OIS-P . The Antennas, PC3114/00B and PC3114/01B, are part of the PC3100 series in the OIS-P family and are used for communication with PC3100 series data tags. They are designed and built for fast data transfer, high reliability and long life applications, where a dynamic communication distance from zero up to 2 metres or alternatively zero up to 4 metres is desired. The rugged and excellent climatic resistance allow indoor as well as outdoor, stationary or mobile installation. Its compact design adds to the installation flexibility. Communication with the data tags is established via a micro- wave link, at the worldwide approved frequency 2.45 GHz. Emitted microwave power from the OIS-P system is well below the limits set by health and tele- communication authorities. The Antenna is connected to the OIS-P Central Unit via a cable up to 100 metres in length, which transfers signal data and provides low voltage DC power to the Antenna. Signal data is protected against electrical interference by the use of balanced data trans- mission techniques and cable shielding. The Antennas comply to ETSI 300 339. Medium and Long Range Antenna OIS-P PC3114/00B, PC3114/01B OIS-P 8 kbyte Data Tag OIS-P PC3104/32A capability with fast moving data tags. In addition it operates at a microwave power level well below the limits set by health and telecommunication authorities. The OIS-P technology maxi- mizes the battery lifetime. The data tag is semi-active type, normally held in a passive state. The current consumption under these passive conditions is merely a few m A. Only when activated in front of an antenna, the data tags data modulation electronics are powered up and the data tag reaches active current consumption in the mA range. As soon as the microwave communi- cation is completed, the data tag returns to its passive state, The read and write data tag PC3104 is a part of the OIS-P PC3100 series. It is designed and built for normal temperature applications requiring dynamic storage of large amounts of user data, fast data transfer, high reliability and long life. The rugged design and excel- lent climatic resistance allow indoor as well as outdoor, station- ary or mobile installation. Its compact design offers installation flexibility. The user data is backed up by a lithium battery. A battery pow- ered data tag makes it possible to obtain communication distances in the metre range, as well as an excellent reading and writing thereby saving battery energy. When data is transferred from the data tag to the Antenna, the data tag simply reflects the microwave energy sent out by the Antenna. No battery energy is expended in establishing this communication link. The battery life expectancy can be computer simulated for customer-specific conditions. In normal industrial applications, the battery life will typically exceed 8 years. The data tag complies to ETSI 300 339. Baumer Ident GmbH, Hertzstrasse 10, D-69469 Weinheim, Germany, Tel +49 6201 9957-0, Fax +49 6201 9957-99 Baumer Ident AB, Box 134, S-561 22 Huskvarna, Sweden, Tel +46 36 139430, Fax +46 36 139450 www.baumerident.com OIS-P Reg No B1003 200 Edition 8 Issued June 1999 Subject to alteration without prior notice. © Baumer Ident AB 1999 Electrical and Mechanical Data PC3104/32A (Note 1) Data speed • Writing 40 kbit/s • Reading 65 kbit/s Wake up time •2 ms Battery life (Note 2) Activation at 20°Cat 50°C • 0.1 %> 8 years> 8 years • 1.0 %6 years5 years The battery is exchangeable. RAM memory capacity • PC3104/32A8 kbyte RAM memory life • Unlimited number of read/write cycles Outline drawing (all dimensions in mm) • Tolerance unless otherwise specified ± 0.5 mm • Mounting proposal: M4 screws, Ø 4.8 ± 0.3 (4 x) Weight • 110 g Casing • Luran S Colour • Grey Temperature range Operating and storage • -40 o C to +70 o C Vibration (operating) • sine ± 0.35 mm 10-60 Hz sine 5 g 60-500 Hz in 3 axes, 40 min/axis ref: IEC 68-2-6-Test Fc • random 0.02 g 2 /Hz 10 - 2000 Hz, 3 hours in ± 3 axes ref: IEC 68-2-34 Test Fdb Bump (survival) • 10 g, 6 ms halfsine x 4000 in 3 axes ref: IEC 68-2-29 Test Eb Shock (survival) •50 g, 6 ms halfsine x 10 in 3 axes ref: IEC 68-2-27 Test Ea Free fall (survival) •1000 mm x 100 falls ref: IEC 68-2-32 Test Ed Enclosure •IP 67 ref: IEC 529 Water immersion (survival) • 9.8 kPa x 2 hrs ref: IEC 68-2-17 Test Qf Solar radiation (survival) • 1.12 kW/m2 x 56 days ref: IEC 68-2-5 Test Sa class C EMC immunity (operating) • Electrostatic discharge: 4/8 kV ref: EN61000-4-2 • Radiation: 3 V/m ref: EN61000-4-3 Environmental Data Note 2 Activation percentage is defined as the maximum part of the time that is used for reading and writing. Under these circum- stances, more than 95% of the data tag will exceed the specified lifetime. For battery lifetime at other temperatures and activation levels, consult your OIS-P sales representative. Typical activation levels in industrial applications are less than 0.1 %. Note 1 Unless otherwise specified at 20 °C. Baumer Ident GmbH, Hertzstrasse 10, D-69469 Weinheim, Germany, Tel +49 6201 9957-0, Fax +49 6201 9957-99 Baumer Ident AB, Box 134, S-561 22 Huskvarna, Sweden, Tel +46 36 139430, Fax +46 36 139450 OIS-P Reg No B0506-200 Edition 8 Issued September 1998 Subject to alteration without prior notice. © Baumer Ident AB 1997 Electrical and Mechanical Data PC3114/00B, PC3114/01B Environmental data Temperature range Operating and storage • - 40 °C to + 70 °C Vibration (operating) • sine ± 0.35 mm 10-60 Hz sine 5g 60-500 Hz in ± 3 axes, 40 min/axes ref: IEC 68-2-6 Test Fc • random 0.01 g 2 /Hz 10 - 2000 Hz, 3 hours in ± 3 axes ref: IEC 68-2-34 Test Fdb Bump (survival) • 15 g, 6 ms halfsine x 1000 in ± 3 axes ref: IEC 68-2-29 Test Eb Shock (survival) • 50 g, 6 ms halfsine x 10 in ± 3 axes ref: IEC 68-2-27 Test Ea Bench handling (survival) • Face 100 mm Corner 100 mm ref: IEC 68-2-31 Test Ec Enclosure • IP 65 ref: IEC 529 Water immersion (survival) • 9.8 kPa x 2 hrs ref: IEC 68-2-17 Test Qf Note 1 Output power, …
