Q9DMSR4000DFSOutdoor 802.11a/b/g/n Access Point

0510871-01 Aruba Networks MSR4000 Installation Guide MSR4000 Installation Guide 1 Copyright 2005-2011 by Aruba Networks, USA. All rights reserved. Statement of Conditions In the interest of improving internal design, operation function, and/or reliability, Aruba Networks reserves the right to make changes to products described in this document without notice. Aruba Networks does not assume any liability that may occur due to the use or application of the product(s) described herein. DISCLAIMER: LIMITATION OF LIABILITY 1．Before installation, it’s strongly recommended and requested that users pay particular attention to the safety warnings in the sequentially detailed operation procedures within the manual. If there’s any uncertainty or incapability of solving problems, contact the company’s customer support center. Please DO NOT incur any risk or try to verify situations by yourself. Otherwise, any consequence caused by the attempt shall be completely due to the user himself. 2．Please periodically check whether the installed MSR4000 is damaged, worn-out or poses any danger. Any actual proof, sign or phenomenon of the afore-mentioned situations should be brought to the attention of the company at point of sale. Please DO NOT attempt to repair the product or replace any component. Otherwise, for any consequence arising out of or relating to the users’ attempt repair the product, including but not limited to damages, disuse, short circuit, fire, bodily injury, etc., the company shall not be liable. 3. Users shall purchase or use the company’s MSR4000 voluntarily. Users shall understand on their own initiative and abide voluntarily by policies, regulations or laws of their respective nation or local territories. The consequence arising out of or relating to any violation of the local laws or regulations by the user, shall be solely imputed to the user himself, and the company shall not be liable. 4. The company disclaims any and all warranties and guarantees, express, implied or otherwise, arising, with respect to the MSR4000 products or services, including but not limited to the warranty of MSR4000 Installation Guide 2 merchandisability, the warranty of fitness for a particular purpose, and any warranty of non- infringement of the intellectual property rights of any third party. Liability of the company for loss is limited to the total amount paid to the company by the customer during the previous calendar year. The company will have no obligation or liability, whether arising in contract (including Warranty), tort (including active, passive or imputed negligence, strict liability or product liability) or otherwise for any special, incidental, consequential or indirect damages including but not limited to loss of use, loss of data, business interruption, loss of revenue, loss of business or other financial loss arising out of or in connection with any of the products or other goods or services furnished by the company under this manual, even if advised of the possibility of such damages. 5．It shall never be understood that the manual expresses or implies to any customer or any third party authorize or transfer any rights. The company reserves fully the final interpretation of the MSR4000 and this manual. Safety Warnings The MSR4000 must be installed by trained professional installation technicians. All warnings below must be read and understood before installation. General Safety Warnings You can be killed or injured if performing antenna installation near electrical power lines. Carefully read and follow all instructions in this guide. Please be sure there are no high voltage and electronic fields nearby. Working Aloft Warning When working on tower or roof, individuals must wear safety belts. Tools must be tied to the individual using them. Workers below must wear safety helmets. Lightning Activity Warning MSR4000 Installation Guide 3 Make sure not to connect or disconnect cables during periods of lightning activity. A surge protective device should be installed to prevent potential damage from very high surges, for instance, the peak surges caused by lightning. Explosive Device Proximity Warning Do not operate wireless network devices close to explosive merchandise or in explosive environments if devices are not certified for operation in such an environment, for example, in the vicinity of a gas station. Antenna Placement Warning Do not install any antenna near overhead power lines or other electric light, or where the antenna can come into contact with such circuits. Antenna Selection Warning Please use DC grounding antenna with lightning protection to prevent surge and static electricity. Grounding Warning Please always remember to protect your MSR4000 system by installation of grounding lines. The ground connection must be complete before connecting power to the MSR4000 enclosure. The requirement of grounding is to make sure the resistance must be less than 5 ohm between the ground termination point to grounding tier. Power Installation Warning MSR4000 Installation Guide 4 The installation of the power switch must be performed by a trained professional technician. The power switch is not supplied with the MSR4000. The power cord must be assembled by a professional installer, and the final assembly must comply with related requirements. Solar Irradiation and High Temperature Protection Pay attention to level of sunlight, which can increase the working temperature of MSR4000 to higher than specifications allow. A solar shield is provided in the Aruba standard package and should be installed to protect any outdoor MSR4000. The Aruba Warrantee policy does not cover those outdoor products for which Solar shields are not installed. Please contact Aruba technical support engineers for detailed information. RF Device Protection Before powering up the MSR4000, the RF port must be connected to an antenna or a valid load (not included in the standard accessories for MSR4000). Otherwise, the RF mo…

Text truncated - open the document above for the full version.

Professional installation Guide Product/s covered in this guide: Model: MSR4K43N0-XX is part of the Aruba’s MSR4000 family, implementing quad radio cards each 2x2 MIMO supporting IEEE 802.11 a/b/g/n/j operation. IMPORTANAT - Visit Aruba Support web page for the latest information and documentation related to this product. IMPORTANAT – Please read this document before installing and using your product. This device must be installed and used in strict accordance with the manufacturer's instructions. Only approved by the manufacturer power adapters must be used. For replacement, contact your supplier or distributor. Installation of this product must comply with local regulations and codes. When this product is used with external antenna/s, please refer to the installation documentation provided for the antenna/s. Changes or modifications to the device not approved by the manufacturer of the product could void the user’s authority to operate the equipment and will void the warranty of the product. No user serviceable parts; all repairs and service must be handled by a qualified service center. All products using external antennas must be professionally installed, and the transmit power of the system must be adjusted by the professional installer/s to ensure that the system’s EIRP is in compliance with the limit specified by the regulatory authority of the country of deployment. During deployment of the system and its initial setup, professional installer must ensure that the allowed EIRP limit is not exceeded (in the Country of exploitation of this equipment). To achieve this professional installer must use approved and recommended by the Manufacturer antennas, 1. ANT-2x2-2714 2.4G,14DB,70DEG SECTR,2x2,N-TYPE 2. ANT-2x2-5614U 5.5G-5.8G,14DB,60DEG SECTR,2x2,N-TYPE 3. AP-ANT-80D 2.4GHz Outdoor 8dBi Omni Antenna 4. AP-ANT-86 4.9G-5.9G Outdoor 10dBi Omni Antenna and enter Antenna gain in the software using to setup and mange the product. In additional attenuation between the device and antenna may have to be measured or calculated. The following formula can be used to calculate from EIRP limit related RF power based on selected antennas (antenna gain) and feeder (Coaxial Cable loss): EIRP = Tx RF Power (dBm) +G A (dB) - F L (dB); EIRP –> limit specific for each Country of deployment Tx RF Power –> RF power measured at RF connector of the unit G A –> Antenna gain F L -> Feeder loss (including the connectors’ loss) Antenna Types and Maximum Antenna Gains Frequency Band Type Gain (dBi) 2.4 GHz Dipole/Omni 9 Directional14 5 GHz Dipole/Omni 11 Directional14 Note: Antenna information provided above reflect approved antennas for initial release of the device. For full list of antennas approved/recommended by the Manufacture please visit the Aruba Networks Inc. web site.

Aruba MSR4000 Wireless Mesh Router Installation Guide 0511354-02 |July 20141 The Aruba AirMesh MSR4000 is a resilient, environmentally hardened, outdoor rated, four-radio, dual-band IEEE 802.11 a/b/g/n wireless mesh router. This outdoor mesh router is part of Aruba’s comprehensive wireless network solution. The MSR4000 delivers high-performance wireless mesh routing to outdoor environments where wired connectivity is impractical or unavailable. The MSR4000 is ideal for deployment in metropolitan and industrial areas, oil fields, mines, and shipping ports. There are two versions of the MSR4000, which mainly differ in the way they receive power. MSR4KP: Power over Ethernet (PoE+) powered MSR4KAC: AC powered (100 - 240 VAC) Guide Overview "MSR4000 Hardware Overview" on page 3 provides a detailed hardware overview of the two MSR4000 models. "Outdoor Planning and Deployment Considerations" on page 8 provides key questions to ask and items to consider when deploying an outdoor wireless network. "Weatherproofing Connections" on page 12 provides instructions on weatherproofing the AP’s connectors. "Installing the MSR4000" on page 20 describes the multi-step process for a successful installation and deployment of an MSR4000. "Safety and Regulatory Compliance" on page 33 provides an overview of safety and regulatory compliance information. MSR4000 Operations Wireless mesh router (IEEE 802.11 a/b/g/n) MSR4KP: IEEE 802.3at Power over Ethernet+ (PoE+) compatible MSR4KAC: IEEE 802.3af Power Sourcing Equipment (PSE) device Package Contents MSR4000 AirMesh Router MSR4000 Mounting Bracket Solar Shield Pole Anchors x 4 The MSR4000 requires the Aruba MeshOS operating system. The MSR4KAC can function as a Power Sourcing Equipment (PSE) device by providing power through its Ethernet port in compliance with the IEEE 802.3af standard. 2Aruba MSR4000 Wireless Mesh Router| Installation Guide M4 x 16 bolts, flat washers, and spring washers x4 (These bolts are attached to the solar shield) M4 x 16 bolts, flat washers, and spring washers x2 M6 x 30 bolts, flat washers, and spring washers x2 M4 x 12 bolt, external-tooth washer, and OT copper lug x1 M8 x 110 bolt, flat washers, spring washers, and nuts x4 Metal Weatherproof Caps x2 for use on unused antenna interfaces RJ-45 Connector Kit with metal RJ-45 connector USB Console Cable Installation Guide Quick Start Guide The MSR4000 does not ship with any power cables; these are available as accessories and should be ordered separately. Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton, including the original packing materials. Use these materials to repack and return the unit to the supplier if needed. Aruba MSR4000 Wireless Mesh Router| Installation Guide3 MSR4000 Hardware Overview The following section describes the hardware features of the MSR4000. Figure 1 MSR4KP Overview Figure 2 MSR4KAC Overview 1Antenna Interface 2 (Radio 2)6Antenna Interface 1 (Radio 0) 2Antenna Interface 2 (Radio 1)7Antenna Interface 1 (Radio 3) 3Antenna Interface 2 (Radio 3)8Antenna Interface 1 (Radio 1) 4Antenna Interface 2 (Radio 0)9Antenna Interface 1 (Radio 2) 5Ethernet Interface10USB Console Interface 1Antenna Interface 2 (Radio 2)7Antenna Interface 1 (Radio 0) 2Antenna Interface 2 (Radio 1)8Antenna Interface 1 (Radio 3) 3Antenna Interface 2 (Radio 3)9Antenna Interface 1 (Radio 1) 4Antenna Interface 2(Radio 0)10Antenna Interface 1 (Radio 2) 5Ethernet Interface 11USB Console Interface 6AC Power Interface 4Aruba MSR4000 Wireless Mesh Router| Installation Guide Antenna Interface The MSR4000 requires the use of detachable outdoor-rated antennas. Select the correct antenna type to support the required frequency band and the desired coverage pattern. The MSR4000 is equipped with eight female N-type antenna interfaces; four on the top of the AP and four on the bottom. The interfaces are grouped into diversity pairs, marked R0 (Radio 0), R1 (Radio 1), R2 (Radio 2) and R3 (Radio 3). USB Console Interface A USB serial console port is provided for connection to a terminal, allowing direct local management. Use the included USB console cable to connect to the AP. You can download the necessary driver for USB- UART adapter from support.arubanetworks.com under the Tools & Resources tab. Use the following setting to access the terminal: The baudrate setting depends on the manufacturing date of the MSR4000 (before or after March 2012) and the Serial Number (14 characters or 9 characters). The table above lists all the SKUs for this product along with the corresponding baudrate. Power Interface The type of power interface on your MSR4000 depends on which model you have purchased. MSR4KP: This version does not include a power interface since it is only powered by PoE+ (802.3at). MSR4KAC: One AC power connector Table 1 Console Settings Product SKUsSerial NumberBaud RateData BitsParityStop Bits Flow Control MSR4K43N0, MSR4K43N0-JP, MSR4K43N0-US, MSR4K43N3, MSR4K43N3-JP, MSR4K43N3-US 14 characters (For example: 26A02110500467) 1152008None1None MSR4KP, MSR4KP-JP, MSR4KP-US MSR4KP-IL MSR4KAC, MSR4KAC-JP, MSR4KAC-US, MSR4KAC-IL 9 characters (For example: AZ1234567) 96008None1None Aruba MSR4000 Wireless Mesh Router| Installation Guide5 Figure 3 Power Interface on MSR4KAC Ethernet Interface The MSR4000 is equipped with a 10/100/1000Base-T Gigabit Ethernet port for wired network connectivity. On the MSR4KP, this port also supports IEEE 802.3at Power over Ethernet (PoE), accepting 48 VDC as a standards-defined powered device (PD) from a power sourcing equipment (PSE) device, such as a PoE midspan injector. Inversely, the MSR4KAC can act as a PSE device to provide IEEE802.3af PoE power to devices connected to the Ethernet port. Grounding Point Always remember to protect your MSR4000 by installing grounding lines. The ground connection must be complete before connecting power to the MSR4000 enclosure. Ensure that the resistance is less…

Text truncated - open the document above for the full version.

Date: 03/24/2014 UL Verification Services Inc. 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). [Remove this section if Regulatory Authority is not FCC] In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until September 19 th , 2014. Sincerely Yours, Greg Rocha Senior Director of Engineering and Operations Aruba Networks, Inc REMARK: 1. This authorization letter will be sent along with your application when filing with UL Verification Services Inc. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database and Industry Canada contact information.

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: Q9DMSR4000DFS To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until August 19th, 2014: External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Greg Rocha Senior Director of Engineering and Operations Aruba Networks, Inc 03/24/2014

Date: April 30, 2014 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely, ________________________ Signature Greg Rocha Director of Engineering Operations Aruba Networks, Inc. REMARK: 1. This authorization letter will be sent along with your application when filing with UL Verification Services Inc. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database and Industry Canada contact information.

FCC UNII Device 5600-5650MHz Band Non- Transmission Restrictions Declaration Date: July 10, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Product/ Model Number: MSR4K43N0 & MSR4K43N3 FCC ID: Q9DMSR4000DFS Regarding restrictions for operation in the 5600 - 5650 MHz band, as described in FCC KDB notice 443999 D01 Approval of DFS UNII Devices v01 "Interim Plans to Approve UNII Devices Operating in the 5470 - 5725 MHz Band with Radar Detection and DFS Capabilities", We declare that the device will not transmit on channels which overlap the 5600 - 5650 MHz band, including the channel 116 and 120 for 40 MHz usage. Name: Rob Hastings Date: 07/10/2014 Title: Compliance Manager

MODEL: MSR4K43N0 IC: 4675A-MSR4000 CMIIT ID: 2011DJ1170 FCC ID: Q9DMSR4000DFS Anh-Thu MSR4K43N0 ARUBA NETWORKS Jinli Wang06/14/11 Jinli Wang06/14/11 Onno Hamrs06/14/11 TA-2011/940 REVISED BY R 003-120204 003ZWA120202 003BVA120203 003-130137 003YWA111098 003WWA100832 003XWA100833 Out the direction ETA-2119/2012/WRLO ETA-2120/2012/WRLO LABEL,AGENCY,MSR4KP 4011530

MSR4K43N3 4675A-MSR4000AC Q9DMSR4000DFS MODEL: FCC ID: IC: SPEC: IP66 100-240V~0.75A 50/60 Hz CMIIT ID: 2012AJ0396 R 003-120204 003ZWA120202 003BVA120203 003-130137 003WWA100832 003XWA100833 Out the direction LABEL,AGENCY,MSR4KAC Anh-Thu TA-2012/1804 ETA-2122/2012/WRLO ETA-2121/2012/WRLO

the wireless lab 8 April 2011 Internal Photographs Aruba Networks, Inc. MSR4000 Main Assy front MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 Tel: +1 (925) 462-0304, Fax: +1 (925) 462-0306, Web: www.micomlabs.com the wireless lab Front Main Assy Page 2 of 10 the wireless lab Back Main Assy Page 3 of 10 the wireless lab Top RF Card Back RF card Page 4 of 10 the wireless lab Top Main RF Holder Back Main RF Holder Page 5 of 10 the wireless lab Front Temperature Sensor Back Temperature Sensor Page 6 of 10 the wireless lab Top Bridge Board Back Bridge Board Page 7 of 10 the wireless lab LED Front LED Back Page 8 of 10 the wireless lab Front Back Plane Back, Back Plane Page 9 of 10 the wireless lab POE Front POE Back Page 10 of 10

FCC Part 1 Subpart I FCC Part 2 Subpart J RF EXPOSURE REPORT FOR WIRELESS MESH ROUTER MODEL NUMBER: MSR4K43N0, MSR4K43N3* FCC ID: Q9DMSR4000DFS REPORT NUMBER: 13U14957-2 ISSUE DATE: OCTOBER 09, 2013 Prepared for ARUBA NETWORKS 1344 CROSSMAN AVENUE SUNNYVALE, CA 94089, U.S.A. Prepared by UL VERIFICATION SERVICES INC. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 *Models differences are explained within the body of this report REPORT NO: 13U14957-2 DATE: OCTOBER 09, 2013 FCC ID: Q9DMSR4000AC Page 2 of 12 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. Revision History Rev. Issue Date Revisions Revised By -- 10/09/13 Initial Issue F. Ibrahim REPORT NO: 13U14957-2 DATE: OCTOBER 09, 2013 FCC ID: Q9DMSR4000AC Page 3 of 12 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. REFERENCES ................................................................................................................... 5 4. FACILITIES AND ACCREDITATION ................................................................................. 5 5. EQUIPMENT UNDER TEST ............................................................................................... 6 5.1. DESCRIPTION OF EUT .............................................................................................. 6 5.2. DESCRIPTION OF MODEL(s) DIFFERENCES ........................................................... 6 6. MAXIMUM PERMISSIBLE RF EXPOSURE ....................................................................... 7 6.1. FCC RULES ................................................................................................................ 7 6.2. IC RULES .................................................................................................................... 8 6.3. EQUATIONS ................................................................................................................ 9 6.4. LIMITS AND IC EXEMPTION .....................................................................................11 7. RF EXPOSURE RESULTS ................................................................................................12 REPORT NO: 13U14957-2 DATE: OCTOBER 09, 2013 FCC ID: Q9DMSR4000AC Page 4 of 12 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: ARUBA NETWORKS 1344 CROSSMAN AVENUE SUNNYVALE, CA 94089, U.S.A. EUT DESCRIPTION: WIRELESS MESH ROUTER MODEL: MSR4K43N0, MSR4K43N3 SERIAL NUMBER: BS0000370 (RF) and BS0001469 (DFS) DATE TESTED: APRIL 8 to OCTOBER 2, 2013 (RF) and AUGUST 21 to SEPTEMBER 24, 2013 (DFS) APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 1 SUBPART I & PART 2 SUBPART J Pass INDUSTRY CANADA RSS 102 ISSUE 3 Pass UL Verification Services Inc. calculated the RF Exposure of the above equipment in accordance with the requirements set forth in the above standards, using test results reported in the test report documents referenced below and/or documentation furnished by the applicant. All indications of Pass/Fail in this report are opinions expressed by UL Verification Services Inc. based on interpretations of these calculations. The results show that the equipment is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by UL Verification Services Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL Verification Services Inc. will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, any agency of the Federal Government, or any agency of any government. Approved & Released For UL Verification Services Inc. By: Tested By: FRANK IBRAHIM Kristopher Nguyen WiSE PROGRAM MANAGER EMC ENGINEER UL Verification Services Inc. UL Verification Services Inc. REPORT NO: 13U14957-2 DATE: OCTOBER 09, 2013 FCC ID: Q9DMSR4000AC Page 5 of 12 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 Thi…

Text truncated - open the document above for the full version.
