0510880-02 Aruba Networks MST200 Installation Guide MST200 Installation Guide 1 Copyright 2005-2011 by Aruba Networks, USA. All rights reserved. Statement of Conditions In the interest of improving internal design, operation function, and/or reliability, Aruba Networks reserves the right to make changes to products described in this document without notice. Aruba Networks does not assume any liability that may occur due to the use or application of the product(s) described herein. DISCLAIMER: LIMITATION OF LIABILITY 1．Before installation, it’s strongly recommended and requested that users pay particular attention to the safety warnings in the sequentially detailed operation procedures within the manual. If there’s any uncertainty or incapability of solving problems, contact the company’s customer support center. Please DO NOT incur any risk or try to verify situations by yourself. Otherwise, any consequence caused by the attempt shall be completely due to the user himself. 2．Please periodically check whether the installed MST200 is damaged, worn-out or poses any danger. Any actual proof, sign or phenomenon of the afore-mentioned situations should be brought to the attention of the company at point of sale. Please DO NOT attempt to repair the product or replace any component. Otherwise, for any consequence arising out of or relating to the users’ attempt repair the product, including but not limited to damages, disuse, short circuit, fire, bodily injury, etc., the company shall not be liable. 3. Users shall purchase or use the company’s MST200 voluntarily. Users shall understand on their own initiative and abide voluntarily by policies, regulations or laws of their respective nation or local territories. The consequence arising out of or relating to any violation of the local laws or regulations by the user, shall be solely imputed to the user himself, and the company shall not be liable. 4. The company disclaims any and all warranties and guarantees, express, implied or otherwise, arising, with respect to the MST200 products or services, including but not limited to the warranty of merchandisability, the warranty of fitness for a particular purpose, and any warranty of non-infringement of the intellectual property rights of any third party. Liability of the company for loss is limited to the total amount paid to the 2 MST200 Installation Guide company by the customer during the previous calendar year. The company will have no obligation or liability, whether arising in contract (including Warranty), tort (including active, passive or imputed negligence, strict liability or product liability) or otherwise for any special, incidental, consequential or indirect damages including but not limited to loss of use, loss of data, business interruption, loss of revenue, loss of business or other financial loss arising out of or in connection with any of the products or other goods or services furnished by the company under this manual, even if advised of the possibility of such damages. 5．It shall never be understood that the manual expresses or implies to any customer or any third party authorize or transfer any rights. The company reserves fully the final interpretation of the MST200 and this manual. Safety and Regulatory Compliance Aruba Networks provides a multi-language document that contains country-specific restrictions and additional safety and regulatory information for all Aruba access points. This document can be viewed or downloaded from the following location: www.arubanetworks.com/safety_addendum Safety Warnings The MST200 must be installed by trained professional installation technicians. All warnings below must be read and understood before installation. General Safety Warnings You can be killed or injured if performing antenna installation near electrical power lines. Carefully read and follow all instructions in this guide. Please be sure there are no high voltage and electronic fields nearby. Working Aloft Warning MST200 Installation Guide 3 When working on tower or roof, individuals must wear safety belts. Tools must be tied to the individual using them. Workers below must wear safety helmets. Lightning Activity Warning Make sure not to connect or disconnect cables during periods of lightning activity. A surge protective device should be installed to prevent potential damage from very high surges, for instance, the peak surges caused by lightning. Explosive Device Proximity Warning Do not operate wireless network devices close to explosive merchandise or in explosive environments if devices are not certified for operation in such an environment, for example, in the vicinity of a gas station. Antenna Placement Warning Do not install any antenna near overhead power lines or other electric light, or where the antenna can come into contact with such circuits. Antenna Selection Warning Please use DC grounding antenna with lightning protection to prevent surge and static electricity. Grounding Warning 4 MST200 Installation Guide Please always remember to protect your MST200 system by installation of grounding lines. The ground connection must be complete before connecting power to the MST200 enclosure. The requirement of grounding is to make sure the resistance must be less than 5 ohm between the ground termination point to grounding tier. Power Installation Warning The installation of the power switch must be performed by a trained professional technician. The power switch is not supplied with the MST200. The power cord must be assembled by a professional installer, and the final assembly must comply with related requirements. Solar Irradiation and High Temperature Protection Pay attention to level of sunlight, which can increase the working temperature of MST200 to higher than specifications allow. A solar shield is provided in the Aruba standard package and should be installed to protect any outdoor MST200. The Aruba Warrantee policy does not cover those outdoor products for which…

Text truncated - open the document above for the full version.

Aruba MST200 Wireless Mesh Router Installation Guide 0511351-02 |July 20141 The Aruba AirMesh MST200 is a resilient, environmentally hardened, outdoor rated, single-radio IEEE 802.11 a/n wireless mesh access router. This router is part of Aruba’s comprehensive wireless network solution.The MST200 delivers high-performance outdoor wireless mesh connectivity for remote locations and devices such as IP video surveillance cameras, remote sensors, and digital signage. The MST200 is also ideal for point-to-point outdoor mesh links between buildings and remote sites. There are two versions of the MST200, which mainly differ in the way they receive power. MST2HP: Power over Ethernet+ (PoE+) powered (802.3at) MST2HAC: AC powered (100 - 240 VAC) Guide Overview "MST200 Hardware Overview" on page 3 provides a detailed hardware overview of the two MST200 models. "Outdoor Planning and Deployment Considerations" on page 9 provides key questions to ask and items to consider when deploying an outdoor wireless network. "Weatherproofing Connections" on page 12 provides instructions on weatherproofing the connectors on the router. "Installing the MST200" on page 11 describes the multi-step process for a successful installation and deployment of a MST200. "Safety and Regulatory Compliance" on page 21 provides an overview of safety and regulatory compliance information. MST200 Operations Wireless mesh router for backhaul (IEEE 802.11 a/n) MST2HP: IEEE 802.3at PoE+ compatible MST2HAC: IEEE 802.3af Power Sourcing Equipment (PSE) device MST200 requires the Aruba MeshOS operating system. The MST2HAC can function as a Power Sourcing Equipment (PSE) device by providing power through its Ethernet port in compliance with the IEEE 802.3af standard. 2Aruba MST200 Wireless Mesh Router| Installation Guide Package Contents Aruba MST200 AirMesh Router MST200 Mounting Bracket MST200 Positioning Bracket Pole Anchors x 2 M6 x 12 bolts, flat washers, and spring washers x5 M8 x 16 bolts, flat washers, and spring washers x2 M4 x 12 bolt, external-tooth washer, and OT copper lug x1 M8 x 110 bolt, flat washers, spring washers, and nuts x4 RJ-45 Connector Kit USB Console Cable Installation Guide Quick Start Guide The MST200 does not ship with any power cables; these are available as accessories and should be ordered separately. Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton, including the original packing materials. Use these materials to repack and return the unit to the supplier if needed. Aruba MST200 Wireless Mesh Router| Installation Guide3 MST200 Hardware Overview The following section describes the hardware features of the MST2HP and MST2HAC. Figure 1 MST2HP overview Ethernet Interface (PoE) LED Status Indicators USB Console Interface Grounding Point Pressure Equalization Port 4Aruba MST200 Wireless Mesh Router| Installation Guide Figure 2 MST2HAC overview (protective caps removed) Ethernet Interface (PoE Out) USB Console Interface LED Status Indicators Power Interface Pressure Equalization Port Grounding Point Aruba MST200 Wireless Mesh Router| Installation Guide5 USB Console Interface A USB serial console port is provided for connection to a terminal, allowing direct local management. Use the included USB console cable to connect to the router. You can download the necessary driver for USB- UART adapter from support.arubanetworks.com under the Tools & Resources tab. Use the following settings to access the terminal: The baud rate setting depends on the manufacture date of the MST200 (before or after March 2012) and the Serial Number (14 characters or 9 characters). The table above lists all the SKUs for MST200 along with the corresponding baud rate. Power Interface The type of power interface on the MST200 depends on the model that you have purchased. MST2HP: This version does not include a power interface since it is only powered by PoE+ (802.3at). MST2HAC: One AC power connector. Ethernet Interface The MST200 is equipped with a 10/100/1000Base-T Gigabit Ethernet port for wired network connectivity. On the MST2HP, this port also supports IEEE 802.3at Power over Ethernet (PoE), accepting 48 VDC as a standards-defined powered device (PD) from a power sourcing equipment (PSE) device, such as a PoE midspan injector. Inversely, the MST2HAC can act as a PSE device to provide IEEE802.3af PoE power to devices such as a video camera, connected to the Ethernet port. Table 1 Console Settings Product SKUsSerial NumberBaud RateData BitsParityStop Bits Flow Control MST2H13N0 MST2H13N0-JP MST2H13N0-US 14 characters (For example: 26A02110500467) 1152008None1None MST2HP MST2HP-JP MST2HP-US MST2HAC MST2HAC-JP MST2HAC-US 9 characters (For example: AZ1234567) 96008None1None 6Aruba MST200 Wireless Mesh Router| Installation Guide Figure 3 Connecting a Video Camera to the Ethernet Interface on MST2HAC Pressure Equalization Port The Pressure Equalization port allows air exchange between the MST200 and environment in a controlled way that doesn’t allow water to get into the MST200. This balances the pressure and humidity inside and outside the MST200. Grounding Point Always remember to protect your MST200 by installing grounding lines. The ground connection must be completed before connecting power to the MST200 enclosure. Ensure that the resistance is less than 5 ohm between the ground termination point and the grounding tier and the cross section of the grounding cable should be no less than 6 square mm. MST2HP LED Status Indicators The MST2HP includes visual indicators for power, link, and radio status. Additionally, each radio has a four- LED array that indicates received signal strength (RSSI). Figure 4 MST2HP LED layout The RSSI LED indicators represent varying degrees in the RSSI level. The absence of a signal is indicated by no LED response. All four LEDs are active and lit is an indication of full signal strength. RSSI for Radio 0 Aruba MST200 Wireless Me…

Text truncated - open the document above for the full version.

FCC UNII Device 5600-5650MHz Band Non- Transmission Restrictions Declaration Date: July 13, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Product/ Model Number: MST2H13N0 & MST2H13N1 FCC ID: Q9DMST200DFS Regarding restrictions for operation in the 5600 - 5650 MHz band, as described in FCC KDB notice 443999 D01 Approval of DFS UNII Devices v01 "Interim Plans to Approve UNII Devices Operating in the 5470 - 5725 MHz Band with Radar Detection and DFS Capabilities", We declare that the device will not transmit on channels which overlap the 5600 - 5650 MHz band, including the channel 116 and 120 for 40 MHz usage. Name: Rob Hastings Date: 07/14/2014 Title: Compliance Manager

LABEL,DEVICE,ARUBA,MST2HAC COLOR OF BASE: MATERIAL PRIMARY COLOR OF FONT: BLACK SN: XXXXXXXXXXXXXX XXXXXXXXXXXX MAC: SILVER MATT PET,T=0.05, BACKSIDE ADHESIVE MATERIAL 85.5mm 40.0mm R 2.0mm,4PLS 5. UL APPROVED INK & MATERIAL 01 6. REQUIREMENT FOR ADHESIVE GLUE: 3M-467 SPEC: IP66 100-240V 0.5A 7. Barcode Font: Code 39 4011389 4011389 01 01 ~ 50/60Hz CMIIT ID: 2012AJ5873 MODEL: MST2H13N1 FCC ID: Q9DMST200DFS IC: 4675A-MST200AC R 003-120306

LABEL,AGENCY,MST2HP COLOR OF BASE: MATERIAL PRIMARY COLOR OF FONT: BLACK SN: XXXXXXXXXXXXXX XXXXXXXXXXXX MAC: SILVER MATT PET,T=0.05, BACKSIDE ADHESIVE MATERIAL 85.5mm 40.0mm R 2.0mm,4PLS MODEL: MST2H13N0 FCC ID: Q9DMST200DFS IC: 4675A-MST200 5. UL APPROVED INK & MATERIAL 01 6. REQUIREMENT FOR ADHESIVE GLUE: 3M-467 CMIIT ID: 2011AJ4504 SPEC: 48V IP66 0.3A 7. Barcode Font: Code 39 01 01 Out the direction 4/22/13 Anh-Thu ETA-2413/2012/WRLO R 003-120306 TA-2012/1164 4011388 Added South Africa ICASA, updated Japan, updated TUV mark 4011388

FCC Part 1 Subpart I FCC Part 2 Subpart J RF EXPOSURE REPORT FOR WIRELESS MESH ACCESS ROUTER MODEL NUMBER: MST2H13N0, MST2H13N1* FCC ID: Q9DMST200DFS REPORT NUMBER: 14U16820-2 ISSUE DATE: FEBRUARY 28, 2014 Prepared for ARUBA NETWORKS 1344 CROSSMAN AVENUE SUNNYVALE, CA 94089, U.S.A. Prepared by UL VERIFICATION SERVICES INC. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 *Models differences are explained within the body of this report REPORT NO: 14U16820-2 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 2 of 12 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of . UL Verification Services Inc. Revision History Rev. Issue Date Revisions Revised By -- 10/09/13 Initial Issue F. Ibrahim REPORT NO: 14U16820-2 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 3 of 12 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of . UL Verification Services Inc. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 4 2. TEST METHODOLOGY ..................................................................................................... 5 3. REFERENCES ................................................................................................................... 5 4. FACILITIES AND ACCREDITATION ................................................................................. 5 5. EQUIPMENT UNDER TEST ............................................................................................... 6 5.1. DESCRIPTION OF EUT .............................................................................................. 6 5.2. DESCRIPTION OF MODEL(s) DIFFERENCES ........................................................... 6 6. MAXIMUM PERMISSIBLE RF EXPOSURE ....................................................................... 7 6.1. FCC RULES ................................................................................................................ 7 6.2. IC RULES .................................................................................................................... 8 6.3. EQUATIONS ................................................................................................................ 9 6.4. LIMITS AND IC EXEMPTION .....................................................................................11 7. RF EXPOSURE RESULTS ................................................................................................12 REPORT NO: 14U16820-2 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 4 of 12 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of . UL Verification Services Inc. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: ARUBA NETWORKS 1344 CROSSMAN AVENUE SUNNYVALE, CA 94089, U.S.A. EUT DESCRIPTION: WIRELESS MESH ACCESS ROUTER MODEL: MST2H13N0, MST2H13N1 SERIAL NUMBER: 54B02114600011 DATE TESTED: APRIL 8 to OCTOBER 4, 2013 (RF) and AUGUST 21 to SEPTEMBER 24, 2013 (DFS) APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 1 SUBPART I & PART 2 SUBPART J Pass INDUSTRY CANADA RSS 102 ISSUE 3 Pass UL Verification Services Inc. calculated the RF Exposure of the above equipment in accordance with the requirements set forth in the above standards, using test results reported in the test report documents referenced below and/or documentation furnished by the applicant. All indications of Pass/Fail in this report are opinions expressed by UL Verification Services Inc. based on interpretations of these calculations. The results show that the equipment is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by UL Verification Services Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL Verification Services Inc. will constitute fraud and shall nullify the document. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, any agency of the Federal Government, or any agency of any government. Approved & Released For UL Verification Services Inc. By: Tested By: FRANK IBRAHIM Kristopher Nguyen WiSE PROGRAM MANAGER EMC ENGINEER UL Verification Services Inc. UL Verification Services Inc. REPORT NO: 14U16820-2 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 5 of 12 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701I 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of . UL Verification Services Inc. 2. TEST METHODOLOGY All calculations were made in accordance with FCC OET Bulletin 65 Edition 97-01 and IC Safety Code 6. 3. REFERENCES All measurements were made as documented in test report UL Verification Services Inc. Document “13U14956-1 FCC IC UNII WLAN with DFS Report” for operation in the 5 GHz bands. Output power, Duty cycle and Antenna gain data is excerpted from the applicable test reports. 4. FACILITIES AND ACCREDITATION The test sites and measurement facilities used to collect data are located at 47173 Benicia Street, Fremont, California, USA. UL Verification Services Inc. is accredited by NVLAP, Laboratory Code 200065-0. The full scope of accreditation can be viewed at http://ts.nist.gov/standards/sc…

Text truncated - open the document above for the full version.

FCC CFR47 PART 15 SUBPART E TEST REPORT FOR WIRELESS MESH ACCESS ROUTER MODEL NUMBER: MST2H13N0, MST2H13N1* FCC ID: Q9DMST200DFS REPORT NUMBER: 14U16820-1 ISSUE DATE: FEBRUARY 28, 2014 Prepared for ARUBA NETWORKS 1344 CROSSMAN AVENUE SUNNYVALE CA, 94089, U.S.A. Prepared by UL VERIFICATION SERVICES INC. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 *Models differences are explained within the body of this report REPORT NO: 14U16820-1 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 2 of 186 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701J 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. Revision History Rev. Issue Date Revisions Revised By -- 10/11/13 Initial Issue F. Ibrahim REPORT NO: 14U16820-1 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 3 of 186 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701J 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ................................................................................. 6 2. TEST METHODOLOGY ..................................................................................................... 7 3. FACILITIES AND ACCREDITATION ................................................................................. 7 4. CALIBRATION AND UNCERTAINTY ................................................................................ 7 MEASURING INSTRUMENT CALIBRATION .............................................................. 7 4.1. SAMPLE CALCULATION ............................................................................................ 7 4.2. MEASUREMENT UNCERTAINTY ............................................................................... 8 4.3. 5. EQUIPMENT UNDER TEST ............................................................................................... 9 DESCRIPTION OF EUT .............................................................................................. 9 5.1. DESCRIPTION OF MODEL(s) DIFFERENCES ........................................................... 9 5.2. MAXIMUM OUTPUT POWER...................................................................................... 9 5.3. DESCRIPTION OF AVAILABLE ANTENNAS .............................................................. 9 5.4. SOFTWARE AND FIRMWARE .................................................................................... 9 5.5. WORST-CASE CONFIGURATION AND MODE .........................................................10 5.6. DESCRIPTION OF TEST SETUP ...............................................................................11 5.7. 6. TEST AND MEASUREMENT EQUIPMENT ......................................................................13 7. ON TIME, DUTY CYCLE AND MEASUREMENT METHODS ...........................................14 ON TIME AND DUTY CYCLE RESULTS ....................................................................14 7.1. MEASUREMENT METHOD FOR POWER AND PPSD ..............................................14 7.2. MEASUREMENT METHOD FOR AVG SPURIOUS EMISSIONS ABOVE 1 GHz .......14 7.3. DUTY CYCLE PLOTS ................................................................................................15 7.4. 8. ANTENNA PORT TEST RESULTS ...................................................................................17 802.11a CDD 2TX MODE IN THE 5.6 GHz BAND ......................................................17 8.1. 8.1.1. 26 dB BANDWIDTH .............................................................................................17 8.1.2. 99% BANDWIDTH ...............................................................................................21 8.1.3. OUTPUT POWER AND PPSD ............................................................................25 8.1.4. PEAK EXCURSION .............................................................................................30 8.1.5. CONDUCTED WEATHER RADAR BAND EMISSIONS.......................................32 802.11n HT20 STBC 2TX MODE IN THE 5.6 GHz BAND ..........................................35 8.2. 8.2.1. 26 dB BANDWIDTH .............................................................................................35 8.2.2. 99% BANDWIDTH ...............................................................................................39 8.2.3. OUTPUT POWER AND PPSD ............................................................................43 8.2.4. PEAK EXCURSION .............................................................................................48 8.2.5. CONDUCTED WEATHER RADAR BAND EMISSIONS.......................................50 802.11n HT40 STBC 2TX MODE IN THE 5.6 GHz BAND ..........................................53 8.3. REPORT NO: 14U16820-1 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 4 of 186 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701J 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. 8.3.1. 26 dB BANDWIDTH .............................................................................................53 8.3.2. 99% BANDWIDTH ...............................................................................................57 8.3.3. OUTPUT POWER AND PPSD ............................................................................61 8.3.4. PEAK EXCURSION .............................................................................................66 8.3.5. CONDUCTED WEATHER RADAR BAND EMISSIONS.......................................68 9. RADIATED TEST RESULTS ......................................................................…

Text truncated - open the document above for the full version.

REPORT NO: 14U16820-1 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 180 of 186 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701J 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. RADIATED RF MEASUREMENT SETUP (BELOW 1 GHz) 12.2. 12.2.1. AC UNIT RADIATED FRONT PHOTO (BELOW 1 GHz) RADIATED BACK PHOTO (BELOW 1 GHz) REPORT NO: 14U16820-1 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 181 of 186 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701J 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. 12.2.2. POE UNIT RADIATED FRONT PHOTO (BELOW 1 GHz) RADIATED BACK PHOTO (BELOW 1 GHz) REPORT NO: 14U16820-1 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 182 of 186 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701J 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. RADIATED RF MEASUREMENT SETUP (ABOVE 1 GHz) 12.3. RADIATED FRONT PHOTO (ABOVE 1 GHz) RADIATED BACK PHOTO (ABOVE 1 GHz) REPORT NO: 14U16820-1 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 183 of 186 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701J 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. RADIATED FRONT PHOTO (ABOVE 1 GHz) RADIATED BACK PHOTO (ABOVE 1 GHz) REPORT NO: 14U16820-1 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 184 of 186 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701J 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. POWERLINE CONDUCTED EMISSIONS MEASUREMENT SETUP 12.4. LINE CONDUCTED FRONT PHOTO (AC Powered) LINE CONDUCTED BACK PHOTO (AC Powered) REPORT NO: 14U16820-1 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 185 of 186 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701J 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. LINE CONDUCTED FRONT PHOTO (PoE) LINE CONDUCTED BACK PHOTO (PoE) REPORT NO: 14U16820-1 DATE: FEBRUARY 28, 2014 FCC ID: Q9DMST200DFS Page 186 of 186 UL VERIFICATION SERVICES INC. FORM NO: CCSUP4701J 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL Verification Services Inc. DYNAMIC FREQUENCY SELECTION MEASUREMENT SETUP 12.5. END OF REPORT EUT FRONT PHOTO EUT BACK PHOTO
