Q9DARBT0035Location Beacon / Tag

Aruba LS-BT35 Location Beacon Startup Guide The Aruba LS-BT35 Location Beacon is designed to provide mobile device location awareness and/or asset tracking with the Meridian Mobile Engagement tools. The LS-BT35 is battery-powered and uses the latest BLE 5.0 chipset. The LS-BT35 has a 5+ year battery life when used in Beacon mode, and a 6+ year battery life when used in Asset Tag mode. The LS-BT35 has the following key features:  Enhanced security  Real-time clock  NFC features  Accelerometer  Mechanical tamper-proof on/off switch  Programmable button  LED visual indicator  Fixed attenuator Package Contents The following materials are included with this product:  Aruba LS-BT35 Inform your supplier if there are any incorrect, missing, or damaged parts. To return this product, repack this unit and other included materials into the original packaging before returning it to the supplier. Installation and Activation This device must be professionally installed and serviced by a trained Aruba-Certified Mobility Professional (ACMP), or similar Aruba- certified technician. The device ships with adhesive pads to install the device on a flat surface in an indoor environment. Optional accessory kits are available that allow you to mount the device in an indoor and outdoor environment. For more information about the indoor and outdoor mounting kits, contact your Aruba sales representative. To install this device, refer to the Aruba LS-BT35 Location Beacon Installation Guide by scanning the QR code in this section, or visiting the Documentation tab on support.arubanetworks.com , then select Hardware Installation Guides > BLE > LS-BT35 Software For instructions on initial setup and software configuration, refer to the latest version of the AP Software Quick Start Guide by scanning the QR code in this section, or visiting the Documentation tab on support.arubanetworks.com, then select the Software User & Reference Guides > Aruba Unified. Software End User License Agreement The End User License Agreement (EULA) information for this product can be found at www.arubanetworks.com/assets/legal/EULA.pdf. Safety and Regulatory Compliance Aruba Networks provides a multi-language document that contains country-specific restrictions and additional safety and regulatory information for all Aruba devices. The regulatory model numbers (RMN) for the LS-BT35 is:  LS-BT35: ARBT0035 Changes or modifications to this unit not expressly approved by Aruba Networks, a Hewlett Packard Enterprise company for regulatory compliance can void the user’s authority to operate this equipment. RF Radiation Exposure Statement The product comply with the US/Canada portable RF exposure limit set forth for an uncontrolled environment and are safe for intended op eration as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. Déclaration d'exposition aux radiations: Le produit est conforme aux limites d'exposition pour les appareils portables RF pour les Etats-Unis et le US/Canada établies pour un envir onnement non contrôlé. Le produit est sûr pour un fonctionnement tel que décrit dans ce manuel. La réduction aux expos itions RF peut être augmentée si l'appareil peut être conservé aussi loin que possible du corps de l'utilisateur ou que le dispositif est r églé sur la puissance de sortie la plus faible si une telle fonction est disponible. Figure 1 Label Placement for the LS-BTXX Brazil Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados. Canada This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Déclaration d’Industrie Canada Ce périphérique est conforme aux règlements RSS exempts de licence d’Industrie Canada. L’utilisation de ce périphérique est soumise aux deux conditions suivantes : (1) ce périphérique ne doit pas provoquer d’interférences, et (2) ce périphérique doit accepter toute interférence, y compris les interférences susceptibles de provoquer un dysfonctionnement. European Union The Declaration of Conformity made under RED 2014/53/EU is available for viewing at: www.hpe.com/eu/certificates. Select the Contact Aruba Copyright © Copyright 2019 Hewlett Packard Enterprise Development LP Open Source Code This product includes code licensed under the GNU General Public License, the GNU Lesser General Public License, and/or certain other open source licenses. A complete machine-readable copy of the source code corresponding to such code is available upon request. This offer is valid to anyone in receipt of this information and shall expire three years following the date of the final distribution of this product version by Hewlett Packard Enterprise Company. To obtain such source code, send a check or money order in the amount of US $10.00 to: Hewlett Packard Enterprise Company Attn: General Counsel 6280 America Center Drive San Jose, CA 95002 USA Warranty This hardware product is protected by an Aruba warranty. For more details visit www.hpe.com/us/en/support.html and select the “HPE Servers, Storage, and Networking” option from the Product Support menu to access HPE’s Warranty Check. 3333 Scott Boulevard Santa Clara, California 95054 USA Main Sitewww.arubanetworks.com Support Sitesupport.arubanetworks.com Airheads Social Forums and Knowledge Base community.arubanetworks.com/ North America Telephone1-800-943-4526 1-408-754-1200 International Telephonewww.arubanetworks.com/support- services/contact-support/ Software Licensing Sitewww.hpe.com/networking/support End-of-Life Informationwww.arubanetworks.com/support- services/end-of-life/ Security Inci…

Text truncated - open the document above for the full version.

Date: 2020/3/17 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: Q9DARBT0035 Product name: Location Beacon / Tag To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model ARBT0035 to the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Dist., TaoYuan City 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e-mail : [email protected] Webs We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : Hewlett Packard Enterprise company Address : 3333 Scott Blvd Santa Clara, CA 94089 Signature : _________________________________ Name and Job Title. : Phillip Carranco, Compliance Manager E-mail : [email protected] Tel. : 650-236-9490

Date: March 17, 2020 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for confidentiality FCC ID: Q9DARBT0035 To whom it may concern: Short-term confidentiality Pursuant to DA 04-1705 of the Commission’s pubic notice, in order to comply with the marketing regulations in 47CFR
2.803 and the importation rules in 47 CFR
2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after issue date.  Internal Photographs  External Photographs  User's manual  Test Set up photo Permanent confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below:  Block Diagram  Schematics  Operational Description
Bill of Materials
Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Applicant : Hewlett Packard Enterprise company Address : 3333 Scott Blvd, Santa Clara, CA 95054, USA Signature : _________________________________ Name and Job Title. : Phillip Carranco Compliance Manager E-mail : [email protected] Tel. : 650-236-9490

Project No.: 9N2801 Page No. : 1 of 11 Photographs of EUT Project No.: 9N2801 Page No. : 2 of 11 Project No.: 9N2801 Page No. : 3 of 11 Project No.: 9N2801 Page No. : 4 of 11

1 white PET Label/Aruba 11 NOTE: 1. DIMENSIONS IN MILLIMETERS 2. THICKNESS: 0.1MM 3. MATERIAL: #75 white PET GLOSSY, ADHESIVE BACKED, ULAPPROVED STOCK LABEL, ULAPPROVED INK 4. GRAPHICSANDTEXT: Black Notes: 1.材質:75#白色特多龍, 上可打印霧PET, 背壓花膠 2.印刷顏色:如图 3.尺寸公差:0/-0.2mm 4.所使用材料需符合RoHS 44.0 37.0 R1.5 (3x) C2.5 印刷 :Black刀模線 Model: ARBT0035 ARBT0035 HPE, Postfach 0001,1122 Wien, Austria 4012611 Made in China FCC ID: Q9DARBT0035 IC: 4675A-ARBT0035 XXX-XXXXXX R-C-HPe-ARBT0035 Label location FCC ID: Q9DARBT0035 IC: 4675A-ARBT0035

Project No.: 9N2801 Page No. : 5 of 11 Project No.: 9N2801 Page No. : 6 of 11 Project No.: 9N2801 Page No. : 7 of 11 Project No.: 9N2801 Page No. : 8 of 11 Project No.: 9N2801 Page No. : 9 of 11 Project No.: 9N2801 Page No. : 10 of 11 Project No.: 9N2801 Page No. : 11 of 11

Report No.: FA9N2801 Page : 1 of 8 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : Q9DARBT0035 Equipment : Location Beacon / Tag Model No. : ARBT0035 Brand Name : Aruba Applicant : Hewlett Packard Enterprise company Address : 3333 Scott Blvd, Santa Clara, CA 95054, USA Standard : 47 CFR FCC Part 2.1093 Received Date : Nov. 28, 2019 Tested Date : Dec. 05 ~ Dec. 12, 2019 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA9N2801 Page : 2 of 8 Report Version: Rev. 01 Table of Contents 1 EXPOSURE EVALUATION OF PORTABLE DEVICES ....................................................................... 4 1.1 SAR TEST EXCLUSION THRESHOLD FOR 100MHz to 6GHz and  50mm ................................... 4 1.2 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 5 1.4 EVALUATION RESULTS ....................................................................................................................... 6 2 TEST LABORATORY INFORMATION ................................................................................................. 8 Report No.: FA9N2801 Page : 3 of 8 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA9N2801 Rev. 01 Initial issue Mar. 12, 2020 Report No.: FA9N2801 Page : 4 of 8 Report Version: Rev. 01 1 EXPOSURE EVALUATION OF PORTABLE DEVICES 1.1 SAR TEST EXCLUSION THRESHOLD FOR 100MHz to 6GHz and  50mm Frequency (MHz) 5 10 15 20 25 Separation distance (mm) 150 39 77 116 155 194 SAR Test Exclusion Threshold (mW) 300 27 55 82 110 137 450 22 45 67 89 112 835 16 33 49 66 82 900 16 32 47 63 79 1500 12 24 37 49 61 1900 11 22 33 44 54 2450 10 19 29 38 48 3600 8 16 24 32 40 5200 7 13 20 26 33 5400 6 13 19 26 32 5800 6 12 19 25 31 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where •f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: FA9N2801 Page : 5 of 8 Report Version: Rev. 01 1.2 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 1.3 MEASUREMENT UNCERTAINTY ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test results be included in the report. The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2) Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA9N2801 Page : 6 of 8 Report Version: Rev. 01 1.4 EVALUATION RESULTS Ant1 Maximum Conducted Output Power Result Condition RF Output Power (dBm) Modulation Mode Freq. (MHz) Average Power (dBm) Rated Power (dBm) Rated Power (mW) LE-125 kbps 2402 -0.33 0 1 LE-125 kbps 2440 -0.31 0 1 LE-125 kbps 2480 -0.35 0 1 LE-500 kbps 2402 -0.32 0 1 LE-500 kbps 2440 -0.29 0 1 LE-500 kbps 2480 -0.34 0 1 LE-1Mbps 2402 -0.29 0 1 LE-1Mbps 2440 -0.26 0 1 LE-1Mbps 2480 -0.32 0 1 LE-2Mbps 2402 -0.31 0 1 LE-2Mbps 2440 -0.28 0 1 LE-2Mbps 2480 -0.33 0 1 [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] =1 / 5 * √2.440 = 0.312 < 3.0 SAR Test Exclusion Thresholds is < 10mW and 3.0 for separation distance 5mm. Therefore, SAR test is not required. Report No.: FA9N2801 Page : 7 of 8 Report Version: Rev. 01 Ant2 Maximum Conducted Output Power Result Condition RF Output Power (dBm) Modulation Mode Freq. (MHz) Average Power (dBm) Rated Power (dBm) Rated Power (mW) LE-125 kbps 2402 -0.65 0 1 LE-125 kbps 2440 -0.55 0 1 LE-125 kbps 2480 -0.55 0 1 LE-500 kbps 2402 -0.66 0 1 LE-500 kbps 2440 -0.56 0 1 LE-500 kbps 2480 -0.55 0 1 LE-1Mbps 2402 -0.63 0 1 LE-1Mbps 2440 -0.54 0 1 LE-1Mbps 2480 -0.52 0 1 LE-2Mbps 2402 -0.66 0 1 LE-2Mbps 2440 -0.57 0 1 LE-2Mbps 2480 -0.54 0 1 [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] =1 / 5 * √2.480 = 0.315 < 3.0 SAR Test Exclusion Thresholds is < 10mW and 3.0 for separation distance 5mm. Therefore, SAR test is not required. Report No.: FA9N2801 Page : 8 of 8 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corp (EMC and Wireless Communication Laboratory), it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise…

Text truncated - open the document above for the full version.

Report No.: FR9N2801 Page : 1 of 81 Report Version: Rev. 01 FCC Test Report FCC ID : Q9DARBT0035 Equipment : Location Beacon / Tag Model No. : ARBT0035 Brand Name : Aruba Applicant : Hewlett Packard Enterprise company Address : 3333 Scott Blvd, Santa Clara, CA 95054, USA Standard : 47 CFR FCC Part 15.247 Received Date : Nov. 28, 2019 Tested Date : Dec. 05 ~ Dec. 12, 2019 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FR9N2801 Page : 2 of 81 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 7 1.3 Test Setup Chart .................................................................................................................................... 7 1.4 Test Equipment List and Calibration Data .............................................................................................. 8 1.5 Test Standards ....................................................................................................................................... 9 1.6 Deviation from Test Standard and Measurement Procedure ................................................................. 9 1.7 Measurement Uncertainty ...................................................................................................................... 9 2 TEST CONFIGURATION ..................................................................................................................... 10 2.1 Testing Condition ................................................................................................................................. 10 2.2 The Worst Test Modes and Channel Details ....................................................................................... 10 3 TRANSMITTER TEST RESULTS ....................................................................................................... 11 3.1 6dB and Occupied Bandwidth .............................................................................................................. 11 3.2 RF Output Power .................................................................................................................................. 22 3.3 Power Spectral Density ........................................................................................................................ 27 3.4 Emissions in Restricted Frequency Bands ........................................................................................... 38 3.5 Emissions in non-restricted Frequency Bands ..................................................................................... 72 4 TEST LABORATORY INFORMATION ............................................................................................... 81 Report No.: FR9N2801 Page : 3 of 81 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR9N2801 Rev. 01 Initial issue Mar. 12, 2020 Report No.: FR9N2801 Page : 4 of 81 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 AC Power Line Conducted Emissions Note N/A 15.247(d) 15.209 Radiated Emissions [dBuV/m at 3m]: 36.79MHz 31.62 (Margin -8.38dB) - PK Pass 15.247(b)(3) Maximum Output Power Power [dBm]: -0.19 Pass 15.247(a)(2) 6dB Bandwidth Meet the requirement of limit Pass 15.247(e) Power Spectral Density Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass N/A means Not Applicable. Note: The EUT consumes DC power from battery, so the test is not required. Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FR9N2801 Page : 5 of 81 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) Bluetooth Mode Ch. Freq. (MHz) Channel Number Data Rate 2400-2483.5 V5.0 LE 2402-2480 0-39 [40] 125 kbps 500 kbps 1 Mbps 2 Mbps Note 1: Bluetooth LE (Low energy) uses GFSK modulation. 1.1.2 Antenna Details Ant. No. Type Connector Gain (dBi) 1 PIFA N/A 3.1 2 PIFA N/A 2.4 1.1.3 Power Supply Type of Equipment under Test (EUT) Power Supply Type DC 3V from battery 1.1.4 Accessories Accessories No. Equipment Description 1 Battery Brand: Wuhan Fanso Technology Co.,Ltd Model: CP505050 Power Rating: 3V, 3000mAH Report No.: FR9N2801 Page : 6 of 81 Report Version: Rev. 01 1.1.5 Channel List Frequency band (MHz) 2400~2483.5 Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 37 2402 9 2422 18 2442 28 2462 0 2404 10 2424 19 2444 29 2464 1 2406 38 2426 20 2446 30 2466 2 2408 11 2428 21 2448 31 2468 3 2410 12 2430 22 2450 32 2470 4 2412 13 2432 23 2452 33 2472 5 2414 14 2434 24 2454 34 2474 6 2416 15 2436 25 2456 35 2476 7 2418 16 2438 26 2458 36 2478 8 2420 17 2440 27 2460 39 2480 1.1.6 Test Tool and Duty Cycle Test Tool n…

Text truncated - open the document above for the full version.

Report No.: FR9N2801 Page: : 1 of 4 Report Version: Rev. 01 Photographs of the Test Configuration Radiated Emission Below 1GHz Test Report No.: FR9N2801 Page: : 2 of 4 Report Version: Rev. 01 Radiated Emission Below 1GHz Test Report No.: FR9N2801 Page: : 3 of 4 Report Version: Rev. 01 Radiated Emission Above 1GHz Test Report No.: FR9N2801 Page: : 4 of 4 Report Version: Rev. 01 Radiated Emission Above 1GHz Test
