PZK-02300Baby Monitor

Thank you for buying the Secure Sounds™ 2.4 GHz Digital Monitor from Summer Infant. This audio monitor is a great addition to any home. The 2.4 GHz digital technology reduces interference and provides a secure and private transmission. The Parent’s Unit features volume control, sound lights, low battery indicator, out of range indicator and convenient belt clip. SECURE SOUNDS ™ DIGITAL AUDIO MONITOR FCC Information This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by Summer Infant Inc. may void the user’s authority to operate the equipment. Use only the AC adaptors included with this product. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed or used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interface by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and the receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help 4 1 Summer Infant, Inc. Monitor Warranty Policy Summer Infant, Inc. will repair or replace (at our option) your unit free of charge for 12 months from the date of purchase if the unit is defective in workmanship or materials. To claim your repair/replacement, the product must be returned to Summer Infant along with a copy of the original purchase receipt. In the absence of the purchase receipt, the warranty will be 12 months from the date of manufacture. This warranty does not apply to normal wear or damage from misuse, abuse, improper storage and handling, installation, accident, unauthorized repair or alteration. Please contact our Customer Service Department by phone at 1-800-268-6237 or via email at [email protected] for details. We at Summer Infant stand behind all of our products. If you are not completely satisfied or have any questions, please contact our Customer Service Department at 1-800-268-6237 or e-mail us at [email protected]. Summer Infant Europe, LTD. 20 Sparrows Herne Bushey, Hertfordshire WD23 1FX UK 44 (0)20 8420 4429 Summer Infant, Inc. 582 Great Road PO Box 829 Slatersville, RI 02876-0899 USA 1-800-268-6237 Feel free to contact us at the below phone number or email if you should need to order replacement or additional products. © 2005 Summer Infant, Inc. Colors and styles may vary. MADE IN CHINA. Please retain information for future reference. 9/06 Please read the following instructions and warnings carefully. Keep this instruction manual for future reference. In portable mode, Parent’s Unit requires 3 AAA batteries (not included). For Technical Support Call 1-800-268-6237 or E-Mail at [email protected] For use with children from birth and up. WARNING: Adult assembly required. Keep small parts away from children when assembling. 0 2 3 0 0 WARNING: THIS PRODUCT CANNOT REPLACE RESPONSIBLE ADULT SUPERVISION. • Prevent cord entanglement – do not place Baby’s Unit in crib or within arm’s reach of baby. Never use extension cords with AC adapters. Only use the AC Adapters provided. • When an AC Adapter is plugged into an electrical outlet, do not touch the exposed end. • Test monitor before first use, periodically, and when changing location of the Baby’s Unit or Parent’s Unit. • Do not use monitor near water (such as bathtub, sink, etc.). • Keep monitor away from heat sources (such as stoves, radiators, etc.) and make sure there is proper ventilation (not on sofas, cushions, beds, etc. which may block ventilation). • Nursery monitors use public airwaves to transmit and receive signals. This monitor may pick up signals from other monitors or similar devices, and signals broadcast by this monitor may be picked up by other receivers. • This product is not a toy. Do not allow children to play with it. • Adult assembly required. Exercise care when unpacking and assembling product. 2 BATTERY WARNING: • Do not mix old and new batteries. • Do not mix alkaline, standard, or rechargeable batteries. • Remove batteries when product is stored for long period of time or when batteries are exhausted. • Dispose of exhausted batteries properly. To use the Parent’s Unit in Portable Mode: For use in portable mode, the Parent’s Unit requires 3 ”AAA” batteries (Figure B). Press and slide down battery compartment door on back of unit and insert batteries . Replace battery compartment door. When the LED above the battery icon on front of unit is flashing, the battery needs to be changed. Belt Clip: For convenience and portability, you can clip the Parent’s Unit to your belt or waistband. 3 S E T U P & U S E : S E T U P & U S E : Parent’s Unit Step 1: Place the Parent’s Unit in the room from which you want to monitor your baby (i.e. bedroom or living room). Plug the AC Adapter into the AC Adapter Jack on the back of the Parent’s Unit and the other end into a standard electrical outlet. Step 2: Press power button for 3 seconds to turn on (Figure A). Power LED will flash slowly when power is on. Step 3: Set Volume to desired level us…

Text truncated - open the document above for the full version.

FCC & IC ID label 39 mm 25 mm

For RF Exposuer (Portable Unit: for controller part) Standard Applicable According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Portable device. Measurement Result: This is a portable device and the Max peak output power is 3.8 dBm (2.042mW) lower than low threshold 60/fGHz mW (25mW), d<2.5cm in general population category； The SAR measurement is not necessary.

Report No.: SZEMO061102490RF Page: 1 of 32 FCC ID: PZK-02300 IC ID: 4400A-02300 Authorized Signature: Robinson Lo Laboratory Manager This report refers to the General Conditions for Inspection and Testing Services, printed overleaf This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the SGS PRODUCT CERTIFICATION MARK.. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. Member of the SGS Group (Société Générale de Surveillance) SGS-CSTC Standards Technical Services Ltd. No.198 Kezhu Road, Science Town Economic& Technology Development District Guangzhou, China 510663 Telephone: +86 (0) 20 8215 5555 Fax: +86 (0) 20 8207 5059 Email: [email protected] TEST REPORT Application No. : SZEMO061102490RF Applicant : Summer Infant, Inc. Manufacturer : 1, New Honest Technologies Ltd. 2, Brain Assets Industries Ltd. FCC ID : PZK-02300 IC ID: : 4400A-02300 Fundamental Frequency : 2.405GHz to 2.470GHz Equipment under Test (EUT): Name : Baby Monitor Model : 02300 Standards : FCC PART 15, SUBPART C and SUBPART B: 2006 :RSS-210 Issue 6 2005 Date of Receipt : 5 December 2006 Date of Test : 5 December 2006 Date of Issue : 6 December 2006 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. FCC ID No.: PZK-02300 IC ID No.: 4400A-02300 Report No.: SZEMO061102490RF Page: 2 of 32 SGS-CSTC Standards Technical Services Ltd. 2 Test Summary Test Test Requirement Stanadard Paragraph Result Occupied Bandwidth FCC PART 15 :2006 RSS-210 Issue 6 Section 15.247 (a2) Section A8.2 PASS Edges Measurement FCC PART 15 2006 RSS-210 Issue 6 Section 15.247 Section A8.5 PASS Maximum Peak Output Power FCC PART 15 :2006 RSS-210 Issue 6 Section 15.247 (b) Section A8.4 PASS Power Spectral Density Measurement FCC PART 15 :2006 RSS-210 Issue 6 Section 15.247 (d) Section A8.2 PASS Spurious Radiated Emission (30MHz to 25GHz) FCC PART 15 :2006 RSS-210 Issue 6 Section 15.109 / 15.209 / 15.247 (C) Section A8.5 PASS Conducted Emissions FCC PART 15:2006 RSS-210 Issue 6 Section 15.107 / 15.207 Seection 7.2.2(RSS- GEN) PASS Antenna requirement. FCC PART 15:2006 RSS-210 Issue 6 Section 15.247 (b) Seection 7.1.4(RSS- GEN) PASS FCC ID No.: PZK-02300 IC ID No.: 4400A-02300 Report No.: SZEMO061102490RF Page: 3 of 32 SGS-CSTC Standards Technical Services Ltd. 3 Contents Page 1 COVER PAGE........................................................................................................................................................1 2 TEST SUMMARY....................................................................................................................................................2 3 CONTENTS..............................................................................................................................................................3 4 GENERAL INFORMATION....................................................................................................................................4 4.1 CLIENT INFORMATION.......................................................................................................................................4 4.2 DETAILS OF E.U.T............................................................................................................................................4 4.3 TEST LOCATION................................................................................................................................................5 4.4 OTHER INFORMATION REQUESTED BY THE CUSTOMER..................................................................................5 5 TEST RESULTS......................................................................................................................................................6 5.1 TEST INSTRUMENTS..........................................................................................................................................6 5.2 E.U.T. OPERATION...........................................................................................................................................6 5.3 TEST PROCEDURE & MEASUREMENT DATA....................................................................................................7 5.3.1 Conducted Emissions................................................................................................................................7 5.3.2 Spurious Radiated Emissions................................................................................................................11 5.3.3 Bandwidth.................................................................................................................................................15 5.3.4 Occupied Bandwidth................................................................................................................................19 5.3.5 Maximum Peak Output Power:..............................................................................................................23 5.3.6 Band Edges Measurement.....................................................................................................................24 5.3.7 Power Spectral Density Measurement..................................................................................................…
