OBLONG ULTRASONIC WAND USER MANUAL Version 1.4 2012-10-25 Oblong Industries, Inc. 923 E 3rd St, Unit 111 Los Angeles, CA 90013 +1 213 683 8863 http://oblong.com Table of Contents General information 3 Scope 3 FCC Compliance Statement 3 Safety warnings 4 Copyright 4 Patents pending 4 Introduction 5 Ultrasonic wand 5 Mezzanine 5 Wand operation 6 Control basics 6 Powering the wand 6 Wand components 6 Wand components diagram 7 Wand motion gestures 8 Wand power management tips 9 Performance tips 10 Wand specifications 11 General information Scope This manual describes operation and specifications for the following two products: Oblong 900MHz Wand Model No. 0000422 Contains FCC ID: TK5-900MOD Oblong 2.4GHz Wand Model No. 0000054 FCC ID: PUQ-0000054 FCC Compliance Statement This equipment has been tested and found to comply with the limits for a class B digital device,pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protectionagainst harmful interference in a residential installation. This equipment generates, uses and canradiate radio frequency energy and if not installed and used in accordance with the instructions,may cause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver isconnected. • Consult the dealer or an experienced radio/TV technician for help. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment. Safety warnings • There are no user-serviceable components in the wand. Please do not open the wand cases for any reason. • Use only the chargers provided by Oblong to recharge the wands. These chargers use power-management techniques specific to the wand batteries. Other chargers do not charge the wands properly and could cause a battery explosion. Never attempt to replace the battery yourself; contact Oblong should this become necessary. • The wands are intended for indoor use only, at typical room temperatures (15-30C). Do not use in unusually moist, hot, or cold conditions. • Moisture can damage the wands’ microphones and internal circuitry, resulting in failure or battery damage. If a wand is exposed to spilled liquids, please contact Oblong immediately. • The wand may contain small parts or materials not suitable for children. • Avoid trapping dirt in the microphones. • To clean a wand, wipe it with a slightly damp cloth while avoiding the microphones. Copyright This document © 2012 Oblong Industries, Inc. Patents pending Introduction Ultrasonic wand The Oblong ultrasonic wand is a new type of input device uniquely suited to support multi- user, multi-screen, interaction. The ultrasonic wand is a hybrid ultrasonic and inertial tracking device. It must be used in an environment with fixed ultrasonic emitters; these emitters produce distinct pulses that are detected by four ultrasonic sensors on the body of the wand. The wand also contains an “inertial measurement unit” that provides information on the wand’s orientation and motion, and a button press detection circuit. The wand continually sends these data to Mezzanine using radio frequency (RF) signals. Mezzanine then computes the wand’s position and orientation in the room and animates interface elements in response. The wand can be used either as a traditional pointing device, or as a gestural input device, allowing fluid and complex maneuvers to be executed simply. Both the pointing and gestural inputs are enhanced and modified by a single button on the wand to control all application functionality. There are three buttons on the wand, one on each of the three sides of the device, but they are functionally equivalent. Mezzanine Oblong’s Mezzanine product is a multi-user, multi-screen, multi-device collaborative environment. The ultrasonic wand is the main control device for Mezzanine. Mezzanine software operation and features are not covered by this document. Wand operation Control basics The wand has a distinctive, triangular shape. Each of the three sides has a similar appearance, and one should be positioned upwards while using the wand. You can pick up a wand resting on a table or accept a wand handed to you without concern for which side faces upwards. All three of the control buttons perform an identical function, but the topmost button should be easiest to press. Pressing two or three buttons simultaneously has the same effect as pressing a single button. Powering the wand Press the power button once to power on the wand, and press it again to turn power off. The power indicator illuminates when the wand is on. After the wand is powered, it may take up to 5 seconds for the RF link to be established. During this time, the wand cursor is not visible on the screen. In some circumstances, it may take another 10 seconds for the wand’s initial position to be computed. During this period it is best to keep the wand motionless and the microphones unoccluded. Wand components power LED ( ) • on when wand is powered • off if wand is unpowered, battery is dead, or hardware failure has occurred RF link LED ( ) • on when wireless communication is continuous • off or flickering when wireless is dropped due to range, interference, or an unpowered tracking system • flashes during startup and setup operations battery LED ( ) • on when powered and server software pipeline is active • flashes to indicate remaining charge during startup power button • turns…
Text truncated - open the document above for the full version.
Report Number: B20508D2 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report 2.4 GHz Wand Model: 0000054 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15 SUBPART B and C TEST REPORT for 2.4 GHZ WAND MODEL: 0000054 Prepared for OBLONG INDUSTRIES, INC. 923 EAST THIRD STREET, UNIT 111 LOS ANGELES, CALIFORNIA 90013 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: OCTOBER 16, 2012 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 13 31 66 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B20508D2 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report 2.4 GHz Wand Model: 0000054 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – Emissions 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 Emissions Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 6.3 Facility Environmental Characteristics 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Conducted Emissions Test 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 13 7.1.3 RF Emissions Test Results 15 8. CONCLUSIONS 16 Report Number: B20508D2 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report 2.4 GHz Wand Model: 0000054 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagram, Charts, and Photos Test Setup Diagram Antenna and Amplifier Factors Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site Report Number: B20508D2 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report 2.4 GHz Wand Model: 0000054 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: 2.4 GHz Wand Model: 0000054 S/N: 1112070 Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Customer: Oblong Industries, Inc. 923 East Third Street, Unit 111 Los Angeles, California 90013 Test Date(s): May 7 and 8, 2012 Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B and Subpart C, Sections 15.205, 15.209, and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power. 2 Radiated RF Emissions 10 kHz to 25000 MHz (Transmitter and Digital Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B20508D2 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report 2.4 GHz Wand Model: 0000054 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the emissions tests performed on the 2.4 GHz Wand, Model: 0000054 (EUT). The Emissions measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 4…
Text truncated - open the document above for the full version.
114 Olinda Drive · Brea, California · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | - |
