Q8T10000037Pet Avoidance System

16 Support / Warranty EXCEPT TO THE EXTENT PROHIBIT ED BY APPLICABLE LAW, NO OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED, OTHER THAN THOSE PROVIDED IN WRITING HEREIN, SHALL APPLY TO THIS UNIT, PERIMETER TECHNOLOGIES, INC. SHALL NOT BE LIABLE FOR ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE FOR ANY PERIOD IN EXCESS FOR THE PERIODS OF EXPRESS WARRANTIES PROVIDED ABOVE. IN ADDITION, UNDER NO CIRCUMSTANCES, SHALL PERIMETER TECHNOLOGIES, INC. BE LIABLE FOR PROPERTY DAMAGE, ECONOMIC LOSS, OR ANY CONSEQUENTIAL DAMAGES SUSTAINED IN CONNECTION WITH SAID UNIT. SOME STATES DO NOT ALLOW LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS, OR DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. PERIMETER TECHNOLOGIES, INC. NEITHER ASSUMES NOR AUTHORIZES ANY REPRESENTATIVE OR OTHER PERSON TO ASSUME FOR IT ANY OBLIGATION OR LIABILITY OTHER THAN SUCH AS IS EXPRESSLY SET FORTH HEREIN. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE. 1 Indoor Wireless Transmitter 10000037 2 Description / Specifications The transmitter can be used in one of two modes, wireless or wired. In wireless mode the transmitter emits a signal radially approximately seven feet. In wired mode, the transmitter will emit a signal strength of approximately four feet on ei ther side of the attached wire. Actual amount of signal generated is a function of wire geometry. The pet wears a battery-powered receiver, and will receive a correction when the receiver collar detects the presence of a signal emitted by the transmitter or the perimeter wire. Features: • Audible and visual wire break indicators on transmitter. • Fully adjustable range. Digital readout of approximate receiver activation range. • Lifetime transmitte r warranty on materials and workmanship. • Proudly designed and manufactured in the United States of America. 15 Support / Warranty LIMITED WARRANTY . PERIMETER TECHNOLOGIES, INC., subject to the terms and conditions contained herein, hereby warrants that it will repair or replace, at its discretion, the equipment described below for the period listed, that proves defective by reason of workmanship and/or material, or by electrical surge, for which the unit was purchased. For the life thereof, any transmitter or receiver, subject to the terms and conditions listed blow, that pr oves defective by reason of workmanship or material; or, on a one time occurrence, any receiver damaged as a result of a pet chew; or, for a “replacement fee”, that the company shall publish from time to time, any receiver that proves defective by reason other than work manship or material. Warranty does not include local service charges that may be imposed by independent dealers rendering servic e. Terms and condition are as follows: a. The warranty is limited to the original purchaser of the unit at retail. When requesting warranty service, proof of purchase may be required. A copy of the warranty registration or sales receipt may be used. b. The unit must be shipped, freight prepaid, or delivered to an authorized Dealer of PERIMETER TECHNOLOGIES, INC. to render the service provided her ein. Dealers may charge a service fee to render on-site service over and above any applicable charges. c. The unit must not have been previously altered, repaired or serviced by anyone other than a se rvice facility authorized by PERIMETER TECHNOLOGIES, INC. The unit must not have been subject to accident, misuse, abuse, or operated contrary to the instructions provided herein. 14 Receiver Problem: Receiver is not detecting signal from the wire 1. Make certain that the transmitter is turned on and transmitting. 2. Make certain that the receiver battery is inserted properly. 3. Make cure that the display is reading a 6 or higher. A setting of less than 6 may not detect a break in the wire. Contact your local dealer if none of these resolve the issue. Problem: Pet is not responding to the correction stimulus / training pulse 1. Check the fit or tightness of the collar. Make certain that the soft probes are making contact with the pet’s skin. In some cases you may want to shave the pet’s hair back so that the probes make good contact with the skin. 2. Make sure that the receiver battery has been recently replaced and is inserted properly. 3. If your unit uses the comfort contacts with rubber tips make sure that they have been replaced. Depending on the pet these may need to be replaced as often as every six months. Contact your local dealer if none of these resolve the issue. Problem: Low battery indicator on the receiver is flashing 1. Replace the receiver battery. Refer to the battery replacement section for specific instructions. Contact your local dealer if none of these resolve the issue. 3 Cautions DO NOT use this system for guard pets or vicious pets. If you believe your pet may pose a threat to others, DO NOT USE THIS SYSTEM. DO NOT use this system as a solid barrier. This product is a deterrent, meant to train pets to remain within or to avoid an established boundary. It will not work without proper training. DO NOT permit children to operate the system. If you are unsure as to whet her or not your pet will be suitable on a PET STOP System, speak with your PET STOP dealer. Additionally, your system will not work unless you: • Adjust the collar tight enough for the posts to make contact with the pet’s skin but not so tight that it will cause injury. • Replace your batteries as required. • Contact your local dealer if there are any issues. • Train your pet properly. We do not recommend leaving your pet unsupervised while on this system. Caution: Changes or modifications to any component, not expressly approved by Perimeter Technologies, Inc. could void the user’s authority to operate this equipment 4 Agency Certifications Note: This equipment has been tested and found to comply wit…

Text truncated - open the document above for the full version.

10000037 FCC Identifier Label Part Number 10240002 Rev – Format: Avery DesignPro V4.0 File Name: Q8T10000037.ZDP Label Location: Case Bottom, Center

RADIATION SCIENCES INC. TEST REPORT NO. RSI-2678E ELECTROMAGNETIC EMISSIONS EVALUATION TESTS PER FCC PART 15, CLASS B OF THE PERIMETER TECHNOLOGIES, INC. INDOOR WIRELESS TRANSMITTER PRODUCT # 10000037 10 FEBRUARY 2005 PREPARED FOR : Perimeter Technologies, Inc. 9933 Alliance Road Cincinnati, OH 45252 SUBMITTED BY : Radiation Sciences Inc. 3131 Detwiler Road Harleysville, PA 19438 PREPARED BY : Jason Signore Technical Writer Radiation Sciences Inc. REVIEWED BY : John Kavalusky EMC Test Engineer Radiation Sciences Inc. RADIATION SCIENCES INC. TABLE OF CONTENTS SECTION TITLE PAGE Table of Contents i List of Figures i Administrative Data ii Summary of Test Results iii 1.0 INTRODUCTION 1 2.0 DESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) 2 3.0 TEST INSTRUMENTATION 3 4.0 TEST RESULTS 4 4.1 Radiated Emissions Test Results (Para. 15.109) 5 4.2 Radiated Emissions Test Results (Para. 15.209) 12 4.3 Conducted Emissions Test Results 19 LIST OF FIGURES FIGURE TITLE PAGE FIGURE 1 Radiated Emissions (Para. 15.109) Test Setup Diagram 6 FIGURE 2 Radiated Emissions (Para. 15.109) Test Setup Photographs 7 FIGURE 3 Radiated Emissions (Para. 15.109) Test Results (Data, Wired) 8 FIGURE 4 Radiated Emissions (Para. 15.109) Test Results (Graph, Wired) 9 FIGURE 5 Radiated Emissions (Para. 15.109) Test Results (Data, Wireless) 10 FIGURE 6 Radiated Emissions (Para. 15.109) Test Results (Graph, Wireless) 11 FIGURE 7 Radiated Emissions (Para. 15.209) Test Setup Diagram 13 FIGURE 8 Radiated Emissions (Para. 15.209) Test Setup Photographs 14 FIGURE 9 Radiated Emissions (Para. 15.209) Test Results (Data, Wired) 15 FIGURE 10 Radiated Emissions (Para. 15.209) Test Results (Graph, Wired) 16 FIGURE 11 Radiated Emissions (Para. 15.209) Test Results (Data, Wireless) 17 FIGURE 12 Radiated Emissions (Para. 15.209) Test Results (Graph, Wireless) 18 FIGURE 13 Conducted Emissions Test Setup Diagram 20 FIGURE 14 Conducted Emissions Test Setup Photographs 21 FIGURE 15 Conducted Emissions Test Results (Wired, Graph Neutral) 22 FIGURE 16 Conducted Emissions Test Results (Wired, Graph Phase) 23 FIGURE 17 Conducted Emissions Test Results (Wireless, Graph Neutral) 24 FIGURE 18 Conducted Emissions Test Results (Wireless, Graph Phase) 25 FIGURE 19 Conducted Emissions Test Results (Manual Readings Data) 26 FIGURE 20 Conducted Emissions Test Results (Wired, Graph Neutral) 27 FIGURE 21 Conducted Emissions Test Results (Wired, Graph Phase) 28 FIGURE 22 Conducted Emissions Test Results (Wireless, Graph Neutral) 29 FIGURE 23 Conducted Emissions Test Results (Wireless, Graph Phase) 30 RSI-2678E i RADIATION SCIENCES INC. ADMINISTRATIVE DATA TEST PERFORMED : Measurement of Radiated and Conducted ElectroMagnetic Emissions. PURPOSE OF TEST : To evaluate the ElectroMagnetic Emissions (EME) characteristics of the Equipment Under Test with respect to Subpart B of Part 15 of the Federal Communications Commission (FCC) Rules for Class B Equipment. EQUIPMENT UNDER TEST (EUT): Model: Indoor Wireless Transmitter Product #: 10000037 CONTRACT: Purchase Order Number: 6820 TEST PERIOD : 12 December 2004 through 4 January 2005 TEST FACILITY : Radiation Sciences Incorporated (RSI), EMC Laboratory, located at: 3131 Detwiler Road, Harleysville, Pennsylvania 19438. TEST PERSONNEL AND COORDINATORS : Radiation Sciences Inc. Perimeter Technologies, Inc. Ron Smith Maria Touchton John Kavalusky RSI-2678E ii RADIATION SCIENCES INC. SUMMARY OF TEST RESULTS The Indoor Wireless Transmitter, Product # 10000037, manufactured by Perimeter Technologies, Inc. of Cincinnati, Ohio, configured as described within, FULLY COMPLIES WITH THE REQUIREMENTS SET FORTH IN SUBPART B OF PART 15 OF THE FEDERAL COMMUNICATIONS COMMISSION RULES FOR CLASS B EQUIPMENT. The test results contained in this report represent emission and/or immunity characteristics of onl y the product(s) (model and serial no.) tested. Radiation Sciences Inc. makes no claim that identical test results will be obtained for future tests of the same model/equipment. RSI-2678E iii RADIATION SCIENCES INC. 1.0 INTRODUCTION This document is a report of tests to determine the ElectroMagnetic Interference (EMI) characteristics of the Indoor Wireless Transmitter, Product # 10000037, manufactured by Perimeter Technologies, Inc. of Cincinnati, Ohio. The purpose of the tests was to evaluate the EMI characteristics of the test sample with respect to Subpart B of Part 15 of the FCC Rules for Unintentional Radiators. Detailed test setups, diagrams, and photographs and the final results of testing are presented herein. All test procedures used meet the requirements of the American National Standards Institute Procedure C63-4: Methods of Measurement of Radio-Noise from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz, dated 17 July 1992. RSI-2678E 1 RADIATION SCIENCES INC. 2.0 DESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) The Indoor Wireless Tx manufactured by Perimeter Technologies, Inc. of Cincinnati, Ohio is a Pet Boundary Control Electronic Fencing Device operating at 14.7 kHz. The device Product # is 10000037. The EUT was tested in the wired and wireless modes of operation. Note: the wire is 10 meters in length. Hereinafter, the Indoor Wireless Tx will be referred to as the EUT (Equipment Under Test). RSI-2678E 2 RADIATION SCIENCES INC. 3.0 TEST INSTRUMENTATION RSI CAL INV DUE NO. DESCRIPTION MANUFACTURER MODEL SERIAL DATE 02 PRE_AMPLIFIER C.M.T. LF51104N 114 9/30/2005 32.1 SPEC. ANALY. H.P. 8566B 3638A08767 8/13/2005 33.1 SPEC. ANALY. DISPLY H.P. 3701A22258 8/13/2005 47 ANTENNA ANT.RES.Assoc. BBH-500B 275 12/13/2005 75 ANTENNA TENSOR 4108 204 6/11/2005 80 ANTENNA AMP.RES.Assoc. AT1000 4094-025 6/14/2005 229 LISN SOLAR 8028-50-TS-24-BNC 009347 8/12/2005 230 LISN SOLAR 8028-50-TS-24-BNC 009348 8/12/2005 390 RECEIVER R & S ESH 3 861742/012 4/18/2005 391 RECEIVER R & S ESVP 861744/015 6/15/2005 501 MINI MAST EMCO 2075-2 0002-2278 502 TURNTABLE EMCO 2065-1.21 0001-2156 503 CONTROLLER EMCO 2090 0001-1489 IF CAL …

Text truncated - open the document above for the full version.

RADIATION SCIENCES INC. TEST REPORT NO. RSI-2678E ELECTROMAGNETIC EMISSIONS EVALUATION TESTS PER FCC PART 15, CLASS B OF THE PERIMETER TECHNOLOGIES, INC. INDOOR WIRELESS TRANSMITTER PRODUCT # 10000037 10 FEBRUARY 2005 PREPARED FOR : Perimeter Technologies, Inc. 9933 Alliance Road Cincinnati, OH 45252 SUBMITTED BY : Radiation Sciences Inc. 3131 Detwiler Road Harleysville, PA 19438 PREPARED BY : Jason Signore Technical Writer Radiation Sciences Inc. REVIEWED BY : John Kavalusky EMC Test Engineer Radiation Sciences Inc. RADIATION SCIENCES INC. TABLE OF CONTENTS SECTION TITLE PAGE Table of Contents i List of Figures i Administrative Data ii Summary of Test Results iii 1.0 INTRODUCTION 1 2.0 DESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) 2 3.0 TEST INSTRUMENTATION 3 4.0 TEST RESULTS 4 4.1 Radiated Emissions Test Results (Para. 15.109) 5 4.2 Radiated Emissions Test Results (Para. 15.209) 12 4.3 Conducted Emissions Test Results 19 LIST OF FIGURES FIGURE TITLE PAGE FIGURE 1 Radiated Emissions (Para. 15.109) Test Setup Diagram 6 FIGURE 2 Radiated Emissions (Para. 15.109) Test Setup Photographs 7 FIGURE 3 Radiated Emissions (Para. 15.109) Test Results (Data, Wired) 8 FIGURE 4 Radiated Emissions (Para. 15.109) Test Results (Graph, Wired) 9 FIGURE 5 Radiated Emissions (Para. 15.109) Test Results (Data, Wireless) 10 FIGURE 6 Radiated Emissions (Para. 15.109) Test Results (Graph, Wireless) 11 FIGURE 7 Radiated Emissions (Para. 15.209) Test Setup Diagram 13 FIGURE 8 Radiated Emissions (Para. 15.209) Test Setup Photographs 14 FIGURE 9 Radiated Emissions (Para. 15.209) Test Results (Data, Wired) 15 FIGURE 10 Radiated Emissions (Para. 15.209) Test Results (Graph, Wired) 16 FIGURE 11 Radiated Emissions (Para. 15.209) Test Results (Data, Wireless) 17 FIGURE 12 Radiated Emissions (Para. 15.209) Test Results (Graph, Wireless) 18 FIGURE 13 Conducted Emissions Test Setup Diagram 20 FIGURE 14 Conducted Emissions Test Setup Photographs 21 FIGURE 15 Conducted Emissions Test Results (Wired, Graph Neutral) 22 FIGURE 16 Conducted Emissions Test Results (Wired, Graph Phase) 23 FIGURE 17 Conducted Emissions Test Results (Wireless, Graph Neutral) 24 FIGURE 18 Conducted Emissions Test Results (Wireless, Graph Phase) 25 FIGURE 19 Conducted Emissions Test Results (Manual Readings Data) 26 FIGURE 20 Conducted Emissions Test Results (Wired, Graph Neutral) 27 FIGURE 21 Conducted Emissions Test Results (Wired, Graph Phase) 28 FIGURE 22 Conducted Emissions Test Results (Wireless, Graph Neutral) 29 FIGURE 23 Conducted Emissions Test Results (Wireless, Graph Phase) 30 RSI-2678E i RADIATION SCIENCES INC. ADMINISTRATIVE DATA TEST PERFORMED : Measurement of Radiated and Conducted ElectroMagnetic Emissions. PURPOSE OF TEST : To evaluate the ElectroMagnetic Emissions (EME) characteristics of the Equipment Under Test with respect to Subpart B of Part 15 of the Federal Communications Commission (FCC) Rules for Class B Equipment. EQUIPMENT UNDER TEST (EUT): Model: Indoor Wireless Transmitter Product #: 10000037 CONTRACT: Purchase Order Number: 6820 TEST PERIOD : 12 December 2004 through 4 January 2005 TEST FACILITY : Radiation Sciences Incorporated (RSI), EMC Laboratory, located at: 3131 Detwiler Road, Harleysville, Pennsylvania 19438. TEST PERSONNEL AND COORDINATORS : Radiation Sciences Inc. Perimeter Technologies, Inc. Ron Smith Maria Touchton John Kavalusky RSI-2678E ii RADIATION SCIENCES INC. SUMMARY OF TEST RESULTS The Indoor Wireless Transmitter, Product # 10000037, manufactured by Perimeter Technologies, Inc. of Cincinnati, Ohio, configured as described within, FULLY COMPLIES WITH THE REQUIREMENTS SET FORTH IN SUBPART B OF PART 15 OF THE FEDERAL COMMUNICATIONS COMMISSION RULES FOR CLASS B EQUIPMENT. The test results contained in this report represent emission and/or immunity characteristics of onl y the product(s) (model and serial no.) tested. Radiation Sciences Inc. makes no claim that identical test results will be obtained for future tests of the same model/equipment. RSI-2678E iii RADIATION SCIENCES INC. 1.0 INTRODUCTION This document is a report of tests to determine the ElectroMagnetic Interference (EMI) characteristics of the Indoor Wireless Transmitter, Product # 10000037, manufactured by Perimeter Technologies, Inc. of Cincinnati, Ohio. The purpose of the tests was to evaluate the EMI characteristics of the test sample with respect to Subpart B of Part 15 of the FCC Rules for Unintentional Radiators. Detailed test setups, diagrams, and photographs and the final results of testing are presented herein. All test procedures used meet the requirements of the American National Standards Institute Procedure C63-4: Methods of Measurement of Radio-Noise from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz, dated 17 July 1992. RSI-2678E 1 RADIATION SCIENCES INC. 2.0 DESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) The Indoor Wireless Tx manufactured by Perimeter Technologies, Inc. of Cincinnati, Ohio is a Pet Boundary Control Electronic Fencing Device operating at 14.7 kHz. The device Product # is 10000037. The EUT was tested in the wired and wireless modes of operation. Note: the wire is 10 meters in length. Hereinafter, the Indoor Wireless Tx will be referred to as the EUT (Equipment Under Test). RSI-2678E 2 RADIATION SCIENCES INC. 3.0 TEST INSTRUMENTATION RSI CAL INV DUE NO. DESCRIPTION MANUFACTURER MODEL SERIAL DATE 02 PRE_AMPLIFIER C.M.T. LF51104N 114 9/30/2005 32.1 SPEC. ANALY. H.P. 8566B 3638A08767 8/13/2005 33.1 SPEC. ANALY. DISPLY H.P. 3701A22258 8/13/2005 47 ANTENNA ANT.RES.Assoc. BBH-500B 275 12/13/2005 75 ANTENNA TENSOR 4108 204 6/11/2005 80 ANTENNA AMP.RES.Assoc. AT1000 4094-025 6/14/2005 229 LISN SOLAR 8028-50-TS-24-BNC 009347 8/12/2005 230 LISN SOLAR 8028-50-TS-24-BNC 009348 8/12/2005 390 RECEIVER R & S ESH 3 861742/012 4/18/2005 391 RECEIVER R & S ESVP 861744/015 6/15/2005 501 MINI MAST EMCO 2075-2 0002-2278 502 TURNTABLE EMCO 2065-1.21 0001-2156 503 CONTROLLER EMCO 2090 0001-1489 IF CAL …

Text truncated - open the document above for the full version.
