PVU-IMYSC21Bluetooth keyboard

Interface: DC-OUT DC-IN DC-IN OFF ON OFF DC-OUT SWITCH BT SWITCH Keyboard Specification :Battery Lithium PolymerCapacity : 3000mAHWorking Current : 2.5mASleeping Current : 600μADC-in : 5V 1.0ADC-out : 5V 1.6ASize : 247 x 195 x 24 mmWeight : 620g Features:-2.4G Bluetooth connection-Support iPad function keys-Protect iPad with clamshell-Convenience keyboard design-Large capacity battery as PowerBankPacking Contents :-Bluetooth keyboard-USB charging cable-User manual How to use? -Turn on Bluetooth on your iPad Select Settings>General>Bluetooth>On-Turn on the Bluetooth keyboard by sliding the power switch The Bluetooth indicator light will be on 5 seconds then go off. -Press the connect button. The Bluetooth indicator light will be blinking The keyboard is now ready to be connected -“Bluetooth keyboard for iPad” will show on your iPad screen as an Available Bluetooth device-Select “Bluetooth keyboard for iPad” and a four-digit code will show.-Type the four-digit code by the Bluetooth keyboard and press Enter-Your keyboard and iPad should automatically connect Bluetooth Keyboard User Manual ON O I O I CONNECT DC-OUT Federal Communication Commission Interference Statement This Equipment has been tested and found to comply with the limits for a Class B digital device. Pursuant to Part 15 of the FCC Rules, these limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if no installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution : Any change or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. iPad is trademarks of Apple Inc.

EMAY TECHNOLOGY COMPANY LIMITED FCC Confidentiality Request Number: CF303 Version: V01 Date: 01-02-2010 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name EMAY TECHNOLOGY COMPANY LIMITED Addresss 2907, Huafeng Bld, 6006 Shennan mid Rd, Futian District, City Shenzhen Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: PVU -IMYSC21 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) Operational Description Block Diagrams Schematics Diagrams Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation:

General Appearance of the EUT

Label Sample This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.

FCC RF Exposure Calculation EUT Description: Bluetooth Keyboard FCC ID: PVU-IMYSC21 Frequency: 2402-2480 MHz (79 channels) Modulation: FHSS (GFSK) Mid-Channel: 2.441 GHz (channel 39) Mid-Channel Peak Power, Conducted: -9.50 dBm == 0.113 mW Antenna Gain: G = 2.78 dBi Calculation: Limit = 60/2.441 = 24.58 mW P radiated, max = P conducted, dBm + G dBi = -9.50 dBm + 2.78 dBi == -6.72 dBm = 0.21 mW Conclusion: The emitted power appears to be (far) below the required limit, so PASS. Doc. No. A8145

DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120817017E FCC ID: PVU-IMYSC21 DATE: 09/10/2012 Page 1 of 39 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Bluetooth keyboard MODEL No.: IMY-SC21, IMY-SC22, IMY-SC23, IMY-SC24, IMY-SC25, IMY-SC26, IMY-SC27, IMY-SC28 BRAND NAME: EMAY FCC ID: PVU-IMYSC21 REPORT NO: KAD120817017E ISSUE DATE: September 10, 2012 Prepared for EMAY TECHNOLOGY COMPANY LIMITED 2907, Huafeng Bld, 6006 Shennan mid Rd, Futian District, Shenzhen, China Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120817017E FCC ID: PVU-IMYSC21 DATE: 09/10/2012 Page 2 of 39 VERIFICATION OF COMPLIANCE Applicant: EMAY TECHNOLOGY COMPANY LIMITED 2907, Huafeng Bld, 6006 Shennan mid Rd, Futian District, Shenzhen, China Manufacturer: EMAY TECHNOLOGY COMPANY LIMITED 2907, Huafeng Bld, 6006 Shennan mid Rd, Futian District, Shenzhen, China Product Description: Bluetooth keyboard Brand Name: EMAY Model Number: IMY-SC21, IMY-SC22, IMY-SC23, IMY-SC24, IMY-SC25, IMY-SC26, IMY-SC27, IMY-SC28 (Note: These samples are the same except appearance, battery capacity and model number, so we prepare IMY-SC21 for EMC test.) Serial Number: N/A File Number: KAD120817017E Date of Test: August 17, 2012 to September 10, 2012 We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247. The test results of this report relate only to the tested sample identified in this report. Approved By Sam Lv / Q.A. Manager DONGGUAN EMTEK CO., LTD. DONGGUAN EMTEK CO., LTD. REPORT NO:KAD120817017E FCC ID: PVU-IMYSC21 DATE: 09/10/2012 Page 3 of 39 Ta b l e o f C o n t e n t s 1. GENERAL INFORMATION ................................................................................................. 5 1.1 PRODUCT DESCRIPTION........................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) ..................................................................................................... 5 1.3 TEST METHODOLOGY.............................................................................................................................. 5 1.4 SPECIAL ACCESSORIES............................................................................................................................ 5 1.5 EQUIPMENT MODIFICATIONS.................................................................................................................. 5 1.6 TEST FACILITY........................................................................................................................................ 6 2. SYSTEM TEST CONFIGURATION .................................................................................... 7 2.1 EUT CONFIGURATION............................................................................................................................. 7 2.2 EUT EXERCISE........................................................................................................................................ 7 2.3 TEST PROCEDURE.................................................................................................................................... 7 2.4 LIMITATION............................................................................................................................................. 7 2.5 CONFIGURATION OF TESTED SYSTEM................................................................................................... 11 3. SUMMARY OF TEST RESULTS ....................................................................................... 12 4. DESCRIPTION OF TEST MODES .................................................................................... 12 5. RADIATED EMISSION TEST ............................................................................................ 13 5.1 MEASUREMENT PROCEDURE................................................................................................................. 13 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 14 5.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 15 5.4 MEASUREMENT RESULT........................................................................................................................ 15 5.5 RADIATED MEASUREMENT PHOTOS: ..................................................................................................... 21 6. CHANNEL SEPARATION TEST ....................................................................................... 22 6.1 MEASUREMENT PROCEDURE................................................................................................................. 22 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ....................................................................... 22 6.3 MEASUREMENT EQUIPMENT USED: ...................................................................................................... 22 6.4 MEASUREMENT RESULTS:..................................................................................................................... 22 7. 20DB BANDWIDTH TEST .................................................................................................. 25 7.1 MEASUREMENT PROCEDURE................................................................................................................. 25 7.2 TEST SET-UP (BLOCK DIA…

Text truncated - open the document above for the full version.

Setup Photos
