PQIXMTR2BTNJITrBUD Wireless Transmitter

JITRBUD  Main User Guide Version 5.0 Part Number 108741-01 JITRBUD  Main User Guide Version 5.0 iiJITRBUD Main User Guide JITRBUD  Main User Guide Changes in equipment, software, or procedures may occur periodically; information describing these changes will be included in future editions of the manual and periodic change-page releases. Because of the inherent delays involved in producing documentation, information in this document is subject to change without notice and does not represent a commitment on the part of Pyxis Corporation to provide additional services or enhancements. Unless otherwise noted, all names of companies, products, street addresses, and persons contained herein are part of a completely fictitious model or models, and are designed solely to document and illustrate the use of the JIT RBUD product. Warning: This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instruction manual, may cause interference with radio communications. It has been tested and found to comply with the limits for a Class “A” digital device pursuant to Subpart B of Part 15 of the FCC Rules, which are designed to provide reasonable protection against such interference when equipment is operated in a commercial environment. Operation of this equipment in a residential area may cause interference, in which case the user, at their own expense, will be required to take whatever measures may be required to correct the interference. This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1.This device may not cause harmful interference, and 2.This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. July 2002 JIT RBUD Main User Guide Part # 108741-01 JIT RBUD is a registered trademark of Pyxis Corporation. The Pyxis logo is a registered trademark of Pyxis Corporation. © 2002 Pyxis Corporation 3750 Torrey View Court San Diego, CA 92130 1-800-367-9947 Fax: 1-858-480-6329 www.pyxis.com All rights reserved. Printed in the United States of America. JITRBUD Main User Guideiii Contents Preface.................................................................. vii Welcome ......................................................................................... vii How this Guide is Organized....................................................... viii Manual Overview............................................................................ viii User Guide Conventions ................................................................ ix Text.................................................................................................... ix Icons .................................................................................................. ix User Guide Terminology................................................................. x Chapter 1 System Overview ................................................. 1-1 Benefits and Features.................................................................... 1-2 System Components ...................................................................... 1-3 JIT RBUD Stations........................................................................ 1-3 S UPPLYCENTER Console .............................................................. 1-3 The Network Information ............................................................1-3 Comprehensive Reporting............................................................1-4 Chapter 2 Station Basics ...................................................... 2-1 Station Basics ................................................................................. 2-2 Using the Touch-Screen............................................................... 2-2 Using the Keyboard .....................................................................2-2 Contents ivJITRBUD Main User Guide Using the JITRBUD Transmitters ................................................ 2-3 Using Window and Screen Features ............................................ 2-3 Command Buttons .................................................................... 2-3 Scroll Bars................................................................................. 2-3 Lists........................................................................................... 2-4 Drop-down Lists ....................................................................... 2-4 Check Boxes ............................................................................. 2-4 Search Boxes............................................................................. 2-4 Confirmation Screens ............................................................... 2-4 Logging In ...................................................................................... 2-5 Logging In Using ID and Password............................................. 2-5 Logging Out ................................................................................... 2-6 To log out.................................................................................. 2-6 Changing Your Password ............................................................. 2-7 Main Menu..................................................................................... 2-8 Main Menu Functions .................................................................. 2-9 Using Additional Tools................................................................ 2-11 Station Communication .............................................................. 2-12 Verifying Communication ......................................................... 2-12 Device Status.............................................................................. 2-13 Metho…

Text truncated - open the document above for the full version.

Pyxis Corporation JIT RBUD Wireless Supply Management System FCC ID#: PQIXMTR2BTN Photo One Front Control Panel

Pyxis Corporation JIT RBUD Wireless Supply Management System FCC ID#: PQIXMTR2BTN Photo Two Side Panel of case shows the location of the ID Label. This location of the package is required due to the adhesive glue that will be used on the back of the case to attached the RF Module to the product utilizing its application.

2.00 .40 109688-01 ASSY, TRANSMITTER 315/434 MHz, CHANNEL "A" FCC ID: PQI-XMTR2BTN IC:4339A-XMTR2BTN 3 4 6 B EC NO.DATEAPPROVED REVISIONS REVDESCRIPTION OF REV DWG NO SHEET SIZE SCALE: DATEAPPROVALS DRAWN ISSUED CHECKED DO NOT SCALE DRAWING FINISH MATERIAL PSAN DIEGO, CA TM XYIS ANGLES TOLERANCES ARE: .XX = ±.030 .XXX = ± .X = ± DECIMALS FRACTIONS UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES .XXXX = ± ± ± 1/16" AUTHORIZED IN WRITING BY PYXIS CORPORATION. NOTICE OF PROPRIETARY RIGHTS IN DATA EXCEPT AS IS SPECIFICALLY DISCLOSURED, MADE AVAILABLE DUPLICATED, TRANSFERRED, PROPRIETARY TO PYXIS CORP. THE DATA CONTAINED HEREIN IS THIS DATA SHALL NOT BE PARTY FOR ANY PURPOSE TO OR USED BY ANY THIRD DTH 7/22/02 SEE NOTE 6 NONE 2:1 1 110144-01 LABEL, FCC ID,XMTR,JB,CH A 02 01 PROTOTYPE RELEASE 7/23/02 DTH XXXX 1 NOTES: (UNLESS OTHERWISE SPECIFIED) 1. INTERPRET DRAWING PER ASME Y14.5M-1994. 2. BACKGROUND COLOR: WHITE. BORDER AND TEXT COLOR: BLACK. 3 FONT: ARIAL, .07 HIGH. 4 APPLY NPL PERMANENT ADHESIVE FAR SIDE. 5. MATERIAL SHALL BE .002 WHITE POLYPROPYLENE. 6 IDENTIFY PART WITH PYXIS PART NUMBER, NEAR SIDE, APPROX. WHERE SHOWN, USING ARIAL FONT, .030 HIGH. 02CHANGE TEXT 7/30/02 DTH XXXX

Pyxis Corporation JIT RBUD Wireless Supply Management System FCC ID#: PQIXMTR2BTN Photo Three Open for Inspection Pyxis Corporation JIT RBUD Wireless Supply Management System FCC ID#: PQIXMTR2BTN Photo Four Close Up of Single PCB with Battery in Place Pyxis Corporation JIT RBUD Wireless Supply Management System FCC ID#: PQIXMTR2BTN Photo Five Flip side of PCB showing adhesive membrane label on and off of the PCB Pyxis Corporation JIT RBUD Wireless Supply Management System FCC ID#: PQIXMTR2BTN Photo Six Close up of PCB showing PCB Antenna Layout

L.S. Compliance, Inc. W66 N220 Commerce Court Cedarburg, WI 53012 262-375-4400 Fax: 262-375-4248 Compliance Testing of the Pyxis Transmitter Prepared For: David Heffron Pyxis Corporation 3750 Torrey View Court San Diego, CA 92130 Test Report Number: 302306TX Test Dates: July 24 th and 30 th , 2002 All results of this report relate only to the items that were tested. This report may not be reproduced, except in full, without written approval of L.S. Compliance, Inc. ________________________________________________________________________ FCC I.D. Page 2 of 23 L.S. Compliance, Inc. Prepared For: David Heffron, Pyxis Corporation Test Report Number: 302306TX Table of Contents Section Description Type of Test Page # Index 2 1 L. S. Compliance in Review 3 2 A2LA Certificate of Accreditation 4 3 A2LA Scope of Accreditation 5 4 Validation Letter- U.S. Competent Body for EMC Directive 89/336/EEC 6 5 Signature Page 7 6 Product General Information 8 7 Introduction 8 8 Purpose 8 9 Product Description 9 10 Test Requirements 9 11 Summary of Test Report 9 12 Radiated Emission Test 10-20 Appendices A Calculations 21-22 B Test Equipment List 23 ________________________________________________________________________ FCC I.D. Page 3 of 23 L.S. Compliance, Inc. Prepared For: David Heffron, Pyxis Corporation Test Report Number: 302306TX 1. L.S. Compliance in Review L. S. Compliance, Inc. is located in Cedarburg, Wisconsin ñ United States. We may be contacted by: Mail: L. S. Compliance, Inc. W66 N220 Commerce Court Cedarburg, Wisconsin 53102 Phone: 262-375-4400 Fax: 262-375-4248 E-Mail: [email protected] As an EMC testing laboratory, our accreditation and assessments are recognized through the following: A2LA ñ American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025: 2001 With electrical (EMC) Scope of Accreditation A2LA Certificate Number: 1255.01 U.S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U.S. conformity assessment Body operating under the U.S./EU, Mutual Recognition Agreement (MRA) operating under the European Union EMC Directive 89/336/EEC, Article 10.2 Date of Validation: January 16, 2001 Federal Communications Commission (FCC) ñ USA Listing of 3 Meter Semi-Anechoic Chamber based on 47CFR 2.948 FCC Registration Number: 90756 Listing of 3 and 10 Meter OATS based on 47CFR 2.948 FCC Registration Number: 90757 Industry Canada On-file, 3 Meter Semi-Anechoic Chamber based on 47CFR 2.948 File Number: IC 3088 On-file 3 and 10 meter OATS based on RSS-210 File Number: IC 3088-A ________________________________________________________________________ FCC I.D. Page 4 of 23 L.S. Compliance, Inc. Prepared For: David Heffron, Pyxis Corporation Test Report Number: 302306TX 2. A2LA Certificate of Accreditation ________________________________________________________________________ FCC I.D. Page 5 of 23 L.S. Compliance, Inc. Prepared For: David Heffron, Pyxis Corporation Test Report Number: 302306TX 3. A2LA Scope of Accreditation ________________________________________________________________________ FCC I.D. Page 6 of 23 L.S. Compliance, Inc. Prepared For: David Heffron, Pyxis Corporation Test Report Number: 302306TX 4. Validation Letter ñ U.S. Competent Body for EMC Directive 89/336/EEC ________________________________________________________________________ FCC I.D. Page 7 of 23 L.S. Compliance, Inc. Prepared For: David Heffron, Pyxis Corporation Test Report Number: 302306TX 5. Signature Page August 30, 2002 Prepared By: ________________________________________________________ Teresa A. White, Document Coordinator Date August 30, 2002 Tested By: ________________________________________________________ Michael Stone, EMC Technician Date August 30, 2002 Tested By: ________________________________________________________ Abtin Spantman, EMC Engineer Date August 30, 2002 Approved By: ________________________________________________________ Kenneth L. Boston, EMC Lab Manager Date PE #31926 Licensed Professional Engineer Registered in the State of Wisconsin, United States ________________________________________________________________________ FCC I.D. Page 8 of 23 L.S. Compliance, Inc. Prepared For: David Heffron, Pyxis Corporation Test Report Number: 302306TX 6. Product and General Information Pyxis Corporation JITrBud Transmitter, Model 109699-02, Rev 1 (315MHz)S/N:124, (434MHz)S/N:101 315 MHz and 434 MHz Manufacturer: Model Number: Serial Number: Frequency Range: Test Voltage: 3.0 VDC Environmental Conditions in the Test Lab : Temperature: 20-25◦ C Atmospheric Pressure: 30-60% Humidity: 86kPa-106kPa 7. Introduction On July 24 th , and 30 th 2002, a series of Radiated Emissions tests were performed on two samples of the Pyxis transmitter, Serial Numbers 101 and 124. This product operates by means of RF transmission of short burst of data containing a command code, with a redundant format, on two separate frequency bands. The transmitter serial number 101 was configured to operate at 434 MHz, and the transmitter serial number 124 was configured to operate at 315 MHz. These tests were performed using the test procedure outlined in ANSI C63.4, 2001 for intentional radiators, and in accordance with the limits set forth in FCC Part 15.231, for a periodic operation of a low power transmitter. 8. Purpose The above-mentioned tests were performed in order to determine the compliance of the equipment under test (EUT), with limits contained in various provisions of Title 47CFR, FCC Part 15, including: 15.205, 15.209, 15.231a, 15.231b, and 15.231c. All radiated emission tests were performed to measure the emissions in the frequency bands described in section 12i of this report, and to determine whether said emissions are below the limits established by the aforementioned standards. These tests were performed in accordance with the procedures described in the American National Standard for methods of measurements of Radio-Noise Emissions from Low-Voltage Elect…

Text truncated - open the document above for the full version.

________________________________________________________________________ FCC I.D. Page 12 of 23 L.S. Compliance, Inc. Prepared For: David Heffron, Pyxis Corporation Test Report Number: 302306TX 12f. Photo of Setup for Radiated Emissions Test EUT placed in horizontal orientation inside the 3 Meter Semi-Anechoic Chamber
