PVM-VTITHBJ9040TireHawk TPMS Kit

for phones TPMS Kit Kit TPMS Kit Smart Way of Watching Tires Quick Installation Guid e 15.105 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 15.19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 15.21 FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

RF_160, Issue 03 Declaration of Authorization We Name: Visionware Technology Inc. Address: 4F-7, No. 77, Sec. 2, Keelung Rd., Xinyi Dist., City: Taipei, Country: Taiwan, R.O.C. Declare that: Name Representative of agent: Daphne Liang Agent Company name: Compliance Certification Services Inc. Address: No.8, Jiucengling, Xinhua Dist., City: Tainan City 712, Country Taiwan, R.O.C is authorized to apply for Certification of the following product(s): Product description: TireHawk TPMS Kit Type designation: TB-X04C; TB-X02B；TB-X02C；TB-X04B； TP-X00B；TP-X00C Trademark: on our behalf. Date:2012-12-03 Signature: ... ............................ Name/Title: Daniel Lin / General Manager Company Name: Visionware Technology Inc. Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Visionware Technology Inc. Address : 4F-7, No. 77, Sec. 2, Keelung Rd., Xinyi Dist., City: Taipei, Country: Taiwan To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: PVM-VTITHBJ9040 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2012.12.03 Name and signature of applicant: Daniel Lin Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

DECLARATION OF CONFORMITY (DoC) Equipment: TireHawk TPMS Kit Trademark(s) and Model(s): / TB-X04C ; TB-X02B；TB-X02C；TB-X04B；TP-X00B；TP-X00C Manufacturer: JOSN Electronic Co., Ltd. FCC ID in case other parts of this equipment are subject to certification: PVM-VTITHBK9040 / PVM-VTITHBJ904 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The following test reports are subject to this declaration: Test report number:Issue date: T120809L08-D October 30, 2012 Company name: Visionware Technology Inc. Name/Title (legal representative): Daniel Lin / General Manager Address: 4F-7, No. 77, Sec. 2, Keelung Rd., Xinyi Dist., Taipei, Taiwan, R.O.C. Phone: + 886-2-2733-0277 Fax: + 886-2-2733-3306 E-mail: [email protected] Date: 2012-12-05 Signature:

Report No.T120809L08 Page 1 of 8 External Photo Report No.T120809L08 Page 2 of 8 Report No.T120809L08 Page 3 of 8 1 USB Car Charge Report No.T120809L08 Page 4 of 8 Report No.T120809L08 Page 5 of 8 Report No.T120809L08 Page 6 of 8 USB Cable Report No.T120809L08 Page 7 of 8 Report No.T120809L08 Page 8 of 8

Report No.T120809L08 Page 1 of 2 Internal Photo Report No.T120809L08 Page 2 of 2

FCC ID：PVM VTITHBJ9040 Report No.：T120809L08 RP1 1 Page 1 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. FCC 47 CFR PART 15 SUBPART C AND ANSI C63.4:2003 TEST REPORT For TireHawk TPMS Kit Model : TB-X04C Data Applies To : TB-X02B； ；； ；TB-X02C； ；； ；TB-X04B； ；； ； TP-X00B； ；； ；TP-X00C Trade Name : VISIONWARE Issued for Visionware Technology Inc. 4F-7, No. 77, Sec. 2, Keelung Rd., Xinyi Dist., Taipei, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. No.11, Wu-Gong 6th Rd., Wugu Industrial Park, New Taipei City 248, Taiwan (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: October 26, 2012 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF or any government agencies. The test results of this report relate only to the tested sample identified in this report. FCC ID：PVM VTITHBJ9040 Report No.：T120809L08 RP1 1 Page 2 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 10/26/2012 Initial Issue All Page 25 Rubeca yu FCC ID：PVM VTITHBJ9040 Report No.：T120809L08 RP1 1 Page 3 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION................................................................................4 2. EUT DESCRIPTION.....................................................................................................5 3. DESCRIPTION OF TEST MODES...............................................................................6 4. TEST METHODOLOGY...............................................................................................6 5. FACILITIES AND ACCREDITATION...........................................................................7 5.1 FACILITIES ............................................................................................................7 5.2 EQUIPMENT..........................................................................................................7 5.3 TABLE OF ACCREDITATIONS AND LISTINGS....................................................7 5.4 MEASUREMENT UNCERTAINTY.........................................................................8 6. SETUP OF EQUIPMENT UNDER TEST......................................................................9 7. FCC PART 15.231 REQUIREMENTS..........................................................................10 7.1 20dB BANDWIDTH ................................................................................................10 12 7.2 LIMIT OF TRANSMISSION TIME ..........................................................................13 15 7.3 RADIATED EMISSION...........................................................................................16 21 7.4 CONDUCTED EMISSION......................................................................................22 24 APPENDIX SETUP PHOTOS ..........................................................................................25 FCC ID：PVM VTITHBJ9040 Report No.：T120809L08 RP1 1 Page 4 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 1. TEST REPORT CERTIFICATION Applicant ： ：： ： Visionware Technology Inc. Address ： ：： ： 4F 7, No. 77, Sec. 2, Keelung Rd., Xinyi Dist., Taipei, Taiwan, R.O.C. Manufacturer ： ：： ： JOSN Electronic Co., Ltd. Manufacturer Address ： ：： ： 9F 5, No. 4, Ln. 609, Sec. 5, Chongxin Rd., Sanchong Dist., New Taipei City, 241, Taiwan Equipment Under Test ： ：： ： TireHawk TPMS Kit Model ： ：： ： TB X04C Data Applies To ： ：： ： TB X02B ； TB X02C ； TB X04B ； TP X00B ； TP X00C Trade Name ： ：： ： VISIONWARE Tested Date ： ：： ： August 09 ~ October 23, 2012 APPLICABLE STANDARD Standard Test Result FCC Part 15 Subpart C AND ANSI C63.4:2003 PASS WE HEREBY CERTIFY THAT: The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Miller Lee Gina Lo Section Manager Section Manager FCC ID：PVM VTITHBJ9040 Report No.：T120809L08 RP1 1 Page 5 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 2. EUT DESCRIPTION Product Name TireHawk TPMS Kit Model Number TB X04C Data Applies To TB X02B；TB X02C；TB X04B；TP X00B；TP X00C Identify Number T120809L08 Received Date August 09, 2012 Frequency Range 433.92MHz Transmit Power 64.13dBuV Channel Spacing 1 Channel Type of Modulation ASK Antenna Type External Tire Sensor (433.92MHz) : Printed Antenna, Antenna Gain 15.02 dBi Power Rating Wireless Repeater : 5Vdc (From car charger) External Tire Sensor : 3Vdc (From battery) Test Voltage 12Vdc, 3Vdc I/O Port USB Port × 1, Mini USB Port × 1 Signal Cable Shielded USB cable 1m × 1 Non shielded telescopic USB cable 0.6m × 1 Car Charger : No. Manufacturer Model No. Power Input Power Output 1 SEMDICAR IC USB A 12Vdc 5Vdc The difference of the series model : Product Series Model Number Difference Bright + TB X02B Bright + TB X02C Bright + TB X04B Bright + TB X04C Power + TP X00B TireHawk TPMS Kit Power + TP X00C Firmware Remark : 1. For more details, please refer to the User’s manual of the EUT. 2. This submittal(…

Text truncated - open the document above for the full version.

FCC IDPVM-VTITHBJ9040 Report No.T120809L08-RP1-1 Page 25 / 25 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. APPENDIX SETUP PHOTOS RADIATED EMISSION SETUP
