PPUTR1500-ARSAM Transmitter

FCC ID: PPUTR1500-ARS Owner’s Guide ARS TR1500 AM transmitter The thrill of owning a vintage radio of the 20’s, 30’s of 40’s is, in itself, a proud pleasure. Having that radio work is even better. But now, you can extend that pleasure to a new level. Imagine tuning your radio and getting the original programs of the era when the set was made! Listen to the programs the radio originally picked up during it’s “heyday”. All of this is possible with the solid state TR1500 made by ARS. This unit, measuring 3 ¼ x 4 ½”, will transmit the output of a tape or CD player to your vintage radio. Amaze your friends and family when receiving a broadcast of the Jack Benny show or Orson Well’s great programs of the 1930’s. For more information, contact ARS or your local distributor. Frequency: 850-1450 KHz. Intended for short range operation only. Includes power supply, antenna, and cables. $XX.XX Tape or CD player NOT included. FCC ID: PPUTR1500-ARS TR1500 operation FEDERAL COMMUNICATIONS COMMISSION RADIO AND TELEVISION INTERFERENCE STATEMENT Changes or modifications not expressly approved by ARS could void the user’s authority to operate the equipment. NOTE: This product was FCC certified under test conditions that included the use of shielded I/O cables and connectors between system components. To be in compliance with FCC regulations, the user must use shielded cables and connectors and install them properly. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The transmitter operates between approximately 850 and 1450 Khz, and accepts inputs from cassette decks, CD players, etc. It is intended for short range (in home) usage. INST ALLAT ION: Run the antenna fully extended in a straight line, avoiding nearby metallic objects. Do not coil it up. DO NOT add any length to the antenna, as it will no longer tune correctly, resulting in lower output. Re-orient the antenna if required for best performance. Run the gro und wire to a gro und so urce. Gro und must be co nnected for correct operation of the unit. Connect the RCA jacks to your signal source (Cassette deck, CD player, etc.) Plug in the attached power supply. Turn on the transmitter and verify that the green pilot LED is on. Operating controls: (accessible from the top of the transmitter with a small tuning tool or jewelers sc rewdriv er) FREQ ADJ – Sets the transmitter frequency. Adjust to an open frequency in yo ur area, to avoid interfering with other broadcasters. Fine tuning may be do ne with yo ur receiver. ANT TUNE – Tunes the antenna for maximum o utput. After you have set your frequency, adjust this for the stro ngest signal. You may wish to temporarily move your receiver f urther away for fine adjustments. If the transmitter antenna is moved, TUNE may require re-adjustment. AUDIO LEVEL – Adjust this for the maximum volume without distorting. . Operating tips: DO NOT: Jam other broadcasters. Attempt to modify the transmitter unit. Transmit obscenities or false distress signals. “make up” call signs. DO: Identify your station. “Radio Bob, Main street, Pittsburgh”.

FCC ID: PPUTR1500-ARS Block Diagram

FCC ID: PPUTR1500-ARS Top External System View FCC ID: PPUTR1500-ARS Close Up Top View of EUT

FCC ID: PPUTR1500-ARS FCC Label FCC ID: PPUTR1500-ARS Top View of EUT (showing FCC Label Placement)

FCC ID: PPUTR1500-ARS FCC Label FCC I D: PPUT R1500-A RS FCC ID: PPUTR1500-ARS Top View of EUT (showing FCC Label Placement) Note: Final FCC label is indicated on previous page (“XXXXXXXX” used for demonstration purposes only

FCC ID: PPUTR1500-ARS Top View of EUT PCB FCC ID: PPUTR1500-ARS Bottom View of EUT PCB

FCC ID: PPUTR1500-ARS Schematic Diagram

Nemko EESI, Inc. 11696 Sorrento Valley Rd., Suite F San Diego, CA 92121-1024 Phone (858) 793-9911 Fax (858) 793-9914 I EES Nemko  FCC, P ART 15, S UBPART C C ERTIFICATION R EPORT For The AM Radio Transmitter Model: TR1500 FCC ID: PPUTR1500-ARS (P ENDING ) P REPARED FOR : Antique Radio Store 7420 Clairemont Mesa Blvd. # 103 San Diego, CA 92111 P REPARED ON A PRIL 18, 2001 R EPORT N UMBER 21-076 This report has been prepared in accordance with all applicable requirements of ANSI C63.4-1992 Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 793-9914 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 05/8/01Antique Radio Store AM Radio Transmitter TR1500 FCC ‘C’ Ce rtification Re port 21-076PPUTR1500- ARS ii DOCUMENT HISTORY REVISIONDATECOMMENTS -05/8/01Prepared By: W. Weber -05/10/01Reviewed By: A. Smith -05/11/01Initial Release: J. L. Griffin NOTE: Nemko EESI, Inc. hereby makes the following statements so as to conform to Chapter 10 (Test Reports) Requirements of ANSI C63.4 (1992) “Methods and Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz”: • The unit described in this report was received at Nemko EESI, Inc.'s facilities on May 15, 2000. Testing was performed on the units described in this report May 17, 2000. • The Test Results reported herein apply only to the units actually tested, and to substantially identical units. • This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. This Report is the property of Nemko EESI, Inc., and shall not be reproduced, except in full, without prior written approval of Nemko EESI, Inc. However, all ownership rights are hereby returned unconditionally to Antique Radio Store, and approval is hereby granted to Antique Radio Store and its employees and agents to reproduce all or part of this report for any legitimate business purpose without further reference to Nemko EESI, Inc. Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 793-9914 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 05/8/01Antique Radio Store AM Radio Transmitter TR1500 FCC ‘C’ Ce rtification Re port 21-076PPUTR1500- ARS iii T ABLE OF C ONTENTS DOCUMENT HISTORY................................................................................................................................ ii CERTIFICATION ......................................................................................................................................... iv 1. ADMINISTRATIVE DATA AND TEST SUMMARY............................................................................. 1 1.1Administrative Data.......................................................................................................................... 1 1.2FCC Test Requirements .................................................................................................................... 1 1.3FCC Test Summary........................................................................................................................... 2 2. SYSTEM DESCRIPTION AND CONFIGURATION............................................................................. 3 2.1System Description and Method of Exercising .................................................................................3 2.2System Components and Power Cables ............................................................................................ 3 2.3Device Interconnection and I/O Cables ............................................................................................ 3 2.4Design Modifications for Compliance .............................................................................................. 3 3. DESCRIPTION OF TEST SITE AND EQUIPMENT............................................................................ 4 3.1Description of Open Area Test Site.................................................................................................. 4 3.2Test Equipment ................................................................................................................................. 4 4. DESCRIPTION OF TESTING METHODS ............................................................................................ 5 4.1Introduction....................................................................................................................................... 5 4.2Configuration and Methods of Measurements for Conducted Emissions........................................... 7 4.3Configuration and Methods of Measurements for Ambient Signals................................................... 9 4.4Configuration and Methods of Measurements for Radiated Emissions ........................................... 11 5. TEST RESULTS ...................................................................................................................................... 13 5.1Conducted Emissions Test Data...................................................................................................... 13 5.215.219 Test Data............................................................................................................................. 15 TEST SETUP DIAGRAMS Figure 1. General EUT Test Setup Diagram.......................................................................................................... 6 Figure 2. Conducted Emissions Test Setup Diagram.............................................................................................. 8 Figure 3. Radiated Emissions Frequency ID Test Setup Diagram .......................................................................... 10 Figure 4. Radiated Emissions (OATS) Test Setup Diagram .................................................................................. 12 APPENDICES Conducted & Radiated Emissions Measurement Uncertainties ....................................…

Text truncated - open the document above for the full version.

Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121 Phone (858) 793-9911 Fax (858) 793-9914 DATEDOCUMENT NAMESUBMITTAL #FCC IDPAGE 05/8/01Antique Radio Store AM Radio Transmitter TR1500 FCC ‘C’ Certification Report 21-076XXXTR150016 5.2.4 Radiated Emissions Test Data

FCC ID: PPUTR1500-ARS Conducted Emissions Test Configuration 1. EUT: TR1500 2. Line Impendence Stabilization Network (LISN) for EUT 3. Audio Tape Player 4. AMN for peripheral devices 1 2 3 4 FCC ID: PPUTR1500-ARS Radiated Emissions Test Configuration 1. Loop Antenna 2. EUT: TR1500 1 2
