Q6SCA980027TX27 MHz Red Brown Camouflage German King Tiger






Operation Description of transmitter for Red Brown Camouflage German King Tiger The transmitter for Red Brown Camouflage German King Tiger operates at 27.145 MHz which is controlled by a crystal. It is powered two a 9V battery. There is an ON/OFF switch, a START & STOP button for resetting the receiver, a “cannon” button for generating sound. There are two control sticks on the body. The left one control the left movement of the tank and the right one control the right movement. Refer to the circuit design, the circuit description is listed as follows : - IC : HE80021M (TX) and associated circuit act as encoder - X1, Q1 and associated circuit act as oscillator - Q2, L2 and associated circuit act as amplifier - C11, C12, T1 and associated circuit act as filter

1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:19-May-2003Sheet of File:C:\HDQ\TANK\FCC tank\TANK01 SCH TX-2.DDBDrawn By: C4 104 C3 22P(NPO) Back/L Back/R Fire Power/ON For/L For/R Corporation: TANK01 27MHZ TX-2 R2 9.1k 1% R4 220K R6 15k R5 100R Q1 C945P Q2 C945P C8 47P C11 150P C6 47P C10 47P C2 104 X 27.145MHZ L2 2.2UH L1 2.2UH ANTENNA R1 330R R8 100R C9 2A203J Z1 3V9 R7 33K C5 68P C1 104 FX1 REST GND PD7 PD1PD0 PC2 PC3 PC4 PD3 PD4 PD5 PD2 PC5 PC6 PC7 VDD U1 HE80021M(TX) S2 TX RX R3 56K Battery 9V C7 104 S1 R10 330R C12 15P T1 14T R9 3K 5MM RED LED1 27MHZ TX L3 6.8uH 02 C13 102 AMPHO(HK)LIMITED HDQ

TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD004930-1 Date : 2003 May 21 Applicant : Tam’s Industrial Co., Ltd. Room 1201, New East Ocean Centre, 9 Science Museum Road, Tsim Sha Tsui East, Kowloon, Hong Kong. Sample Description : One(1) submitted sample stated to be 27 MHz Red Brown Camouflage German King Tiger of Model No. CA9800. Rating : 1 x 9 V size battery No. of sample(s) : Two(2) pieces *** Date Received : 2003 March 25. 2003 May 10. Test Period : 2003 March 25 – 2003 April 03. 2003 April 07 – 2003 April 14. 2003 May 10 – 2003 May 15. Test Requested : FCC Part 15 Certification Test Method : FCC Rules and Regulations Part 15 – May 2002 ANSI C63.4 – 1992 Test Result : See attached sheet(s) from page 2 to 10. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. For and on behalf of CMA Testing and Certification Laboratories Authorized Signature : Page 1 of 10 Danny Chui EMC Engineer - EL. Division FCC ID : Q6SCA980027TX TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD004930-1 Date : 2003 May 21 Table of Contents 1 General Information........................................................................................................................ 3 1.1 General Description.................................................................................................................. 3 1.2 Related Submittal Grants........................................................................................................... 3 1.3 Location of the test site.............................................................................................................. 4 1.4 List of measuring equipment...................................................................................................... 5 2 Description of the radiated emission test.......................................................................................... 6 2.1 Test Procedure.......................................................................................................................... 6 2.2 Test Result................................................................................................................................ 6 2.3 Radiated Emission Measurement Data........................................................................................ 7 3 Description of the Line-conducted Test............................................................................................ 8 3.1 Test Procedure.......................................................................................................................... 8 3.2 Test Result................................................................................................................................ 8 3.3 Graph and Table of Conducted Emission Measurement Data....................................................... 8 4 Photograph..................................................................................................................................... 9 4.1 Photographs of the Test Setup for Radiated Emission and Conduction Emission........................... 9 4.2 Photographs of the External and Internal Configurations of the EUT............................................ 9 5 Supplementary document................................................................................................................. 9 5.1 Bandwidth................................................................................................................................ 9 6 Appendices.................................................................................................................................... 10 Page 2 of 10 FCC ID : Q6SCA980027TX TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD004930-1 Date : 2003 May 21 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for Red Brown Camouflage German King Tiger operating at 27.145 MHz which is controlled by a crystal. The EUT is powered a 9 V battery. There is an ON/OFF switch, a START & STOP button for resetting the receiver, a “cannon” button for generating sound. There are two control sticks on the body. The left one control the left movement of the tank and the right one control the right movement. The brief circuit description is listed as follows : - IC : HE80021M (TX) and associated circuit act as encoder - X1, Q1 and associated circuit act as oscillator - Q2, L2 and associated circuit act as amplifier - C11, C12, T1 and associated circuit act as filter 1.2 Related Submittal Grants The receiver for this transmitter is exempted from the Part 15 technical rules per 15.101(b). Page 3 of 10 FCC ID : Q6SCA980027TX TEST REPORT This document shall not be reproduced either in full or in part except with written approval by the Authorized Representative of CMA Testing. Room 1401-3, Yan Hing Centre, 9-13 Wong Chuk Yeung St.., Fo Tan, Shatin, Hong Kong. Tel: (852) 2698 8198 Fax: (852) 2695 4177 E-mail: [email protected] Web Site: http://www.cmatcl.com Report No. : AD004930-1 Date : 2003 May 21 1.3 Location o…
