Q79-703Child Perimerter Safety Device

GOTCHA™ Child Perimeter Safety Device by National Scientific Corporation Thank you for purchasing the NSC Gotcha™ Perimeter Safety Device. These units can be thought of as an ‘electronic leash’ with a variable range. When the child wanders beyond the range that has been set for them the child unit will automatically alarm. When the child comes back into your comfort zone the alarm can either be canceled from the parent unit or it will automatically cancel. This product is intended to assist you in keeping track of your children in busy environments, such as shopping malls or parks. One parent unit can track multiple child units simultaneously (additional child units sold separately). Owner's Manual Version 1d © 2003 National Scientific Corporation Please read this operation manual carefully before using the product. Please keep this manual in a safe place for future reference. A full version of this manual is also on our web site www.national-scientific.com BASIC PRODUCT USE Gotcha consists of two units: one part is worn by the parent (parent unit) and the other is worn by the child (child unit). The child unit also has an anti tamper feature. If the child unit is removed the alarm will automatically activate. The alarm can only be canceled by re-attaching the unit to the childs clothing and pressing the LOCATE/CANCEL button on the parent unit. Each parent unit has a unique ID code. Each child unis must be programmed to recognise the correct parent unit it belongs to. This means that your child unit will now only respond to your parent unit. However additional child units may be bought and programmed to operate with a specific parent unit. The parent unit has a LOCATE/CANCEL button and an on/off switch. The child unit is automatically switched on by opening the belt clip and attaching it to the childs clothing. It can only be switched off by a comand from the parent unit. When your child wanders beyond the preset perimeter, the child’s unit will automatically sound an alarm. This audible child unit alarm (there is no alert directly in the parent unit) alerts you that the child is outside the safety zone. You should immediately respond to this alarm. You can easily locate your child by following the direction of the alarm sound. The alarm will either automatically re-set or it can be cancelled by the parent pressing the LOCATE/CANCEL button on the parent unit when your child is back inside the safety zone. For added safety, the child unit is also designed to alarm when tampered with. Warning THIS PRODUCT DOES NOT TAKE THE PLACE OF STRICT AND ATTENTIVE ADULT SUPERVISION. IT IS INTENDED AS A TOOL TO ASSIST ADULTS IN KEEPING TRACK OF NEARBY CHILDREN. BUTTONS BATTERY INSTALLATION Your Gotcha parent unit requires one CR2 battery and the child unit requires one 2032 battery BATTERY INSTALLATION AND SET UP Parent unit: 1. Turn parent unit off (switch in the up position). 2. Locate and remove the 2 battery compartment screws (located at the top back corners of the unit) with a small Philips screwdriver. 3. Remove battery compartment cover. 4. Remove old battery (if installed) noting polarity. 5. Install new battery ensuring correct polarity with diagram in battery compartment. 6. Re-attach battery door and fasten screws. Child unit: 1. Remove battery compartment screw (located at the top right hand corner of the back face). 2. Remove battery compartment cover. 3. Insert CR2032 battery (by sliding it under the battery clip) into to child unit with the +ve symbol facing up. 4. Re-assemble the battery compartment and screw. BUTTONS (PARENT) FUNCTION OFF TO ON (PARENT) SWITCHES THE PARENT UNIT ON ON TO OFF (PARENT) SWITCHES THE PARENT UNIT OFF, ALSO SENDS CODE TO CHILD UNIT THAT IT WILL BE SWITCHED OFF. RANGE (PARENT) SETS THE DISTANCE THE CHILD CAN WANDER. 3 SETTINGS OF CLOSE, MEDIUM AND FAR LOCATE / CANCEL (PARENT) IF THE CHILD UNIT IS NOT IN ALARM – THE CHILD UNIT WILL BE LOCATED IF THE CHILD UNIT IS IN ALARM – THIS WILL CANCEL THE ALARM CLASP ON CHILD UNIT ON / OFF FUNCTION AS WELL AS TAMPER TEACHING ADULT / CHILD UNITS: The child unit now must be taught to listen out for the correct parent unit. Each parent unit has a unique ID code. Each child unist must be taught which parent unit it belongs to. This means that your child unit will now only respond to your parent unit. 1. Open the clip on the back of the child unit. 2. Attach the child unit to either a piece of clothing or some other thin object (such as this card) that will keep the clip open. 3. The LED on the child unit will now flash rapidly. 4. Place the parent unit near the child unit. 5. Switch on the parent unit. 6. The LED on the parent unit will flash rapidly and then pulse regularly 7. Press the locate / cancel button on the parent unit until the alarm stops – the child unit should chirp the locate alarm Note: In the unlikely event that the child unit does not recognize the parent unit it will emit a series of long beeps after about 20 second these beeps should stop. The LED on the Child unit should now pulse approximately every 2 seconds. 1. Remove the child unit from the item it was attached to and close the clasp. 2. The child unit should now alarm (anti-tamper feature). 3. Re-attach the child unit to the item it was attached to. 4. Press the locate / cancel button until alarm cancels – the unit will now stop alarming To become familiar with its operation and features, you should now experiment with your Gotcha!! TO SWITCH THE UNITS OFF 1. Switch parent unit off. 2. LED on parent unit will stop flashing. 3. Child unit will begin to chirp (warning that it is expecting to be switched off). 4. Remove child unit from clothing. 5. Close clasp on child unit. 6. Chirping will stop and unit is switched off. NOTE IF YOU TAKE LONGER THAN 5 SECONDS TO REMOVE THE CHILD UNIT THE CHILD UNIT WILL AUTOMATICALLY ALARM. YOU WILL HAVE TO SWITCH THE PARENT UNIT BACK ON AGAIN AND REPEAT STEPS 1 THROUGH 6. RANGE SENSITIVITY The range sensitivity switc…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Please be advised that National Scientific Corporation authorizes Washington Laboratories, Ltd. to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Yours faithfully, Graham Clark VP Technology Applications

Date: July 16, 2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: Q79-703 Please be advised that the following exhibits are to be held confidential on behalf of National Scientific Corporation: • Schematics • Theory of operation The above referenced application documents contain technical information that National Scientific Corporation deems to be trade secrets and proprietary. If made public, the information could be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Yours faithfully, Graham Clark VP Technology Applications

Front Back Left Side Right Side Top Bottom

Date: July 16, 2003 Brian Dettling, Washington Laboratories Ltd 7560 Lindbergh Drive Gaithersburg, MD 20879 RE: Gotcha! Certification Application 1. Our FCC ID for this application is Q79-703 2. Our FCC Registration Number is 0009081357 3. Our proposed label will be as follows: It will be permanently embossed into the plastic moulding, and be located on the outside back casing centered just above or below the casing retaining screw (depending upon what proves to be the most aesthetically pleasing. Please see enclosed photograph Yours sincerely, Graham Clark VP Technology National Scientific Corp Gotcha! FCC ID: Q79-703 - 2 -

View of Open Housing Top View of Board Bottom View of Board

Document 7623-01, Rev. 0 FCC ID: Q79-703 FCC Certification Test Report Washington Laboratories, Ltd July 2003 FCC Certification Test Report for National Scientific Corporation FCC ID: Q79-703 July 23, 2003 Prepared for: National Scientific Corporation 14455 North Hayden Road Scottsdale, AZ 85260 Prepared By: Washington Laboratories, Ltd. 7560 Lindbergh Drive Gaithersburg, Maryland 20879 FCC Certification Test Report Document 7623-01, Rev. 0 FCC ID: Q79-703 FCC Certification Test Report Washington Laboratories, Ltd July 2003 FCC Certification Test Program FCC Certification Test Report for the National Scientific Corporation Gotcha! Perimeter Safety Device FCC ID: Q79-703 July 23, 2003 WLL JOB# 7623 Prepared by: Brian J. Dettling Documentation Specialist Reviewed by: Gregory M. Snyder Wireless/Telco Services Manager & Chief EMC Engineer Document 7623-01, Rev. 0 FCC ID: Q79-703 FCC Certification Test Report Washington Laboratories, Ltd July 2003 ii Abstract This report has been prepared on behalf of National Scientific Corporation to support the attached Application for Equipment Authorization. The test report and application are submitted for a Periodic Intentional Radiator under Part 15.231 of the FCC Rules and Regulations. This Federal Communication Commission (FCC) Certification Test Report documents the test configuration and test results for a National Scientific Corporation Gotcha! Child Perimeter Safety Device. Testing was performed on an Open Area Test Site (OATS) of Washington Laboratories, Ltd, 7560 Lindbergh Drive, Gaithersburg, MD 20879. Site description and site attenuation data have been placed on file with the FCC's Sampling and Measurements Branch at the FCC laboratory in Columbia, MD. Washington Laboratories, Ltd. has been accepted by the FCC and approved by NIST NVLAP (NVLAP Lab Code: 200066-0) as an independent FCC test laboratory. The National Scientific Corporation Gotcha! Perimeter Safety Device complies with the limits for a Periodic Intentional Radiator device under Part 15.231 of the FCC Rules and Regulations. Document 7623-01, Rev. 0 FCC ID: Q79-703 FCC Certification Test Report Washington Laboratories, Ltd July 2003 iii Table of Contents Abstract......................................................................................................ii 1 Introduction...................................................................................................................1 1.1 Compliance Statement............................................................................................1 1.2 Test Scope............................................................................................................1 1.3 Contract Information..............................................................................................1 1.4 Test Dates.............................................................................................................1 1.5 Test and Support Personnel....................................................................................1 1.6 Abbreviations.........................................................................................................2 2 Equipment Under Test....................................................................................................3 2.1 EUT Identification & Description............................................................................3 2.2 Test Configuration..................................................................................................3 2.3 Testing Algorithm...................................................................................................3 2.4 Test Location.........................................................................................................4 2.5 Measurements........................................................................................................4 2.5.1 References.....................................................................................................4 2.6 Measurement Uncertainty.......................................................................................4 3 Test Equipment..............................................................................................................5 4 Test Results...................................................................................................................5 4.1 Duty Cycle Correction...........................................................................................5 4.2 Occupied Bandwidth: (FCC Part §2.1049)..........................................................11 4.3 Radiated Spurious Emissions: (FCC Part §2.1053)...............................................12 4.3.1 Test Procedure..........................................................................................12 List of Tables Table 1. Device Summary....................................................................................................3 Table 2: Test Equipment List................................................................................................5 Table 3; Duty Cycle Correction..........................................................................................10 Table 4. Occupied Bandwidth Results................................................................................12 Table 5. Radiated Spurious Emissions Limits.......................................................................12 Table 6: Radiated Emission Test Data.................................................................................14 List of Figures Figure 1. Duty Cycle; Narrow Pulse Width...........................................................................6 Figure 2. Duty Cycle; Medium Pulse Width..........................................................................7 Figure 3. Duty Cycle; Wide Pulse Width...............................................................................8 Figure 4. Duty Cycle Plot, Worst Case 100ms................…

Text truncated - open the document above for the full version.

Radiated Emissions Test Setup, Front Radiated Emissions Test Setup, Rear
