605RSeriesRemoteAccessPoints|InstallationGuide1 605RSeriesRemoteAccessPoints InstallationGuide TheAruba605RSeriesaccesspointsaredual-radiotri-band802.11axWi-Fi6Eremoteaccesspointsthat provideconnectivityforbothwiredandwirelessclientdevices. PackageContents Thefollowingmaterialsareincludedwiththisproduct: nAP-605RAccessPointx1 nAC-to-DC PowerAdapter(withpowercord)x1 n(ForAP-605Rbundleonly)ArubaAP-605CM12LTECAT12CellularModule(pre-installed)x1 Tosimplifytheordering,ArubaofferstheAP-605R bundlethatcombinesanAP-605Raccesspoint,apoweradapter (withpowercord)andaAP-605CM12LTECAT12CellularModule(pre-installed) HardwareOverview Figure1AP-605RFrontView 1SystemStatusLED 2LCDPanel 3LCD Button 2|Rev01|April2023 Figure2AP-605RBundleFrontView 1SystemStatusLED 2LCDPanel 3LCD Button TheantennasoftheLTE moduleareinafoldedpositionwhentakenoutofthepackage.Toensuretheantennas functionwell,puttheantennasinaverticalpositionasshownin. SystemStatusLED ThesystemstatusLEDislocatedonthetoppaneloftheaccesspointindicatesthesystemstatusofthe accesspoint. Color/StateMeaning OffAccesspointpoweredoff Green-blinking 1 Accesspointbooting,notready Green-solidAccesspointready,fullyfunctional RedSystemerrorconditionorthermalshutdownengaged-Immediateatten- tionrequired Table1:SystemStatusLED 1.Blinking:onesecondon,onesecondoff,2secondscycle. LEDDisplaySettings TheLEDshavethreeoperatingmodesthatcanbeselectedinthesystemmanagementsoftware: nNormalmode:defaultafterpoweron.RefertoTable1. nOffmode:theLEDisoff nBlinkmode:theLEDblinksgreen Pressingtheresetbuttonforlessthan10secondsduringnormaloperationwilltoggletheLEDmode between“normal”(defaultafterpoweron)and“off”mode. Pressingtheresetbuttonforlongerthan10secondsmaycausetheaccess pointtoresetandreturntothefactory defaultstate. LCDPanel TheLCDpanelislocatedonthefrontpaneloftheaccesspointthatdisplaystheaccesspoint'sbootupand systemstatusinformation. TheLCDbuttonislocatedontherightsideoftheLCD panelandusedtooperatetheLCDpanel: nWhenbootedup,theLCDwilldisplaythehomepage,whichisArubalogobydefault,butitis configurablebythesystemmanagementsoftware.ShortpressingtheLCDbuttonwillscrollthroughthe pagesontheLCDscreen.TheLCDdisplaywillreturntothehomepageafter10secondsofinactivity. nLongpressingtheLCDbuttonwilladjusttheLCD'sbacklightbrightness. AcessPoint StateLCD Displays Duringaccesspoint boot(systemstatus LED blinkinggreen) Displaybootupstatusinformation,suchas"AP powering up...","Connectingtonetwork"andetc. Accesspoint isupandrunning(systemstatus LEDsolidgreen) Displaylogo(homepage)andsystemstatusinformation. ShortpressingtheLCDbuttonontherightoftheLCD screen willscrollthroughpages. Accesspointisinerrorconditionorthermal shutdownmode(systemstatusLED solidred) Displayrelevantinformationabouttheerrorcondition. Table2:LCDPanelDisplays Rev01|April2023|3 4|Rev01|April2023 Figure3605RSeriesRearandSideView 1ResetButton 2Micro-BConsolePort 3E0EthernetPort(Orange) 4E1EthernetPort(OrangeandBlue) 5 E2EthernetPort(Blue) 6 E3EthernetPort(Blue) 7 E4EthernetPort(Red) 8USBInterface 9KensingtonLockSlot ResetButton Theresetbuttoncanbeusedtoresettheaccesspointtofactorydefaultsettingsorturnoff/ontheLED display. Useoneofthefollowingmethodstoresettheaccesspointtofactorydefaultsettings: nToresetduringnormaloperation: lHoldtheresetbuttonformorethan10secondswhiletheaccesspointisrunning. lReleasetheresetbutton. nToresetduringpowerup,holdtheresetbuttonwhiletheaccesspointispoweringup. ThesystemstatusLEDwillflashagainwithin15secondsindicatingthattheresetiscompleted.Theaccess pointwillnowcontinuetobootwiththefactorydefaultsettings. TotogglethesystemstatusLEDbetween“normal”(defaultafterpoweron)and“off”mode,duringthe normaloperationoftheaccesspoint,shortlypresstheresetbuttonforlessthan10seconds. Micro-BConsolePort Tocreateaconsoleconnectiontotheaccesspoint,followthesesteps: 1.Connecttheconsoleportontheaccesspointtotheserialportonthecomputerusingtheproprietary ArubaAP-CBL-SERUcableorAP-MOD-SERUmodule,whichneedtobepurchasedseparately. 2.Starttheterminalemulationsoftwareonthecomputerandconfigureanewserialsessionwiththe followingsettings: nSpeed:9600bps nDatabits: 8 nStopbits:1 nParity:None nFlowcontrol:None 3.Starttheterminalemulationsession. 4.PressEnteronce.Iftheconnectionissucessful,youarepromptedtologin. Forthisconsoleportpin-outdetails,refertoFigure4. Figure4Micro-BConsolePortPin-out 1:NC 2:RXD 3:TXD 4:GND 5:GND Ifneeded,theAPconsoledrivercanbefoundattheArubasupportportal. EthernetPorts The605RSeriesaccesspointhasfiveEthernetports(E0-E4),showninFigure3. nTheE0portisa100/1000Base-Tauto-sensingMDI/MDIXuplinkport. nTheE1portisa100/1000/2500Base-Tauto-sensingMDI/MDIXport,whichcanbeconfiguredasa secondaryuplinkportordownlinkportbysystemmanagementsoftware. nTheE2-E4portsare100/1000Base-Tauto-sensingMDI/MDIXdownlinkports.E4portisthePoEoutport andcapabletosupplyPoEpowertoa802.3af-compliantdevicethatisphisicallyconnectedtotheE4 portbyEthernetcable. EthernetPortLEDs EachoftheE0-E3portshasoneLEDlocatedontheleftside,indicatingthenetworkstatusoractivityonthe port. TheE4porthastwoLEDslocatedonbothsides,theleftLED indicatingthenetworkstatusoractivityonthe port,whiletherightLED indicatingthePoEpoweringstatuswhentheaccesspointisoperatingasaPower SourcingEquipment(PSE).SeeFigure3andTable3 Rev01|April2023|5 6|Rev01|April2023 LED Color/StateMeaning Left OffMeetoneofthefollowingconditions: naccesspointispoweredoff nportisdisabled nnolinkestablished Green-blinkingActivitydetectedontheport Green-solidLinkestablishedatoptimumspeed(1Gbpsor2.5Gbps) Amber-solidLinkestablishedatreducedspeed(100Mbps) Right(E4only) OffMeetoneofthefollowingconditions: naccesspointispoweredoff naccesspointisnotsupplyingPoEpower Green-blinking AccesspointisnegotiatingPoEpowerwiththedevicecon- nectedtothisport. Green-solid AccesspointissupplyingPoEpowertothedevice connectedtothisport. Table3:EthernetPortLEDs USBinterface TheUSB2.0USB-Ainterfaceiscompatiblewithselectedcellularmodemsandotherperipherals.When active,thisUSBinterfacecansupplyupto5W/1Atoaconnecteddevice. Kensin…
