PWX-SL91GSM 900/1800/1900, UMTS Mobile Phone with BT

Table of Contents1 See also index at the end of this User Guide right page (1) of ONYX SL91 FCC am (11.09.2006, 12:00) BenQ 2006, Z:\SL91_ONYX\output\FUG\ ONYX_FCC_am_060911_te\F M\ONYX_FUGIVZ.fm Template: Minion, 140x105 mm, Version 2.0; VAR Language: am; VAR issue date: 060711 Legal notices ..................................... 3 Safety precautions ............................ 6 Antenna care ......................................8 Phone operation ................................8 Electronic devices ..............................9 Phone overview ............................... 12 Display symbols .............................. 16 Getting started ................................ 17 Inserting the SIM card ....................17 Inserting/removing the Micro SD card ..................................17 Inserting the battery ........................18 Charging the battery .......................19 Operating time and temperature ..............................20 Switching phone on/off, entering PIN ................................... 21 Offline mode ....................................22 Emergency number (SOS) .............22 General instructions ....................... 23 Standby mode ..................................23 Signal strength .................................23 Connectivity .....................................23 Digital Rights Mgmt. (DRM) .........24 User guide ........................................24 Main menu .......................................24 Tabs ...................................................25 Navigation key .................................25 Menu control .................................. 25 Standard functions ......................... 26 Security ........................................... 29 PIN codes ......................................... 29 Connecting to Windows® PCs ......... 30 Text entry ........................................ 31 Calling ............................................. 35 Video calls ....................................... 35 Settings during a call ...................... 36 Accepting a call ............................... 37 Rejecting a call ................................ 37 Handsfree talking ........................... 37 Swapping between 2 calls ................................................ 38 Conference ...................................... 39 Tone sequences (DTMF) ............... 41 Contacts .......................................... 43 Voice-activated dialling ................. 50 Call records ..................................... 51 Duration/charges ............................ 52 Camera ............................................ 54 Create message ................................ 58 SMS/MMS ....................................... 58 E-mail ............................................... 60 Inbox ............................................... 62 Message lists .................................... 69 Drafts ................................................ 69 Sent messages .................................. 69 Table of Contents See also index at the end of this User Guide 2Table of Contents See also index at the end of this User Guide BenQ 2006, Z:\SL91_ONYX\output\FUG\ ONYX_FCC_am_060911_te\F M\ONYX_FUGIVZ.fm left page (2) of ONYX SL91 FCC am, (11.09.2006, 12:00) Template: Minion, 140x105 mm, Version 2.0; VAR Language: am; VAR issue date: 060711 Message settings ............................. 70 SMS settings .....................................70 MMS settings ...................................72 E-mail settings .................................75 CB settings ........................................78 Voice mailbox ................................. 79 Internet ........................................... 80 Enter URL ........................................80 Bookmarks list .................................80 History ..............................................80 Browser settings ...............................80 Games ............................................. 86 Organiser ........................................ 87 Calendar ...........................................87 Dictat. machine ................................89 Time zones .......................................90 Synchronisation ...............................90 Extras .............................................. 92 My menu ..........................................92 SIM toolkit (optional) .....................92 Alarm clock ......................................92 FM radio ...........................................94 Calculator .........................................95 Unit converter ..................................95 Sound recorder ................................96 Stopwatch .........................................97 Media player ................................... 98 My stuff ......................................... 101 Settings .......................................... 104 Profiles ........................................... 104 Ringtones ....................................... 105 Themes ........................................... 106 Display ........................................... 106 Vibration (silent alert) ................. 107 Connectivity .................................. 108 Shortcuts ........................................ 111 Call setup ....................................... 112 Phone ............................................. 115 Clock .............................................. 117 Security .......................................... 119 Network ......................................... 121 Accessories .................................... 123 Mobile Phone Manager ................ 124 Questions & Answers .................... 126 Customer Care .............................. 130 Care and maintenance .................. 132 Product data .................................. 133 SAR ................................................ 135 U.S. FDA ....................................... 136 FCC/Industry Canada Notice .......... 142 In…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 September 8, 2006 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Company requests confidentiality for the following products: FCC ID Number Product Title/Model PWX-SL91 SL91 For the product stated above, we request that the following information be held confidential: 1. Circuit diagrams, BOM, and PCBs submitted as Equipment Authorization Electronic Filing attachment: "schematics”. 2. Block diagram submitted as Equipment Authorization Electronic Filing attachment: “blockdiagram”. 3. Operational description submitted as Equipment Authorization Electronic Filing attachment: “operational description” The above exhibits contain Company trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile handset. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Dr. Martin Weinberger Company: BenQ Mobile GmbH & Co OHG Address: Haidenauplatz 1 81667 München Germany Phone: Tel. +49 89 4111 3748 Email: [email protected]

Cetecom ICT Services GmbH Untertürkheimer Str. 6-10 66117 Saarbrücken Attn. Mr. Gerald Schmidt Certification Manager September 8, 2006 Dear Mr. Schmidt, Pursuant to FCC Public Notice DA04-1705 “OET Equipment Authorization System Upgrade Permits Electronic Submittal of Short-Term Confidentiality Requests” , Company requests confidentiality for the following products: FCC ID Number Product Title/Model PWX-SL91 SL91 For the product stated above, we request that the following information be held confidential until October 20, 2006: 1. Circuit diagrams, BOM, and PCBs submitted as Equipment Authorization Electronic Filing attachment: "schematics”. 2. Block diagram submitted as Equipment Authorization Electronic Filing attachment: “blockdiagram”. 3. Operational description submitted as Equipment Authorization Electronic Filing attachment: “operational description” 4. External Photos 5. Internal Photos 6. Test Setup Photos 7. User’s Manual 8. Parts List 9. Tune-up Procedures The above exhibits contain Company trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our mobile handset. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me at the address shown below. Sincerely, (signed) Name: Dr. Martin Weinberger Company: BenQ Mobile GmbH & Co OHG Address: Haidenauplatz 1 81667 München Germany Phone: Tel. +49 89 4111 3748 Email: [email protected]

BMG PH RD HW RFK Department: BMG PH RD HW KLF Sl91 Date: 01/09/2006 Author: External pictures Page: 1/4 SL91 Front View, Closed SL91 Back View, Closed BMG PH RD HW RFK Department: BMG PH RD HW KLF Sl91 Date: 01/09/2006 Author: External pictures Page: 2/4 SL91 Front View, Open SL91 Back View, Open BMG PH RD HW RFK Department: BMG PH RD HW KLF Sl91 Date: 01/09/2006 Author: External pictures Page: 3/4 SL91 Right Side View, Open SL91 Left Side View, Open BMG PH RD HW RFK Department: BMG PH RD HW KLF Sl91 Date: 01/09/2006 Author: External pictures Page: 4/4 SL91 Right Side View, Closed SL91 Left Side View, Closed SL91 Bottom View SL91 Top View

BMG PH RD HW RFK Department: BMQ PH RD HW KLF SL91 Date: 01.09.2006 Author: External pictures Page: 1/7 SL91 Battery Lid Opened BMG PH RD HW RFK Department: BMQ PH RD HW KLF SL91 Date: 01.09.2006 Author: External pictures Page: 2/7 Disassemble Step 1: Battery Cover BMG PH RD HW RFK Department: BMQ PH RD HW KLF SL91 Date: 01.09.2006 Author: External pictures Page: 3/7 Disassemble Step 2: Front Cover and Keypad separated from Slider BMG PH RD HW RFK Department: BMQ PH RD HW KLF SL91 Date: 01.09.2006 Author: External pictures Page: 4/7 Disassemble Step 3: Display and Keypad separated from Slider BMG PH RD HW RFK Department: BMQ PH RD HW KLF SL91 Date: 01.09.2006 Author: External pictures Page: 5/7 Disassemble Step 4: Slider Upper Case Back, Open Disassemble Step 5: Slider Upper Case Back, Close BMG PH RD HW RFK Department: BMQ PH RD HW KLF SL91 Date: 01.09.2006 Author: External pictures Page: 6/7 Disassemble Step 6: Rear Cover Base Disassemble Step 7: Rear Cover Base with PCB BMG PH RD HW RFK Department: BMQ PH RD HW KLF SL91 Date: 01.09.2006 Author: External pictures Page: 7/7 Disassemble Step 8: Back Side of main PCB Disassemble Step 9: Front Side of main PCB

DAT-P-152/98-01 SAR Report, BenQ_6620_607_FCC_CalData_SL91 dasy_report_fcc_850_1900_cal_data_2.0.doc/08.01.2005/CH Appendix for the Report Dosimetric Assessment of the BenQ Siemens SL91 (FCC ID: PWX-SL91) According to the FCC Requirements Calibration Data August 29, 2006 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer BenQ Mobile GmbH & Co OHG Südstraße 9 D-47475 Kamp-Lintfort This report shall not be reproduced except in full without the written approval of the testing laboratory.

DAT-P-152/98-01 SAR Report, Siemens_6620_607_FCC_1900_SAR Plots_SL91 Page 1 of 29 Appendix for the Report Dosimetric Assessment of the BenQ Siemens SL91 (FCC ID: PWX-SL91) According to the FCC Requirements SAR Distribution Plots August 29, 2006 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer BenQ Mobile GmbH & Co. OHG Südstraße 9 D-47475 Kamp-Lintfort The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH SAR Report, Siemens_6620_607_FCC_1900_SAR Plots_SL91 Page 2 of 29 dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH Table of Contents 1 SAR DISTRIBUTION PLOTS, PCS 1900 HEAD, SLIDER UP................................................................. 3 2 SAR DISTRIBUTION PLOTS, PCS 1900 HEAD, SLIDER DOWN.......................................................... 7 3 SAR DISTRIBUTION PLOTS, PCS 1900 HEAD, WORST CASE WITH BT....................................... 11 4 SAR DISTRIBUTION PLOTS, PCS 1900 BODY WITH SLIDER UP.................................................... 12 5 SAR DISTRIBUTION PLOTS, PCS 1900 BODY WITH SLIDER DOWN............................................. 19 6 SAR Z-AXIS SCANS (VALIDATION)......................................................................................................... 28 7 SAR Z-AXIS SCANS (MEASUREMENTS)................................................................................................ 29 SAR Report, Siemens_6620_607_FCC_1900_SAR Plots_SL91 Page 3 of 29 dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH 1 SAR Distribution Plots, PCS 1900 Head, slider up Test Laboratory: Imst GmbH, DASY Yellow (II); File Name: 575yplm_1_su.da4 DUT: BenQ Siemens ; Type: SL91; Serial: 004401410210575 Program Name: Cheek Left Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.39 mho/m; ε r = 38.8; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(8.25, 8.25, 8.25); Calibrated: 23.09.2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 09.03.2006 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 171 Cheek Left/Area Scan (7x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.149 mW/g Cheek Left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.23 V/m; Power Drift = 0.121 dB Peak SAR (extrapolated) = 0.224 W/kg SAR(1 g) = 0.137 mW/g; SAR(10 g) = 0.079 mW/g Maximum value of SAR (measured) = 0.151 mW/g Fig. 1: SAR distribution for PCS 1900, channel 661, cheek position, left side of head (August 21, 2006; Ambient Temperature: 21.6° C; Liquid Temperature: 20.8° C). SAR Report, Siemens_6620_607_FCC_1900_SAR Plots_SL91 Page 4 of 29 dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH Test Laboratory: Imst GmbH, DASY Yellow (II); File Name: 575yplm_2_su.da4 DUT: BenQ Siemens ; Type: SL91; Serial: 004401410210575 Program Name: Tilted Left Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.39 mho/m; ε r = 38.8; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(8.25, 8.25, 8.25); Calibrated: 23.09.2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 09.03.2006 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 171 Tilted Left/Area Scan (6x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.127 mW/g Tilted Left/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.60 V/m; Power Drift = 0.038 dB Peak SAR (extrapolated) = 0.187 W/kg SAR(1 g) = 0.119 mW/g; SAR(10 g) = 0.070 mW/g Maximum value of SAR (measured) = 0.128 mW/g Fig. 2: SAR distribution for PCS 1900, channel 661, tilted position, left side of head (August 21, 2006; Ambient Temperature: 21.6° C; Liquid Temperature: 20.8° C). SAR Report, Siemens_6620_607_FCC_1900_SAR Plots_SL91 Page 5 of 29 dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH Test Laboratory: Imst GmbH, DASY Yellow (II); File Name: 575yprm_1_su.da4 DUT: BenQ Siemens ; Type: SL91; Serial: 004401410210575 Program Name: Cheek Right Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.39 mho/m; ε r = 38.8; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: - Probe: EX3DV4 - SN3536; ConvF(8.25, 8.25, 8.25); Calibrated: 23.09.2005 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn335; Calibrated: 09.03.2006 - Phantom: SAM Glycol 1340; Type: QD 000 P40 CB; Serial: TP-1340 - Measurement SW: DASY4, V4.7 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 171 Cheek Right/Area Scan (6x12x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.105 mW/g Cheek Right/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.69 V/m; Power Drift = -0.072 dB Peak SAR (extrapolated) = 0.149 W/kg SAR(1 g) = 0.107 mW/g; SAR(10 g) = 0.067 mW/g Maximum value of SAR (measured) = 0.117 mW/g Fig. 3: SAR distribution for PCS 1900, channel 661, cheek position, right side of head (August 21, 2006; Ambient Temperature: 21.6° C; Liquid Temperature: 20.8° C). SAR Report, Siemens_6620_607_FCC_1900_SAR Plots_SL91 Page 6 of 29 dasy_report_fcc_1900_plots_1.1.doc/08.07.2005/CH Test Laboratory: Imst GmbH, DASY Yellow (II); File Name: 575yprm_2_su.da4 DUT: BenQ Siemens ; Type: SL91; Serial: 004401410210575 Program Name: Tilted Right Communication System: GSM 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium parameters used: f = 1880 MHz; σ = 1.39 mho/m; ε r = 38.8; ρ = 1000 k…

Text truncated - open the document above for the full version.

DAT-P-152/98-01 SAR Report, BenQ_6620_607_FCC_1900_SL91 Page 1 of 42 Report Dosimetric Assessment of the Portable Device BenQ Siemens SL91 (FCC ID: PWX-SL91) According to the FCC Requirements August 29, 2006 IMST GmbH Carl-Friedrich-Gauß-Str. 2 D-47475 Kamp-Lintfort Customer BenQ Mobile GmbH & Co. OHG Südstraße 9 D-47475 Kamp-Lintfort The test results only relate to the items tested. This report shall not be reproduced except in full without the written approval of the testing laboratory. Dasy_Report_FCC_1900_4.8.doc/22.05.2006/CH SAR Report, BenQ_6620_607_FCC_1900_SL91 Page 2 of 42 Dasy_Report_FCC_1900_4.8.doc/22.05.2006/CH Executive Summary The Siemens SL91 is a mobile phone (Portable Device) from BenQ operating in the 900 MHz, 1800 MHz,1900 MHz and 1950 MHz frequency range. The device has an integrated antenna and the system concepts used are the GSM 900, GSM 1800, PCS 1900 and WCDMA I (FDD) standards including GPRS Class 10 and Bluetooth capability. The objective of the measurements done by IMST was the dosimetric assessment of one device in the PCS 1900 standard with slider up and down. The examinations have been carried out with the dosimetric assessment system „DASY4“. The measurements were made according to the Supplement C to OET Bulletin 65 of the Federal Communications Commission (FCC) Guidelines [OET 65] for evaluating compliance of mobile and portable devices with FCC limits for human exposure (general population) to radiofrequency emissions. All measurements have been performed in accordance to the recommendations given by SPEAG. The BenQ Siemens SL91 mobile phone (FCC ID: PWX-SL91) is in compliance with the Federal Communications Commission (FCC) Guidelines [OET 65] for uncontrolled exposure. The phone was tested in addition to the head positions in the following configurations: Body worn with the following accessories: • GSM without accessory, slider up and down (10 mm distance) • GSM with headset, slider up and down (10 mm distance) • GPRS (Class 10) without accessory, slider up and down (10 mm distance) • GPRS (Class 10) with data cable, slider up and down (10 mm distance) • GPRS (Class 10) with BT activated, slider up and down (10 mm distance) prepared by: ........................................... reviewed by: ..................................... Alexander Rahn André van den Bosch test engineer quality assurance engineer IMST GmbH Carl-Friedrich-Gauß-Straße 2 D-47475 Kamp-Lintfort Tel. +49- 2842-981 378 Fax +49- 2842-981 399 email: [email protected] SAR Report, BenQ_6620_607_FCC_1900_SL91 Page 3 of 42 Dasy_Report_FCC_1900_4.8.doc/22.05.2006/CH Table of Contents 1 SUBJECT OF INVESTIGATION.................................................................................................................... 4 2 THE IEEE STANDARD C95.1-1999 AND THE FCC EXPOSURE CRITERIA....................................... 4 2.1 DISTINCTION BETWEEN EXPOSED POPULATION, DURATION OF EXPOSURE AND FREQUENCIES........... 4 2.2 DISTINCTION BETWEEN MAXIMUM PERMISSIBLE EXPOSURE AND SAR LIMITS....................................... 5 2.3 SAR LIMIT.................................................................................................................................................. 5 3 THE FCC MEASUREMENT PROCEDURE................................................................................................. 6 3.1 GENERAL REQUIREMENTS......................................................................................................................... 6 3.2 DEVICE OPERATING NEXT TO A PERSON’S EAR....................................................................................... 6 4 BODY-WORN CONFIGURATIONS.............................................................................................................. 9 4.1 POC POSITION......................................................................................................................................... 9 4.2 PHANTOM REQUIREMENTS...................................................................................................................... 10 4.3 TEST TO BE PERFORMED......................................................................................................................... 10 5 THE MEASUREMENT SYSTEM................................................................................................................. 10 5.1 PHANTOM................................................................................................................................................. 12 5.2 PROBE...................................................................................................................................................... 12 5.3 MEASUREMENT PROCEDURE.................................................................................................................. 13 5.4 UNCERTAINTY ASSESSMENT................................................................................................................... 14 6 SAR RESULTS............................................................................................................................................... 15 7 EVALUATION................................................................................................................................................. 18 8 APPENDIX....................................................................................................................................................... 20 8.1 ADMINISTRATIVE DATA............................................................................................................................ 20 8.2 DEVICE UNDER TEST AND TEST CONDITIONS......................................................................................... 20 8.3 TISSUE RECIPES...................................................................................................................................... 21 8.4 MATERIAL PARAMETERS....................................................…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report no.: 2-4375-05-02/06 Date: 2006-08-25 Page 1 of 36 Recognized by the Federal Communications Commission Anechoic chamber registration no.: 90462 (FCC) Anechoic chamber registration no.: 3463 (IC) TCB ID: DE 0001 Accredited by the German Accreditation Council DAR–Registration Number DAT-P-176/94-D1 Independent ETSI compliance test house ETSI Accredited Bluetooth ® Test Facility (BQTF) Test report No. : 2-4375-05-02/06 Applicant : BenQ Mobile Type : SL 91 Test Standard : FCC Part 24 RSS -133 FCC ID : PWX-SL91 Certification No. IC : 6175C-SL91 The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Cetecom ICT is under license CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report No.: 2-4375-05-02/06 Date: 2006-08-25 Page 2 of 36 Table of contents 1 GENERAL INFORMATION ................................................................................................................................... 3 1.1. ADMINISTRATIVE DATA OF THE TEST FACILITY..................................................................................................... 3 1.1.1 Identification of the testing laboratory ......................................................................................................... 3 1.2. NOTES................................................................................................................................................................... 3 1.3 DETAILS OF APPLICANT......................................................................................................................................... 4 1.4 APPLICATION DETAILS.......................................................................................................................................... 4 1.5 ADDITIONAL EUT INFORMATION FOR IC CANADA (APPENDIX 2).......................................................................... 5 1.6 TEST SETUP........................................................................................................................................................... 6 1.7 TEST STANDARDS.................................................................................................................................................. 6 2 STATEMENT OF COMPLIANCE .......................................................................................................................... 7 2.1 SUMMARY OF MEASUREMENT RESULTS................................................................................................................ 7 2.1.1 PCS 1900 ...................................................................................................................................................... 7 3 MEASUREMENTS AND RESULTS ....................................................................................................................... 8 3.1 PART PCS 1900 ................................................................................................................................................... 8 3.1.1 RF Power Output .......................................................................................................................................... 8 3.1.2 Frequency Stability..................................................................................................................................... 12 3.1.3 Radiated Emissions..................................................................................................................................... 15 3.1.4 Receiver Radiated Emissions ...................................................................................................................... 22 3.1.5 Conducted Spurious Emissions ................................................................................................................... 25 3.1.6 Block Edge Compliance .............................................................................................................................. 28 3.1.7 Occupied Bandwidth................................................................................................................................... 30 4 USED TEST EQUIPMENT ..................................................................................................................................... 34 CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Test report No.: 2-4375-05-02/06 Date: 2006-08-25 Page 3 of 36 1 General information 1.1. Administrative data of the test facility 1.1.1 Identification of the testing laboratory Company name: Cetecom ICT Services GmbH Address: Untertürkheimerstr. 6-10 D-66117 Saarbruecken Germany Laboratory accreditation: DAR-Registration No. DAT-P-176/94-D1 Bluetooth Qualification Test Facility (BQTF) Federal Communications Commission (FCC) Identification/Registration No : 90462 Responsible for testing laboratory: Dirk Hausknecht Phone: +49 681 598 0 Fax: +49 681 598 9075 email: [email protected] 1.2. Notes The test results of this test report relate exclusively to the test item specified in 1.5. The CETECOM ICT Services GmbH does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the CETECOM ICT Services GmbH. .................................................................................. Responsible for testing (Jakob Reschke) .............................…

Text truncated - open the document above for the full version.

CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4375-05-02/06 Date: 2006-08-25 Page 18 of 29 6 Annex B: Photographs of Test site Photo 1 (Radiated Emissions): Photo 2 (Radiated Emissions): CETECOM ICT Services GmbH Untertürkheimer Str. 6-10, 66117 Saarbruecken Phone: +49 (0) 681 598-0 Fax: -9075 RSC-Laboratory Phone: +49 (0) 681 598-0 Fax: -9075 Annex to Test report no.: 2-4375-05-02/06 Date: 2006-08-25 Page 19 of 29 Photo 3 (Conducted Emissions):
