Q8R-73201271-18th Scale 1963 Impala R/C Lowrider

Craft House Corporation

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: May 31, 2004
Application Purpose: Original Equipment
Date of Application: May 31, 2004
Equipment Note: 1-18th Scale 1963 Impala R/C Lowrider
Frequency Range: 27.15000000 - 27.15000000
Company: Craft House Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1/18 FULL FUNCTION RADIO CONTROL LOWRIDER - Please read carefully before operating. - Warning! Use under the direct supervision of an adult. - Keep the operation manual and display box for reference. - Use 5 AA Alkaline (1.5 V) not included & 1- 9V battery not included. - 6.0 V rechargeable battery pack can also be used for this item. - Operating range is up to 30 feet. Subject to outside radio interference. TRANSMITTER BATTERY INSTALLATION Caution when using batteries: - Install batteries making sure that the + and - poles of the batteries are positioned correctly. - Make sure the transmitter & vehicle on/off switch is in the off position when installing batteries. - Remove all batteries from the vehicle and the transmitter after playing. 1) Remove battery door in back of transmitter. 2) Insert 9 volt battery into compartment. 3) Replace battery door. VEHICLE BATTERY INSTALLATION - Remove battery door from the underside of the vehicle with screwdriver. - Insert 5 AA batteries or 1- 6.0 volt rechargeable battery. - Replace battery door. - Do not mix old and new batteries. - Avoid using alkaline, standard (carbon-zinc), or rechargeable (nickel- cadmium) batteries. CAUTION - Avoid combined use of charged Ni-Cd and discharged Ni-CD batteries. - Do not mix old and new batteries. - Avoid using alkaline batteries and Ni-Cd batteries together. Three major causes of vehicle malfunction: 1. Weak batteries 2. Incorrect battery installation 3. Radio interference. HOW TO OPERATE VEHICLE 1. Twist the antennae into the top of the transmitter. 2. Turn the vehicle & transmitter ON/OFF switch to the ON position. 3. The first toggle on the left side on the transmitter will move the vehicle forward when pushed. The vehicle will move in reverse when the toggle is pulled back towards you. 4. Push the middle toggle to start the hopping action. The car can hop while moving or while standing still. 5. The last toggle on the right will steer the vehicle either left or right. NOTE - You can control the vehicle at a longer distance by holding the transmitter higher with the antenna straight up. - When the vehicle slows down or starts moving erratically, replace all dying batteries with fully charged batteries. OPERATING SAFETY RULES Select a SAFE place to operate your vehicle. Do not drive in the street. Avoid driving on sand or through puddles of water. These hazards can impair your performance. Check the surface ahead of you and watch for obstacles. The radio receiver in your vehicle and transmitter are sensitive instruments. Do not leave vehicle or transmitter near sources of HEAT or DIRECT SUNLIGHT for long periods of time. Avoid leaving vehicle or transmitter outside overnight. NIGHT DAMPNESS IS HARMFUL TO INTERIOR MECHANISM. RADIO INTERFERENCE Sometimes erratic behavior or loss of control of vehicle is the result of interference caused by high tension wires, high voltage transformers, certain types of buildings, concrete walls or narrow places where radio signals sent from your transmitter may be scattered thus making it difficult for your vehicle to receive a good radio signal. If you encounter this type of behavior or loss of control, change to a different location. You will encounter interference if another radio controlled vehicle or CB radio is operating in the same vicinity on your same frequency. CAUTION Keep out of reach of small children under 36 months old as there is danger of getting hurt. This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received. Including interference that may cause undesired operation. Your R/C vehicle might cause TV or radio interference even when it’s operating properly. To determine whether your R/C car is causing interference, turn off your R/C car. If the interference goes away, your R/C car is causing the interference. Try to eliminate the interference by: - Moving your r/c car away from the receiver. - Contact your local store for help. If you cannot eliminate the interference the FCC requires that you stop using your R/C car. IT IS A VIOLATION OF THE FCC REGULATIONS TO REMODEL OR ALTER THIS DEVICE IN ANY WAY WITHOUT PERMISSION. ANYONE WHO VIOLATES THE REGULATIONS WILL LOSE THE RIGHT TO OPERATE THE DEVICE.

Test Report

Page 1 of 15 Engineering Test Report No. 33505-01 Measurement of RF Interference from a 1/18 Scale 1963 Impala Lowrider RC Car Transmitter For : Craft House Corporation Toledo, OH Date Received : May 17, 2004 Date Tested : May 17, 2004 Test Personnel : Daniel E. Crowder Specification : FCC "Code of Federal Regulations” Title 47 Part 15, Subpart C Test Report By : Daniel E. Crowder Approved By : Raymond J. Klouda Registered Professional Engineer of Illinois - 44894 Elite Electronic Engineering Inc. 1516 Centre Circle Downers Grove, IL 60515 Tel : (630) 495-9770 Fax: (630) 495-9785 www.elitetest.com Engineering Test Report No. 33505-01 Page 2 of 15 THIS REPORT SHALL NOT BE REPRODUCED, EXCEPT IN FULL, WITHOUT THE WRITTEN APPROVAL OF ELITE ELECTRONIC ENGINEERING INCORPORATED. TABLE OF CONTENTS PARAGRAPH DESCRIPTION OF CONTENTS PAGE NO. 1.0 INTRODUCTION ................................................................................................................................................ 3 1.1 Description of Test Item.................................................................................................................................... 3 1.2 Purpose ............................................................................................................................................................. 3 1.3 Deviations, Additions and Exclusions ............................................................................................................... 3 1.4 Applicable Documents ...................................................................................................................................... 3 1.5 Subcontractor Identification .............................................................................................................................. 3 1.6 Laboratory Conditions..................................................................................................................................... 3 2.0 TEST ITEM SETUP AND OPERATION............................................................................................................. 3 2.1 Power Input...................................................................................................................................................... 3 2.2 Grounding......................................................................................................................................................... 3 2.3 Peripheral Equipment........................................................................................................................................ 4 2.4 Interconnect Cables........................................................................................................................................... 4 2.5 Operational Mode ............................................................................................................................................. 4 3.0 TEST EQUIPMENT............................................................................................................................................. 4 3.1 Test Equipment List .......................................................................................................................................... 4 3.2 Calibration Traceability ................................................................................................................................... 4 3.3 Measurement Uncertainty................................................................................................................................ 4 4.0 REQUIREMENTS, PROCEDURES AND RESULTS.......................................................................................... 5 4.1 Powerline Conducted Emissions ..................................................................................................................... 5 4.1.1 Requirements............................................................................................................................................ 5 4.2 Radiated Measurements................................................................................................................................... 5 4.2.1 Requirements............................................................................................................................................ 5 4.2.2 Procedures ................................................................................................................................................ 5 4.2.2.1 Preliminary Radiated Measurements ............................................................................................... 5 4.2.2.2 Final Radiated Measurements ........................................................................................................... 6 4.2.3 Results ...................................................................................................................................................... 6 4.3 Band Edge Measurements ............................................................................................................................... 6 4.3.1 Requirement ............................................................................................................................................. 6 4.3.2 Procedures ................................................................................................................................................ 7 4.3.3 Results ...................................................................................................................................................... 7 5.0 CONCLUSIONS................................................................................................................................................... 7 6.0 CERTIFICATION ................................................................................................................................................ 7 7.0 ENDORSEMENT DISCLAIMER...…
