PWYJY49TX84000R/C Car Transmitter

U.S.A & Canada 60-Day Limited Warranty Jada Toys R/C Products Jada Toys, Inc. warrants to the original consumer purchaser that this product will be free of defects in material and workmanship for sixty (60) days from the date of purchase. Jada Toys will repair or replace the product, at our sole option, in the event of such a defect within the warranty period. In the event of a defect covered under this warranty, first call the toll-free number listed below. Many problems can be solved in this manner. If necessary, you will be instructed to return the product, postage pre-paid and insured, to the address below. Enclose your name, address, telephone number, copy of dated sales receipt, and a brief explanation of the defect. Repair or replacement, and return shipment, will be free of charge. Please return on the defective part or unit, packed securely. This warranty does not cover damage resulting from unauthorized modification, accident, misuse or abuse. If the product is returned without a dated sales receipt, the product may be excluded from coverage under this warranty. Jada Toy’s liability for defects in material and workmanship under this warranty shall be limited to repair or replacement, at our sole option, and in no event shall we be responsible for incidental, consequential, or contingent damages (except in those states that do not allow this exclusion or limitation). This warranty is exclusive, and is made in lieu of any express or implied warranty. Valid only in U.S.A. and Canada. This warranty gives you specific legal rights and you may have other rights, which may vary from state to state. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusions or limitations may not apply to you. TOLL-FREE NUMBER: 1-800-679-JADA (5232) (valid only in U.S.A. and Canada) Hours: 9:00 A.M. – 5:00 P.M. Pacific Time; Monday – Friday. Expect some delay in January following the holiday season. Please be patient and keep trying the toll-free number. Address for Returns: Consumer Relations, Jada Toys, Inc 938 Hatcher Ave. City of Industry, CA 91748 Important! Problems? Before taking your new R/C back to the retailer, call our friendly R/C technicians at: 1-800-679-5232 between the hours of 9 am to 5 pm Pacific Time; Monday - Friday. Questions or problems with your vehicle? DO NOT RETURN IT TO THE STORE! TROUBLE SHOOTING PROBLEM SOLUTION Car will not START Car does not respond to controls. Car does not drive straight. 1. Power switch is off. Turn on. 2. Batteries are installed with incorrect polarities. Check the + and - markings to make sure the batteries are properly aligned. 3. Batteries are drained. Charge batteries and/or install new batteries. 1. Transmitter controller battery is drained. Replace the 9V controller battery. 2. Vehicle is out of range. Bring controller closer to the vehicle. 3. Interference from surrounding electrical machinary. Bring to a wide open space. 1. Adjust the steering dial underneath the front axle, left or right, until the wheels point straight forward. QUICK TIPS • When your vehicle starts to lose power, it may lose functions or performance. It’s time for fresh batteries (or a recharge). Your vehicle’s running time may change depending on your driving style. • Radio interference can make your vehicle run badly. Interference can be caused by other R/C vehicles running on the same frequency; electrical wires, large buildings; or CB radios. Try to stay away from these! • Point your transmitter controller antenna up – not down toward your vehicle. If your vehicle gets too far away, it won’t work properly. • Don’t drive your vehicle in sand or through water or snow. • Don’t store your vehicle near heat or in direct sunlight. Always turn switches OFF and remove all batteries for storage. Cleaning instruction: To clean, wipe excess dirt from toy. Remove batteries first. Wipe toy clean with wet cloth using plain water. Wipe dry. DO NOT IMMERSE IN WATER and DO NOT CLEAN VEHICLE WITH ANY CHEMICALS. Let the toy completely dry up before putting batteries back into clean, dry battery compartment. COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S. ONLY) THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION OF THIS DEVICE IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. 2. THIS DEVICE MUST ACCEPT ANY HARMFUL INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. This device generates and uses radio frequency energy and if not used properly may cause interference to radio and television reception. It has been tested and found to comply with the limits set by the FCC which are designed to provide reasonable protection against such interference. FCC Warning: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such change or modifications could void the User’s authority to operate the equipment.

Keep these instructions for future reference: they contain important information. IMPORTANT: Please read all “Consumer Information” before operating your vehicle. CAUTION: ELECTRICALLY OPERATED PRODUCT Not recommended for children under 8 years of age. As with all electric products, precautions should be observed during handling and use to prevent electric shock. ADULT SUPERVISION REQUIRED. Surfaces may become hot and cause burns if electronics get wet. Do not operate vehicle through water or snow. Consumer Information: Note to Adults: to ensure that the child’s play is both safe and fun, please review all operating instructions and safety rules with your child. CONTENTS Vehicle Transmitter Controller Antenna for Transmitter Controller 9.6V Ni-Cd Battery Pack Charger for 9.6V Ni-Cd Battery Pack (120V AC 60Hz) Safety Tips • NEVER drive your vehicle on streets! They’re for real cars! • DO NOT pick up vehicle while in motion. • Avoid collisions with wall or hard surfaces. • Keep fingers, hair and loose clothing away from tires and the wheel hubs while the vehicle is switched ON. • Adult supervision is recommended when this vehicle is being operated. • To avoid accidental operation, remove all batteries when not in use. • Battery charger used with the toy to be regularly examined for damage to cord plug enclosure and other parts: and in the event of such damage. Toy must not be used with the battery charger until such damage has been repaired. • For transformer toys and toys with battery boxes: toy is not to be connected to more than recommended number of power supplies. • Recommended rechargeable battery 9.6V 700mAH Ni-Cd. • Be sure to rest your vehicle for at least 5 minutes after every 15 minutes of operation. BEFORE BATTERY INSTALLATION Your new R/C is designed to work with standard R/C 9.6-volt Ni-Cd batteries and charger. Controller is designed to work with a 9-volt alkaline battery. For detailed information regarding Ni-Cd battery charging and safety, please follow the specific instructions that came with your battery pack and charger. BATTERY CHARGING: (When using 9.6V Ni-Cd Battery Pack) **RECHARGEABLE BATTERIES ARE TO BE CHARGED BY ADULT ONLY** (The rechargeable Ni-Cd battery pack is not charged, please charge battery for 4 (four) hours prior to use) 1. Plug the wall pack battery charger into wall outlet. 2. Connect the cables leading from the Battery Pack and the charger together by snapping the jack and the socket tightly. (See diagram 1) 3. To disconnect cables, press down on the clip and pull apart. (See diagram 1) 4. After charging for 4 (four) hours, the battery will be warm. This condition is normal for fully charged batteries. DO NOT overcharge the battery. 5. After use, the battery pack will be hot!!! Wait at least 20 minutes until the battery cools before recharging. Recharging a warm or hot battery pack will greatly shorten the use life of the battery. INSTALLING BATTERIES IN THE R/C 9.6V Ni-Cd 1. Push the ON/OFF to “OFF” position on vehicle. 2. To install the 9.6V Ni-Cd battery, use a Phillips screwdriver (not included), to remove the battery compartment door underneath the vehicle. (See diagram 2) 3. Remove the battery compartment door. 4. Plug the battery pack into the cable by snapping the jack and socket lightly. 5. Replace the battery compartment door and use Phillips screwdriver to lock the compartment door. INSTALLING CONTROLLER – 9 VOLT BATTERY 1. Open the battery cover as shown (See Diagram 3) 2. Install one 9V battery with polarity (+/-) as shown inside battery compartment. 3. Replace battery cover. Battery Safety Information • Insure that battery polarity is correct. • Use only batteries of the type recommended (or equivalent). • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. • Remove used-up batteries immediately. Remove batteries if vehicle will not be used for a long period of time to prevent possible leakage. • Do not recharge non-rechargeable batteries. • Do not short-circuit terminals. • Remove rechargeable batteries before recharging. • Rechargeable battery must be charged by adult only. • Dispose of batteries safely. Do not dispose of batteries (or products containing non-replaceable batteries) in fire, as batteries may explode or leak. • Do not disassemble the battery pack. • Do Not overcharge the battery. Use only the charger provided. Do Not use other chargers to charge battery. Like any other rechargeable battery, explosion may occur, if improperly charged. ©2005 Jada Toys, Inc. City of Industry, CA 91748 USA DUB CITY® and R/C ROLLER$™ are trademarks of Jada Toys, Inc. All Rights Reserved. 83002-IS-US04 Operations Tips: Locate the transmitter antenna mount on the top of the transmitter. Insert the antenna into the mount opening and rotate in a clockwise direction until snug. Car: ON / OFF switch located on the bottom of the car. Transmitter: ON / OFF switch located on the front of the transmitter. When you ready to run, please make sure push the ON / OFF switches to “ON” position on both. Go to get fun. To replace battery pack remove screw on battery cover as shown in illustration and replace battery pack Steering Dial Press here when opening Press here when opening FRONT REAR Battery Charger 9.6V Ni-Cd battery pack 9.6V Ni-Cd battery pack 9.6V Ni-Cd battery pack Insert 9 volt battery into transmitter Power on LED Light Up TRANSMITTER CONTROLLER BOTTOM OF TRANSMITTER CONTROLLER Left / Right Screw On On / Off Stop Go Forward Reverse TO ADJUST STEERING ALIGNMENT Adjust the steering alignment lever on the underside of the vehicle when the vehicle doesn’t run straight forward. steering alignment lever

External Photos

Label Sample and Location

Internal Photos

TEST REPORT Report No. : AF011349-001 Date : 2005 June 01 For and on behalf of CMA Testing and Certification Laboratories Authorized Signature : Page 1 of 11 Danny Chui EMC Engineer - EL. Division FCC ID : PWYJY49TX84000 This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Application No. : LF207167(1) Applicant : Jada Toys Co. Ltd. Unit 901, 9/F, Energy Plaza, 92 Granville Road, TST East, Kowloon, Hong Kong Sample Description : One(1) submitted sample stated to be 9.6V R/C Car of Model No. 83002, 83005 Rating : 1 X 9V size battery No. of submitted sample : Two (2) piece (s)*** Date Received : Test Period : Test Requested : Test Method : Test Result : Conclusion : 2005 April 22 2005 April 22 – 2005 May 19 FCC Part 15 Certification FCC Rules and Regulations Part 15 – July 2004 ANSI C63.4 – 2003 See attached sheet(s) from page 2 to 11. The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. Remark : All two models are the same in circuitry and components; and therefore model 83005 was chosen to be the representative of the test sample. TEST REPORT Report No. : AF011349-001 Date : 2005 June 01 Page 2 of 11 FCC ID : PWYJY49TX84000 This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Table of Contents 1 General Information........................................................................................................................ 3 1.1 General Description.................................................................................................................. 3 1.2 Location of the test site............................................................................................................. 4 1.3 List of measuring equipment...................................................................................................... 5 2 Description of the radiated emission test........................................................................................... 6 2.1 Test Procedure......................................................................................................................... 6 2.2 Test Result...............................................................................................................................6 2.3 Radiated Emission Measurement Data....................................................................................... 7 3 Description of the Line-conducted Test............................................................................................ 8 3.1 Test Procedure......................................................................................................................... 8 3.2 Test Result...............................................................................................................................8 3.3 Graph and Table of Conducted Emission Measurement Data....................................................... 8 4 Photograph..................................................................................................................................... 9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission........................... 9 4.2 Photographs of the External and Internal Configurations of the EUT........................................... 9 5 Supplementary document............................................................................................................... 10 5.1 Bandwidth............................................................................................................................. 10 5.2 Duty Cycle............................................................................................................................. 10 6 Appendices...............................................................................................................................11 TEST REPORT Report No. : AF011349-001 Date : 2005 June 01 Page 3 of 11 FCC ID : PWYJY49TX84000 This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for 9.6V R/C Car. Operating at 49.860 MHz which is controlled by a crystal. The EUT is powered by 9V battery. There are two control trigger in the EUT. When the forward, backward, turn left and turn right rigger is pressed once. It will transmit a difference radio signal for receiver go difference direction. The brief circuit description is listed as follows : - U2 and associated circuit act as signal encoder. - X101, Q102 and associated circuit act as oscillator. - C108, T101, C109 and associated circuit act as low pass fitter. - Q101 and associated circuit act as RF amplifier. - D101 and associated circuit act as voltage regulator. TEST REPORT Report No. : AF011349-001 Date : 2005 June 01 Page 4 of 11 FCC ID : PWYJY49TX84000 This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1302, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com 1.2 Location of the test site Radiated emissions measurement…

Text truncated - open the document above for the full version.

CMA Testing and Certification Laboratories Job No.: J00025334 WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Bandwidth Plot Bandwidth 1

CMA Testing and Certification Laboratories Job No.: J00025334 WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Duty Cycle Duty Cycle 1 Duty Cycle 2 CMA Testing and Certification Laboratories Job No.: J00025334 WF-EL-EMC-15 Edition 3 2005 Mar 29 Page of Duty Cycle 3
