Q6F-ABM11Bluetooth Module
Advanced Brain Monitoring Incorporated
Click to zoom
Application Details
- Equipment Class
- DSS - Part 15 Spread Spectrum Transmitter
- Date of Grant
- Jun 16, 2011
- Application Purpose
- Original Equipment
- Date of Application
- Jun 16, 2011
- Equipment Note
- Bluetooth Module
- Frequency Range
- 2402.00000000 - 2480.00000000
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
Rev: 0 www.free2move.net Low power Audio Bluetooth™ Module with antenna F2M03ALA Preliminary datasheet Features • Fully qualified end product with Bluetooth™ v2.0+EDR, CE and FCC • Low power consumption • Integrated high output antenna • Transmit power up to +4dBm (class2) • Range up to 100m (line of sight) BLUETOOTH is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Free2move • Piconet and Scatternet capability, support for up to 7 slaves • Require only few external components • Industrial temperature range -40 ° C to +85 ° C • Serial interface up to 3 Mbps • Extensive digital and analog I/O interface • 15-bit mono audio codec • Analogue and digital audio interface • Low power modes • Surface mountable, physical size: 24x13 mm • Fully footprint compatible with F2M03AC2 • RoHS compliant Applications • Headsets • Automotive hands-free kits • Industrial and domestic appliances • Medical systems • Automotive applications • Stand-alone sensors • Embedded systems • Cordless headsets • Handheld, laptop and desktop computers • Mobile phones General Description F2M03ALA is a low power embedded Bluetooth™ v2.0+EDR audio module with an on board antenna, integrated audio codec and amplifier. The module fully Bluetooth™ qualified as an end product requiring no additional qualification. With a transmit power of up to +4 dBm and receiver sensibility of down to –86 dBm combined with audio codec and low power consumption the F2M03ALA is suitable for the most demanding audio applications. The module is certified according to CE and FCC, which give fast and easy Plug-and-Go implementation and short time to market. The standard firmware for F2M03ALA is the exceedingly reliable and powerful easy-to-use Wireless UART v4 firmware implementing the Bluetooth™ Serial Port Profile (SPP). Rev: 0 Low power Audio Bluetooth™ Module with antenna F2M03ALA Preliminary datasheet © 2007 Free2move AB Page 2(2) Table of contents 1 Device pinout.........................................................................................................................3 2 Device terminal functions.....................................................................................................4 3 Electrical Characteristics......................................................................................................5 3.1 Power Consumption........................................................................................................................ 7 4 Radio Characteristics............................................................................................................8 5 Firmware versions.................................................................................................................9 5.1 Wireless UART............................................................................................................................. 11 5.2 HCI................................................................................................................................................ 16 6 Device terminal description................................................................................................19 6.1 Mono Audio Interface.................................................................................................................... 19 6.2 PCM CODEC Interface................................................................................................................. 22 6.3 UART Interface............................................................................................................................. 30 6.4 USB Interface................................................................................................................................32 6.5 Serial Peripheral Interface............................................................................................................ 36 6.6 I 2 C Interface.................................................................................................................................. 36 6.7 PIOs.............................................................................................................................................. 37 6.8 Power supply................................................................................................................................38 7 Application information.......................................................................................................39 7.1 Recommended land pattern.......................................................................................................... 39 7.2 Layout guidelines.......................................................................................................................... 40 7.3 Typical application schematic....................................................................................................... 40 7.3 Typical application schematic....................................................................................................... 41 8 Package information............................................................................................................42 9 Certifications........................................................................................................................43 9.1 Bluetooth (TBD)............................................................................................................................ 43 9.2 CE (TBD)....................................................................................................................................... 43 9.3 FCC (TBD).................................................................................................................................... 44 10 RoHS and WEEE Statement................................................................................................45 11 Tape and Reel information..........................................................................…
Text truncated - open the document above for the full version.
Cover Letter(s)
Halmstad 2011-04-04 1 (1) Certificate This certificate allows Advanced Brain Monitoring, Inc. 2237 Faraday Ave., Suite 100, Carlsbad, CA 92008 to use the test results from tests done by Free2move on the F2M03 ALA Bluetooth module. This does not imply that Free2move is taking any responsibility for the end product function or behavior. ....................................................... Per-Arne Wiberg CEO Free2move AB
External Photos
TOP BOTTOM FRONT REAR
ID Label/Location Info
Decal size: 1.43”x 1.90” white letters on black vinyl Li-Polymer Batteries 3.7 Volts Made in America 2011 1 0 1 000 0 0 1 X10 Contains FCC/IC certified transmitter module FCC ID: Q6F-ABM11 IC ID: 9541A-ABM11 Enclosure is the same for both X10 and X24 Device upright back view Back View – X10 label shown Front View – X10 label shown
Internal Photos
TOP BOTTOM FRONT REAR
Test Report
7 layers AG Aufsichtsratsvorsitzenderh Registergerichth registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Markus Becker USt-IdNr h VAT Nr: Phone: +49 (0) 2102 749 0 Vorstandh Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. Hans-Jürgen Meckelburg TAX No. 147/5869/0385 www.7Layers.com René Schildknecht InterLab isaregisteredtrademarkof7layersAG FCCMeasurement/TechnicalReporton Bluetoothtransceiver F2M03ALA FCC&ID:R47F2M03AL ReportReference: MDE_Free2_0801_FCCb TestLaboratory: 7layersAG Borsigstrasse11 40880Ratingen Germany email: [email protected] DAT-P-192/99-01 Note: Thefollowingtestresultsrelateonlytothedevicesspecifiedinthisdocument.Thisreportshallnotbe reproducedinpartswithoutthewrittenapprovalofthetestinglaboratory. TestreportReference:MDE_Free2_0801_FCCbPage2of95 TableofContents 0 Summary3 0.1 TechnicalReportSummary3 0.2 MeasurementSummary4 1 AdministrativeData7 1.1 TestingLaboratory7 1.2 ProjectData7 1.3 ApplicantData7 1.4 ManufacturerData7 2 Productlabelling8 2.1 FCCIDlabel8 2.2 LocationofthelabelontheEUT8 3 TestobjectData9 3.1 GeneralEUTDescription9 3.2 EUTMaincomponents10 3.3 AncillaryEquipment10 3.4 EUTSetups10 3.5 OperatingModes11 4 TestResults11 4.1 Occupiedbandwidth11 4.2 Peakpoweroutput11 4.3 SpuriousRFconductedemissions11 4.4 Spuriousradiatedemissions22 4.5 Bandedgecompliance28 4.6 Dwelltime32 4.7 Channelseparation34 4.8 Numberofhoppingfrequencies36 5 TestEquipment37 6 PhotoReport40 7 SetupDrawings42 8 Annexmeasurementplots43 8.1 Occupiedbandwidth43 8.2 Peakpoweroutput52 8.3 BandedgecomplianceconductedandSpuriousRFconductedemissions 61 8.4 Bandedgecomplianceradiated79 8.5 Radiatedemissions(f<30MHz)82 8.6 Dwelltime83 8.7 Channelseparation92 8.8 Numberofhoppingfrequencies95 TestreportReference:MDE_Free2_0801_FCCbPage3of95 0 Summary 0.1 TechnicalReportSummary TypeofAuthorization CertificationforanIntentionalRadiator(FrequencyHoppingSpreadSpectrum). ApplicableFCCRules PreparedinaccordancewiththerequirementsofFCCRulesandRegulationsaslistedin 47CFRCh.1Parts2(10&1&07Edition)and15(10&1&07Edition).Thefollowingsubparts areapplicabletotheresultsinthistestreport. Part2,SubpartJ&EquipmentAuthorizationProcedures,Certification Part15,SubpartC–IntentionalRadiators §15.201 Equipmentauthorizationrequirement §15.207 Conductedlimits §15.209 Radiatedemissionlimits;generalrequirements §15.247 Operationwithinthebands902&928MHz,2400&2483.5MHz and5725&5850MHz Note: ThetestswereselectedandperformedwithreferencetotheFCCPublicNoticeDA00& 705,releasedMarch30,2000 InsteadofapplyingANSIC63.4&1992whichisreferencedintheFCCPublicNote,the newerANSIC63.4&2003isapplied. SummaryTestResults: TheEUTcompliedwithallperformedtestsaslistedinchapter0.2 MeasurementSummary. TestreportReference:MDE_Free2_0801_FCCbPage4of95 0.2 MeasurementSummary FCCPart15,SubpartC§15.207 Conductedemissions(ACpowerline) ThemeasurementwasperformedaccordingtoANSIC63.42003 OP6ModeSetupPortFinalResult ACPort(powerline) N/A FCCPart15,SubpartC§15.247(a)(1) Occupiedbandwidth ThemeasurementwasperformedaccordingtoFCC§15.3110&1&07 OP6ModeSetupPortFinalResult op&mode1Setup_b01Tempant.connector passed op&mode2Setup_b01Tempant.connector passed op&mode3Setup_b01Tempant.connector passed op&mode6Setup_b01Tempant.connector passed op&mode7Setup_b01Tempant.connector passed op&mode8Setup_b01Tempant.connector passed op&mode10Setup_b01Tempant.connector passed op&mode11Setup_b01Tempant.connector passed op&mode12Setup_b01Tempant.connector passed FCCPart15,SubpartC§15.247(b)(1) Peakpoweroutput ThemeasurementwasperformedaccordingtoFCC§15.3110&1&07 OP6ModeSetupPortFinalResult op&mode1Setup_b01Tempant.connector passed op&mode2Setup_b01Tempant.connector passed op&mode3Setup_b01Tempant.connector passed op&mode6Setup_b01Tempant.connector passed op&mode7Setup_b01Tempant.connector passed op&mode8Setup_b01Tempant.connector passed op&mode10Setup_b01Tempant.connector passed op&mode11Setup_b01Tempant.connector passed op&mode12Setup_b01Tempant.connector passed FCCPart15,SubpartC§15.247(d) SpuriousRFconductedemissions ThemeasurementwasperformedaccordingtoFCC§15.3110&1&07 OP6ModeSetupPortFinalResult op&mode1Setup_b01Tempant.connector passed op&mode2Setup_b01Tempant.connector passed op&mode3Setup_b01Tempant.connector passed op&mode6Setup_b01Tempant.connector passed op&mode7Setup_b01Tempant.connector passed op&mode8Setup_b01Tempant.connector passed op&mode10Setup_b01Tempant.connector passed op&mode11Setup_b01Tempant.connector passed op&mode12Setup_b01Tempant.connector passed TestreportReference:MDE_Free2_0801_FCCbPage5of95 FCCPart15,SubpartC§15.247(d),§15.35(b),§15.209 Spuriousradiatedemissions ThemeasurementwasperformedaccordingtoANSIC63.42003 OP6ModeSetupPortFinalResult op&mode1Setup_a01Enclosurepassed op&mode2Setup_a01Enclosurepassed op&mode3Setup_a01Enclosurepassed op&mode6Setup_a01Enclosurepassed op&mode7Setup_a01Enclosurepassed op&mode8Setup_a01Enclosurepassed op&mode10Setup_a01Enclosurepassed op&mode11Setup_a01Enclosurepassed op&mode12Setup_a01Enclosurepassed FCCPart15,SubpartC§15.247(d) Bandedgecompliance Themeasurementwasperfo…
Text truncated - open the document above for the full version.
Test Report
Report No. SC1010487A-01-02 Page 1 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 E M C - T E S T R E P O R T EUROPEAN STANDARD EN 60601-1-2: 2007 and IEC 60601-1-2: 2007 Test Report File No. : SC1010487A-01-02 Date of Issue: 13 January 2011 Model / Serial No. : MODEL: X10 / S/N: 101000003 Product Type : B-ALERT SYSTEM Configuration Test Mode : PATIENT MODE Applicant : ADVANCED BRAIN MONITORING SYSTEMS Manufacturer : ADVANCED BRAIN MONITORING SYSTEMS License holder : ADVANCED BRAIN MONITORING SYSTEMS Address : 2850 Pio Pico Drive, Suite A : Carlsbad, CA 92008 – USA Test Result : Positive Negative Test Project Number : SC1010487A Total pages - Test Report : 48 This TÜV SÜD America, Inc. report results apply only to the specific sample tested under the stated test conditions agreed upon by the client, prior to testing. Production compliance is the responsibility of the client. TÜV SÜD America, Inc. shall have no liability for deductions, inferences or generalizations drawn from this report by the client or others. This report shall only be reproduced in its entirety. The client shall not use this report to claim product endorsement by NVLAP, NIST, or any agency of the U.S. Government. (TÜV SÜD America, Inc.’s (San Diego, California) NVLAP Lab Code: 100268-0.) Report No. SC1010487A-01-02 Page 2 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 D I R E C T O R Y T e s t R e p o r t Pages Test Report: 1 – 48 Directory 2 Test Regulations 3 General Remarks and Summary 17 Equipment: Conducted Emissions 5 Radiated Emissions 6 Current Harmonics Tests 7 Voltage Fluctuation and Flicker Test 8 Electrostatic Discharge 9 Radiated Electromagnetic Fields 10 Fast Transients (Burst) 11 Surge Transients 12 Conducted Disturbance 13 Power Frequency Magnetic Field 14 Voltage Dips, Interruptions and Variations 15 Technical Documentation Test Data Sheets and Test Setup Drawing(s) 18 Appendices Appendix A - Test Setups (Photographs) 31 Appendix B - Product Information Form(s) 40 Appendix C - Change History 47 Appendix D - Supplemental Information 48 Report No. SC1010487A-01-02 Page 3 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 TEST REGULATIONS: The tests were performed according to the following regulations: ------------------------------------------------------------------- - IEC 60601-1-2: 2007 - EN 60601-1-2: 2007 ------------------------------------------------------------------- - CISPR 11: 2009 - Class A - Class B - EN 55011: 2007; Amendment A2: 2007 - Class A - Class B - EN 61000-3-2: 2006 - IEC 61000-3-2: 2005; Amendment 1, 2008 - EN 61000-3-3: 1995, Amendment 2: 2006 - IEC 61000-3-3: 2008 - IEC 61000-4-2: 2008 EN 61000-4-2: 1995; Amendment 2, 2001 - IEC 61000-4-3: 2008 EN 61000-4-3: 2006, Amendment 1, 2008 - IEC 61000-4-4: 2007 EN 61000-4-4: 2004 - IEC 61000-4-5: 2005 EN 61000-4-5: 2006 - IEC 61000-4-6: 2008 EN 61000-4-6: 2007 - IEC 61000-4-8: 2001 EN 61000-4-8: 1993; Amendment 1, 2001 - IEC 61000-4-11: 2004 EN 61000-4-11: 2004 ___________________________ Note: Un-dark squares are not applicable Report No. SC1010487A-01-02 Page 4 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Environmental Conditions In The Laboratory: Actual Temperature : 18 – 25 °C Relative Humidity : 42 – 55 % Atmospheric Pressure : 98.9 – 100.8 kPa Power Supply Utilized: Power supply system : 3.7 VDC Symbol Definitions: - Applicable - Not Applicable Report No. SC1010487A-01-02 Page 5 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Conditions: CONDUCTED EMISSIONS (Interference Voltage) The CONDUCTED EMISSIONS (Interference Voltage) measurements were performed in the following location at the San Diego Testing Facility: - Test not applicable OPERATING MODE DESCRIPTION: Remarks: DC Powered. Testing Not Applicable. Report No. SC1010487A-01-02 Page 6 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Conditions: RADIATED EMISSIONS (Electric Field) The RADIATED EMISSIONS (Electric Field) measurements were performed in the following location at the San Diego Testing Facility: - Test not applicable - SR6 (3 and 10 meter Semi-Anechoic Chamber), San Diego, CA (Date of listing June 21, 2010. Site Verification NSA) Testing was performed at a test distance of: - 10 meters Test Equipment Used: Model No.: Prop. No.: Description: Manufacturer: Serial No./Version No.: 3142C SA1033 Antenna, Bilog EMCO 44556 ESMI SA1043,44 EMI Test Receiver Rhode & Schwarz 848926/003 PAM-0202 SA1016 Pre-Amplifier PAM 187 ES-K1 -- Test Software Rohde & Schwarz 1.60 Service Pack 2 Result: - Pass - Fail OPERATING MODE DESCRIPTION: Patient Mode Remarks: One year calibration cycle for all test equipment. Report No. SC1010487A-01-02 Page 7 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Conditions: CURRENT HARMONICS TEST The CURRENT HARMONICS TEST measurements were performed in the following location at the San Diego Testing Facility: - Test not applicable OPERATING MODE DESCRIPTION: Remarks: DC Powered. Testing Not Applicable. Report No. SC1010487A-01-02 Page 8 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Conditions: VOLTAGE FLUCTUATION AND FLICKER TEST The VOLTAGE FLUCTUATION AND FLICKER TEST measurements were performed in the following location at the San Diego Testing Facility: - Test not applicable OPERATING MODE DESCRIPTION: Remarks: DC Powered. Testing Not Applicable. Report No. SC1010487A-01-02 Page 9 of 48 Rev.No 1.0…
Text truncated - open the document above for the full version.
Test Report
Report No. SC1010487B-01-02 Page 1 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 E M C - T E S T R E P O R T EUROPEAN STANDARD EN 60601-1-2: 2007 and IEC 60601-1-2: 2007 Test Report File No. : SC1010487B-01-02 Date of Issue: 17 January 2011 Model / Serial No. : MODEL: X10 / S/N: 101000003 Product Type : B-ALERT SYSTEM Configuration Test Mode : CHARGE MODE Applicant : ADVANCED BRAIN MONITORING SYSTEMS Manufacturer : ADVANCED BRAIN MONITORING SYSTEMS License holder : ADVANCED BRAIN MONITORING SYSTEMS Address : 2850 Pio Pico Drive, Suite A : Carlsbad, CA 92008 – USA Test Result : ¢ Positive o Negative Test Project Number : SC1010487B Total pages - Test Report : 72 This TÜV SÜD America, Inc. report results apply only to the specific sample tested under the stated test conditions agreed upon by the client, prior to testing. Production compliance is the responsibility of the client. TÜV SÜD America, Inc. shall have no liability for deductions, inferences or generalizations drawn from this report by the client or others. This report shall only be reproduced in its entirety. The client shall not use this report to claim product endorsement by NVLAP, NIST, or any agency of the U.S. Government. (TÜV SÜD America, Inc.’s (San Diego, California) NVLAP Lab Code: 100268-0.) Report No. SC1010487B-01-02 Page 2 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 D I R E C T O R Y T e s t R e p o r t Pages Test Report: 1 – 72 Directory 2 Test Regulations 3 General Remarks and Summary 19 Equipment: Conducted Emissions 5 Radiated Emissions 6 Current Harmonics Tests 7 Voltage Fluctuation and Flicker Test 8 Electrostatic Discharge 9 Radiated Electromagnetic Fields 10 Fast Transients (Burst) 11 Surge Transients 13 Conducted Disturbance 14 Power Frequency Magnetic Field 16 Voltage Dips, Interruptions and Variations 17 Technical Documentation Test Data Sheets and Test Setup Drawing(s) 20 Appendices Appendix A - Test Setups (Photographs) 50 Appendix B - Product Information Form(s) 64 Appendix C - Change History 71 Appendix D - Supplemental Information 72 Report No. SC1010487B-01-02 Page 3 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 TEST REGULATIONS: The tests were performed according to the following regulations: ------------------------------------------------------------------- ¢ - IEC 60601-1-2: 2007 ¢ - EN 60601-1-2: 2007 ------------------------------------------------------------------- ¢ - CISPR 11: 2009 o - Class A ¢ - Class B ¢ - EN 55011: 2007; Amendment A2: 2007 o - Class A ¢ - Class B ------------------------------------------------------------------- o - EN 61000-3-2: 2006 o - IEC 61000-3-2: 2005; Amendment 1, 2008 o - EN 61000-3-3: 1995, Amendment 2: 2006 o - IEC 61000-3-3: 2008 ------------------------------------------------------------------- ¢ - IEC 61000-4-2: 2008 EN 61000-4-2: 1995; Amendment 2, 2001 ¢ - IEC 61000-4-3: 2008 EN 61000-4-3: 2006, Amendment 1, 2008 ¢ - IEC 61000-4-4: 2007 EN 61000-4-4: 2004 o - IEC 61000-4-5: 2005 EN 61000-4-5: 2006 ¢ - IEC 61000-4-6: 2008 EN 61000-4-6: 2007 ¢ - IEC 61000-4-8: 2001 EN 61000-4-8: 1993; Amendment 1, 2001 o - IEC 61000-4-11: 2004 EN 61000-4-11: 2004 ___________________________ Note: Un-dark squares are not applicable Report No. SC1010487B-01-02 Page 4 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Environmental Conditions In The Laboratory: Actual Temperature : 18 – 25 °C Relative Humidity : 42 – 55 % Atmospheric Pressure : 98.9 – 100.8 kPa Power Supply Utilized: Power supply system : 3.7 VDC Symbol Definitions: ¢ - Applicable o - Not Applicable Report No. SC1010487B-01-02 Page 5 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Conditions: CONDUCTED EMISSIONS (Interference Voltage) The CONDUCTED EMISSIONS (Interference Voltage) measurements were performed in the following location at the San Diego Testing Facility: o - Test not applicable ¢ - SR-3, Shielded Room, 12’ x 20’ x 8’, Metal Chamber Test Equipment Used: Model No.: Prop. No.: Description: Manufacturer: Serial No./Version No.: ESHS 20 2534 EMI Test Receiver Rohde & Schwarz 837055/003 CAT-20 8634 20 dB Attenuator Mini-Circuits -- FCC-LISN-50-25-2 6837 LISN Fisher Custom Comm. 5025 ESHS 20 -- Test Software Rohde & Schwarz 3.21 Limit margin: 110 VAC / 60 Hz -10.2 dB at 1.025 MHz Limit margin: 230 VAC / 50 Hz -5.6 dB at 0.15 MHz Result: ¢ - Pass o - Fail OPERATING MODE DESCRIPTION: Charge Mode with Laptop USB Port Remarks: One year calibration cycle for all test equipment. Report No. SC1010487B-01-02 Page 6 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Conditions: RADIATED EMISSIONS (Electric Field) The RADIATED EMISSIONS (Electric Field) measurements were performed in the following location at the San Diego Testing Facility: o - Test not applicable ¢ - SR6 (3 and 10 meter Semi-Anechoic Chamber), San Diego, CA (Date of listing June 21, 2010. Site Verification NSA) Testing was performed at a test distance of: ¢ - 10 meters Test Equipment Used: Model No.: Prop. No.: Description: Manufacturer: Serial No./Version No.: 3142C SA1033 Antenna, Bilog EMCO 44556 ESMI SA1043,44 EMI Test Receiver Rhode & Schwarz 848926/003 PAM-0202 SA1016 Pre-Amplifier PAM 187 ES-K1 -- Test Software Rohde & Schwarz 1.60 Service Pack 2 Result: ¢ - Pass o - Fail OPERATING MODE DESCRIPTION: Charge Mode with Laptop USB Port Remarks: One year calibration cycle for all test equipment. Report No. SC1010487B-01-02 Page 7 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Conditions: CURRENT HARMONICS TEST The CURRENT HARMON…
Text truncated - open the document above for the full version.
Test Report
Report No. SC1010487B-01-02 Page 25 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 26 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 27 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 28 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 29 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 30 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 31 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 32 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 33 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 34 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 35 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 36 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 37 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 38 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 39 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 40 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 41 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 42 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Report No. SC1010487B-01-02 Page 43 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Conducted Emissions Test Setup, 0.15 to 30 MHz ELECTRICAL AND ELECTRONIC EQUIPMENT IN THE RANGE OF 9 kHz TO 40 GHz Report No. SC1010487B-01-02 Page 44 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Radiated Emissions Test Setup, 30 to 1000 MHz Report No. SC1010487B-01-02 Page 45 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Configuration for ESD, Tabletop Unit Report No. SC1010487B-01-02 Page 46 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Configuration for Radiated E Fields Immunity Report No. SC1010487B-01-02 Page 47 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Configuration for Electrical Fast Transient/Burst Immunity Report No. SC1010487B-01-02 Page 48 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Configuration for Immunity to Conducted Disturbances EUT AMPLIFIER SIGNAL GENERATOR EM CLAMP Report No. SC1010487B-01-02 Page 49 of 72 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Test Setup for Power Frequency Magnetic Field
Test Setup Photos
Test report Reference: MDE_Free2_0801_FCCa Page 40 of 95 6 Photo Report Photo 1: Test setup for radiated measurements (above 1 GHz) Photo 2: Test setup for radiated measurements (below 1 GHz)
Test Setup Photos
Report No. SC1010487A-01-02 Page 32 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Photograph of Test Setup: Radiated Emissions : Report No. SC1010487A-01-02 Page 33 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Photograph of Test Setup: Radiated Emissions : Report No. SC1010487A-01-02 Page 34 of 48 Rev.No 1.0 TÜV SÜD AMERICA INC 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 858 678 1400 FAX: 858 546 0364 Photograph of Test Setup: Electrostatic Discharge (ESD) : Report No. SC1010487A-01-02 Pa…
Text truncated - open the document above for the full version.
Contact Information
Applicant
Daniel J Levendowski(President)
[email protected]760 720 0099
Technical Contact
T�V S�D AMERICA INCFerdinand Custodio
[email protected]+1 858 678 1436
10040 Mesa Rim Road · San Diego, California · United States
Test Firm
7layers AGRobert Machulec
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 2 | 15C | 2.40 GHz - 2.48 GHz | 2.55 mW |
