PRURENG2Energy Saving Lamp

Page 1 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 EXHIBIT 5 User’s Manual CAUTIONS AND INSTRUCTION 1. Use only on 110-120V, 60Hz. 2. Never disassemble or modify the lamp. 3. To prevent risk of fire, never install this device in the following fixtures: a. Fixture on dimming circuits. b. Emergency exit lights powered by direct current (DC). 4. To avoid risk of electronic shock----use only in dry locations. 5. This product may cause interference to the radio equipment and should no be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30MHz. 6. This product may produce interference when using a T.V., radio or a wireless remote control. If interference should occur, move the lamp away form such equipment three feet or more, otherwise, plug the lamp or the receiver into a different outlet. 7. To prevent burns and avoid electric shock, please do not touch the bulb or cap during operation or immediately after switching off. 8. COMPLIANCE INFORMATION STATEMENT Product Name: Energy Saving Lamp Model Number: 70405, 70409, 70413, 50205, 50209, 70315, 70320, 80109(A), 80205(A) Statement: This device complies with part 18 of FCC Rules operation is subject to the following two conditions: 1) This device may not cause harmful interference. Page 2 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG 2) This device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This product may cause interference to the radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30MHz. Page 2 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG

Page 1 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 EXHIBIT 2 FCC ID Label Info Figure 1 M/N: 704 Series General Appearance and Label Location Figure 2 M/N: 502 Series General Appearance and Label Location FCC ID PRURENG2 Page 2 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 FCC ID PRURENG2 Figure 3 M/N: 80109(A) General Appearance and Label Location Figure 4 M/N: 80205(A) General Appearance and Label Location FCC ID PRURENG2 FCC ID PRURENG2 Page 3 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 Figure 5 Label Page 3 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2

Page 1 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 EXHIBIT 2 FCC ID Label Info Figure 1 M/N: 704 Series General Appearance and Label Location Figure 2 M/N: 502 Series General Appearance and Label Location FCC ID PRURENG2 Page 2 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 FCC ID PRURENG2 Figure 3 M/N: 80109(A) General Appearance and Label Location Figure 4 M/N: 80205(A) General Appearance and Label Location FCC ID PRURENG2 FCC ID PRURENG2 Page 3 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2

Page 1 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 EXHIBIT 2 Internal Photographs Figure 1 Main Board, Component Side Figure 2 Main Board, Soldered Side Page 2 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 70315, 70320 70315, 70320 80109(A) 80109(A) 70405, 70409 70413, 50205, 50209, 80205(A) 70405, 70409 70413, 50205, 50209, 80205(A)

Page 1 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 EXHIBIT 3 Circuit Diagram (FOR 70405, 70409, 70413, 50205, 50209, 80109(A), 80205(A)) (FOR 70315, 70320) Page 2 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2

Page 1 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 EXHIBIT 4 Te s t R e p o r t APPLICATION FOR CERTIFICATION On Behalf of Ningbo Global Lamp Co., Ltd. Energy Saving Lamp Model Number : 70405, 70409, 70413, 70315, 70320 50205, 50209, 80109(A), 80205(A) Prepared for : Ningbo Global Lamp Co., Ltd. All 24 th F1 181 Zhongshan E Rd Ningbo Zhejiang China Prepared by : Shenzhen Most Technology Co., Ltd C-13B,Shennan Gardon Nanshan Zone Shenzhen Guangdong China Telephone : (0755)26506933 Report Number : SMT-F32002 Date of Test : July 30, 2002 Date of Report : August 27-29, 2002 Page 2 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 TABLE OF CONTENTS Description Page FCC Test Report for Declaration of Conformity 1. GENERAL INFORMATION....................................................................................................... 5 1.1. Description of Device (EUT) ...................................................................................................................... 5 1.2. Test Facility ............................................................................................................................................ 6 1.3. Test Uncertainty ......................................................................................................................................... 6 2. POWER LINE CONDUCTED EMISSION TEST..................................................................... 7 2.1. Test Equipment........................................................................................................................................... 7 2.2. Block Diagram of Test Setup ..................................................................................................................... 7 2.3. Power Line Conducted Emission Test Limits............................................................................................. 7 2.4. Configuration of EUT on Test.................................................................................................................... 7 2.5. Operating Condition of EUT ...................................................................................................................... 8 2.6. Test Procedure ............................................................................................................................................ 8 2.7. Power Line Conducted Emission Test Results ........................................................................................... 8 3. MODIFICATION TO TEST SPECIFICATIONS ................................................................... 12 4. PHOTOGRAPH........................................................................................................................... 13 4.1. Photo of Power Line Conducted Emission Test ....................................................................................... 13 4.2. Photo of Radiated Emission Test (In Anechoic Chamber)........................................................................ 13 APPENDIX I (6 pages) Page 3 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 Page 4 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 1. GENERAL INFORMATION 1.1. Description of Device (EUT) Description : Energy Saving Lamp Model Number : 70405, 70409, 70413, 70315, 70320 50205, 50209, 80109(A), 80205(A) The 50205,80205(A),70405 are the same just the lamp-chimney is different. The 50209, 70409 are the same just the lamp-chimney is different. Applicant : Ningbo Global Lamp Co., Ltd. All 24 th F1 181 Zhongshan E Rd Ningbo Zhejiang China Manufacturer : Ningbo Global Lamp Co., Ltd. All 24 th F1 181 Zhongshan E Rd Ningbo Zhejiang China Date of Test : July 30, 2002 Page 5 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 1.2. Test Facility Site Description 3m Anechoic Chamber : Certificated by FCC, USA Aug. 24, 2000 3m & 10m Open Site : Certificated by FCC, USA Feb. 13, 1998 EMC Lab. : Certificated by VCCI, Japan Oct. 29, 1998 Certificated by DATech, German Feb. 02, 1999 Certificated by NVLAP, USA until Mar. 03, 2001 NVLAP Code: 200372-0 Certificated by DNV, Norway May 26, 1999 Name of Firm : Audix Technology (Shenzhen) Co., Ltd. Site Location : No. 6, Ke Feng Rd., 52 Block, Shenzhen Science & Industrial Park, Nantou, Shenzhen, Guangdong, P.R China 1.3. Test Uncertainty Conducted Emission Uncertainty = ±2.66dB Radiated Emission Uncertainty = ±4.26dB Page 6 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 : 2. POWER LINE CONDUCTED EMISSION TEST 2.1 Test Equipment The following test equipments are used during the power line conducted emission test: Item Equipment Manufacturer Model No. Serial No. Last Cal. Cal. Interval 1. Test Receiver Rohde & Schwarz ESHS20 836600/006 Jun. 04, 02 1 Year 2. L.I.S.N. Kyoritsu KNW-407 8-541-4 Jun. 04, 02 1 Year 3. Terminator EMCO 50Ω No. 1 Jun. 04, 02 1 Year 4. Terminator EMCO 50Ω No. 2 Jun. 04, 02 1 Year 5. RF Cable FUJIKURA RG-55/U LISN Cable Feb 28, 02 1/2 Year 6. Passive Probe Rohde & Schwarz ESH-Z3 299.7810.52 Jun. 04, 02 1 Year 7. Coaxial Switch Anritsu MP59B M73989 Feb.28, 02 1/2 Year 2.2 Block Diagram of Test Setup Block diagram of connection between the EUT and simulators (EUT: Saving Lamp) 2.3 Power Line Conducted Emission Test Limits Maximum RF Line Voltage Frequency MHz dB( μ V) 0.45 ~ 2.51 48 2.51 ~ 3.0 70 3.0 ~ 30 48 2.4 Configuration of EUT on Test The following equipment are installed on Power Line Conducted Emission Test to meet the commission requirement and operating regulations in a manner which tends to maximize its emission characteristics in a normal application. 2.4.1 Saving Lamp (EUT) Model Number : 70405, 70409, 70413, 70315, 70320 50205, 50209, 80109(A), 80205(A) Manufacturer : Ningbo Global Lamp Co., Ltd. All 24 th F1 181 Zhongshan E Rd Ningbo Zhejiang China AC Mains EUT L.I.S.N. Receiver Page 7 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 2.5 Operating Condit…

Text truncated - open the document above for the full version.

Page 1 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2 Setup SETUP PHOTOGRAPH 1.1. Photo of Power Line Conducted Emission Test Page 2 Ningbo Global Lamp Co., Ltd. Energy Saving Lamp FCC ID: PRURENG2
