremont, CA 94538 Phone: 510-490-4307 Fax: 510-490-3441 Note • This report or certificate does not represent endorsement by NVLAP or any agency of the US Government. • This report or certificate shall not be reproduced except in full without the written approval of the issuer. Report Number: PSI0003 Date: 14 November 2001 Page 3 of 53 Page: TABLE OF CONTENTS Paragraph Title Page 1.0 SCOPE 5 1.1 Objective 5 1.2 Description of EUT 5 1.3 Results/Modifications 5 1.4 Test Limits 5 2.0 APPLICABLE DOCUMENTS 6 2.1 FCC Document 6 2.2 Other Documents 6 3.0 GENERAL SETUP AND TEST CONDITIONS 6 3.1 Test Facility 6 3.2 Description of Open- Area Test Site 8 3.3 Site Attenuation 8 3.4 Ground Plane (Ground Screen) 8 3.5 Input Power for EUT 9 3.6 Accessory Equipment Precautions 9 3.7 Ambient Interference 9 3.8 Personnel 9 3.9 Use of Interference Measuring Equipment 9 3.10 Calibration of Measuring Equipment 10 4.0 PREPARATION OF EUT FOR TEST 10 4.1 Identification of EUT 10 4.2 Setup of EUT 10 4.3 Peripherals Connected 11 5.0 DETAILED MEASUREMENTS 11 5.1 Conducted Emissions, Power Leads, 450kHz to 30MHz 11 5.2 Radiated Emissions Test, 30MHz to 1000MHz 11 5.2.1 Vertical Polarization Measurements 13 5.2.2 Horizontal Polarization Measurements 14 5.2.3 Test Results 14 5.2.4 Test Instrumentation 14 5.2.5 Recommendations 14 5.3 Radiated Emissions Test, 1000MHz to 2988 MHz 15 Report Number: PSI0003 Date: 14 November 2001 Page 4 of 53 Page: LIST OF FIGURES Figure Title Page 1 EMCE Test Site Layout 7 2 Typical Test Setup for Radiated Emissions Measurement 12 LIST OF APPENDICES Appendix Title Page A EMI Measurement With the Automatic Spectrum 16-23 Analyzer B Instrument Data 24-30 C Measurement Equipment Calibration Certification 31-38 D Test Data Sheets 39-59 E Photographs of Test Setup 60-62 F FCC Labeling and User Information 63-65 Report Number: PSI0003 Date: 14 November 2001 Page 5 of 53 Page: 1.0 SCOPE This test report describes the equipment setup, test methods employed and results obtained during EMI testing of a Class C ‘Intentional Radiator’ as defined in Part 15, Subpart A, paragraph 15.3 (o). The tests described herein measured the RF radiated (RFI Field Strength) up through the tenth harmonic. Power line conducted (RFI Noise Voltage) emissions were not measured because the Transmitter is battery powered with no provision for recharging the batteries. The tests conformed to the measurement and test site requirements of ANSI C63.4-1992. 1.1 Objective The tests described herein were performed to establish that the EUT is capable of compliance with the requirements of Part 15, Subpart C, paragraph 15.201 for Intentional Radiators (a Low Power Transmitter). 1.2 Description of EUT The EUT is a BLINK-A-TAG XMTR, Model Number: BAT-T, Serial Number: 1002, manufactured by Physio Systems, Inc., Newark, California. The EUT contained the following options: No Options. 1.3 Results/Modifications The EUT passed FCC radiated emissions tests. No modification was necessary. The manufacturer may submit the EU…
