POVBTM40XPAFERS-BTM-40X

XSPIN;T-KIT XSPIN;T-KIT This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment, End users must follow the specific operation instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. Regulations/Warning Made in China Model: PAFERS XSPIN; T-KIT Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.

RV-0000000 Project No.: 1309185 Page 2 of 6 Neutron Engineering Inc. Model Name: XSPIN 1309185 1309185 RV-0000000 Project No.: 1309185 Page 3 of 6 Neutron Engineering Inc. Model Name: T-KIT 1309185 1309185

RV-0000000 Project No.: 1309185 Page 4 of 6 Neutron Engineering Inc. 1309185 RV-0000000 Project No.: 1309185 Page 5 of 6 Neutron Engineering Inc. 1309185 1309185 Antenna RV-0000000 Project No.: 1309185 Page 6 of 6 Neutron Engineering Inc. 1309185 1309185

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 46 of 5 0 FCC ID: POVBTM40X 9. RF EXPOSURE COMPLIANCE 9.1 LIMIT Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 NOTE: f = frequency in MHz ; *Plane-wave equivalent power density. 9.2 MEASUREMENT INSTRUMENTS LIST Item Kind of Equipment Manufacturer Type No. Serial No. Calibrated until 1 Power Meter Anritsu ML2495A 1128008 Feb,26,2014 2 Power Meter Sensor Anritsu MA2411B 1126001 Feb,26,2014 NOTE: N/A: denotes No Model Name, No Serial No. or No Calibration specified. 9.3 MPE CALCULATION METHOD E (V/m) ＝ d GP××30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP × ×× From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 47 of 5 0 FCC ID: POVBTM40X 9.4 TEST SETUP LAYOUT 9.5 DEVIATION FROM TEST STANDARD No deviation 9.6 EUT OPERATING CONDITIONS The EUT tested system was configured as the statements of 4.1.6 Unless otherwise a special operating condition is specified in the follows during the testing. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 48 of 5 0 FCC ID: POVBTM40X 9.7 TEST RESULTS EUT PAFERS-BTM-40X Model Name XSPIN; T-KIT Temperature 26°C Relative Humidity 60% Test Voltage DC 3V Test Mode CH00, CH19, CH39 -1 Mbps Frequency Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Result 2402 MHz -0.52 0.8872 0.6800 1.1695 0.000207 1 PASS 2440 MHz -0.52 0.8872 1.0300 1.2677 0.000224 1 PASS 2480 MHz -0.52 0.8872 1.3600 1.3677 0.000242 1 PASS

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 1 of 5 0 FCC ID: POVBTM40X FCC Radio Test Report FCC ID: POVBTM40X This report concerns (check one): Original Grant Class II Change Issued Date : Sep. 30, 2013 Project No. : 1309185 Equipment : PAFERS-BTM-40X Model Name : XSPIN; T-KIT Applicant : PAFERS Tech Co., Ltd. Address : No. 208-18, Zhongqing Rd., Xitun Dist., Taichung City 407, Taiwan (R.O.C.) Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Sep. 24, 2013 Date of Test: Sep. 24, 2013 ~ Sep. 28, 2013 Testing Engineer : (Gary Chou) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 2 of 5 0 FCC ID: POVBTM40X Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C, or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences o r generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 3 of 5 0 FCC ID: POVBTM40X Table of Contents Page 1 . CERTIFICATION 5 2 . SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3 . GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 10 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 11 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 3.5 DESCRIPTION OF SUPPORT UNITS 13 4 . EMC EMISSION TEST 14 4.1 RADIATED EMISSION MEASUREMENT 14 4.1.1 RADIATED EMISSION LIMITS 14 4.1.2 MEASUREMENT INSTRUMENTS LIST ANS SETTING 15 4.1.3 TEST PROCEDURE 16 4.1.4 DEVIATION FROM TEST STANDARD 16 4.1.5 TEST SETUP 17 4.1.6 EUT OPERATING CONDITIONS 18 4.2.8 TEST RESULTS-BETWEEN 30MHZ AND 1000MHZ 19 4.1.7 TEST RESULTS (ABOVE 1000 MHZ) 21 5 . BANDWIDTH TEST 33 5.1 APPLIED PROCESURES / LIMIT 33 5.2 MEASUREMENT INSTRUMENTS LIST 33 5.3 TEST PROCEDURE 33 5.4 DEVIATION FROM STANDARD 33 5.5 TEST SETUP 33 5.6 EUT OPERATION CONDITIONS 33 5.7 TEST RESULTS 34 6 . MAXIMUM OUTPUT POWER TEST 36 6.1 APPLIED PROCEDURES / LIMIT 36 6.2 MEASUREMENT INSTRUMENTS LIST 36 6.3 TEST PROCEDURE 36 6.4 DEVIATION FROM STANDARD 36 6.5 TEST SETUP 36 6.6 EUT OPERATION CONDITIONS 36 6.7 TEST RESULTS 37 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 38 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 4 of 5 0 FCC ID: POVBTM40X Table of Contents Page 7.1 APPLIED PROCEDURES / LIMIT 38 7.2 MEASUREMENT INSTRUMENTS LIST 38 7.3 TEST PROCEDURE 38 7.4 DEVIATION FROM STANDARD 38 7.5 TEST SETUP 38 7.6 EUT OPERATION CONDITIONS 38 7.7 TEST RESULTS 39 8 . POWER SPECTRAL DENSITY TEST 43 8.1 APPLIED PROCEDURES / LIMIT 43 8.2 MEASUREMENT INSTRUMENTS LIST 43 8.3 TEST PROCEDURE 43 8.4 DEVIATION FROM STANDARD 43 8.5 TEST SETUP 43 8.6 EUT OPERATION CONDITIONS 43 8.7 TEST RESULTS 44 9 . RF EXPOSURE COMPLIANCE 46 9.1 LIMIT 46 9.2 MEASUREMENT INSTRUMENTS LIST 46 9.3 MPE CALCULATION METHOD 46 9.4 TEST SETUP LAYOUT 47 9.5 DEVIATION FROM TEST STANDARD 47 9.6 EUT OPERATING CONDITIONS 47 9.7 TEST RESULTS 48 10 . EUT TEST PHOTO 49 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 5 of 5 0 FCC ID: POVBTM40X 1. CERTIFICATION Equipment : PAFERS-BTM-40X Brand Name : PAFERS Model Name : XSPIN; T-KIT Applicant : PAFERS Tech Co., Ltd. Date of Test : Sep. 24, 2013 ~ Sep. 28, 2013 Standard(s) : FCC Part 15, Subpart C: 2012 (15.247) ANSI C63.4: 2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1309185) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 6 of 5 0 FCC ID: POVBTM40X 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part 15, Subpart C: 2012 (15.247) Standard(s) SectionTest Item Judgment Remark 15.207 Conducted Emission - N/A 15.247(d) Antenna conducted Spurious EmissionPASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(b)(3) Peak Output Power PASS 15.209/15.205 Radiated Spurious Emission PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS 1.1307 1.1310 2.1091 2.1093 RF Exposure Compliance PASS NOTE: (1)” N/A” denotes test is not applicable in this test report. (2) The test follows FCC KDB Publication No. 558074 D01 DTS Meas Guidance v03r01 (Measurement Guidelines of DTS) Neutron Engineering Inc. Report No…

Text truncated - open the document above for the full version.

Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 49 of 5 0 FCC ID: POVBTM40X 10. EUT TEST PHOTO Radiated spurious emission test photos 1309185 1309185 Neutron Engineering Inc. Report No.: NEI-FCCP-1-1309185 Page 50 of 5 0 FCC ID: POVBTM40X Radiated spurious emission test photos 1309185
