Q4X-HHTU1LMR UHF TRANSCEIVER

1 Frequency Synthesized Handy Transceiver 308S0625/1/06, 16:15Page 1Adobe PageMaker 6.5C/PPC 2 Introduction Thank you for purchasing our synthesized Handy Transceiver. Your unit has been manufactured and checked under the strictest possible quality con- trol to ensure that each unit leaves the factory in perfect condition. If in the unlikely event you find any defects or have any problem, please contact your dealer, our branch or service center. Please read this manual carefully to obtain maximum performance & extended service life from the unit. Features Very compact and rugged construction The transceiver is housed entirely in a high-impact polycarbonate (PC) cabinet and strengthened by an alloy chassis to achieve professional grade ruggedness required in most applications. Rubber gasket seals around all ex- ternal controls & connectors keep out dust, rain or spray, assuring years of reliable operation even in harsh environment. Easy programming The channel frequencies, CTCSS/DCS codes, key functions and scan sequence can be programmed using PC. Programmable keys There are three feature keys which can be programmed to select Hi-Lo power level, normal or deep squelch, talkaround function, monitor function, enable and disable VOX, showing battery status, starts or ends scanning and direct access to certain channels. MultiTalk In addition to the PTT button, the three feature keys can be programmed to transmit on different channels for easy access to different parties without the need to turn the channel selector. Scanning Scanning can be selectable between normal sequential scan or priority scan via software. 308S0625/1/06, 16:15Page 2Adobe PageMaker 6.5C/PPC 3 Light weight When equipped with the TLB-20 Li-ion battery pack, the whole trans- ceiver weights only 330g. a. Helical Rubber Antenna ................................................................................ 1 b. TNB-18 7.2V 1100mAh Ni-mH Battery Pack with belt clip ......................... 1 c. TSC-10 Slow Charge Cradle with AC adapter ............................................. 1 d. Main unit ........................................................................................................ 1 e. User manual .................................................................................................. 1 Standard Accessories a.b.c.d.e. Precautions Do not expose your transceiver unit to environment with extreme temperature, humidity or dust. Do not attempt to open the cabinet, there is no serviceable parts inside. In case of defects, please consult your dealer, our branch or service center. When the transceiver is left unused for a long period of time, it is rec- ommended to detach the battery pack from the main body. The unit should be protected from excessive vibrations, mechanical impact or strong electromagnetic field. 308S0625/1/06, 16:15Page 3Adobe PageMaker 6.5C/PPC 4 GETTING PREPARED Battery When the battery is new or its charge level is very low, it is necessary to charge the battery before use to ensure optimum capacity and performance. Always charge a new battery 14–16 hours before initial use. When charging a battery attached to the transceiver, switch off the transceiver to ensure a full charge. It is recommended the battery should be at room temperature (about 25°C) when charging. Too cold temperature (below 10°C) may result in leakage of electrolyte and ultimately in failure of battery. Too high temperature (above 35°C) may reduce discharge capacity and affect the performance of the transceiver. TQC-70 Intelligent Desk Top Rapid Charger (optional)/TQC- 76 6 Gang Rapid Charger (optional) 1. Set the position of switch located at the bottom of cradle to suit to the type of battery being charged (Li-ion or Ni-mH. For Ni-mH, also select the battery capacity : 1100mAh or 1600mAh). Incorrect setting may lead to battery not fully charged or cause damage to battery. TSC-10 Slow Charger 1. Switch off the transceiver. 2. Place the battery, either singly or attached to the transceiver, into the slow charge cradle. 3. Plug in the supplied AC adapter to an AC outlet and connect its output plug to the DC jack at the back of the cradle. 4. The power indicator shall light up red. 5. The charging indicator shall light up green, showing the battery is in slow charge mode. If indicator does not light up, probably the battery is not in- serted properly or the battery is damaged. 6. Leave the battery in cradle for 14 -16 hours if it is new or 10-11 hours if it is under re-charge. For Li-ion battery (TLB-20), the charging indicator will goes off once it is fully charged. For Ni-mH battery ( TNB-18/TNB-19), the charg- ing indicator continues to light up green even it is fully charged. 308S0625/1/06, 16:15Page 4Adobe PageMaker 6.5C/PPC 5 Charging LED colourStatus Blinking redBattery improperly inserted or battery is damaged or battery temperature too high or too low. Steady redBattery is in rapid charge mode Steady greenBattery is 90% charged up and is under trickle charging Blinking greenBattery is fully charged 2. Switch off the transceiver. 3. Place the battery, either singly or attached to the transceiver, into the rapid charger cradle. 4. Plug in the switching power supply to an AC outlet and connect its output plug to the DC jack at the back of the cradle. 5. The power indicator shall light up red. 6. The charging indicator shall show following : CONTROLS AND CONNECTORS
        308S0625/1/06, 16:15Page 5Adobe PageMaker 6.5C/PPC 6 1. VOL (Volume) Control Switch on or off the transceiver and adjust the speaker volume. Turn clockwise to increase the volume. 2. CH (Rotary Channel Selector) Control Set the transceiver to operate on different channels. 3. Antenna Connector This connector will accept the supplied helical rubber antenna. Besure to screw in the antenna securely to obtain best performance on reception and transmission. 4. Tx/Busy/Low Battery Indicator The 2-colour LED lights up in red when signal is be…

Text truncated - open the document above for the full version.

Techwall Electronics Co., Ltd. 24lF. Tower i. Tern C€.tre, 237. Qu*n s Road, Ce.iral, Hong Kong. Te 2850 6860 Fax:28506936 E-mai lwailhk@nelvigatof com Cable Add.: TECHWALL i*.4"8+Aqa'sa €;EC,6f ;E+237qi tFrF,l.* E2a?* a;5 : 2a50 6860 El{tF 2850 6936 e+4€ : lwa hk@nelvsalor com .fl : TECHWALL To whom It May Conc€m D€ar sirs, Equipmert : FCC Rdes : 261s,Wt2006 FCC ID :Q4X-HHTUI MT16Ui308SU Part 90 LMR LJHF TrarEceiver we, the manufactuer ofthe captioned equipment, hereby declare as follow : The tr€quercy prognmming capability ofthe unit is defined by the softwarc capsbilities and the manufactursr adlor dcalcr. Prograroming each ladio to opeiate on approved fpquencies only as requesled by the eld user. No user defined ext€mal control programming fimctions are available which allow th€ unit to operate outside the approved tequencies ofoperation- The TLC-19 ad TLC-20 carrying cas€ arejust viryl clver to proteat the radio. The bett clip use.d during the testing is the clip or the bctery pack The unit demonstrates c.mpliance to the RF exposwe requirements of2,1093 for occupational use as the SAR tgst rgpoit demonshates. The unit submitted for FCC teEting is a production unit. 2. l- 3. Yours truly, Featl6tuYd

September 19, 2006 Office of Engineering and Technology Federal Communications Commission Authorization and Evaluation Division Columbia, MD 21046 Applicant: SPEEDCAM INC. 1755 Lexington Avenue Deland, FL 32724 Re: Confidentiality Request regarding application for Certification of FCC ID: Q4X-HHTU1 Dear Sirs: Short-term Pursuant to DA 04-1705 of the Commission’s pubic notice, we request short-term confidential treatment for the following information until 45 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos file MT16U External Photos.pdf Internal Photos MT16U Internal Photo.pdf Test Setup Photos MT16U Test setup Photo.pdf User Manual MT16U manual.pdf Permanent SPEEDCAM INC. requests that the material in the Parts List, Schematics, block diagram, and Operational Description be withheld from public disclosure in accordance with Section 0.459 of the Commissions Rules, 47 C.F.R. 0.459, following grant of the application. In support of this request, SPEEDCAM INC. submits the following: Parts List file MT16U Parts.pdf Schematics files MT16U Schematic layout.pdf MT16U Schematic diagram 1.pdf MT16U Schematic diagram 2.pdf Block Diagram MT16U Block Diagram.pdf Operational Description MT16U Theory of operation.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053

KDB Inquiry Tracking Number - 671808

ROGERS LABS, INC. Speedcam, Inc. 4405 W. 259th Terrace MODEL: MT16U FCCID#: Q4X-HHTU1 Louisburg, KS 66053 Test #: 060515U IC: 6725A-HHTU1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 90 Page 1 of 1 MT16U External photos.doc 9/19/2006 Equipment photographs for MT16U. ROGERS LABS, INC. Speedcam, Inc. 4405 W. 259th Terrace MODEL: MT16U FCCID#: Q4X-HHTU1 Louisburg, KS 66053 Test #: 060515U IC: 6725A-HHTU1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 90 Page 2 of 2 MT16U External photos.doc 9/19/2006 ROGERS LABS, INC. Speedcam, Inc. 4405 W. 259th Terrace MODEL: MT16U FCCID#: Q4X-HHTU1 Louisburg, KS 66053 Test #: 060515U IC: 6725A-HHTU1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 90 Page 3 of 3 MT16U External photos.doc 9/19/2006

ROGERS LABS, INC. Speedcam, Inc. 4405 W. 259th Terrace MODEL: MT16U IC:6725A-HHTU1 Louisburg, KS 66053 Test #: 060515U FCCID#: Q4X-HHTU1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 90 Page 1 of 1 MT16U Label Info.doc 12/4/2006 FCC ID label location photograph for MT16U. Q4X-HHTU1 “This device must be restricted to occupational use to satisfy FCC RF exposure compliance. See the owner’s manual for specific operating requirements.”

ROGERS LABS, INC. Speedcam, Inc. 4405 W. 259th Terrace MODEL: MT16U IC:6725A-HHTU1 Louisburg, KS 66053 Test #: 060515U FCCID#: Q4X-HHTU1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 90 Page 1 of 2 MT16U FCC ID Label request 12/4/2006 December 4, 2006 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Federal Communications Commission Equipment Approval Services P.O. Box 35815 Pittsburgh, PA 15251-3315 Applicant: SPEEDCAM INC. 1755 Lexington Avenue Deland, FL 32724 Equipment: FCC ID: Q4X-HHTU1 FCC Rules: Part 90 LMR UHF Transceiver Gentlemen: SpeedCam Inc. requests acceptance of the labeling proposal described below for transceivers bearing FCC identifier Q4X-HHTU1. The subject transceivers are compact handheld models as shown in the picture below. This equipment must be assembled by the end user before use and is shipped without the battery attached. This configuration exposes the FCC ID label information to the end user whenever the battery is removed. Because the majority of the transceiver housing is composed of display, speaker, operating controls, and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, SpeedCam Inc. proposes placing the label carrying the FCC identifier on the case below the removable battery. In this location, the label will be protected from physical abuse and remain readable for the anticipated life of the device. The packaging for this equipment allows the transceiver for the equipment and FCC ID label information to be viewed at the time of purchase upon opening the packaging and removing the transmitter. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 ROGERS LABS, INC. Speedcam, Inc. 4405 W. 259th Terrace MODEL: MT16U IC:6725A-HHTU1 Louisburg, KS 66053 Test #: 060515U FCCID#: Q4X-HHTU1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 90 Page 2 of 2 MT16U FCC ID Label request 12/4/2006 Q4X-HHTU1 “This device must be restricted to occupational use to satisfy FCC RF exposure compliance. See the owner’s manual for specific operating requirements.”

ROGERS LABS, INC. Speedcam, Inc. 4405 W. 259th Terrace MODEL: MT16U IC: 6725A-HHTU1 Louisburg, KS 66053 Test #: 060515U FCCID#: Q4X-HHTU1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 90 Page 1 of 2 MT16U Internal Photo.doc 9/19/2006 Photograph of inside MT16U case. ROGERS LABS, INC. Speedcam, Inc. 4405 W. 259th Terrace MODEL: MT16U IC: 6725A-HHTU1 Louisburg, KS 66053 Test #: 060515U FCCID#: Q4X-HHTU1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 90 Page 2 of 2 MT16U Internal Photo.doc 9/19/2006 Please refer to schematics exhibit for PCB layout and component locations located under shields.

ROGERS LABS, INC. Speedcam, Inc. 4405 W. 259th Terrace MODEL: MT16U IC: 6725A-HHTU1 Louisburg, KS 66053 Test #: 060515U FCCID#: Q4X-HHTU1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 90 Page 1 of 1 MT16U Tune.doc 9/19/2006 Tuning procedure for MT16U. There are no field adjustable tuning options. The only adjustments are made at the factory for power output. When the unit is set for high power, adjust RV2 to obtain 3.5 Watts. When set for low power, adjust RV1 for 1-watt output power.

No. DAT-P-114/01-01 TEST REPORT No. SAR2006014 FCCID Q4X-HHTU1 Test name Electromagnetic Field (Specific Absorption Rate) Product Handheld Transceiver Model 308SU/MT16U Client Techwall Electronics Co., Ltd. Type of test Non Type approval Telecommunication Metrology Center of Ministry of Information Industry Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 2 of 61 Notes 1. . The test report shall be invalid if there is no “specified stamp for the test report” or the stamp of the test organization on it. 2. Copies of the test report shall be invalid if there is no “specified stamp for the test report” or the stamp of the test organization on it. 3. The test report shall be invalid if there are no signatures of the testing person, reviewing person and approving person on it. 4. The test report shall be invalid if it is altered. 5. Any demurral about the test shall be put forward to the testing organization within 15 days after the receiving of the test report. 6. This test report standalone dose not constitute or imply by its own an approval of the product by any Certification Authorities or Competent Bodies. 7. This report is only valid if complete, and test report shall not be reproduced except in full, without written approval of the laboratory. 8. This report cannot be used partially or in full for publicity and/or promotional purposes without previous written approval of Telecommunication Metrology Center of MII and the Accreditation Bodies, if it applies. Address: No. 52, Huayuan Bei Road, Haidian District, Beijing, P. R. China (Telecommunication Metrology Center of MII) Post code: 100083 Telephone: +86 10 62302041 Fax: +86 10 62304793 Web site: http://www.emcite.com E-mail: [email protected] Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 3 of 61 TABLE OF CONTENT 1 COMPETENCE AND WARRANTIES..........................................................................................5 2 GENERAL CONDITIONS............................................................................................................5 3 DESCRIPTION OF EUT ..............................................................................................................5 3.1 ADDRESSING INFORMATION RELATED TO EUT............................................................................................... 5 3.2 CONSTITUENTS OF EUT ................................................................................................................................. 6 3.3 GENERAL DESCRIPTION.................................................................................................................................. 7 4 OPERATIONAL CONDITIONS DURING TEST ..........................................................................8 4.1 SCHEMATIC TEST CONFIGURATION................................................................................................................. 8 4.2 SAR MEASUREMENT SET-UP.......................................................................................................................... 8 4.3 DASY4 E-FIELD PROBE SYSTEM..................................................................................................................... 9 4.4 E-FIELD PROBE CALIBRATION...................................................................................................................... 10 4.5 OTHER TEST EQUIPMENT............................................................................................................................. 11 4.6 EQUIVALENT TISSUES................................................................................................................................... 12 4.7 SYSTEM SPECIFICATIONS.............................................................................................................................. 12 5 CHARACTERISTICS OF THE TEST ........................................................................................13 5.1 APPLICABLE LIMIT REGULATIONS................................................................................................................ 13 5.2 APPLICABLE MEASUREMENT STANDARDS.................................................................................................... 13 5.3 CHARACTER OF THE TEST............................................................................................................................. 13 6 LABORATORY ENVIRONMENT...............................................................................................13 7 CONDUCTED OUTPUT POWER MEASUREMENT.................................................................14 7.1 SUMMARY.................................................................................................................................................... 14 7.2 CONDUCTED POWER.................................................................................................................................... 14 8 TEST RESULTS ........................................................................................................................15 8.1 DIELECTRIC PERFORMANCE......................................................................................................................... 15 8.2 SYSTEM VALIDATION.................................................................................................................................... 15 8.3 SUMMARY OF MEASUREMENT RESULTS....................................................................................................... 16 8.4 CONCLUSION................................................................................................................................................ 17 9 MEASUREMENT UNCERTAINTY ............................................................................................17 10 MAIN TEST INSTRUMENTS...................................................................................................18 11…

Text truncated - open the document above for the full version.

Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 31 of 61 Mode 1 with Ni-mh Battery, Middle Frequency Date/Time: 2006-10-27 14:02:30 Electronics: DAE3 Sn536 Medium: 450 MHZ Head Medium parameters used: f = 450 MHz; σ = 0.84 mho/m; ε r = 45.6; ρ = 1000 kg/m 3 Ambient Temperature:22.9 o C Liqiud Temperature: 22.1 o C Communication System: Handy Transceiver Frequency: 455.012 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1600 ConvF(7.95, 7.95, 7.95) Middle Frequency/Area Scan (81x161x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 2.68 mW/g Middle Frequency/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 52.9 V/m; Power Drift = -0.148 dB Peak SAR (extrapolated) = 3.65 W/kg SAR(1 g) = 2.52 mW/g; SAR(10 g) = 1.85 mW/g Maximum value of SAR (measured) = 2.64 mW/g 0 dB = 2.64mW/g Fig. 9 Mode 1 with Ni-mh Battery, Channel 2 Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 32 of 61 Fig. 10 Z-Scan at power reference point (Mode 1 with Ni-mh Battery, Channel 2) Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 33 of 61 Mode 1 with Ni-mh Battery, Low Frequency Date/Time: 2006-10-27 13:36:23 Electronics: DAE3 Sn536 Medium: 450 MHZ Head Medium parameters used: f = 450 MHz; σ = 0.84 mho/m; ε r = 45.6; ρ = 1000 kg/m 3 Ambient Temperature:22.9 o C Liqiud Temperature: 22.1 o C Communication System: Handy Transceiver Frequency: 440.012 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1600 ConvF(7.95, 7.95, 7.95) Low Frequency/Area Scan (81x161x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 2.53 mW/g Low Frequency/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 54.9 V/m; Power Drift = -0.182dB Peak SAR (extrapolated) = 3.43 W/kg SAR(1 g) = 2.42 mW/g; SAR(10 g) = 1.81 mW/g Maximum value of SAR (measured) = 2.51 mW/g 0 dB = 2.51mW/g Fig. 11 Mode 1 with Ni-mh Battery, Channel 1 Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 34 of 61 Fig. 12 Z-Scan at power reference point (Mode 1 with Ni-mh Battery, Channel 1) Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 35 of 61 Mode 2 with Li-ion Battery, High Frequency Date/Time: 2006-10-27 16:57:43 Electronics: DAE3 Sn536 Medium: 450 MHz Body Medium parameters used: f = 450 MHz; σ = 0.96 mho/m; ε r = 57.1; ρ = 1000 kg/m 3 Ambient Temperature:23.0 o C Liqiud Temperature: 22.5 o C Communication System: Handy Transceiver Frequency: 469.913 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1600 ConvF(7.74, 7.74, 7.74) High Frequency/Area Scan (81x161x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 4.83 mW/g High Frequency/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 68.4 V/m; Power Drift = -0.166dB Peak SAR (extrapolated) = 6.46 W/kg SAR(1 g) = 4.36 mW/g; SAR(10 g) = 3.14 mW/g Maximum value of SAR (measured) = 4.57 mW/g 0 dB = 4.57mW/g Fig.13 Mode 2 with Li-ion Battery, Channel 3 Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 36 of 61 Fig. 14 Z-Scan at power reference point (Mode 2 with Li-ion Battery, Channel 3) Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 37 of 61 Mode 2 with Li-ion Battery, Middle Frequency Date/Time: 2006-10-27 18:02:34 Electronics: DAE3 Sn536 Medium: 450 MHz Body Medium parameters used: f = 450 MHz; σ = 0.96 mho/m; ε r = 57.1; ρ = 1000 kg/m 3 Ambient Temperature:23.0 o C Liqiud Temperature: 22.5 o C Communication System: Handy Transceiver Frequency: 455.012 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1600 ConvF(7.74, 7.74, 7.74) Middle Frequency/Area Scan (81x161x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 4.83 mW/g Middle Frequency/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 70.7 V/m; Power Drift = -0.152 dB Peak SAR (extrapolated) = 6.40 W/kg SAR(1 g) = 4.29 mW/g; SAR(10 g) = 3.1 mW/g Maximum value of SAR (measured) = 4.51 mW/g 0 dB = 4.51mW/g Fig.15 Mode 2 with Li-ion Battery, Channel 2 Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 38 of 61 Fig. 16 Z-Scan at power reference point (Mode 2 with Li-ion Battery, Channel 2) Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 39 of 61 Mode 2 with Li-ion Battery, Low Frequency Date/Time: 2006-10-27 15:36:14 Electronics: DAE3 Sn536 Medium: 450 MHz Body Medium parameters used: f = 450 MHz; σ = 0.96 mho/m; ε r = 57.1; ρ = 1000 kg/m 3 Ambient Temperature:23.0 o C Liqiud Temperature: 22.5 o C Communication System: Handy Transceiver Frequency: 440.012 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1600 ConvF(7.74, 7.74, 7.74) Low Frequency/Area Scan (81x161x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 4.39 mW/g Low Frequency/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 65.0 V/m; Power Drift = -0.174 dB Peak SAR (extrapolated) = 5.98 W/kg SAR(1 g) = 4.07 mW/g; SAR(10 g) = 2.95 mW/g Maximum value of SAR (measured) = 4.28 mW/g 0 dB = 4.28mW/g Fig.17 Mode 2 with Li-ion Battery, Channel 1 Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 40 of 61 Fig. 18 Z-Scan at power reference point (Mode 2 with Li-ion Battery, Channel 1) Telecommunication Metrology Center of Ministry of Information Industry No. SAR2006014 Page 41 of 61 Mode 2 with Ni-mh Battery, High Frequency Date/Time: 2006-10-27 18:45:37 Electronics: DAE3 Sn536 Medium: 450 MHz Body Medium parameters used: f = 450 MHz; σ = 0.96 mho/m; ε r = 57.1; ρ = 1000 kg/m 3 Ambient Temperature:23.0 o C Liqiud Temperature: 22.5 o C Communication System: Handy Transceiver Frequency: 469.913 MHz Duty Cycle: 1:1 Probe: ET3DV6 - SN1600 ConvF(7.74, 7.74, 7.74) High…

Text truncated - open the document above for the full version.

SUBMITTAL APPLICATION REPORT FOR GRANT OF CERTIFICATION MODEL: MT16U UHF TRANSCEIVER FCC ID: Q4X-HHTU1 Operating under rule of CFR 47, Paragraph 90, Subpart I FOR Speedcam, Inc. 1755 Lexington Avenue Deland, FL 32724 Test Report Number 060515U TEST REPORT For APPLICATION of CERTIFICATION For Speedcam, Inc. 1755 Lexington Avenue Deland, FL 32724 MODEL: MT16U UHF TRANSCEIVER FREQUENCY: 450-470 MHz FCC ID: Q4X-HHTU1 Test Date: May 15, 2006 Certifying Engineer: Scot D. Rogers ROGERS LABS, INC. 4405 West 259th Terrace Louisburg, KS 66053 Phone: (913) 837-3214 FAX: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Speedcam Inc. IC: 6725A-HHTU1 4405 West 259th Terrace MODEL: MT16U UHF Transceiver FCC ID#: Q4X-HHTU1 Louisburg, KS 66053 Test #:060515U SN:308SU-1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2, 15, and 90 Page 3 of 31 Certification\Speedcam MT16U Test Report 9/20/2006 TABLE OF CONTENTS TABLE OF CONTENTS 3 FORWARD 4 APPLICABLE STANDARDS & TEST PROCEDURES 4 LIST OF TEST EQUIPMENT 4 2.1033(C) APPLICATION FOR CERTIFICATION 5 2.1046 RF POWER OUTPUT 6 Measurements Required 6 Test Arrangement 7 Results 7 2.1047 MODULATION CHARACTERISTICS 8 Measurements Required 8 Test Arrangement 8 Results 9 2.1049 OCCUPIED BANDWIDTH 11 Measurements Required 11 Test Arrangement 11 Results 11 2.1051 SPURIOUS EMISSIONS AT ANTENNA TERMINALS 15 Measurements Required 15 Test Arrangement 15 Results 18 2.1053 FIELD STRENGTH OF SPURIOUS RADIATION 19 Measurements Required 19 Test Arrangement 19 Results 21 2.1055 FREQUENCY STABILITY 22 Measurements Required 22 Test Arrangement 23 Results 25 TRANSIENT FREQUENCY BEHAVIOR, PER 90.214 25 Measurements Required 25 Test Arrangement 26 Results 27 APPENDIX 28 NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Speedcam Inc. IC: 6725A-HHTU1 4405 West 259th Terrace MODEL: MT16U UHF Transceiver FCC ID#: Q4X-HHTU1 Louisburg, KS 66053 Test #:060515U SN:308SU-1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2, 15, and 90 Page 4 of 31 Certification\Speedcam MT16U Test Report 9/20/2006 FORWARD In accordance with the Federal Communications Code of Federal Regulations, dated October 1, 2005, Part 2 Subpart J, Paragraphs 2.907, 2.911, 2.913, 2.915, 2.925, 2.926, 2.1031 through 2.1057, applicable parts of paragraphs 15, and 90, the following information is submitted. Applicable Standards & Test Procedures In accordance with the Federal Communications Code of Federal Regulations, dated October 1, 2005, Part 2, Subpart J, Paragraphs 2.907, 2.911, 2.913, 2.925, 2.926, 2.1031 through 2.1057, and applicable paragraphs of Part 90 the following is submitted for consideration in obtaining a Grant of Certification. Test procedures used are the established Methods of Measurement of Radio-Noise Emissions as described in ANSI 63.4-2003 and TIA/EIA 603. List of Test Equipment A Hewlett Packard 8591EM and or 8562A Spectrum Analyzer was used as the measuring device for the emissions testing. The analyzer settings used are described in the following table. Refer to the Appendix for a complete list of Test Equipment. HP 8591EM SPECTRUM ANALYZER SETTINGS AC LINE CONDUCTED EMISSIONS RBW AVG. BW DETECTOR FUNCTION 9 kHz 30 kHz Peak/Quasi Peak RADIATED EMISSIONS (30 – 1000 MHz) RBW AVG. BW DETECTOR FUNCTION 120 kHz 300 kHz Peak/Quasi Peak HP 8562A SPECTRUM ANALYZER SETTINGS RADIATED EMISSIONS (1 – 40 GHz) RBW AVG. BW DETECTOR FUNCTION 1 MHz 1 MHz Peak/Average ANTENNA CONDUCTED EMISSIONS RBW AVG. BW DETECTOR FUNCTION 120 kHz 300 kHz Peak NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Speedcam Inc. IC: 6725A-HHTU1 4405 West 259th Terrace MODEL: MT16U UHF Transceiver FCC ID#: Q4X-HHTU1 Louisburg, KS 66053 Test #:060515U SN:308SU-1 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2, 15, and 90 Page 5 of 31 Certification\Speedcam MT16U Test Report 9/20/2…
