PONFDBB-V2MBaby Monitor, Parent Unit

Model: FDBB-V2 BABY MONITOR 300m Be sure to read this instruction manual before operation and keep properly. Contents 1. Illustration .........................................................................................................................1 2. Scope of Application ............................................................................................. 3 3. Intend use........................................................................................................................ 3 4. Basic parts and accessories .............................................................................. 3 5. Product features ........................................................................................................ 3 6. Cautions .............................................................................................................................4 7. Icons shown on LCD .............................................................................................. 5 8. How to use the baby monitor ....................................................................... 6 9. Specifications .............................................................................................................10 10. Troubleshooting ...................................................................................................11 11. Laws and regulation ..........................................................................................12 12. Cleaning and storage for the device .....................................................12 13. Product and battery disposal instructions .......................................12 14. Declaration of Conformance ......................................................................13 15. WARRANTY ................................................................................................................13 1 1.Illustration A. Baby Unit front back battery compartment 1. temperature sensor 2. antenna 3. night light 4. on/off/lock button 5. LCD 6. speaker 7. microphone 8. night light on/off button 9. next 10. music play/stop button 11. volume up 12. volume down 13. DC adapter jack 14. battery compartment 15. Celsius/Fahrenheit switch 16. sound sensitivity switch 1516 2 B. Parent Unit 1. connecting and sound level indicators 2. LCD 3. night light on/off button 4. next 5. on/off button 6. flashlight on/off button 7. music play/stop button 8. microphone 9. speaker 10. charger port 11. power indicator 12. volume up 13. volume down 14. flashlight 15. talk button 16. clip 17. battery compartment 18. DC adapter jack C. AC adapter 电源适配器 小插头 3 2. Scope of Application Family, hospital, safety protection etc. 3. Intended use The unit is using for wireless monitor the sound and ambient temperature of baby side. 4. Basic parts and accessories Baby unit, parent unit, charger, AC adapter, 3x AA normal alkaline batteries, 3x AAA re- chargeable NiMH batteries. 5. Product features 5.1 Multiplicate power supply normal alkaline battery, rechargeable NiMH battery, AC adapter . 5.2 Wireless low power consumption, automatic frequency hopping Wireless transmitting power, automatic control, automatic frequency hopping to avoid interference with the work under power saving mode. 5.3 Long-distance wireless voice control The parent unit can monitor the baby unit in 300m without obstacles. 5.4 Wireless two-way intercom Parents cam hear the voice from baby side through wireless transmission. 5.5 Baby unit can detect the ambient temperature The LCD of baby unit can display the ambient temperature, and wireless transmit the temperature information to parent unit. 5.6 Night light of baby unit The night light can be used to light the night. 5.7 Eight baby songs Play songs timed or long time, you can also cycle selections. 5.8 Celsius and Fahrenheit switch Toggle the Celsius and Fahrenheit switch inside the battery compartment, both units will change the temperature automatically. 5.9 Adjustable sound sensitivity Toggle the sound sensitivity switch inside battery compartment can adjust the sound level of baby unit. 4 5.10 backlight You can operate the unit easily and see the LCD clearly both day and night. 5.11 Flashlight of parent unit At night, parents can shine the flashlight at any time. 5.12 Base re-charger of parent unit Parent unit re-charges when place on base unit. 5.13 lock baby unit In order to prevent misuse button, baby unit with lock funtion. 5.14 Alarm for wireless disconnection If the distance too far or the baby unit is off, the parent unit will alarm. 5.15 Alarm for low power Either baby unit or parent unit is low power, the LCD will show the icon, and parent unit will alarm. 6. Cautions 1 Before using this product, please read this manual carefully, and keep for future reference. 2 The baby monitor is only as an auxiliary, not substitute for adult supervision 3 When baby unit and parent unit close together, do not adjust the volume of the parent unit too high. 4 When the signal confirmation icon is flashing or alarm, please make sure the parent unit and baby unit are switch on, then close to these two units till connection. 5 Do not put the product into the metal box when using it, so as not to shield the product wireless signal. 6 When you bath, shower and pool time, please do not use this product, hence the product will cause an electric shock to sink to the water 7 This product can only operate in line with the instructions of the power supply adapter, if your home is not this type of power supply, consult your dealer or local power company. 8 Do not make the product is exposed to extreme temperatures. 9 Please do not put candles, cigarettes, etc. on the product. 10 Do not place the product on an unstable cart or table, the product may fall causing serious damage. 11 Ensure that the baby unit and the power cord out of reach of the baby (at least 1 meter). 12 If you will not use the product for a long time, please remove the batteries. 5 13 Th…

Text truncated - open the document above for the full version.

Letter for Confidentiality for baby monitor(parent unit) Federal Communications Commission Authorization and Evaluation Division Date: Dec.03,2012 Confidentiality Request regarding application for certification of FCC ID: PONFDBB-V2M Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1.Schematic 2.Theory of Operation 3.Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, We do not want these documents to be accessible to the general public. Sincerely, Applicant’s Contact Information: Famidoc Technology Co.,Ltd. Telephone: 0769-89272488-8674 Fax No.: 89272498 Title: Vice-general Manager E-mail : [email protected]

External Photos(parent unit)

Internal Photos(parent unit)

FCC TEST REPORT 47 CFR FCC Part 15.249 Report Reference No. ..................... : FCC ID. ............................................. : TRE12090089 R/C: 49780 PONFDBB-V2M Compiled by ( position+printed name+signature) .. : File administrators Eric Zhang Supervised by ( position+printed name+signature) .. : Test Engineer Tim Zhang Approved by ( position+printed name+signature) .. : Manager Wenliang Li Date of issue ..................................... : Dec 04, 2012 Testing Laboratory Name .............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name ............................ : Famidoc Technology Co., Ltd. Address ............................................. : No.212 Yilong Road, Hexi Industrial Zone, Jinxia, Changan Town, Dongguan 523853, Guangdong Province, P.R.China. Manufacturer’s name ..................... : Famidoc Technology Co., Ltd. Address ............................................. : No.212 Yilong Road, Hexi Industrial Zone, Jinxia, Changan Town, Dongguan 523853, Guangdong Province, P.R.China. Test specification: Standard .......................................... : 47 CFR FCC Part 15 Subpart C & 15.249 ANSI C63.10: 2009 TRF Originator .................................. : Shenzhen Huatongwei International Inspection CO., Ltd Master TRF ....................................... : Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment Under Test .................. : Baby Monitor Trade Mark ....................................... : / Model/Type reference ....................... : FDBB-V2 (parent unit) Listed Models .................................. : / Modulation ........................................ : GFSK Result ................................................ : Complied Report No.: TRE12090089 Page 2 of 32 Issued: 2012-12-04 FCC ID: PONFDBB-V2M Shenzhen Huatongwei International Inspection Co., Ltd T E S T R E P O R T Test Report No. : TRE12090089 Dec 04, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : Baby Monitor Model /Type : FDBB-V2 (parent unit) Listed Models : / Applicant : Famidoc Technology Co., Ltd. Address : No.212 Yilong Road, Hexi Industrial Zone, Jinxia, Changan Town, Dongguan 523853, Guangdong Province, P.R.China. Manufacturer : Famidoc Technology Co., Ltd. Address : No.212 Yilong Road, Hexi Industrial Zone, Jinxia, Changan Town, Dongguan 523853, Guangdong Province, P.R.China. Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE12090089 Page 3 of 32 Issued: 2012-12-04 FCC ID: PONFDBB-V2M Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY ............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. Related Submittal(s) / Grant (s) 5 2.6. Modifications 5 3. TEST ENVIRONMENT ............................................................... 6 3.1. Address of the test laboratory 6 3.2. Test Facility 6 3.3. Statement of the measurement uncertainty 7 3.4. Summary of standards and result 7 3.5. Environmental conditions 7 3.6. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................. 9 4.1. ANTENNA REQUIREMENT 9 4.2. Conducted Emissions Test 10 4.3. Radiated Emission Test 13 4.4. Out of band emissions 20 4.5. 20dB Bandwidth Measurement 22 5. TEST SETUP PHOTOS OF THE EUT .......................................... 25 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 27 Report No.: TRE12090089 Page 4 of 32 Issued: 2012-12-04 FCC ID: PONFDBB-V2M Shenzhen Huatongwei International Inspection Co., Ltd 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Rules Part 15.249: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. ANSI C63.10: 2009 – American National Standard for Teating Unlicensed Wireless Devices Report No.: TRE12090089 Page 5 of 32 Issued: 2012-12-04 FCC ID: PONFDBB-V2M Shenzhen Huatongwei International Inspection Co., Ltd 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Oct 11, 2012 Testing commenced on : Oct 11, 2012 Testing concluded on : Dec 04, 2012 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ● 120V / 60Hz ○ 12 V DC ○ 24 V DC ○ Other (specified in blank below) AC Adapter MODEL: JD5W-0900350 US INPUT:100-240V～50/60Hz 0.2A OUTPUT: 9V 350mA Power Cable: 150cm ◇ Shield ◆ Unshield 2.3. Short description of the Equipment under Test (EUT) 2.4 GHz (Baby Monitor), For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. 2.5. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: PONFDBB-V2M filing to comply with Section 15.249 of the FCC Part 15, Subpart C Rules. 2.6. Modifications No modifica…

Text truncated - open the document above for the full version.

Test photos
