PWQGV-600Capture Card

FCC NOTICE NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal- lation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equip- ment. Such modifications could void the user's authority to operate the equipment. GV-600 Multi Channel Image Capture Board GV-600 Rev. 2.0 Supports NTSC/PAL video Supports image resolution up to 640X480 Max. 30 Frame image capture Total 16channel video input Watchdog function Product Overview The GV-600 is a complete solution for multi channel image capture on the PCI bus. The GV-600 takes advantage of the PCI-based system’s high bandwidth and inherent multimedia capacity. It is designed to be interoperable with any other PCI multimedia device. The GV-600 has all the video capture features of BT878 chip. The GV-600 simplifies the computer/ broadcast signal interface down to a single PCI connection. General Features * PCI Rev. 2.1 compliant * Support NTSC/PAL video * Max. 30frame image capture * Total 16channel video input * Watchdog function * 640X480, 320X240, 160X120 image resolution Functional Block Diagram Video VideoVideo Video Detector DetectorDetector Detector BT878 BT878BT878 BT878EEPROM EEPROMEEPROM EEPROM Connectors ConnectorsConnectors Connectors BNC BNCBNC BNC Ports PortsPorts Ports MUX MUXMUX MUX Detector DetectorDetector Detector WatchDog WatchDogWatchDog WatchDog PCI connector PCI connectorPCI connector PCI connector Video(5-16) Video(5-16)Video(5-16) Video(5-16) Video(1-4) Video(1-4)Video(1-4) Video(1-4) Reset ResetReset Reset PowerSignal PowerSignal PowerSignal PowerSignal Connectors ConnectorsConnectors Connectors Audio AudioAudio Audio GV-600 V2.00 GV-600 V2.00GV-600 V2.00 GV-600 V2.00 Copyright@2001 Geovision Ltd. All rights reserved. Applications * Digital Video Recorder * Image Capture System * Security System * Web Broadcast System * Video Conference System * Surveillance System Specification GV-600 Rev 2.0 Interface PCI connector, BNC x4, 5pin port x4, 40pin port, reset port x2 Resolution 640X480, 320X240, 160X120 Video Mode YUV 4:2:2, RGB 24bit Video Channel Full 16 channels Frame Rate Max. 30FPS Brightness Adjustable Hue Adjustable Saturation Adjustable Supplied Accessory 5pin connector, 40pin connector Dimention CAM5-8 CAM5-8CAM5-8 CAM5-8CAM9-12 CAM9-12CAM9-12 CAM9-12 CAM CAMCAM CAM 13-16 13-1613-16 13-16 CAM1-4 CAM1-4CAM1-4 CAM1-4OVERLAY OVERLAYOVERLAY OVERLAY BT878 BT878BT878 BT878 RESET RESETRESET RESET CAM1 CAM1 CAM1 CAM1 CAM2 CAM2 CAM2 CAM2 CAM3 CAM3 CAM3 CAM3 CAM4 CAM4 CAM4 CAM4 POWER POWERPOWER POWER SIGNAL SIGNALSIGNAL SIGNAL 150 150150 150 91 91 91 91 99 99 99 99 15 1515 1526 2626 2662.5 62.562.5 62.514.5 14.514.5 14.530 3030 30 2 22 2 6 6 6 6 18 18 18 18 18 18 18 18 18 18 18 18 23 23 23 23 18 18 18 18 13.5 13.513.5 13.5 20 20 20 20 7.5 7.57.5 7.5 AUDIO AUDIOAUDIO AUDIO 18 18 18 18 18 18 18 18 18 18 18 18 41 41 41 41 26 26 26 26 14 1414 14 18.4 18.418.4 18.4 2.2 2.22.2 2.22.2 2.22.2 2.2 18.4 18.418.4 18.4 121 121 121 121 Notice * Geovision reserves the right to change the circuitry and specifications without notice. Copyright@2001 Geovision Ltd. All rights reserved.

Korea Technology Institute Co., Ltd. Page 1 of 1 Label location

Korea Technology Institute Co., Ltd. Page 1 of 1 FCC ID Sample Label Model Number: GV-600 FCC ID : PWQGV-600 GEOVISION INC. Made in Taiw an This device complies w ith part 15 of the FCC Rules. Operation is subject to the follow ing tw o conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 1 of 5 External photo-Front KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 2 of 5 External photo-Rear KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 3 of 5 External photo-Connector KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 4 of 5 Accessories-Camera KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 5 of 5 Accessories-Adaptor

KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 1 of 13 Test Report Test Report No.:KTI01E-F0936 Registration No.:99058 Applicant:GEOVISION INC. Applicant Address:4F-1,No.298,Ruei-Guang Road,Nei-Hu,Taipei114Taiwan,R.O.C. Product:Capture Card FCC ID:PWQGV-600Model No.GV-600 Receipt No.:KTI20010816Date of receipt:Aug, 16, 2001 Date of Issue:Aug, 23, 2001 Testing location Korea Technology Institute Co., Ltd. 51-19, Sanglim3-Ri, Docheok-Myeun, Gwangju-Shi, Gyeungki-Do, Korea Test Standards:ANSI. C63.4 : 1992 Rule Parts:FCC Part 15, Subpart B Equipment Class:JBP Test Result:The above mentioned product has been tested and passed. Prepare by: J. H. LeeTested by: S. B. Kim/ EngineerApproved by: G. C. Min/ President Signature DateSignature DateSignature Date Other Aspects : Abbreviations : OK, Pass=passed Fail=failed N/A=not applicable ♠ This test report is not permitted to copy partly without our permission. ♠ This test result is dependent on only equipment to be used. ♠ This test result is based on a single evaluation of one sample of the above mentioned. ♠ This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. ♠ We certify this test report has been based on the measurement standards that is traceable to the national or international standards. KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 2 of 13  Contents  1. 2. 3. 4. 5. 6. Annex1 Annex2 Contents List of Tables List of Figures List of Photographs General Test Site 2.1 Location 2.2 List of Test and Measurement Instruments 2.3 Test Data 2.4 Test Environment Description of the tested samples 3.1 Rating and Physical characteristics 3.2 Submitted documents Measureme nt cond itio ns 4.1 Modes of operation 4.2 Additional equipments 4.3 Uncertainty 4.4 Test Setup Emission Test 5.1 Conducted Emissions 5.2 Radiated Emissions Photographs of the Test Set-up Label Photographs of EUT 2 2 2 3 3 3 4 4 4 5 5 5 6 6 6 6 6 7 8 8 9 11 13 14~16  List of Tables Table 1 List of test and measurement equipment Table 2 Test Data. Radiated Emissions  List of Photographs Photograph 1 Setup for Conducted Emissions Photograph 2 Setup for Radiated Emissions 4 10 11 12 Korea Technology Institute Co., Ltd. Page 3 of 13 KTI01E-F0936 FCC ID : PWQGV-600 1. General This equipment has been show n to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by Korea Technology Institute Co., LTD. And were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site Korea Technology Institute Co., LTD 2.1 Location 51-19, Sanglim3-Ri, Docheok-Myeun, Gwangju-Shi, Gyeungki-Do, Korea The Test Site is in compliance with ANSI C63.4/1992 for measurement of radio Interference. Korea Technology Institute Co., Ltd. Page 4 of 13 KTI01E-F0936 FCC ID : PWQGV-600 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment • Conducted Emissions Kind of Equipment Type S/N Calibrated until Spectrum Analyzer R3261C 61720427 11.2001 Field Strength Meter ESPC 832827/011 4.2002 LISN ESH3-Z5 8254601019 5.2002 LISN KNW407 8-1097-7 11.2001 Pulse limiter ESH3Z2 357.8810.52 11.2001 Conducted Cable N/ A N/ A 11.2001 • Radiated Emissions Kind of Equipment Type S/N Calibrated until Field Strength Meter ESPC 832827/011 11.2001 Spectrum Analyzer R3261C 61720427 11.2001 Pre Amplifier 8447D 2944A06874 11.2001 KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 5 of 13 KTI01E-F0936 FCC ID : PWQGV-600 3. Description of the tested samples The EUT is Capture Card. 3.1 Rating and Physical Characteristics Interface PCI connector, BNC×4,5pin port×4,40pin port, reset port×2 Resolution 640×480,320×240,160×120 Video Mode YUV 4:2:2,RGB 24bit Video Channel Full 16 channels Frame Rate Max. 30FPS Brig htness Adjustable Hue Adjustable Saturation Adjustable Supplied Accessory 5pin connector, 40pin connector 3.2 Submitted Documents User’s Guide Block Diagram KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 6 of 13 KTI01E-F0936 FCC ID : PWQGV-600 4. Measurement Conditions Testing Input Voltage: AC 220V. 4.1 Modes of Operation The EUT was in the following operation mode during all testing; 4.2 Additional Equipment DEVICE TYPE Manufacturer M/N S/N FCC ID PC COMPAQ COMPUTER CORPORATION Deskpro EXM 6F13JC8JN619 - Monitor Samsung Electronics 750S P223HVAR502035 - Keyboard COMPAQ COMPUTER CORPORATION KB-9963 B26960GBUKKOVW - Mouse logitech M-S48a None JNZ201213 Mouse SEJIN ELECTRON INC. SMB-400 0CIM004047 GJJS965M3 Printer Hewlett Packard C4569A SG78M1H0CF - Camera1 N/A N/A N/A - Camera2 N/A N/A N/A - Camera3 N/A N/A N/A KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 7 of 13 4.4 Test setup Computer Mouse_2 Keyboard Monitor Mouse_1 Printer camera1 POWER LINE camera2 c a m e r a 3 c a m e r a 4 KTI01E-F0936 FCC ID : PWQGV-600 Korea Technology Institute Co., Ltd. Page 8 of 13 5. EMISSION Test 5.1 Conducted Emissions Result : Pass The line-conducted facility is located inside a 2.3M x 3.5M x 5.5M shielded closure. The shielding effectiveness of the shielded room is in accordance with MIL-Std-285 or NSA 605-05. A 1m x 1.5m wooden table 80cm. High is placed 80cm away from the vertical wall and 1.5m away from the side wall of the shielded room. R&S Model ESH3-Z5(10kHz-30MHz) 50ohm/50 uH line-Impedance Stabilization Networks(LISN) are bonded to the shielded room. The EUT is powered from the R&S LISN and the support equipment is powered from the Kyoritsu LISN. Power to the LISN are filtered by a high-current high-insertion loss shield enclosures power line filters(100dB 14kHz-1Ghz). The purpose of the filter is to …

Text truncated - open the document above for the full version.

Korea Technology Institute Co., Ltd. Page 1 of 2 6. Photograph of the Test Set-Up Photograph 1 : Setup for radiated Emissions Korea Technology Institute Co., Ltd. Page 2 of 2 Photograph 2 : Setup for Conducted Emissions
