PZK-02020TBaby's Quiet Sounds Movement & Sound Monitor

PZK-02020T Exterior Photos Page 1 of 4 EUT Top View PZK-02020T Exterior Photos Page 2 of 4 EUT Bottom View PZK-02020T Exterior Photos Page 3 of 4 EUT Rear View PZK-02020T Exterior Photos Page 4 of 4 Sensor Pad and Tubing/Cables

FCC ID:PZK-02020T Label Location This photo is for location information only, actual label will be molded into the equipment.

PZK-02020T Interior Photos Page 1 of 7 EUT Sensor Pad connector board Component Side PZK-02020T Interior Photos Page 2 of 7 EUT Sensor Pad connector board Solder Side PZK-02020T Interior Photos Page 3 of 7 Inside Top Housing, showing microphone connector and wiring. PZK-02020T Interior Photos Page 4 of 7 Inside View showing component side of motion sensor/RF board. PZK-02020T Interior Photos Page 5 of 7 Component Side of Motion Sensor/RF board PZK-02020T Interior Photos Page 6 of 7 Solder Side of Motion Sensor/ RF board PZK-02020T Interior Photos Page 7 of 7 Antenna and connection

Compliance Worldwide, Inc. – 357 Main Street – Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 334-02 TEST REPORT TO INDUSTRY CANADA RSS 210 SECTION 8.6.2 FEDERAL COMMUNICATIONS COMMISSION CFR47 PART15.235 Low Power License-Exempt Radio communication Devices Intentional Radiators for Summer Infant Products 6 Blackstone Valley Place Lincoln, RI 02865 (401) 334 9966 of 49 MHz Sound and Movement Monitor 02020 FCC ID: PZK-02020T on 11/20/02 Tested by Clifton P. Brick Reviewed by Larry K. Stillings This report may not be duplicated, except in full without written permission from Compliance Worldwide, Inc. Page 2 of 26 Compliance Worldwide, Inc. – 357 Main Street – Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 334-02 TABLE OF CONTENTS • Test Description • Test Results and Conclusions • Test Procedures • RSS 210 /Part 15 Subpart C Test Limits • Test Facility Description • Test Setup and Connection Information • Test Measurements and Results Radiated Measurements Radiated Output Power & Occupied Bandwidth Conducted Measurements • Notes and Comments • Photographs Radiated Test Setup (Front & Rear) Conducted Test Setup (Front & Rear) Exterior and Interior Photographs of Product Page 3 of 26 Compliance Worldwide, Inc. – 357 Main Street – Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 334-02 TEST DESCRIPTION 1. TEST OBJECTIVE To test the 49 MHz Sound and Movement 02020 Tx to RSS 210 / Part 15 Subpart C Rules and write a report. 2. E.U.T. DESCRIPTION GENERAL The 49 MHz Sound and Movement 02020 Tx is a Baby Monitor Audio and Motion sensing system. SERIAL NUMBERS: production prototype Page 4 of 26 Compliance Worldwide, Inc. – 357 Main Street – Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 334-02 TEST RESULTS AND CONCLUSIONS PRODUCT TESTED - 49 MHz Sound and Movement MODEL NUMBER - 02020 Tx RADIATED TEST RESULTS The test results show that the emissions radiated from this equipment are in compliance with IC Rules RSS 210 / FCC Rules Part 15 Subpart C. OCCUPIED BANDWIDTH & OUTPUT POWER The test results show that the occupied bandwidth and output power of this equipment are in compliance with IC Rules RSS 210 / FCC Rules Part 15 Subpart C . CONDUCTED TEST RESULTS The test results show that the emissions conducted through the power line from this equipment are in compliance with IC Rules RSS 210 / FCC Rules Part 15 Subpart C. ANALYSIS AND CONCLUSIONS Based upon the radiated and conducted measurements we find that this equipment is within the limits of the IC Rules RSS 210 / FCC Rules Part 15 Subpart C. All results are based on a test of one sample, and represent other production units, only in as much as a sample represents other production units. If any significant changes are made to the unit, the changes shall be evaluated and a retest may be required. NOTES (Special conditions unique to this test) Please note the last paragraph on page 6. Page 5 of 26 Compliance Worldwide, Inc. – 357 Main Street – Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 334-02 TEST PROCEDURES 1. TEST EQUIPMENT A. HP 8546A (9 kHz - 6.5 GHz) EMI Receiver w/ RF Filter Section, S/N 3704A00323 / 3650A00360. Calibration Date 10-25-2002, calibrated annually. B. Com-Power Biconilog Antenna, Model AC220, S/N 25509. Calibration Date 12-14-2001, calibrated annually. C. EMCO LISN, Model EM 3825/2, S/N 9109-1860. Calibration Date: 3-11-2002, calibrated annually. 2. FREQUENCY RANGE TO BE SCANNED. A. Radiated Test from 30 MHz to 40 GHz (or the 10 th harmonic of the highest frequency whichever is lower). B. Conducted Test from 450 kHz to 30 MHz. Page 6 of 26 Compliance Worldwide, Inc. – 357 Main Street – Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 334-02 3. TEST PROCEDURES. Radiated test procedure: The EUT, associated cables and peripheral devices are placed on the supporting table and any support equipment is placed off the site. The EUT is turned on and any necessary operating or test software installed and allowed to warm up. The EUT is pre-scanned in our ferrite tile lined chamber where it is rotated 360 degrees and examined in both horizontal and vertical polarization, all emission frequencies are identified and recorded. The EUT is then moved to the OATS and the frequency band from 30 MHz to 40 GHz is scanned, all frequencies identified in the chamber are investigated, as well as harmonic frequencies of the EUT. When an emission is found the emission is maximized by varying the bundle position of the connecting cables, the antenna height, the antenna polarization (vertical and horizontal) and the table orientation (360 degrees). The maximum reading is recorded and the next signal is searched for. Conducted test procedure: The power line of the EUT is connected to the LISN (Line Impedance Stabilization Network). A measurement of the emissions are made from the power line for both phase and neutral on the analyzer in the frequency range from 450 kHz to 30 MHz. The maximum readings are recorded for each phase. All measurements are made according to the procedures defined in: "ANSI C63.4-1992 Standard Methods of Measurement of Radio Noise Emissions from Low-Voltage Electrical and Electronics Equipment in the Range of 9 kHz to 40 GHz, American National Standard for (ISBN 1- 55937-215-5). Page 7 of 26 Compliance Worldwide, Inc. – 357 Main Street – Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 334-02 FCC PART 15 and RSS 210 TEST LIMITS 1. RSS 210 Section 6.2.2, Table 3 Radiation Limits (Quasi-Peak): FCC Part 15.209, 15.235, 15.249 Radiation Limits (Quasi-Peak): Frequency MHz Distance meters Limit dBμV/m Limit μV/m 1.705 - 30 30 29.5* 30* 30 - 88 3 40.0 100 49.82 - 49.90 3 80.0* 10,000* 88 - 216 3 43.5 150 216 - 960 3 46.0 200 902 - 928 3 94.0* 50,000* 960 - 1000 3 54.0 500 1000 - 40000 3 54.0* 500* *N…

Text truncated - open the document above for the full version.

PZK-02020T Setup Photos Page 1 of 4 Conducted Test Setup Front View PZK-02020T Setup Photos Page 2 of 4 Conducted Test Setup Rear View PZK-02020T Setup Photos Page 3 of 4 Radiated Test Setup Rear View, worst case orthogonal plane shown. PZK-02020T Setup Photos Page 4 of 4 Radiated Test Setup Front View
