System provided by: Service provided by: Installation Instructions Verify the materials in the box: 1 Telephone Cord 1 Gateway Module 1 Power Adapter Choose a location for your Gateway Module within 6 feet of a telephone jack and a standard electrical outlet not controlled by a wall switch. Use only the power cord supplied with this product. Connect the telephone line cord. Connect the telephone. (Optional) Standard Electrical Outlet Modular Phone Jack Enclosed is the Gateway Module for the Propane Tank Monitoring System. Connect the power cord. The Gateway Module can be set on a countertop using the detachable stand, or it can be mounted on the wall using the mounting keyholes. After installation it will display a "00" which means the self test and phone test were successful. The Gateway Module will show data within 72 hours. STEP 2: STEP 1: STEP 3: Gateway Module (Back) Gateway Module (Front) Frequently Asked Questions (FAQs) How much power does the Gateway Module use? It uses very little power, typically it uses less power than a small digital alarm clock. The display is the only part that is active when it is not receiving an update from the Data Module, recording the internal temperature, or making a phone call. How accurate are the fuel level and outside temperature readings? The outside temperature may vary depending on if the tank is shaded or not. The temperature is accurate to within 2% when it is read. Remember that the Gateway Module is only updated every 3 hours, so the reading may be as much as 3 hours old. When does the Gateway Module use the phone? Under normal circumstances, it only makes one call per day (in the middle of the night). The phone call lasts less than one minute, and is made to a local number. If something unexpected occurs on a fuel level reading, it may make a short phone call to inform the fuel company of the situation. Where does it call? Gateway Module FAQs and Answers After the Gateway Module is installed, it will call an 800 number and request its configuration information. This includes a local number for the Gateway Module to call for its normal nightly reports. Will the Gateway Module ever answer the phone? No. What happens if I accidentally disconnect the Gateway Module from power, or we have a power failure? When power is restored, the Gateway Module will self reset. It will detect a dial tone and return to its normal state. What happens if the Gateway Module is disconnected from the phone line? The fuel provider will notice that there have been no updates from your system, and contact you. If the Gateway Module displays an unreadable message, what should I do? Contact your fuel provider. They may help you to reset your Gateway Module. What is the Gateway Module monitoring in my house? The Gateway Module monitors only the indoor temperature. Can the Gateway Module be used to report if my indoor temperature goes too low or too high? The Gateway Module can report unexpectedly low temperatures, but the Gateway Module does not have a high temperature alarm. Does the Data Module require batteries? No. It has a small solar panel which gathers enough light to charge its rechargeable batteries during even cloudy winter days in full shade. How can I tell if the Data Module is working? The Data Module has no lights, buzzers or status indicators. If the Gateway Module does not receive a periodic update from the Data Module, it will make a phone call and relay the problem to the fuel provider. There is nothing you need to do as the home owner. Who should I contact if the Data Module is damaged? Contact your fuel provider. If it is physically damaged (broken case, damaged cable...), it may still be working but may not be as reliable as it should be. Is there anything in the Data Module that can hurt animals or children? No, there are no sharp edges, no dangerous voltages, and no chemicals in the Data Module. Data Module FAQs and Answers FCC PART 68 INFORMATION This equipment complies with Part 68 of the FCC Rules and the requirements adopted by ACTA. On the back of this equipment is a label that contains, a product identifier in the format US:AAAEQ##TXXXX. If requested, this information must be provided to your telephone company. The plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. The Gateway Module must be positioned vertically using the built-in stand or wall mounted, for best operation. See installation instructions for details. , The REN is used to determine the number of devices that may connect to a telephone line. Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most but not all areas, the sum of the RENs should not exceed five (5.0). To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact your local telephone company. For product approved after July 23, 2001, the REN for this product is part of the product identifier that has the format US:AAAEQ##TXXXX. The digits represented by ## are the REN without the decimal point (e.q., 03 is a REN of 0.3). For earlier products, the REN is separately shown on the label. If this Gateway Module causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice isn't practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary. The telephone company may make changes in it's facilities, equipment, operations or procedures that could affect the proper functioning of your equipment. If they do, you will b…
Text truncated - open the document above for the full version.
21614 NE 173 rd Avenue Battle Ground, WA 98604 ph: (360) 687-1472 fax: (360) 735-8602 [email protected] Date: 4/15/04 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize Compliance Engineering Services, Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Compliance Engineering Service, Inc. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely, Thomas A. Walker, President The Fuel Web, Inc.
21614 NE 173 rd Avenue Battle Ground, WA 98604 ph: (360) 687-1472 fax: (360) 735-8602 [email protected] 4/15/04 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 Re: Request for Confidentiality Gentlemen: In reference to the application under FCC ID: PX5 - GWM1001and pursuant to Sections 0.457(d)(l)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: - Schematics - Block Diagrams -Theory of Operation These documents contain detailed system and equipment description and related information about the product that The Fuel Web, Inc. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, The Fuel Web, Inc. considers that this information would be of benefit to its competitors, and that disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Thomas A. Walker, President The Fuel Web, Inc.
PROPOSED FCC ID LABEL AND LOCATION THE FUEL WEB, INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: PX5 -GWM1001 FCC ID LABEL LOCATION
Engineering Group 16070 Via Este Sonora, CA 95370 ph: (209) 533-2588 fx: (209) 533-2563 [email protected] Antenna Specifications MJT Rev 1.0 4/20/04 For: Data Module Model # DM-SHRF-1 Gateway Module Model # GWM-P-SHRF-1 ITEM SPECIFICATION Type Vertical dipole Size 6” Center Frequency 905 MHz Frequency Range 902 – 908 MHz Bandwidth 1 MHz Impedance 75 Polarization Vertical Pattern Omnidirectional Gain 1 dBi Connector None – Integrated onto Printed Circuit Board Element Material Plated copper on FR4 PCB
FCC CFR47 PART 15 SUBPART C CERTIFICATION TEST REPORT FOR THE FUEL WEB, INC. GATEWAY MODULE MODEL: GWM-P-SHRF-1 FCC ID: PX5-GWM1001 REPORT NUMBER: 04U2623-2 ISSUE DATE: APRIL 21, 2004 Prepared for THE FUEL WEB, INC. 21614 NE 173 RD AVE. BATTLE GROUND WA. 98604, USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 04U2623-2 DATE: 04/21/04 EUT: GATEWAY MODULE FCC ID: PX5-GWM1001 Page 2 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION.................................................................................................. 3 2. EUT DESCRIPTION.......................................................................................................................... 4 3. EUT MODIFICATION ...................................................................................................................... 4 4. TEST METHODOLOGY .................................................................................................................. 5 5. FACILITIES AND ACCREDITATION .......................................................................................... 5 6. CALIBRATION AND UNCERTAINTY.......................................................................................... 6 6.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 6 6.2. MEASUREMENT UNCERTAINTY ............................................................................................... 6 6.3. TEST AND MEASUREMENT EQUIPMENT................................................................................ 7 7. SETUP OF EQUIPMENT UNDER TEST ....................................................................................... 7 8. APPLICABLE LIMITS AND TEST RESULTS ........................................................................... 10 8.1. RADIATED EMISSIONS.............................................................................................................10 8.2. POWERLINE CONDUCTED EMISSIONS ................................................................................ 15 9. SETUP PHOTOS .............................................................................................................................. 18 REPORT NO: 04U2623-2 DATE: 04/21/04 EUT: GATEWAY MODULE FCC ID: PX5-GWM1001 Page 3 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. TEST RESULT CERTIFICATION COMPANY NAME: THE FUEL WEB 21614 NE 173 RD AVE. BATTLE GROUND, WA 98604, USA EUT DESCRIPTION: GATEWAY MODULE MODEL: GWM-P-SHRF-1 DATE TESTED: APRIL 19, 2004 – APRIL 21, 2004 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART C NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. Approved & Released For CCS By: Tested By: THU CHAN THANH NGUYEN EMC SUPERVISOR EMC TECHNICIAN COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 04U2623-2 DATE: 04/21/04 EUT: GATEWAY MODULE FCC ID: PX5-GWM1001 Page 4 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. EUT DESCRIPTION The Fuel Web’s propane tank monitoring system consists of three main functions, a Data Module (DM), a Gateway Module (GM), and the Gateway Server (GWS.) The GM lives inside the customer’s premises and is always connected to a phone line and 110V AC. The GM displays the current time, interior and outside temperature, and tank level for each DM it is monitoring. The outside temperature and tank level are updated at least every six readings. The GM will contact the GWS nightly, delivering 24 hours worth of data for all its associated DMs. 3. EUT MODIFICATION To pass the FCC Part 15 class B standard, these modifications were applied: 1) 'L48' was a 1.5pF capacitor across the antenna, replaced with a 1.8pF to help reduce the 2nd harmonic The part number is GRM188SCIHIR8CZ01D by Morata. 2) Added Ferrite beads to R12 and R13 to reduce emissions from 260-512 MHz, part number is BLM18AG102FNI By Murata. UNITFrequency BandPeak ReadingLimitMargin (MHz)(dBuV/m)(dBuV/m)(dB) GW90593.7894.00-0.22 REPORT NO: 04U2623-2 DATE: 04/21/04 EUT: GATEWAY MODULE FCC ID: PX5-GWM1001 Page 5 of 21 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (4…
