PWYJT24TX99039Disney RC,MICKEY ROADSTER RC,MINNIE ROADSTER RC, Peppa Pig RC car

Jada Toys Company Limited

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Feb 24, 2021
Application Purpose: Original Equipment
Date of Application: Feb 24, 2021
Equipment Note: Disney RC,MICKEY ROADSTER RC,MINNIE ROADSTER RC, Peppa Pig RC car
Frequency Range: 2418.00000000 - 2462.00000000
Company: Jada Toys Company Limited
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

JADA TOYS CO. LTD. Declaration of Identical Product Hereby, Name of manufacturer: JADA TOYS CO. LTD. Address: Unit 318, 3/F, Tower A, New Mandarin Plaza, No.14 Science Museum Road, TST East, Kowloon, HK. City: Kowloon Country: Hong Kong declares that: Product description: Disney RC,MICKEY ROADSTER RC,MINNIE ROADSTER RC，Peppa Pig RC car Type designation(s): JDRX2701,84172,84143,84757,84793,84144, 84761,84145, 84165,84166, 84693, 84694, 32943, 32944, 84758, 84759, 84141,84756, 97161,30433,30434,32907 Trademark: JADA Family name is technically identical to: Product description: Disney RC,MICKEY ROADSTER RC,MINNIE ROADSTER RC，Peppa Pig RC car Type designation: JDTX2701 Trademark: JADA Certificate number (if applicable) They are identical with the test model JDTX2701 except the color of the appearance and model name for trading purpose。 Date: 2021.1.25 City: Kowloon Name: Dennis Suen Signature

Cover Letter(s)

SCS-F019: Confidentiality Request Letter Page 1 of 2 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] W ebsite: https://www.cps.bureauveritas.com/ Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 Updated References and Contact Info 6.0 7.0 Aug-30-2020 SCS-F019: Confidentiality Request Letter Page 2 of 2 Rev 7.0 JADA TOYS CO. LTD. 2021.1.25 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046-1609 Cc: Bureau Veritas Consumer Products Services Inc. 775 Montague Expressway Milpitas, CA 95035 Subject: Confidentiality Request for FCC ID: PWYJT24TX99039 Pursuant to CFR 47 sections 0.457 and 0.459, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application be held confidential: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagram Short Term External Photos Short Term Permanent i Internal Photos Short Term Permanent Operational Description/ Theory of Operation Short Term Permanent Parts List Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent i User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: To avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of not to exceed 180 days from the Grant Date The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name: Dennis Suen Title : Assistan General Manager Contact information / address : Unit 318, 3/F, Tower A, New Mandarin Plaza, No.14 Science Museum Road, TST East, Kowloon, HK. Permanent confidentiality may be requested in accordance with FCC KDB 726920

External Photos

ID Label/Location Info

Label and Location FCC ID size: 2mm(H)*16mm(L) Model number size: 2mm(H)*12mm(L) Model: JDTX2701 Jada Toys. Inc., FCC ID: PW YJT24TX99039 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

Test Report

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 25 Report Version 1 Test Report No.: RF2101WDG0009 TEST REPORT Applicant JADA TOYS CO. LTD. Address Unit 318, 3/F, Tower A, New Mandarin Plaza,No.14 Science Museum Road,TST East, Kowloon, HK. Manufacturer or Supplier JADA TOYS CO. LTD. Address Unit 318, 3/F, Tower A, New Mandarin Plaza,No.14 Science Museum Road,TST East, Kowloon, HK. Product: Disney RC Additional Product MICKEY ROADSTER RC, MINNIE ROADSTER RC, Peppa Pig RC car Brand Name: JADA Model: JDTX2701 Additional Model & Model Difference JDRX2701, 84172, 84143, 84757, 84793,84144, 84761,84145, 84165, 84166, 84693, 84694, 32943, 32944, 84758, 84759, 84141, 84756, 97161, 30433, 30434, 32907 Date of tests: Jan. 11, 2021 ~ Feb. 24, 2021 the tests have been carried out according to the requirements of the following standard: FCC Part 15, Subpart C, Section 15.249 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Evans He Project Engineer / EMC Department Approved by David Huang Supervisor / EMC Department Date: Feb. 24, 2021 This report is governed by, and incorporates by reference, CPS Conditions of Service as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute you unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 25 Report Version 1 Test Report No.: RF2101WDG0009 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................................ 3 1 SUMMARY OF TEST RESULTS .................................................................................................... 4 2 MEASUREMENT UNCERTAINTY ................................................................................................. 4 3 GENERAL INFORMATION ............................................................................................................ 5 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................... 5 3.2 DESCRIPTION OF TEST MODES ................................................................................................. 6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................ 7 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................................................... 7 4. TEST TYPES AND RESULTS ........................................................................................................ 8 4.1 RADIATED EMISSION MEASUREMENT ...................................................................................... 8 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT ...................................................... 8 4.1.2 TEST INSTRUMENTS ....................................................................................................... 9 4.1.3 TEST PROCEDURES ..................................................................................................... 10 4.1.4 DEVIATION FROM TEST STANDARD ........................................................................... 10 4.1.5 TEST SETUP .................................................................................................................... 11 4.1.6 EUT OPERATING CONDITIONS .................................................................................... 12 4.1.7 TEST RESULTS .............................................................................................................. 13 4.2 20DB BANDWIDTH MEASUREMENT ......................................................................................... 20 4.2.1 LIMITS OF 20DB BANDWIDTH MEASUREMENT ............................................................. 20 4.2.2 TEST INSTRUMENTS ......................................................................................................... 20 4.2.3 TEST PROCEDURE ............................................................................................................ 21 4.2.4 DEVIATION FROM TEST STANDARD ............................................................................... 21 4.2.5 TEST SETUP ....................................................................................................................... 21 4.2.6 EU…

Text truncated - open the document above for the full version.

Test Setup Photos
