SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Superinworld Technology Co., Ltd. 2015/10/23 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ___ Superinworld Technology Co., Ltd. _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： Tablet PC Trade Name： Superinworld Model Name： SM708 Serial Model： N/A FCC ID： Q6I-SUPERSM708 Sincerely, Client’s name / title : QING LI / General Manager Contact information / address : Room 1107-1109 Jueshi Building Jiabin Road, Luohu District, Shenzhen City,Guangdong Province,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Superinworld Technology Co., Ltd. 2015/10/23 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: Q6I-SUPERSM708 We hereby request confidential treatment of information accompanying this application as outlined below: - . Block Diagram - Schematics - Operational Description - BOM - - tune up procedure - The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s name / title : QING LI / General Manager Contact information / address : Room 1107-1109 Jueshi Building Jiabin Road, Luohu District, Shenzhen City,Guangdong Province,China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label Tablet PC Model NO.: SM708 Input Rating: DC 5V/ 2A FCC ID:Q6I-SUPERSM708 Superinworld Technology Co., Ltd. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT/WIFI ANT Photo 3 Photo 4 Photo 5 Photo 6 2G/3G ANT Photo 7 Photo 8 Photo 9 Photo 10

FCC RADIO TEST REPORT-BT FCC ID:Q6I-SUPERSM708 Product： Tablet PC Trade Name： Superinworld Model Name： SM708 Serial Model： N/A Report No.： NTEK-2015NT09302780F2 Prepared for Superinworld Technology Co., Ltd. Room 1107-1109 Jueshi Building Jiabin Road, Luohu District, Shenzhen City,Guangdong Province,China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 73 Report No.:NTEK-2015NT09302780F2 TEST RESULT CERTIFICATION Applicant’s name ................. : Superinworld Technology Co., Ltd. Address ................................. : Room 1107-1109 Jueshi Building Jiabin Road, Luohu District, Shenzhen City,Guangdong Province,China Manufacture's Name ............ : Superinworld Technology Co., Ltd. Address ................................. : Room 1107-1109 Jueshi Building Jiabin Road, Luohu District, Shenzhen City,Guangdong Province,China Product description Product name ........................... : Tablet PC Model and/or type reference : SM708 Serial Model： N/A Standards ............................. : FCC Part15.247: 01 Oct. 2015 Test procedure ..............................ANSI C63.10-2013 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 30 Sep. 2015 ~14 Oct. 2015 Date of Issue ........................................... : 14 Oct. 2015 Test Result ............................................... : Pass Testing Engineer : (Eileen Liu) Technical Manager : (Brown Lu) Authorized Signatory : (Sam Chen) Page 3 of 73 Report No.:NTEK-2015NT09302780F2 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 23 3.2.1 RADIATED EMISSION LIMITS 23 3.2.2 TEST PROCEDURE 24 3.2.3 DEVIATION FROM TEST STANDARD 24 3.2.4 TEST SETUP 25 3.2.5 EUT OPERATING CONDITIONS 26 3.2.6 TEST RESULTS (BELOW 30 MHZ) 27 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 28 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 30 4 . NUMBER OF HOPPING CHANNEL 31 4.1 APPLIED PROCEDURES / LIMIT 31 4.1.1 TEST PROCEDURE 31 4.1.2 DEVIATION FROM STANDARD 31 4.1.3 TEST SETUP 31 4.1.4 EUT OPERATION CONDITIONS 31 4.1.5 TEST RESULTS 32 5 . AVERAGE TIME OF OCCUPANCY 33 5.1 APPLIED PROCEDURES / LIMIT 33 Page 4 of 73 Report No.:NTEK-2015NT09302780F2 Table of Contents Page 5.1.1 TEST PROCEDURE 33 5.1.2 DEVIATION FROM STANDARD 33 5.1.3 TEST SETUP 34 5.1.4 EUT OPERATION CONDITIONS 34 5.1.5 TEST RESULTS 35 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 41 6.1 APPLIED PROCEDURES / LIMIT 41 6.1.1 TEST PROCEDURE 41 6.1.2 DEVIATION FROM STANDARD 41 6.1.3 TEST SETUP 41 6.1.4 EUT OPERATION CONDITIONS 41 6.1.5 TEST RESULTS 42 7 . BANDWIDTH TEST 48 7.1 APPLIED PROCEDURES / LIMIT 48 7.1.1 TEST PROCEDURE 48 7.1.2 DEVIATION FROM STANDARD 48 7.1.3 TEST SETUP 48 7.1.4 EUT OPERATION CONDITIONS 48 7.1.5 TEST RESULTS 49 8 . PEAK OUTPUT POWER TEST 55 8.1 APPLIED PROCEDURES / LIMIT 55 8.1.1 TEST PROCEDURE 55 8.1.2 DEVIATION FROM STANDARD 55 8.1.3 TEST SETUP 55 8.1.4 EUT OPERATION CONDITIONS 55 8.1.5 TEST RESULTS 56 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 62 9.1 DEVIATION FROM STANDARD 62 9.2 TEST SETUP 62 9.3 EUT OPERATION CONDITIONS 62 9.4 TEST RESULTS 63 10 . ANTENNA REQUIREMENT 71 10.1 STANDARD REQUIREMENT 71 10.2 EUT ANTENNA 71 11 . EUT TEST PHOTO 72 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 73 Report No.:NTEK-2015NT09302780F2 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 73 Report No.:NTEK-2015NT09302780F2 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 73 Report No.:NTEK-2015NT09302780F2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Tablet PC Trade Name Superinworld Model Name SM708…

Text truncated - open the document above for the full version.

Page 72 of 73 Report No.:NTEK-2015NT09302780F2 11. EUT TEST PHOTO Radiated Measurement Photos Page 73 of 73 Report No.:NTEK-2015NT09302780F2 CONDUCTED EMISSION Photos
