P/N : 97E9500149 User’s Reference HH LL    SS HH LL    SS HH LL    SS HH ii gg hh R R ee ss oo ll uu tt ii oo nn TT FF TT L L CC DD M M oo nn ii tt oo rr DAEWOO INTERNATIONAL Corp. DAEWOO INTERNATIONAL Corp. http://www.daewoo.com 1 Contents 1. Precautions 2 2. Items 4 3. Setting up the LCD monitor 5 How to connect the power cord and the several cables to the LCD monitor. 5 Plug & Play 5 Warm-up Time 5 4. Adjusting The Monitor 6 The Function Control Buttons 6 How to use the Function Key. 6 Main OSD Menu 6 BRIGHTNESS/CONTRAST 7 COLOR 7 POSITION &CLOCK/PHASE 7 OSD FUNCTION ADJUSTMENT 7 SETUP MENU 7 5. Appendix 8 Display Modes 8 15-pin D-Sub Connector 9 DPMS Power Saving Mode 9 6. Troubleshooting 10 3 2 Precautions 1 AC outlet Power cord Warning : The following information will help you avoid the risk of electric shock, serious injury, and death. Plug the power cord into aproperly grounded outlet.There is the risk of electricshock.Do not unplug from the outletby pulling the power cord orwhen your hands are wet.There is the risk of electricshock and fire. Do not allow any object or liq-uid to enter inside the monitor.There is the risk of electricshock, fire, or damage to themonitor. Do not bend the power cordexcessively or place heavy objectson it. Keep children and pets awayfrom the power cord as they maydamage the power cord. There isthe risk of electric shock and fire. Do not use a damaged powercord or plug. Make sure theplug fits snugly into the outlet.There is the risk of electricshock or fire. Do not expose the monitor tothe direct sun light. Keep the monitor away from hightemperature, humidity, and dust. Operating environment =0~25degrees Celsius Operating environment =30~80relative humidity. Do not block the fan louvers.There is the risk of fire or dam-age to the monitor. 220V Use a proper voltage/currentlevel indicated Do not clean the LCD withabrasive chemicals.There is the risk of damage tothe LCD. Do not scratch and damagethe LCD with sharp objects. Keep the monitor away fromobjects and electrical appli-ances that may generate elec-tromagnetic fields. Place the monitor on a flat, sta-ble surface. The monitor mayfall and there is the risk ofdamage or injury Unplug the power cord whenthe monitor is not in use for aprolonged period of time. If you hear a noise or smellsmoke from the computer oradaptor, unplug the power cordimmediately, and call the servicecenter. There is the risk of elec-tric shock or fire. Do not overload an electricaloutlet with too many devices.There is the risk of fire. Do not attempt to disassemble,fix, or modify the monitor.There is the risk of electricshock or fire. Caution : The following information will help you avoid the risk of minor or moderate injury, or damage to the monitor. 5 4 Items 2 Please make sure the following items are included with your monitor.If any items are missing, contact your dealer. Notice User Manual 15-pin D-Sub Signal Cable Stand ※ Push the hook untilhanging LCD Monitor Power cord Setting up the LCD monitor 3 How to connect the power cord and the several cables to the LCD monitor. 12 Power Power Cord 15-pin D-Sub Signal Cable PC No. Cable connections Name All LCD monitors need time to become thermally stable whenever you turn on the monitor after letting the monitor be turned off for a couple of hours. Therefore, toachieve more accurate adjustments for parameters, allow the LCD monitor to bewarmed up for at least 30 minutes before making any screen adjustments. Warm-up TimeThe adoption of the new VESA Plug and Play solution eliminates complicated andtime consuming setup. It allows you to install your monitor in a Plug and Play compati-ble system without the usual hassles and confusion. Your PC system can easily identi-fy and configure itself for use with your display. This monitor automatically tells the PCsystem its Extended Display Identification Data (EDID) using Display Data Channel(DDC) protocols so the PC system can automatically configure itself to use the flatpanel display.Plug & Play 7 ● Brightness : Changes the overall light intensity of the images being displayed. ● Contrast : Changes the ratio of light intensity between the brightest white and darkest black. ● Gamma : Change the gamma value. BRIGHTNESS/CONTRAST Adjusting Gamma Value is useful in case of game or movie screen. Notice If image is not clear (noise), you can adjust Clock/Phase. Notice COLOR● The tone of color can be changed form bluish white to reddish white. ● Color1 - Blue type ● Color2 - Red type ● RED, GREEN, BLUE - You can adjust red, green and blue values that you want. CLOCK/PHASE● When image is not clear, you can use clock/phase menu. ● CLOCK/PHASE : Although ‘Auto Adjustment’ automatically finds the optimum values of Clock and Phase parameters as well as image position, it may be necessary for you to adjustthose parameters manually. It is recommended for you to use ‘Auto Adjustment’ first. If theadjustment results are not satisfactory, then use Clock and Phase adjustment features to getthe best adjustment results. Bear in mind that Clock and Phase adjustment may change thewidth of the image and affect image position as well. If the image is clear while out of centerby a couple of pixels, use image position to center the image. POSITION & CLOCK/PHASE POSITION● Changes the location of the image. ● H-Position : Moves to the Left/Right ● V-Position : Moves to the Bottom/Top OSD FUNCTION ADJUSTMENT ● Sets the OSD menu display position. ● OSD Position : Moves the OSD menu to the horizontal or vertical direction. ● OSD TIME : Shows the OSD TIME displays from 5 to 60sec. ● LANGUAGE : Select language in OSD menu. SETUP MENU● White balance : Automatic djust color (white level) for various input source’s white level. ● Information : display monitor’s information. ● Recall : Discards current setting and replaced all paramotors with the factory default values. 6 Adjusting The Monitor 4 The Function Control Buttons How to use the Function Key. …

Text truncated - open the document above for the full version.

GIN0M HC L K on PA N E L DDC_DAT TSU16AJ & PANEL 3 RIN0RIN0MGIN0GIN0MBIN0BIN0MVSYNC0HSYNC0 on PA N E L I N T H F S H W R ESE T HC L K HD A T A SOGIN0 AdjBACKLITE HD A T A I N T VSY NC0 INVERTER & POWER 1 AdjBACKLITE on BA C K L I T E RIN0M 97E0D0613Y 1 BLOCK DIAGRAM 15 HL711S Tit leDocument Number Rev Sheet of DESIGN CHECK APPROVAL WooYoung Telecom Co., Ltd. Model HSYNC0 MCU_WT61P4_PLCC 4 HSYNC0 HC L K H W R ESE T I N T on PA N E L VSYNC0 H F S HD A T A DDC_DATDDC_CLKST_DET onBACKLITE AdjBACKLITE SOGIN0 BIN0MRIN0BIN0 ST_DET DDC_CLK H F S onBACKLITE D-SUB INPUT 2 GIN0RIN0 BIN0 ST_DET DDC _ D A T DDC _ C L K RIN0M BIN0M GIN0M HSYNC0 VSYNC0 SOGIN0 GIN0 AdjBACKLITE H W R ESE T
