Q2Q-OPL9813Data Collector with GPS and Bluetooth

Data Collector with GPS & Bluetooth OPL 9813 The OPL 9813 is a laser data collector featuring GPS (Global Positioning System) feature, Bluetooth 2.1 communication and time stamp functionality. Preliminary Specifications Manual Opticon OPL 9813 Preliminary Specifications Manual 2 All information subject to change without notice. Document History Model Number: OPL 9813 Specification Number: Edition: 2 Original Spec Number: Date: 2012-02-23 Copyright 2012 Opticon. All rights reserved. This manual may not, in whole or in part, be copied, photocopied, reproduced, translated or converted to any electronic or machine readable form without prior written consent of Opticon. Limited Warranty and Disclaimers PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING OR USING THE PRODUCT. Serial Number A serial number appears on all Opticon products. This official registration number is directly related to the device purchased. Do not remove the serial number from your Opticon device. Removing the serial number voids the warranty. Warranty Unless otherwise agreed in a written contract, all Opticon products are warranted against defects in materials and workmanship for two years after purchase. Opticon will repair or, at its option, replace products that are defective in materials or workmanship with proper use during the warranty period. Opticon is not liable for damages caused by modifications made by a customer. In such cases, standard repair charges will apply. If a product is returned under warranty and no defect is found, standard repair charges will apply. Opticon assumes no liability for any direct, indirect, consequential or incidental damages arising out of use or inability to use both the hardware and software, even if Opticon has been informed about the possibility of such damages. Packaging The packing materials are recyclable. We recommend that you save all packing material to use should you need to transport your data collector or send it for service. Damage caused by improper packaging during shipment is not covered by the warranty. Trademarks Trademarks used are the property of their respective owners. Opticon Inc. and Opticon Sensors Europe B.V. are wholly owned subsidiaries of OPTOELECTRONICS Co., Ltd., 12- 17, Tsukagoshi 4-chome, Warabi-shi, Saitama, Japan 335-0002. TEL +81-(0) 48-446-1183; FAX +81-(0) 48-446-1184 SUPPORT USAEurope Phone: 800-636-0090 Email: [email protected]: [email protected] Web: www.opticonusa.comWeb: www.opticon.com Opticon OPL 9813 Preliminary Specifications Manual 3 Contents 1.Abstract ..................................................................................................................................... 5 2.Overview ................................................................................................................................... 5 3.Physical Features ..................................................................................................................... 6 3.1.Dimensions ....................................................................................................................... 6 3.2.Weight ............................................................................................................................... 6 3.3.Color ................................................................................................................................. 6 4.Environmental Specifications.................................................................................................. 6 4.1.Operating Temperature and Humidity................................................................................ 6 4.2.Storage Temperature and Humidity................................................................................... 6 4.3.IP (dust/water) rating ......................................................................................................... 6 4.4.Drop .................................................................................................................................. 6 4.5.Ambient Light Immunity ..................................................................................................... 7 5.Controls..................................................................................................................................... 8 6.Electrical Specifications........................................................................................................... 8 6.1.Main Battery ...................................................................................................................... 8 6.2.Battery Operating Time and Charging Time ...................................................................... 8 7.Optical Specifications .............................................................................................................. 9 7.1.Laser Scan Specifications ................................................................................................. 9 8.Technical Specifications .......................................................................................................... 9 8.1.Print Contrast Signal (PCS) ............................................................................................... 9 8.2.Minimum Resolution .......................................................................................................... 9 8.3.Scan Area and Resolution ............................................................................................... 10 8.3.1.Depth of Field...........................................................................................................................10 8.4.Pitch, Skew, and Tilt ........................................................................................................ 11 8.4.1.Pitch Angle ...............................................................................................................................11 8.4.2.Skew Angle and Dead Zone ..................…

Text truncated - open the document above for the full version.

July 19, 2012 Telecommunication Certification Body RFI Global Services Ltd Pavilion A Ashwood Park Ashwood Way Basingstoke Hampshire RG23 8BG England Subject: Certification Application FCC ID: Q2Q-OPL9813 It is requested that the following information is to be held confidential on behalf of Opticon Sensors Europe B.V., pursuant to sections 0.457d and 0.459 of the CFR 47. Exhibit Category File Name Number of pages Parts List/BOM BOM_A1109190B.pdf 3 Parts List/BOM BOM_B1109190D.pdf 2 Block diagram Schematics Operational Description M3767.pdf OPL-9813 - REV 3.pdf OPL-9813 Operational Description[3].pdf 4 6 3 Above mentioned documents contain trade secrets and proprietary information not customarily released to the public. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Yours sincerely, Gilles van den Berge (Senior Quality Assurance Engineer)

Made in China Manufactured: Xxxxxxxx 20xx PN: SN: 12953 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. *000001* FCC ID: Q2Q-OPL9813 OPL-9813 LASER RADIATION CLASS 2 LASER PRODUCT Wavelength 650nm DO NOT STARE INTO BEAM IEC60825-1:2007 Maximum output 1.0mW Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: OPL-9813 FCC ID: Q2Q-OPL9813 To: FCC Part 15.247: 2011 Subpart C Test Report Serial No.: RFI-RPT-RP85982JD01A V2.0 Version 2.0 Supersedes All Previous Versions This Test Report Is Issued Under The Authority Of John Newell, Group Quality Manager: Checked By: Ian Watch Signature: Date of Issue: 25 July 2012 The Bluetooth ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by RFI Global Services Ltd. is under licence. Other trademarks and trade names are those of their respective owners. This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may not be reproduced other than in full, except with the prior written approval of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. TEST REPORT SERIAL NO: RFI-RPT-RP85982JD01A V2.0 VERSION NO. 2.0 ISSUE DATE: 25 JULY 2012 Page 2 of 36 RFI Global Services Ltd This page has been left intentionally blank. TEST REPORT SERIAL NO: RFI-RPT-RP85982JD01A V2.0 VERSION NO. 2.0 ISSUE DATE: 25 JULY 2012 RFI Global Services Ltd Page 3 of 36 Table of Contents 1. Customer Information .................................................................................................................4 2. Summary of Testing ....................................................................................................................5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 6 2.4. Deviations from the Test Specification 6 3. Equipment Under Test (EUT) .....................................................................................................7 3.1. Identification of Equipment Under Test (EUT) 7 3.2. Description of EUT 7 3.3. Modifications Incorporated in the EUT 7 3.4. Additional Information Related to Testing 8 3.5. Support Equipment 9 4. Operation and Monitoring of the EUT during Testing ............................................................10 4.1. Operating Modes 10 4.2. Configuration and Peripherals 10 5. Measurements, Examinations and Derived Results ...............................................................11 5.1. General Comments 11 5.2. Test Results 12 5.2.1. Receiver/Idle Mode AC Conducted Spurious Emissions 12 5.2.2. Receiver/Idle Mode Radiated Spurious Emissions 15 5.2.3. Transmitter 20 dB Bandwidth 19 5.2.4. Transmitter Carrier Frequency Separation 21 5.2.5. Transmitter Number of Hopping Frequencies and Average Time of Occupancy 22 5.2.6. Transmitter Maximum Peak Output Power 24 5.2.7. Transmitter Radiated Emissions 26 5.2.8. Transmitter Band Edge Radiated Emissions 32 6. Measurement Uncertainty ........................................................................................................35 Appendix 1. Test Equipment Used ..............................................................................................36 TEST REPORT SERIAL NO: RFI-RPT-RP85982JD01A V2.0 VERSION NO. 2.0 ISSUE DATE: 25 JULY 2012 Page 4 of 36 RFI Global Services Ltd 1. Customer Information Company Name: Opticon Sensors Europe Address: Opaallaan 35 2132 XV Hoofddorp Netherlands TEST REPORT SERIAL NO: RFI-RPT-RP85982JD01A V2.0 VERSION NO. 2.0 ISSUE DATE: 25 JULY 2012 RFI Global Services Ltd Page 5 of 36 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.247 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart C (Intentional Radiators) - Section 15.247 Specification Reference: 47CFR15.107 and 47CFR15.109 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart B (Unintentional Radiators) - Sections 15.107 and 15.109 Specification Reference: 47CFR15.207 and 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications) 2011: Part 15 Subpart C (Intentional Radiators) - Sections 15.207 and 15.209 Site Registration: FCC: 209735 Location of Testing: RFI Global Services Ltd, Wade Road, Basingstoke, Hampshire, RG24 8AH. Test Dates: 29 March 2012 to 25 April 2012 2.2. Summary of Test Results FCC Reference (47CFR) Measurement Result Part 15.107(a) Receiver/Idle Mode AC Conducted Emissions Part 15.109 Receiver/Idle Mode Radiated Spurious Emissions Part 15.247(a)(1) Transmitter 20 dB Bandwidth Part 15.247(a)(1) Transmitter Carrier Frequency Separation Part 15.247(a)(1)(iii) Transmitter Number of Hopping Frequencies and Average Time of Occupancy Part 15.247(b)(1) Transmitter Maximum Peak Output Power Part 15.247(d) & 15.209(a) Transmitter Radiated Emissions Part 15.247(d) & 15.209(a) Transmitter Band Edge Radiated Emissions Key to Results = Complied = Did not comply TEST REPORT SERIAL NO: RFI-RPT-RP85982JD01A V2.0 VERSION NO. 2.0 ISSUE DATE: 25 JULY 2012 Page 6 of 36 RFI Global Services Ltd 2.3. Methods and Procedures Reference: ANSI C63.4 (2009) Title: American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz Reference: ANSI C63.10 (2009) Title: American National Standard for Testing Unlicensed Wireless Devices 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: RFI-RPT-RP85982JD01A V2.0 VERSION NO. 2.0 ISSUE DATE: 25 JULY 2012 RFI Global Services Ltd Page 7 of 36 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Brand Name: Opticon Model Name or Number: OPL-9813 Serial Number: ES000001 (Radiated sample #1); ES000002 (Radiated sample #2); ES000003 (Conducted RF port sample) Hardware Version Number: OP1110_c…

Text truncated - open the document above for the full version.
