PW4FJ3668Energy Saving Lamp

U SER ’ S M ANUAL Federal Communication Commission Interference Statement This light device has been tested and found to comply with the limits for Consumer RF Lighting Device, pursuant to part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. 1. Use only on 120 volt, 60 hertz. 2. Never disassemble or modify-any changes could void the user’s authority to operate this device. 3. Not for use in totally enclosed fixtures. 4. Risk of electric shock-do not use where directly exposed to water. 5. This product could interference when used near a TV, radio, wireless remote control or maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30MHz. If interference should occur, move the lamp away from the appliance a distance of three feet or more. Or, plug the lamp or the appliance into a different outlet. 6. To prevent burns, do not touch the bulb during operation or immediately after switching off. 7. Not for use with dimmers, electronic timer or photocell devices or occupancy sensor.

F IGURE 1 E NERGY S AVING L AMP (M/N: LJ-24S) G ENERAL A PPEARANCE FIGURE 2 ENERGY SAVING LAMP (M/N: LJ-20S) GENERAL APPEARANCE F IGURE 3 E NERGY S AVING L AMP (M/N: LJ-18S) G ENERAL A PPEARANCE FIGURE 4 ENERGY SAVING LAMP (M/N: LJ-15S) GENERAL APPEARANCE

Label Drawing (Size of 2:1) PW4FJ3668 PW4FJ3668 PW4FJ3668 PW4FJ3668

Label Location Information Refer to the below red arrow: (for example)

F IGURE 1 E NERGY S AVING L AMP (M/N: LJ-24S) C OVER R EMOVED F IGURE 2 E NERGY S AVING L AMP (M/N: LJ-24S) M AIN B OARD (C OMPONENT S IDE ) FIGURE 3 ENERGY SAVING LAMP (M/N: LJ-24S) MAIN BOARD (SOLDERED SIDE) F IGURE 4 E NERGY S AVING L AMP (M/N: LJ-20S) C OVER R EMOVED F IGURE 5 E NERGY S AVING L AMP (M/N: LJ-20S) M AIN B OARD (C OMPONENT S IDE ) FIGURE 6 ENERGY SAVING LAMP (M/N: LJ-20S) MAIN BOARD (SOLDERED SIDE) F IGURE 7 E NERGY S AVING L AMP (M/N: LJ-18S) C OVER R EMOVED F IGURE 8 E NERGY S AVING L AMP (M/N: LJ-18S) M AIN B OARD (C OMPONENT S IDE ) FIGURE 9 ENERGY SAVING LAMP (M/N: LJ-18S) MAIN BOARD (SOLDERED SIDE) F IGURE 10 E NERGY S AVING L AMP (M/N: LJ-15S) C OVER R EMOVED F IGURE 11 E NERGY S AVING L AMP (M/N: LJ-15S) M AIN B OARD (C OMPONENT S IDE ) FIGURE 12 ENERGY SAVING LAMP (M/N: LJ-15S) MAIN BOARD (SOLDERED SIDE)

Schematics

Fujian Lijia Electrical Appliance Co., Ltd FCC ID:PW4FJ3668 Page 1 of 25 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01074 Application for FCC Certificate On Behalf of Fujian Lijia Electrical Appliance Co., Ltd Energy Saving Lamp Model No.: LJ-24S LJ-20S LJ-18S LJ-15S FCC ID : PW4FJ3668 Prepared For : Fujian Lijia Electrical Appliance Co., Ltd No.02 Section 1, Cangshan Hi-Tech Industrial Park Fuzhou, Fujian, China Prepared By : Audix Technology (Shanghai) Co., Ltd. 3 F 34 Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel: +8621-64955500 Fax: +8621-64955491 Report No. : ACI-F01074 Date of Test : Sept 12-15, 2001 Date of Report : Sept 21, 2001 Fujian Lijia Electrical Appliance Co., Ltd FCC ID:PW4FJ3668 Page 2 of 25 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01074 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test ........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 6 2.4 Test Configuration ...................................................................................................................... 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures........................................................................................................................... 7 2.7 Test Results................................................................................................................................. 8 3 FIELD STRENGTH TEST ........................................................................................................... 12 3.1 Test Equipment......................................................................................................................... 12 3.2 Block Diagram of Test Setup ................................................................................................... 12 3.3 Test Configuration .................................................................................................................... 12 3.4 Operating Condition of EUT .................................................................................................... 12 3.5 Test Procedure .......................................................................................................................... 13 3.6 Test Result ................................................................................................................................ 13 Fujian Lijia Electrical Appliance Co., Ltd FCC ID:PW4FJ3668 Page 3 of 25 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01074 TEST REPORT FOR FCC CERTIFICATE Applicant : Fujian Lijia Electrical Appliance Co., Ltd Manufacturer : Fujian Lijia Electrical Appliance Co., Ltd EUT Description : Energy Saving Lamp (A) Model No.: LJ-24S LJ-20S LJ-18S LJ-15S (B) Serial No.: E090703 E090702 E090704 E090701 (C) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2000) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Aug 14-18, 2001 Prepared by : Test Engineer : JEENY LUO (Assistant) SOLON GONG (Engineer) Reviewer : Approved Signatory : BYRON KWO (Supervisor) ALEX CHIU (Assistant Manager) Fujian Lijia Electrical Appliance Co., Ltd FCC ID:PW4FJ3668 Page 4 of 25 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01074 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Energy Saving Lamp Type of EUT : ; Production … Pre-product … Pro-type Model Number : LJ-24S, LJ-20S, LJ-18S, LJ-15S Applicant : Fujian Lijia Electrical Appliance Co., Ltd No.02 Section 1, Cangshan Hi-Tech Industrial Park Fuzhou, Fujian, China Manufacturer : Fujian Lijia Electrical Appliance Co., Ltd No.02 Section 1, Cangshan Hi-Tech Industrial Park Fuzhou, Fujian, China M/N A PPARENT P OWER (VA) R EAL P OWER (W) LJ-24S 44.6 24.0 LJ-20S 38.1 19.2 LJ-18S 32.1 17.0 LJ-15S 29.3 14.9 Fujian Lijia Electrical Appliance Co., Ltd FCC ID:PW4FJ3668 Page 5 of 25 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F01074 1.2 Description of Test Facility Site Description : Sept. 17, 1998 file on (Semi-Anechoic Chamber) Federal Communications Commission FCC Engineering Laboratory 7435 Oakl…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test 2. Field strength Test
