PZELLP2E-20

For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations using the belt-clip placed 2.0 cm. from the body. To comply with RF exposure requirements, a minimum separation distance of 2.0 cm. must be maintained between the user’s body and the belt- clip/holster, including the antenna. The use of other belt-clip/holsters and other non- tested accessories may not comply with FCC RF Exposure requirements and should be avoided. WARNING! Read this information before using your phone

November 27, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Safe Environment Engineering FCC ID: PZELLP2E-20 Part 90 Certification Gentlemen: Submitted herewith, on behalf of Safe Environment Engineering, is an application for Part 90 Certification of the following Personal Safety Monitor (PSM): FCC ID: PZELLP2E-20 Trade Name/Model(s): Life line LLP2E-20 EUT Classification: Licensed Non-Broadcast Transmitter Held to Face (TBF) Tx Freq. Range: 403 ~ 512 MHz Max. Output Power: 2.0 Watts Attached is the letter of authorization, measurement report data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematic diagrams, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Safe Environment Engineering

February 20, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: Safe Environment Engineering FCC ID: PZELLP2E-20 731 Confirmation No.: EA946379 Correspondence Reference No.: 21865 Request for Tech. Info.: 1/25/02 Dear Joe: Transmitted herewith, on behalf of Safe Environment Engineering, is an amendment provided in response to the request for technical information dated January 25, 2002. 1. To show compliance with 90.203(g), the applicant provided the following statements. All programming is performed internal to the device. The device must be taken apart and a special cable attached to a header on the main controller board. This cable is manufactured specifically for internal use at Safe Environment Engineering and is not commercially sold. Accordingly, only technicians, engineers, or service/maintenance personnel have access to programming equipment. Access to the programming header is normally inaccessible to the operator and would typically involve destroying a product numbering bar code in the process, as well as, fully dismantling the device. The programming cable must further be connected to a Radio Interface Box (RIB) were its programming protocol is converted to RS232 for communications with a computer. Frequency programming is accomplished using Motorola’s HT1000 software. The application will not allow the radio to transmit while the actual programming is taking place. 2. The device has the ability to operate with a 12.5 kHz BW. Please find the attached occupied BW plots, frequency response, and modulating limiting plots for 12.5 kHz. 3. Please find the attached transient frequency behavior plots and test procedures. 4. Please find the attached modulation characteristics, frequency response, and modulating limiting plots for 25 kHz BW. 5. The occupied bandwidth data is attached for 12.5 kHz and 25 kHz spacing. 6. The emission masks plots showing compliance with 90.210 is attached. 7. Please find the attached justification for the emission designator for the initial filing and the additional designator added by this amendment. 8. PCTEST does not yet have a dipole for 450 MHz, so we validated at 835 MHz to ensure that the measurement system was operating within the specification. We then changed the liquid to 450 MHz simulating tissue and entered the appropriate probe setting before taking the measurements. 9. Please find the attached probe calibration parameters for 450 MHz muscle. 10. Please find the attached SAR data sheets showing the conversion factors used during the SAR testing. 11. The tissue parameters on the data sheets are measured parameters and not target parameters. 12. Please find the attached warning label to be placed on the radio. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: Symbol Technologies, Inc.

March 8, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: Safe Environment Engineering FCC ID: PZELLP2E-20 731 Confirmation No.: EA946379 Correspondence Reference No.: 22156 Request for Tech. Info.: 3/04/02 Dear Joe: Transmitted herewith, on behalf of Safe Environment Engineering is an amendment provided in response to the request for technical information dated March 4, 2002. 1. Please find the attached mouth SAR plots. 2. Please find the attached user’s manual RF safety page. We trust this information is sufficient for the immediate grant of this application. If you have any further questions, please do not hesitate to contact us. cc: Safe Environment Engineering

© 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM)

© 2001PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

© 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM)

SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz FM Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.13 mW/g, SAR (10g): 1.26 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM Low Channel [403.100MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio back, w/BeltClip Test Date -- 11-02-2001 SAR Tot [mW/g] 2.02E-1 6.07E-1 1.01E+0 1.42E+0 1.82E+0 PCTEST Engineering Laboratory, Inc. SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz FM Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.43 mW/g, SAR (10g): 1.90 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM Mid Channel [438.050MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio back, w/BeltClip Test Date -- 11-02-2001 SAR Tot [mW/g] 2.13E-1 6.38E-1 1.06E+0 1.49E+0 1.91E+0 PCTEST Engineering Laboratory, Inc. SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz FM Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 3.53 mW/g, SAR (10g): 2.90 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM High Channel [469.650MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio back, w/BeltClip Test Date -- 11-02-2001 SAR Tot [mW/g] 3.38E-1 1.01E+0 1.69E+0 2.37E+0 3.04E+0 PCTEST Engineering Laboratory, Inc. SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz Mouth SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.35 mW/g, SAR (10g): 1.91 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM Low Channel [403.100MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio front Test Date -- 11-02-2001 SAR Tot [mW/g] 2.87E-1 8.62E-1 1.44E+0 2.01E+0 2.58E+0 PCTEST Engineering Laboratory, Inc. SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz Mouth SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 3.08 mW/g, SAR (10g): 2.50 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM Mid Channel [438.050MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio front Test Date -- 11-02-2001 SAR Tot [mW/g] 2.87E-1 8.62E-1 1.44E+0 2.01E+0 2.58E+0 PCTEST Engineering Laboratory, Inc. SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz Mouth SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 4.23 mW/g, SAR (10g): 3.50 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM High Channel [469.650MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio front Test Date -- 11-02-2001 SAR Tot [mW/g] 3.83E-1 1.15E+0 1.91E+0 2.68E+0 3.45E+0 PCTEST Engineering Laboratory, Inc.

© 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM) © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 NVLAP Lab Code: 100431-0 Personal Safety Monitor (PSM)

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) SAFE ENVIRONMENT ENGINEERING Dates of Tests: November 1-2, 2001 25061 West Avenue Stanford, #30 Test Report S/N: SAR.211010614.PZE Valencia, CA 91355 Test Site: PCTEST Lab, Columbia, MD USA Attn: David M. Lamensdorf, President FCC ID PZELLP2E-20 APPLICANT SAFE ENVIRONMENT ENGINEERING EUT Type: Personal Safety Monitor (PSM) Tx/Rx Frequency Range: 403 ~ 512 MHz Max. RF Output Power: 2.0 W Max. SAR Measurement: 3.53mW/g AMPS Body SAR; 4.23mW/g AMPS Mouth SAR Trade Name/Model(s): Life line LLP2E-20 FCC Classification: Licensed Non-Broadcast Transmitter Held to Face (TBF) FCC Rule Part(s): §2.1093; FCC/OET Bulletin Supplement C [July 2001] Application Type: Certification This wireless portable device has been shown to be capable of continued compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992 and IEEE Std. 1528 (Draft Aug.2000). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 211010614.PZE SAR Measurement Report FCC Part 90 Certification © 2001 PCTEST Lab i Table of Contents 1.1 SCOPE 1 2.1 INTRODUCTION / SAR DEFINITION 2 3.1 SAR MEASUREMENT SET-UP 3 4.1 E-FIELD PROBE SYSTEM 4 5.1 E-FIELD PROBE CALIBRATION PROCESS 5-6 6.1 PHANTOM, HOLDER, & EQUIVALENT TISSUE 7 7.1 SYSTEM SPECIFICATIONS 8 8.1 MEASUREMENT PROCESS 9 9.1 HEAD SAR TEST POSITIONS OF THE PHONE 10 10.1 BODY SAR TEST SETUP 11 11.1 ANSI/IEEE C95.1 RF EXPOSURE LIMITS 12 12.1 MEASUREMENT UNCERTAINTIES 13 13.1 TEST DATA SUMMARY 14-15 14.1 SAR TEST EQUIPMENT LIST 16 15.1 CONCLUSION 17 16.1 REFERENCES 18 Test Report S/N: SAR.211010614.PZE SAR Measurement Report Test Date(s): November 1-2, 2001 FCC Part 90 Certification © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 1 Personal Safety Monitor (PSM) SAR MEASUREMENT REPORT 1.1 Scope Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human head and body tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 Company Name: SAFE ENVIRONMENT ENGINEERING Address: 25061 West Avenue Stanford, #30 Valencia, CA 91355 Attention: David M. Lamensdorf, President • EUT Type: Personal Safety Monitor (PSM) • Trade Name / Model: Life line LLP2E-20 • FCC IDENTIFIER: PZELLP2E-20 • Tx/Rx Frequency Range: 403 ~ 512 MHz • FCC Classification: Licensed Non-Broadcast Transmitter Held to Face (TBF) • Modulation(s): AMPS • FCC Rule Part(s): §2.1093, OET Bulletin 65, Supplement C (July 2001) • Max. RF Output Power: 2.0W • Max SAR Measurement: 3.53mW/g AMPS Body SAR 4.23mW/g AMPS Mouth SAR • Application Type: Certification • Dates of Tests: November 1-2, 2001 Place of Tests: PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.211010614.PZE 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET Docket 93-62. Fig. 1 SAR Test Setup Test Report S/N: SAR.211010614.PZE SAR Measurement Report Test Date(s): November 1-2, 2001 FCC Part 90 Certification © 2001 PCTEST Lab Safe Environment FCC ID: PZELLP2E-20 2 Personal Safety Monitor (PSM) 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects and Exposure Criteria for Radiofrequency Electromagnetic Fields,” NCRP Report No. 86 (c) NCRP, 1986, Bethesda, MD 20814.[5] SAR is a measure of the rate of energy absorption due to exposure to an RF transmitting source. SAR values have been related to threshold levels for potential biological hazards. 2.2 SAR Definition Specific Absorption Rate (SAR) is defined as the time derivative (rate) of the incremental energy (dU) absorbed by (dissipated in) an incremental mass (dm) contained in a volume element (dV) of a given density (ρ). It is also defined as the rate of RF energy absorption per unit mass at a point in an absorbi…

Text truncated - open the document above for the full version.

Probe ET3DV6 SN:1560 Manufactured:December 1, 2000 Calibrated:February 20, 2001 Calibrated for System DASY3 Page 1 of 8 ET3DV6 SN:1560 DASY3 - Parameters of Probe: ET3DV6 SN:1560 Sensitivity in Free SpaceDiode Compression NormX1.48 μV/(V/m) 2 DCP X98mV NormY1.51 μV/(V/m) 2 DCP Y98mV NormZ1.43 μV/(V/m) 2 DCP Z98mV Sensitivity in Tissue Simulating Liquid Head450MHz ε r =43.5 ± 5% σ = 0.87 ± 10% mho/m ConvF X7.17 extrapolatedBoundary effect: ConvF Y7.17 extrapolatedAlpha0.25 ConvF Z7.17 extrapolatedDepth3.21 Head900MHz ε r =42 ± 5% σ = 0.97 ± 10% mho/m ConvF X6.59 ± 7% (k=2)Boundary effect: ConvF Y6.59 ± 7% (k=2)Alpha0.32 ConvF Z6.59 ± 7% (k=2)Depth2.93 Head1500MHz ε r =40.4 ± 5% σ = 1.23 ± 10% mho/m ConvF X5.82 interpolatedBoundary effect: ConvF Y5.82 interpolatedAlpha0.41 ConvF Z5.82 interpolatedDepth2.55 Head1800MHz ε r =40 ± 5% σ = 1.40 ± 10% mho/m ConvF X5.43 ± 7% (k=2)Boundary effect: ConvF Y5.43 ± 7% (k=2)Alpha0.46 ConvF Z5.43 ± 7% (k=2)Depth2.36 Sensor Offset Probe Tip to Sensor Center2.7mm Optical Surface Detection2.0 ± 0.2mm Page 2 of 8 ET3DV6 SN:1560 Receiving Pattern (φ), θ = 0° f = 30 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 100 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 300 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 900 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot Page 3 of 8 ET3DV6 SN:1560 Isotropy Error (φ), θ = 0° -1.00 -0.80 -0.60 -0.40 -0.20 0.00 0.20 0.40 0.60 0.80 1.00 060120180240300360 error[dB] 30 MHz 100 MHz 300 MHz 900 MHz 1800 MHz 2500 MHz f = 1800 MHz, WG R22 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 2500 MHz, WG R26 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot Page 4 of 8 ET3DV6 SN:1560 Frequency Response of E-Field ( TEM-Cell:ifi110, Waveguide R22) 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50 050010001500200025003000 f [MHz] frequency response TEMR22 Page 5 of 8 ET3DV6 SN:1560 Dynamic Range f(SAR brain ) ( TEM-Cell:ifi110 ) ET3DV6 SN:1560 1.E+0 1.E+1 1.E+2 1.E+3 1.E+4 1.E+5 1.E+6 1.E+7 0.00010.0010.010.11.10.100. mW/cm 3 μ V not compensatedcompensated -2.0 -1.0 0.0 1.0 0.0010.010.1110100 mW/cm 3 errror[dB] Page 6 of 8 Conversion Factor Assessment Head900MHz ε r =42 ± 5% σ = 0.97 ± 10% mho/m ConvF X6.59 ± 7% (k=2)Boundary effect: ConvF Y6.59 ± 7% (k=2)Alpha0.32 ConvF Z6.59 ± 7% (k=2)Depth2.93 Head1800MHz ε r =40 ± 5% σ = 1.40 ± 10% mho/m ConvF X5.43 ± 7% (k=2)Boundary effect: ConvF Y5.43 ± 7% (k=2)Alpha0.46 ConvF Z5.43 ± 7% (k=2)Depth2.36 ET3DV6 SN:1560 f = 900 MHz, WG R9 (head) 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 0204060 z[mm] SAR[mW/cm 3 ] / W AnalyticalMeasuremets f = 1800 MHz, WG R22 (head) 0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00 0204060 z[mm] SAR[mW/cm 3 ] / W AnalyticalMeasuremets Page 7 of 8 Deviation from Isotropy in HSL Error (θ,φ), f = 900 MHz 0 40 80 120 160 200 240 280 320 0 10 20 30 40 50 60 -1.00 -0.80 -0.60 -0.40 -0.20 0.00 0.20 0.40 0.60 0.80 1.00 Error [dB] θ φ -1.00--0.80-0.80--0.60-0.60--0.40-0.40--0.20-0.20-0.00 0.00-0.200.20-0.400.40-0.600.60-0.800.80-1.00 Page 8 of 8

835MHz Muscle Dipole Validation Generic Twin Phantom; Flat Section; Probe: ET3DV5 - SN1560 -- Probe Cal Date 20/02/01 Med. Parameters 835 MHz Muscle: σ = 0.97 mho/m ε r = 55.2 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.16 mW/g, SAR (10g): 1.44 mW/g 835MHz Muscle Dipole Validation (D835V2 S/N: 406) Frequency: 835 MHz; Antenna Input Power: 250 [mW] PCTEST Muscle Tissue Simulating Liquid SAR Tot [mW/g] 2.17E-1 6.59E-1 1.08E+0 1.56E+0 1.99E+0 PCTEST Engineering Laboratory, Inc.

Probe ET3DV6 SN:1560 Manufactured:December 1, 2000 Calibrated:February 20, 2001 Calibrated for System DASY3 Page 1 of 8 ET3DV6 SN:1560 DASY3 - Parameters of Probe: ET3DV6 SN:1560 Sensitivity in Free SpaceDiode Compression NormX1.48 μV/(V/m) 2 DCP X98mV NormY1.51 μV/(V/m) 2 DCP Y98mV NormZ1.43 μV/(V/m) 2 DCP Z98mV Sensitivity in Tissue Simulating Liquid Head450MHz ε r =43.5 ± 5% σ = 0.87 ± 10% mho/m ConvF X7.17 extrapolatedBoundary effect: ConvF Y7.17 extrapolatedAlpha0.25 ConvF Z7.17 extrapolatedDepth3.21 Head900MHz ε r =42 ± 5% σ = 0.97 ± 10% mho/m ConvF X6.59 ± 7% (k=2)Boundary effect: ConvF Y6.59 ± 7% (k=2)Alpha0.32 ConvF Z6.59 ± 7% (k=2)Depth2.93 Head1500MHz ε r =40.4 ± 5% σ = 1.23 ± 10% mho/m ConvF X5.82 interpolatedBoundary effect: ConvF Y5.82 interpolatedAlpha0.41 ConvF Z5.82 interpolatedDepth2.55 Head1800MHz ε r =40 ± 5% σ = 1.40 ± 10% mho/m ConvF X5.43 ± 7% (k=2)Boundary effect: ConvF Y5.43 ± 7% (k=2)Alpha0.46 ConvF Z5.43 ± 7% (k=2)Depth2.36 Sensor Offset Probe Tip to Sensor Center2.7mm Optical Surface Detection2.0 ± 0.2mm Page 2 of 8 ET3DV6 SN:1560 Receiving Pattern (φ), θ = 0° f = 30 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 100 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 300 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 900 MHz, TEM cell ifi110 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot Page 3 of 8 ET3DV6 SN:1560 Isotropy Error (φ), θ = 0° -1.00 -0.80 -0.60 -0.40 -0.20 0.00 0.20 0.40 0.60 0.80 1.00 060120180240300360 error[dB] 30 MHz 100 MHz 300 MHz 900 MHz 1800 MHz 2500 MHz f = 1800 MHz, WG R22 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot f = 2500 MHz, WG R26 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 XYZTot Page 4 of 8 ET3DV6 SN:1560 Frequency Response of E-Field ( TEM-Cell:ifi110, Waveguide R22) 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50 050010001500200025003000 f [MHz] frequency response TEMR22 Page 5 of 8 ET3DV6 SN:1560 Dynamic Range f(SAR brain ) ( TEM-Cell:ifi110 ) ET3DV6 SN:1560 1.E+0 1.E+1 1.E+2 1.E+3 1.E+4 1.E+5 1.E+6 1.E+7 0.00010.0010.010.11.10.100. mW/cm 3 μ V not compensatedcompensated -2.0 -1.0 0.0 1.0 0.0010.010.1110100 mW/cm 3 errror[dB] Page 6 of 8 Conversion Factor Assessment Head900MHz ε r =42 ± 5% σ = 0.97 ± 10% mho/m ConvF X6.59 ± 7% (k=2)Boundary effect: ConvF Y6.59 ± 7% (k=2)Alpha0.32 ConvF Z6.59 ± 7% (k=2)Depth2.93 Head1800MHz ε r =40 ± 5% σ = 1.40 ± 10% mho/m ConvF X5.43 ± 7% (k=2)Boundary effect: ConvF Y5.43 ± 7% (k=2)Alpha0.46 ConvF Z5.43 ± 7% (k=2)Depth2.36 ET3DV6 SN:1560 f = 900 MHz, WG R9 (head) 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 0204060 z[mm] SAR[mW/cm 3 ] / W AnalyticalMeasuremets f = 1800 MHz, WG R22 (head) 0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00 0204060 z[mm] SAR[mW/cm 3 ] / W AnalyticalMeasuremets Page 7 of 8 Deviation from Isotropy in HSL Error (θ,φ), f = 900 MHz 0 40 80 120 160 200 240 280 320 0 10 20 30 40 50 60 -1.00 -0.80 -0.60 -0.40 -0.20 0.00 0.20 0.40 0.60 0.80 1.00 Error [dB] θ φ -1.00--0.80-0.80--0.60-0.60--0.40-0.40--0.20-0.20-0.00 0.00-0.200.20-0.400.40-0.600.60-0.800.80-1.00 Page 8 of 8

SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz FM Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01; ConF(7.65,7.65,7.65) Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.13 mW/g, SAR (10g): 1.26 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM Low Channel [403.100MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio back, w/BeltClip Test Date -- 11-02-2001 SAR Tot [mW/g] 2.02E-1 6.07E-1 1.01E+0 1.42E+0 1.82E+0 PCTEST Engineering Laboratory, Inc. SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz FM Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01; ConF(7.65,7.65,7.65) Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.43 mW/g, SAR (10g): 1.90 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM Mid Channel [438.050MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio back, w/BeltClip Test Date -- 11-02-2001 SAR Tot [mW/g] 2.13E-1 6.38E-1 1.06E+0 1.49E+0 1.91E+0 PCTEST Engineering Laboratory, Inc. SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz FM Body SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01; ConF(7.65,7.65,7.65) Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 3.53 mW/g, SAR (10g): 2.90 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM High Channel [469.650MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio back, w/BeltClip Test Date -- 11-02-2001 SAR Tot [mW/g] 3.38E-1 1.01E+0 1.69E+0 2.37E+0 3.04E+0 PCTEST Engineering Laboratory, Inc. SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz Mouth SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01; ConF(7.65,7.65,7.65) Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.35 mW/g, SAR (10g): 1.91 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM Low Channel [403.100MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio front Test Date -- 11-02-2001 SAR Tot [mW/g] 2.87E-1 8.62E-1 1.44E+0 2.01E+0 2.58E+0 PCTEST Engineering Laboratory, Inc. SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz Mouth SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01; ConF(7.65,7.65,7.65) Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 3.08 mW/g, SAR (10g): 2.50 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM Mid Channel [438.050MHz]; Flat Phantom Conducted Power = 2Watts; Spacing = 2.0cm from flat phantom to radio front Test Date -- 11-02-2001 SAR Tot [mW/g] 2.87E-1 8.62E-1 1.44E+0 2.01E+0 2.58E+0 PCTEST Engineering Laboratory, Inc. SAFE ENVIRONMENT Model: LLP2E-20 -- 450MHz Mouth SAR Generic Twin Phantom; Flat Section; Probe: ET3DV6 - SN1560 -- Probe Cal Date 20/02/01; ConF(7.65,7.65,7.65) Med. Parameters 450 MHz Muscle: σ = 0.94 mho/m ε r = 56.7 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 4.23 mW/g, SAR (10g): 3.50 mW/g SAFE ENVIRONMENT ENGINEERING Portable Radio Model:LLP2E-20 FM High Channel [469.650MHz]; Flat Phantom Conducted Power …

Text truncated - open the document above for the full version.
