AP-100 Series Wireless Access Point Installation Guide About the Aruba AP-100 Series Access Points The Aruba AP-104 and AP-105 wireless access points support the IEEE 802.11n standard for high-performance WLAN. This access point uses MIMO (Multiple-in, Multiple-out) technology and other high-throughput mode techniques to deliver high-performance, 802.11n 2.4 GHz and 5 GHz functionality while simultaneously supporting existing 802.11a/b/g wireless services. The AP-100 Series access point works only in conjunction with an Aruba Controller. The Aruba AP-100 Series access point provides the following capabilities: Wireless transceiver Protocol-independent networking functionality IEEE 802.11a/b/g/n operation as a wireless access point IEEE 802.11a/b/g/n operation as a wireless air monitor Compatibility with IEEE 802.3af PoE Central management configuration and upgrades through an Aruba Controller Package Contents AP-104 or AP-105 access point Installation guide (this document) AP-100 Series Hardware Overview Figure 1 AP-100 Front (AP-104 shown) LEDs The AP-100 Series is equipped with four LEDs that indicate the status of the various components of the AP. PWR: Indicates whether or not the AP-100 Series is powered-on ENET: Indicates the status of the AP-100 Series’s Ethernet port 11A/N: Indicates the status of the 802.11a/n radio 11B/G/N: Indicates the status of the 802.11b/g/n radio For information about the AP-100 Series’s LED behavior, see Table 1 on page 2. External Antenna Connectors The AP-104 is designed for use with external antennas and equipped with four external antenna connectors. The AP-105 is equipped with internal antennas. Figure 2 AP-100 Series Rear Console Port Use the console port to connect to a terminal for direct local management. Ethernet Port AP-100 Series is equipped with a single 10/100/1000Base-T (RJ-45) auto-sensing, MDI/MDX wired-network connectivity port. This port supports IEEE 802.3af Power over Ethernet (PoE) compliance, accepting 48VDC as a standard defined Powered Device (PD) from a Power Sourcing Equipment (PSE) such as a PoE midspan injector, or network infrastructure that supports PoE. DC Power Socket If PoE is not available, an optional Aruba AP AC-DC adapter kit (sold separately) can be used to power the AP-100 Series. Reset Button The reset button can be used to return the AP to factory default settings. To reset the AP: 1. Power off the AP. 2. Press and hold the reset button using a small, narrow object, such as a paperclip. 3. Power-on the AP without releasing the reset button. The power LED will flash within 5 seconds. 4. Release the reset button. The power LED will flash again within 15 seconds indicating that the reset is completed. The AP will now continue to boot with the factory default settings. Before You Begin Pre-Installation Network Requirements After WLAN planning is complete and the appropriate products and their placement have been determined, the Aruba controller(s) must be installed and initial setup performed before the Aruba APs are deployed. For initial setup of the controller, refer to the ArubaOS Quick Start Guide for the software version installed on your controller. AP Pre-Installation Checklist Before installing your AP-100 Series AP, ensure that you have the following: CAT5 UTP cable of required length One of the following power sources: IEEE 802.3af-compliant Power over Ethernet (PoE) source Supports full functionality for AP-100 Series The POE source can be any power source equipment (PSE) controller or midspan PSE device Aruba AP AC-DC adapter kit (sold separately) Aruba Controller provisioned on the network: Layer 2/3 network connectivity to your access point One of the following network services: Aruba Discovery Protocol (ADP) DNS server with an “A” record DHCP Server with vendor-specific options Summary of the Setup Process Successful setup of an AP-100 Series access point consists of five tasks, which must be performed in this order: 1. Verify pre-installation connectivity. 2. Identify the specific installation location for each AP. 3. Install each AP. 4. Verify post-installation connectivity. 5. Configure each AP. Verifying Pre-Installation Connectivity Before you install APs in a network environment, make sure that the APs are able to locate and connect to the controller after power on. Specifically, you must verify the following conditions: When connected to the network, each AP is assigned a valid IP address APs are able to locate the controller Refer to the ArubaOS Quick Start Guide for instructions on locating and connecting to the controller. Identifying Specific Installation Locations You can mount the AP-100 Series access point on a wall or on the ceiling. Use the AP placement map generated by Aruba’s RF Plan software application to determine the proper installation location(s). Each location should be as close as possible to the center of the intended coverage area and should be free from obstructions or obvious sources of interference. These RF absorbers/reflectors/ interference sources will impact RF propagation and should have been accounted for during the planning phase and adjusted for in RF plan. Identifying Known RF Absorbers/Reflectors/Interference Sources Identifying known RF absorbers, reflectors, and interference sources while in the field during the installation phase is critical. Make sure that these sources are taken into consideration when you attach an AP to its fixed location. RF absorbers include: Cement/concrete—Old concrete has high levels of water dissipation, which dries out the concrete, allowing for potential RF propagation. New concrete has high levels of water concentration within the concrete, blocking RF signals. Natural Items—Fish tanks, water fountains, ponds, and trees Brick RF reflectors include: Metal Objects—Metal pans between floors, rebar, fire doors, air conditioning/ heating ducts, mesh windows, blinds, chain link fences (depending on aperture…

Text truncated - open the document above for the full version.

Letter of Authorization Company: Aruba Networks Address: 1344 Crossman Ave., Sunnyvale CA 94089 Product Name: Aruba Access point FCC ID: Q9DAP104 Model Number: AP-104 We authorize MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. This shall include the following:  Testing  Approval applications and procedures  Payment of approval fees We declare that MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA, is allowed to forward all information related to the approval project to the applied notified body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature of applicant: Name: Ivaylo Tankov Date: 0 3/10/2012 Title: Compliance Manager

Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 March 29, 2012 Re: SDR Certification Company name: Aruba Networks, Inc. FCC ID: Q9DAP104 Gentlemen, In accordance with 0.459 of CFR 47, Aruba Networks, Inc. hereby requests confidentiality of following documents for the subject application:  Electrical Schematics  Block Diagram  Theory of Operations - Operational Description  SDR Security Description Guide - Aruba_Secure_Mobility_System_SDR  Bill of Materials . Professional Installation Instructions - ProfInstall-Instruction . These documents contain detailed system and equipment description and related information about the product which Aruba Networks considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Aruba Networks considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Signature Ivaylo Tankov Compliance Manager Aruba Networks, Inc. 1344 Crossman Ave., Sunnyvale, CA 94089 Tel: (408) 227 4500 Email: [email protected]

AP-104 Access point External Photos Photo 1 – Top View Front Photo 2 – Bottom View Back Photo 3 – Connectors Bottom View

AP-104 Access point Internal Photos Photo 1 – Cover off View Photo 2 – Main Board Top View Photo 3 – Main Board Top View (RF Shielding off) Photo 4 – Main Board Bottom View Photo 5 – Main Board Bottom View (Shielding off)

MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 Tel: +1 (925) 462-0304, Fax: +1 (925) 462-0306, Web: www.micomlabs.com the wireless lab Maximum Permissible Exposure FCC, Part 15 Subpart C §15.407(f) Industry Canada RSS-Gen §5.5 Calculations for Maximum Permissible Exposure Levels Power Density = Pd (mW/cm 2 ) = EIRP/(4πd 2 ) EIRP = P * G * 3 P = Peak output power (mW) G = Antenna numeric gain (numeric) d = Separation distance (cm) Numeric Gain = 10 ^ (G (dBi)/10) The Aruba AP-104 has two transmitters. The peak power in the table below is calculated by assuming a worst case scenario where the two transmitters are operating simultaneously in the same band. The Peak Power in mW is calculated by taking the maximum conducted power measured. Because the EUT belongs to the General Population/Uncontrolled Exposure the limit of power density is 1.0 mW/cm 2 Freq. Band (MHz) Antenna Gain (dBi) Numeric Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Calculated Power Density @ 20cm (mW/cm 2 ) Minimum Separation Distance (cm) 5150 - 5250 7.5 5.62 +14.81 30.27 0.034 20* *Note: for mobile or fixed location transmitters the minimum separation distance is 20cm, even if calculations indicate the MPE distance to be less. Specification Maximum Permissible Exposure Limits FCC §1.1310 Limit = 1mW / cm 2 from 1.310 Table 1 RSS-Gen §5.5 Before equipment certification is granted, the application requirements of RSS-102 shall be met. Laboratory Measurement Uncertainty for Power Measurements Measurement uncertainty ±1.33 dB

COVER PAGE Test of Aruba AP-104 802.11a/b/g/n Wireless AP To: FCC 47 CFR Part 15.407 & IC RSS-210 Test Report Serial No.: ARUB99-U3 Rev A TITLE PAGE TEST REPORT FROM Test of Aruba AP-104 802.11a/b/g/n Wireless AP to To: FCC 47 CFR Part 15.407 & IC RSS-210 Test Report Serial No.: ARUB99-U3 Rev A Note: this report contains data with regard to the 5,150 to 5,250 MHz band for the Aruba Networks AP-104 Wireless Access Point. 2.4 and 5.8 GHz test data are reported in MiCOM Labs test report ARUB86-A2. This report supersedes: MiCOM Labs Inc Report NONE Applicant: Aruba Networks, Inc 1344 Crossman Avenue Sunnyvale CA 94089, USA Product F unction: Wireless LAN Access Point Copy No: pdf Issue Date: 4th April 2012 This Test Report is Issued Under the Authority of; MiCOM Labs, Inc. 440 Boulder Cour t, Suite 200 Pleasanton, CA 94566 USA Phone: +1 (925) 462-0304 Fax: +1 (925) 462-0306 www.micomlabs.com TEST CERTIFICATE #2381.01 MiCOM Labs is an ISO 17025 Accredited Testing Laboratory This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. Title: Aruba AP-104 802.11a/b/g/n Wireless AP To: FCC 47 CFR Part 15.407 & IC RSS-210 Serial #: ARUB99- U3 Rev A Date: 4th April 2012 Page: 3 of 111 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com This page has been left intentionally blank Title: Aruba AP-104 802.11a/b/g/n Wireless AP To: FCC 47 CFR Part 15.407 & IC RSS-210 Serial #: ARUB99- U3 Rev A Date: 4th April 2012 Page: 4 of 111 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs p ersonnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com TABLE OF CONTENTS ACCREDITATION, LISTINGS & RECOGNITION............................................................ 5 RECOGNITION................................................................................................................... 6 PRODUCT CERTIFICATION.............................................................................................. 7 1. ................................................................................... 9 TEST RESULT CERTIFICATE 2. ........................................ 10 REFERENCES AND MEASUREMENT UNCERTAINTY 2.1. ............................................................................................. 10 Normative References 2.2. ............................................................................ 11 Test and Uncertainty Procedures 3. .......................................... 12 PRODUCT DETAILS AND TEST CONFIGURATIONS 3.1. ..................................................................................................... 12 Technical Details 3.2. ............................................................................................ 13 Scope of Test Program 3.3. ............................................................. 14 Equipment Model(s) and Serial Number(s) 3.4. ....................................................................................................... 14 Antenna Details 3.5. .............................................................................................. 15 Cabling and I/O Ports 3.6. .................................................................................................. 15 Test Configurations 3.7. .......................................................................................... 16 Equipment Modifications 3.8. .......................................................................... 16 Deviations from the Test Standard 3.9. ............................................................. 16 Subcontracted Testing or Third Party Data 4. ...................................................................................................... 17 TEST SUMMARY 5. ........................................................................................................ 19 TEST RESULTS 5.1. ............................................................................................. 19 Device Characteristics 5.1.1. ........................................................................ 19 26 dB and 99 % Bandwidth 5.1.2. ............................................................................... 32 Transmit Output Power 5.1.3. ..................................................................... 39 Peak Power Spectral Density 5.1.4. ................................................................................. 52 Peak Excursion Ratio 5.1.5. ..................................................................................... 65 Frequency Stability 5.1.6. ................................................................ 66 Maximum Permissible Exposure 5.1.7. .................................................................................... 67 Radiated Emissions 5.1.8. .......................... 103 AC Wireline Conducted Emissions (150 kHz – 30 MHz) 6. ..................................................................................................... 106 PHOTOGRAPHS 6.1. .................................................................................. 106 Radiated Emissions > 1GHz 6.2. .................................................................................. 107 Radiated Emissions < 1GHz 6.3. ........................................................................ 108 AC Wireline Conducted Emissions 6.4. ............................................................ 109 Conducted RF Measurement Test Set-Up 7. ...............................................................................…

Text truncated - open the document above for the full version.

MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 Tel: +1 (925) 462-0304, Fax: +1 (925) 462-0306, Web: www.micomlabs.com the wireless lab Aruba Networks AP-104 Test Setup photographs Radiated Emissions > 1GHz Page 2 of 4 the wireless lab Radiated Emissions < 1GHz Page 3 of 4 the wireless lab AC Wireline Conducted Emissions Page 4 of 4 the wireless lab Conducted RF Measurement Test Set-Up
