PQF2116-914MIQ Hand Control Unit (RAT)

iQ System Installation Manual Model Number: 2116-01-nnn Notice Quantel Limited accepts no responsibility for the accuracy of the information contained herein and reserves the right to change the contents without prior notice. This document does not form part of the product’s Technical or Functional Specification and does not form part of any contractual agreement. This manual is a change controlled document. Please quote the revision status of this manual when re-ordering. The revision status is determined by the content, any change in any part being reflected in the manual revision status. This Manual is Revision A. Copyright © Quantel Ltd 2000-2001 2116-58-030 AQuantel Installation Manuali Notices Important Product Information WARNING: Read the Important Product Information book before use. Conventions Used ☛ WARNINGS: Indicate danger to life and limb if the indicated statements are ignored, or the indicated procedures are not performed correctly.  Cautions: Indicate possible damage to (or misalignment of) the equipment if the indicated statements are ignored, or the indicated procedures are not performed correctly. Maintenance ☛ WARNING (WM 2) Service Personnel - Maintenance and Calibration within the equipment enclosure is only to be carried out by SERVICE PERSONNEL. (12/97) Equipment Isolation ☛ WARNING (WI 5) Equipment Isolation - The plug on the power supply cord, for Pluggable Equipment, is considered to be the isolation device and therefore the socket-outlet must be installed near the equipment and shall always be accessible for this purpose. For permanently connected equipment, where the unit’s mains supply inlet is permanently connected, a readily accessible disconnect device must be incorporated in the fixed wiring. (12/97) Trade Marks Most of the product names mentioned in this manual are manufacturer trade marks and are used within this manual only for the purpose of identification. iQ is a registered trademark is of Quantel Limited. iiContent 04/012116-58-030 A About This Manual This manual was written and produced by the Quantel Technical Publications Department. This is a change controlled document. Each page of this document is given an issue letter (shown at the bottom of each page with the drawing number and revision date) which represents the status of the page. Revision A on any page indicates that the page is the original. Any changes to any pages will raise the revision status of the document. When re-ordering, always quote the document type, the documents number and revision status along with the unit’s serial number: A04/01E31212All pages Chapter 1 : Overview This chapter provides an introduction to the system. Chapter 2 : Preparation This chapter details pre-installation advice; including environmental and electrical supply requirements. Chapter 3 : Unpacking This chapter details the unpacking and handling of the various system units. Chapter 4 : Racking This chapter details the rack mounting of the various system units. Chapter 5 : Connection This chapter details the systems inter-connections and cable configurations. Chapter 6 : Start-Up This chapter details the system power-up and power-down procedures, and also details the various reset methods for each system unit. Chapter7 : Maintenance This chapter provides details of the maintenance required for each of the system’s units. 2116-58-030 AQuantel Installation Manualiii Installation Check List • Check all packaging for any sign of shipping damage before it is unpacked. • Ensure that installation sites meets the requirements detailed in chapter 2 - “Preparation”. • Unpack boxes in a clear area close to the installation site and follow all lifting guidelines. • Keep all paper work and documentation in a safe place as it will be required later. • Assemble and rack mount the system in accordance with the guide lines in chapter 4 - “Racking”. •Interconnect the system’s units together using the cables provided (or cables meeting the required specifications detailed in the Technical Specification supplied) as detailed in chapter 5 - “Connection”. •Start-up the system for the first time as detailed in chapter 6 - “Start-up” and check basic operation of pen/tablet/menu. •Configure the system as detailed in the Setup and Admin guide. ivContent 04/012116-58-030 A Contents 01 - Description Overview1-3 System Components1-3 IQ Platform1-3 Dylan HD Disk Arrays1-3 IQ Workstation1-3 IQ Platform Dimensions (2116-01-nnn)1-5 Dylan HD Dimensions (2110-12-nnn Serial)1-6 Tablet Dimensions1-7 Keyboard Dimensions1-8 Hand Unit & Docking Port Dimensions 1-9 Control Interface Box Dimensions 1-10 Fader Panel Dimensions1-11 Jog / Shuttle Panel Dimensions 1-12 02 - Preparation General2-3 Equipment Location2-3 System Air Flow2-5 Electrical Supply2-7 Description2-7 Electrical Supply Quality2-8 Environment2-9 Operating Environment2-9 Shipment & Storage Environment 2-10 03 - Unpacking General3-3 Unpacking Advice3-3 iQ Platform3-3 04 - Racking Rack Mounting4-3 Important Information4-3 Rack Layout4-4 IQ Platform Rack Mounting Procedure 4-5 Dylan HD Disk Arrays4-9 Fitting the Rails to the Cabinet 4-9 Securing the Enclosure to the Rails 4-10 Fitting the PSU Modules4-11 Fitting the Interface Module 4-12 Fitting the Disk Carriers4-13 Workstation4-15 Workstation Layout4-15 Mounting the Tablet4-15 Mounting the Keyboard4-15 Mounting the Fader Panel4-16 Mounting the Jog / Shuttle Panel 4-16 Assembling the Hand Unit / Mounting the Docking Port4-16 Important Battery Information4-16 2116-58-030 AQuantel Installation Manualv 05 - Connection System Connection5-3 System Connection Overview5-3 Electrical Supply Considerations 5-4 Cabling Considerations5-4 IQ Platform5-5 Rear Panel Layout5-5 Mains Connection5-5 Digital Video Connections5-6 General5-6 SD Video Inputs and Outputs 5-6 HD Video Inputs and Outputs 5-7 Serial Control Connections5-7 General5-7 VCR Connections5-8 Workstation Connection5-8 SCSI Port5-8 Locking References5-9 SVGA Monitor Output5-10 An…

Text truncated - open the document above for the full version.

ISS.ECODATESIG A B C D E QUANTEL This drawing/document is strictly confidential. It is used by and is the property of Quantel. It shall not be reproduced or utilised in any way without the express written permission of Quantel Ltd. QUANTEL c 2116-22-135 BATTERY ACCESS COVER (914) ARTWORK 031201 CM E31719 FCC ID:PQF2116-914M

ThePaintProcess ThePaintMenu The Paint process can be used on each layer in turn. Selecting thePaint menu will display the functions that are available. The menu area at the bottom of the screen displays the painting, stencil and cutout menus while the desktop provides an image working area to allow frames to be painted or retouched. BuyingandSellingFrames When a clip layer is processed using thePaintmenu each frame is held (ie bought) in a buffer so that it can be painted, retouched or modified as a still. Each frame can be processed then sold back to the clip. This simple mechanism allows clips to be retouched or painted frame by frame in a quick and efficient manner. The buying and selling processes are controlled by the hand unit buttons or by the keyboard. The Buy function (ie button 2 or the <Insert>/<Page Up> key) is used to copy the current frame of the clip to the desktop (or canvas) for processing. The Sell function (ie button 4 or the <End> key) is used to transfer the desktop image back to the currently selected position in the clip. The Next function (button 1 or the <Home> key) is used to step to the next frame to be processed. The Previous function (ie button 3 or the <Delete>/<Page Down> key) is used to step back to the previous frame. UsingthePallette,BrushesandCanvas When a frame is selected it is placed on the canvas (ie the image processing area on the desktop) as the current image ready for processing. Before anything can be done to the image, however, the brush type, brush size and brush colour must be selected and the menu swiped-off to remove the protection from the image. 2116-57-007AQuantelApplicationReference053 Paint 2 1Background clip 0:200:25 Foreground clip Foreground clip 3 CombineZoom 1920x1080 Render %100 00:00:00:2500:00:00:25 >||| <<>>|| 2 tcC LK <-> KReset Settings |< 1 del clipsA HD QeditQioQscribeQeffectsQplugin Paint Qexapp Tracker Blur Colour Key Dve Painting Pasteup restore blur field wash zip copy save sten two load one pic useshowdraw wiperev redoundoswipe undo edit line rectangle circle ellipse draw grid save

Radiometrix Ltd, TX3A & RX3 Data Sheet page 1 UHF FM Data Transmitter and Receiver Modules Features: • European version conforms to EN 300 220-3, EN 301 489-3 • North American version conforms to FCC part 15.249 • Frequencies available as standard: 869.85MHz, 914.5MHz • Data rates up to 64kb/s • Usable range up to 120m • Fully screened Available for operation in the 868-870MHz band in Europe and the 902–928MHz band in North America, both modules combine full screening with internal filtering to ensure EMC compliance by minimising spurious radiation and susceptibility. The TX3A & RX3 will suit one-to-one and multi-node wireless links in such applications as car and building security, EPOS and inventory tracking, remote industrial process monitoring and data networks. Because of their small size and low power requirements, both modules are ideal for use in portable, battery-powered applications such as hand-held terminals. Transmitter – TX3A • Crystal-locked PLL, FM modulated at up to 64 kb/s • Operation from 2.2V to 12V @ 7.5mA • Built-in regulator for improved stability and supply noise rejection • 1mW nominal RF output • Enable facility • Update of the original TX3 with enhanced performance Receiver – RX3 • Single conversion FM superhet with SAW front end filter • Operation from 2.7V to 12V @ 9.5mA • Built-in regulator for improved stability and supply noise rejection • 64kb/s, -100dBm sensitivity @ 1ppm BER • RSSI output with 75dB range • Enable facility Radiometrix Issue 3, 24 April 2001 TX3A & NEW NEW NEW NEW European versions: TX3A-869-64/RX3-869-64 USA versions: TX3A-914-64/RX3-914-64 The TX3A & RX3 are miniature UH F radio transmitter & receiver modules designed for PCB mounting. They allow the simple implementation o f data links at speeds up to 64kb/s and distances up to 30m in-building or 120m over open ground. Radiometrix Ltd, TX3A & RX3 Data Sheet page 2 Functional description The TX3A transmitter module uses a frequency modulated crystal-locked PLL and operates between 2.2V and 12V at a current of 7.5mA nominal. At 3V supply it delivers nominally 0dBm (1mW) RF output. The SIL style TX3A measures 32 x 12 x 3.8 mm, excluding pins. The RX3 module is a single conversion FM superhet receiver capable of handling data rates of up to 64kb/s. It will operate from a supply of 2.7V to 12V and draws 9.5mA when receiving. The RX3 features a fast power-up time for effective duty cycle power saving and a signal strength (RSSI) output with 75dB of range. Full screening and a SAW front-end filter give good immunity to interference. The SIL style RX3 measures 48 x 17.5 x 4.5 mm, excluding pins. TX3A transmitter Fig 1 :TX3A block diagram Vcc (pin 5) +2.2V to +12V DC supply. Max ripple content 0.1V P-P . Decoupling is not generally required. 0V (pin 6) DC supply ground. Internally connected to pins 1 & 3 and module screen. TXD (pin 7) DC-coupled modulation input. Accepts serial digital data at 0V to 2.5V levels. See applications notes for suggested drive methods. Input is high impedance (>1M Ω ). Pin description RF GND (pins 1&3) RF ground, internally connected to the module screen and pin 6 (0V). These pins should be directly connected to the RF return path - e.g. coax braid, main PCB ground plane etc. RF OUT (pin 2) 50 Ω RF output to the antenna. Internally DC-isolated. See antenna section of apps notes for details of suitable antennas. En (pin 4) Tx enable. <0.15V shuts down module (current <1 μ A). >1.7V enables the transmitter. Impedance ~1M Ω . Observe slew rate requirements (see apps notes). 868/915 MHz band pass filter buffer 2 RF out 3 RF gnd Loop Filter 35kHz LPF ref osc φ 7 TXD 1 supply regulator 4 En 5 2.2 -- 12V ÷ 64 V C O 6 0V 3.8 mm 32 mm 12.0 mm 12.5 mm PCB level Radiometrix TX3 7 holes, 0.7 mm dia, pin spacing 2.54 mm Fig2: TX3A physical dimensions 15.24 mm 1 23 4567 1 = RF GND 2 = RF OUT 3 = RF GND 4 = En 6 = 0V 7 = TXD 5 = Vcc Radiometrix Ltd, TX3A & RX3 Data Sheet page 3 RX3 receiver VCO 35kHz 8 AF out 9 RXD 6 0V 4 En 1st Mixer 2, 3 RF gnd IF Amp Demod REF Φ 64 ÷ supply regulator 7 V cc 5 RSSI 10.7MHz 1 RF in Preamp. 868/915 MHz Band Pass Filter data slicer 10k Fig.3: RX3 block diagram En (pin 4) Rx enable. <0.15V shuts down module (current <1 μ A). >1.7V enables the receiver. Impedance ~1M Ω . Observe Fig.4: RX3 physical dimensions slew rate requirements (see apps notes). RSSI (pin 5) Received signal strength indicator with >65dB range. See applications notes for typical characteristics. 0V (pin 6) DC supply ground. Internally connected to pins 2 & 3 and module screen. Vcc (pin 7) +2.7V to +12V DC supply. Max ripple content 0.1V P-P . Decoupling is not generally required. AF out (pin 8) Buffered and filtered analogue output from the FM demodulator. Standing DC bias 1.3V approx. External load should be >50k Ω // <100pF. NOTE: AF waveform from this pin is inverted . RXD (pin 9) Digital output from the internal data slicer. The data is true data, i.e. as fed to the transmitter. Output is “open-collector” format with internal 10k Ω pullup to Vcc (pin 7). Pin description RF IN (pin 1) 50 Ω RF input from antenna. Internally DC-isolated. See antenna section of applications notes for suggested antennas and feeds. RF GND (pins 2 & 3) RF ground, internally connected to the module screen and pin 6 (0V). These pins should be connected to the RF return path - e.g. coax braid, main PCB ground plane etc. 9 holes of 0.7 mm dia. pin spacing 2.54mm 12 3 48 mm 17.5 mm 18.0 mm PCB level Radiometrix RX3 456798 25.4 mm 1 = RF IN 2 = RF GND 3 = RF GND 4 = En 5 = RSSI 6 = 0V 7 = Vcc 8 = AF out 9 = RXD 4.5 mm Radiometrix Ltd, TX3A & RX3 Data Sheet page 4 Absolute maximum ratings Exceeding the values given below may cause permanent damage to the module. Operating temperature -20°C to +70°C Storage temperature -40°C to +100°C TX3A Vcc (pin 5) -0.3V to +16V TXD (pin 7) ±7V En (pin 4) -0.3V to +Vcc V RF OUT (pin 2) ±50V DC, +10dBm RF RX3 RSSI, Vcc, RXD (pins 5,7,9) -0.3V to +16V En, AF (pins 4,8) -0.3V…

Text truncated - open the document above for the full version.

QUANTEL BILL OF MATERIAL STRUCTURE REPORT UK Stock ========================================= Item No: 2116-68-205 Explosion Level : 1 Requested By: PETERC Desc : RAT MAIN 914 Implemented Only: Yes Report Date : 03 DEC 2001 Rev : 09 As of: 03-DEC-01 11:13 Engineering Bill: No Page No : 1 Display: Current Item Op Effective Disable Lvl Item Description Rev Seq UOM Qntity Seq Date Date ECO Designator Comment --- ------------- ---------------------------------- --- ---- --- ------ -- -- --------- --------- ------ ---------- ------- 1 2116-68-006 CIRCUIT DIAGRAM H 2 Ea 0.00 50 02-OCT-01 E31090 1 2116-68-008 COMPONENT LAYOUT C 3 Ea 0.00 50 02-OCT-01 E31090 1 2116-68-091 PASTE MASK - BOTTOM C 5 Ea 0.00 50 02-OCT-01 E31090 1 2116-68-092 PASTE MASK - TOP C 6 Ea 0.00 50 02-OCT-01 E31090 1 01-51-0592 RES/FMF SM 1K2 0W125 1% 0 10 Ea 4.00 200 02-OCT-01 E31090 R38 B1-T R39 B1-T R40 B1-T R41 B1-T 1 01-51-0657 RES/FMF SM 100K 0W125 1% 0 20 Ea 1.00 150 14-NOV-01 E32377 R43 A1-B 1 01-51-0690 RES/FMF SM 2M2 0W125 1% 0 40 Ea 1.00 150 02-OCT-01 E31090 R22 A1-B 1 01-51-0827 RES/F MF SM ZERO OHM LINK 0 50 Ea 1.00 150 14-NOV-01 E32377 R18 B1-B 1 01-51-0975 RES/FMF SM 120R 0W125 1% 0 60 Ea 1.00 200 02-OCT-01 E31090 R28 B1-T 1 01-51-1270 RES/FMF SM 390K 0W125 1% 0 70 Ea 1.00 150 02-OCT-01 E31090 R27 A1-B 1 01-51-1327 RES/FMF SM 1M0 0W125 1% 0 80 Ea 1.00 150 02-OCT-01 E31090 R21 A1-B 1 01-51-1360 RES/FMG SM 10K 0W063 1% 0 90 Ea 1.00 200 02-OCT-01 E31090 R10 B1-T 1 01-51-1408 RES/FMF SM 221K 0W063 1% 0 100 Ea 11.00 150 02-OCT-01 E31090 R1 A1-B R2 A1-B R3 A1-B R30 A1-B R31 A1-B R4 A1-B R5 A1-B R6 A1-B R7 A1-B R8 A1-B R9 A1-B 1 01-51-1408 RES/FMF SM 221K 0W063 1% 0 110 Ea 7.00 200 02-OCT-01 E31090 R11 B1-T R12 B1-T R24 B1-T R25 B1-T R26 B1-T R35 B1-T R36 B1-T 1 01-51-1424 RES/FMF SM 68K1 0W063 1% 0 120 Ea 2.00 150 02-OCT-01 E31090 R15 A1-B R34 A1-B QUANTEL BILL OF MATERIAL STRUCTURE REPORT UK Stock ========================================= Item No: 2116-68-205 Explosion Level : 1 Requested By: PETERC Desc : RAT MAIN 914 Implemented Only: Yes Report Date : 03 DEC 2001 Rev : 09 As of: 03-DEC-01 11:13 Engineering Bill: No Page No : 2 Display: Current Item Op Effective Disable Lvl Item Description Rev Seq UOM Qntity Seq Date Date ECO Designator Comment --- ------------- ---------------------------------- --- ---- --- ------ -- -- --------- --------- ------ ---------- ------- 1 01-51-1424 RES/FMF SM 68K1 0W063 1% 0 130 Ea 1.00 200 02-OCT-01 E31090 R23 B1-T 1 01-51-1483 RES/FMF SM ZERO OHM LINK 0 140 Ea 1.00 150 02-OCT-01 E31090 R32 A1-B 1 01-51-1580 RES/FMF SM 75R 0W063 1% 0 150 Ea 1.00 200 02-OCT-01 E31090 R29 A1-T 1 02-08-1482 RES/V JOYSTICK 10Kx2 0W125 0 160 Ea 1.00 50 02-OCT-01 E31090 VR1 A1-T 1 03-51-0077 CAP/FCER SM 10N 50V 20% 0 170 Ea 2.00 150 02-OCT-01 E31090 C27 A1-B C28 A1-B 1 03-51-0085 CAP/FCER SM 100N 50V +80% 0 180 Ea 1.00 200 02-OCT-01 E31090 C26 A1-T 1 03-51-0182 CAP/FCER SM 1N 50V 20% 0 190 Ea 12.00 150 02-OCT-01 E31090 C10 A1-B C11 A1-B C12 A1-B C13 A1-B C14 A1-B C19 A1-B C24 A1-B C25 A1-B C6 A1-B C7 A1-B C8 A1-B C9 A1-B 1 03-51-0247 CAP/FCER SM 2P2 50V 0P5 0 200 Ea 2.00 150 02-OCT-01 E31090 C1 B1-B C30 B1-B 1 03-51-0344 CAP/FCER SM 330N 50V +80% 0 210 Ea 1.00 150 02-OCT-01 E31090 C29 B1-B 1 03-51-0344 CAP/FCER SM 330N 50V +80% 0 220 Ea 1.00 200 02-OCT-01 E31090 C16 B1-T 1 03-51-0425 CAP/FCER SM 1U 16V 20% 0 230 Ea 1.00 200 02-OCT-01 E31090 C23 B1-T 1 03-51-0832 CAP/FCER SM 10u 10V +80-20% 0 240 Ea 5.00 150 02-OCT-01 E31090 C17 A1-B C18 B1-B C21 A1-B C22 B1-B C5 A1-B 1 03-51-0832 CAP/FCER SM 10u 10V +80-20% 0 250 Ea 2.00 200 02-OCT-01 E31090 C2 B1-T C3 B1-T 1 04-52-0483 ICMSO8x.12 LIN 1307CMS8 SM 0 260 Ea 1.00 150 02-OCT-01 E31090 I2 A1-B 1 04-56-0345 ICSO8x0.15MOS 1483CS8 SM 0 270 Ea 1.00 200 02-OCT-01 E31090 I1 B1-T 1 04-57-0189 ICSO14x0.3 ACC 202JQC CERPAK SM 0 280 Ea 1.00 150 02-OCT-01 E31090 I4 A1-B QUANTEL BILL OF MATERIAL STRUCTURE REPORT UK Stock ========================================= Item No: 2116-68-205 Explosion Level : 1 Requested By: PETERC Desc : RAT MAIN 914 Implemented Only: Yes Report Date : 03 DEC 2001 Rev : 09 As of: 03-DEC-01 11:13 Engineering Bill: No Page No : 3 Display: Current Item Op Effective Disable Lvl Item Description Rev Seq UOM Qntity Seq Date Date ECO Designator Comment --- ------------- ---------------------------------- --- ---- --- ------ -- -- --------- --------- ------ ---------- ------- 1 04-88-0390 ICTQFP 44PIN MOS 16F877-20P/T PROG 0 290 Ea 1.00 150 02-OCT-01 E31090 I3 B1-B 1 05-04-0078 IC VR TO92 LIN 78L05CZ 5V 0 300 Ea 1.00 50 02-OCT-01 E31090 RG1 B1-T 1 05-51-0015 TRS SOT23 NPN BC847C SM 0 310 Ea 2.00 200 02-OCT-01 E31090 TR1 B1-T TR3 B1-T 1 05-51-0023 TRS SOT23 PNP BC857C SM 0 320 Ea 1.00 150 02-OCT-01 E31090 TR2 B1-B 1 06-51-0019 DIODE SM LL4148 100V150MA 0 330 Ea 3.00 150 02-OCT-01 E31090 D10 A1-B D3 A1-B D9 A1-B 1 06-51-0027 DIODE SOT23 SM HSMS2800 70V 0 340 Ea 3.00 200 02-OCT-01 E31090 D2 B1-T D6 B1-T D7 B1-T 1 06-53-0095 LED+R 2PIN HLMP6800-011 GRN SM 0 350 Ea 1.00 150 02-OCT-01 E31090 LD1 A1-B 1 06-54-0023 RECT D0214AA SM ES2D 200V 2A 0 360 Ea 1.00 150 02-OCT-01 E31090 D8 A1-B 1 07-51-0365 CHOKE SM 1210 10u 10% SM 0 370 Ea 1.00 150 02-OCT-01 E31090 L1 A1-B 1 08-07-3155 CNRPL SIL 20W LOW PROFILE 0 380 Ea 2.00 400 02-OCT-01 E31090 RCP1 B1-B RCP2 B1-B 1 08-57-0213 CNRPL 8W RA HDR SM 0 390 Ea 1.00 150 02-OCT-01 E31090 PL1 A1-B 1 10009-102 2 WAY BERGSTICK 0.1 PITCH 0 400 Ea 2.00 1 02-OCT-01 E31090 BS1 A1-B BS2 A1-B 1 2116-22-115 RAT BATTERY TERML SHORT (-VE) A 410 Ea 1.00 50 02-OCT-01 E31090 BTN1 A1-B 1 2116-22-120 RAT BATTERY TERML LONG (+VE) B 420 Ea 1.00 50 02-OCT-01 E31090 BTP1 A1-B 1 2116-68-003 BARE PCB RAT MAIN C 430 Ea 1.00 50 02-OCT-01 E31090 1 26-04-1406 SW MICRO SPCO 50mA/30VDC 0 440 Ea 4.00 50 02-OCT-01 E31090 SW1 A1-T SW2 A1-T SW3 B1-T SW4 A1-T 1 26-54-0011 SW P/B SPNO PCMTG SM 0 450 Ea 1.00 150 02-OCT-01 E31090 SW9 A1-B 1 26-54-0011 SW P/B SPNO PCMTG SM 0 460 Ea 4.00 200 02-OCT-01 E31090 SW5 A1-T SW6 A1-T SW7 A1-T SW8 A1-T 1 28-04-0091 FM DATA…

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To: FCC Part 15: 2000 Sections 15.249 and 15.109 Test Report Serial No: RFI/EMCB1/RP42535A This Test Report Is Issued Under The Authority Of Richard Jacklin, Operations Director: Checked By: Tested By:Release Version No: PDF01 Issue Date: 20 November 2001Test Dates: 4 October 2001 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. The results in this report apply only to the sample(s) tested. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP42535A EMC DepartmentPage 2 of 37 Issue Date: 20 November 2001 Test Of:Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To:FCC Part 15: 2000 Class A Section 15.249 and 15.109 This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP42535A EMC DepartmentPage 3 of 37 Issue Date: 20 November 2001 Test Of:Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To:FCC Part 15: 2000 Class A Section 15.249 and 15.109 Table of Contents 1. Client Information......................................................................................................4 2. Equipment Under Test (EUT).....................................................................................5 3. Test Specification, Methods And Procedures........................................................10 4. Deviations From The Test Specification.................................................................11 5. Operation Of The EUT During Testing....................................................................12 6. Summary Of Test Results........................................................................................13 7. Measurements, Examinations And Derived Results..............................................14 8. Measurement Uncertainty........................................................................................22 Appendix 1. Test Equipment Used...............................................................................23 Appendix 2. Measurement Methods............................................................................24 Appendix 3. Test Configuration Drawings..................................................................26 Appendix 4. Graphical Test Results............................................................................29 RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP42535A EMC DepartmentPage 4 of 37 Issue Date: 20 November 2001 Test Of:Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To:FCC Part 15: 2000 Class A Section 15.249 and 15.109 1. Client Information Company Name: Quantel Ltd. Address: 31 Turnpike Road Newbury Berkshire RG14 2NX. Contact Name: Mr. D. Bowman. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP42535A EMC DepartmentPage 5 of 37 Issue Date: 20 November 2001 Test Of:Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To:FCC Part 15: 2000 Class A Section 15.249 and 15.109 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name: Quantel Model Name or Number: Hand Control Unique Type Identification: 2116-22-018 Serial Number: 252553/3 Country of Manufacture: United Kingdom FCC ID Number: None stated Date of Receipt: 02 October 2001 Brand Name: Quantel Model Name or Number: Hand Control Dock Unique Type Identification: 2116-29-018 Serial Number: 820254/1 Country of Manufacture: United Kingdom FCC ID Number: None stated Date of Receipt: 02 October 2001 RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP42535A EMC DepartmentPage 6 of 37 Issue Date: 20 November 2001 Test Of:Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To:FCC Part 15: 2000 Class A Section 15.249 and 15.109 2.2. Description Of EUT The Hand Control is a hand held (mouse/puck type) control low power radio transmitter. It uses 5 push button switches, a switch joystick, analog joystick and inertial sensors as some of the control functions for Quantel iQ series video editing/effects equipment The Hand Control Dock is the radio receiver for the data transmitted from the Hand Control. Hand Control Data received by the Hand Control Dock is passed to the Quantel iQ mainframe by an RS485 serial data link. The Hand Control Dock is connected to the iQ control system by a 4 way (2 tw/pr) power/data cable. As well as being the receiver for Hand Control data it provides a parking bay and battery charging point for the Hand Control. The Hand Control and Hand Control Dock are component parts of the Quantel iQ Control Station which is used to control the various editing, retouching, animation, clip loading, playout and data entry functions of the Quantel iQ video editing/effects system. 2.3. Modifications Incorporated In EUT When the Hand Control functionality is set to transfer switch status data to the iQ system via the LP radio link and Hand Control Dock, a change of switch status data causes the Hand Control to transmit the switch status data packet for one second. In order that the radiated power level of the RF module may easily be measured, the Hand Control can be loaded …

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 PHOTOGRAPH SECTION FOR RFI TEST REPORT SERIAL NO: RFI/EMCB1/RP42535A Test Of: Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To: FCC Part 15: 2000 Sections 15.249 and 15.109 RADIO FREQUENCY INVESTIGATION LTD.Photograph Section S.No: RFI/EMCB1/RP42535A EMC Department Test Of:Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To:FCC Part 15: 2000 Sections 15.249 and 15.109 This section contains the following photographs: Photo Reference NumberTitle PHT/42535/001Overall View of EUT PHT/42535/002Open Area Test Set-up PHT/42535/003EUT Turntable Set-up RADIO FREQUENCY INVESTIGATION LTD.Photograph Section S.No: RFI/EMCB1/RP42535A EMC Department Test Of:Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To:FCC Part 15: 2000 Sections 15.249 and 15.109 PHT/42535/001 Overall View of EUT RADIO FREQUENCY INVESTIGATION LTD.Photograph Section S.No: RFI/EMCB1/RP42535A EMC Department Test Of:Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To:FCC Part 15: 2000 Sections 15.249 and 15.109 PHT/42535/002 Open Area Test Set-up RADIO FREQUENCY INVESTIGATION LTD.Photograph Section S.No: RFI/EMCB1/RP42535A EMC Department Test Of:Quantel Ltd. 2116-22-018 Hand Control and 2116-29-018 Hand Control Dock To:FCC Part 15: 2000 Sections 15.249 and 15.109 PHT/42535/03 EUT Turntable Set-up
