QA9RC09037Remote Control Toy Transmitter

Date: 9/05/03 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 USA Dear Sirs, Re.: Letter of Appointment This is the letter of authorization to accept our appointment of The Hong Kong Standards and Testing Centre Ltd. as agent for 21 st Century Hong Kong Ltd. Room 712, 7 th Floor, Harbour Crystal Centre, 100 Granville Road, Tsim Sha Tsui East, Kowloon, Hong Kong to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with Certification of the following product of 21 st Century Toys, Inc. Product name:1:6 Radio Control M5 Stuart Tank Model:RC09037 This authorization will expire one year from the date of this letter. Anthony Anthony W.C. Yuen Engineering Manager 21 st Century Toys Hong Kong Ltd. Room 712, 7th Floor, Harbour Crystal Centre, 100 Granville Road, TST East, Kowloon, Hong Kong

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT

FCC ID: QA9RC09037 MADE IN CHINA This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 45 MM 40 MM

FCC ID: QA9RC09037 MADE IN CHINA This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 45 MM 40 MM

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW INNER CIRCUIT BOTTOM VIEW

Date: 2003-09-13 TEST REPORT Page 1 of 19 No.: HM111513 FCC PART 15 SUBPART C CERTIFICATION REPORT FOR LOW POWER TRANSMITTER TEST REPORT No.:HM111513 Equipment Under Test [EUT]:1:6 Radio Control M5 Stuart Tank Model Number:RC09037 Applicant:21 st Century Toys HK Ltd. FCC ID :QA9RC09037 Date: 2003-09-13 TEST REPORT Page 2 of 19 No.: HM111513 CONTENT: Cover Page 1 of 19 Content Page 2-3 of 19 Conclusion Page 4 of 19 1.0 General Details 1.1Test Laboratory Page 5 of 19 1.2Applicant Details Page 5 of 19 Applicant HKSTC Code Number for Applicant Manufacturer 1.3Equipment Under Test [EUT] Page 6 of 19 Description of EUT operation 1.4Date of Order Page 6 of 19 1.5Submitted Sample Page 6 of 19 1.6Test Duration Page 6 of 19 1.7Country of Origin Page 6 of 19 1.8 Additional Information of EUT Page 7 of 19 2.0 Technical Details 2.1Investigations Requested Page 8 of 19 2.2Test Standards and Results Summary Page 8 of 19 3.0 Test Results 3.1Emission Page 9-12 of 19 3.2Bandwidth Measurement Page 13-14 of 19 Date: 2003-09-13 TEST REPORT Page 3 of 19 No.: HM111513 Appendix A List of Measurement Equipment Page 15 of 19 Appendix B Duty Cycle Correction During 100 msec Page 16-17 of 19 Appendix C Photographs Page 18-19 of 19 Date: 2003-09-13 TEST REPORT Page 4 of 19 No.: HM111513 CONCLUSION The submitted product was deemed to have COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Verified byK C Lee for Chief Executive Date: 2003-09-13 TEST REPORT Page 5 of 19 No.: HM111513 1.0General Details 1.1Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong Telephone:852 2666 1888 Fax:852 2664 4353 1.2Applicant Details Applicant 21 st Century Toys HK Ltd. Room 712, 7th.Floor, Harbour Crystal Centre 100 Granville Road, TST East, Kowloon, Hong Kong. HKSTC Code Number for ApplicantCET004 Manufacturer Kin Sun Industrial Ltd. Unit H, 4 th Floor, Valiant Ind. Centre, 2-12 Au Pui Wan Street, Fo Tan, N.T., Hong Kong. Date: 2003-09-13 TEST REPORT Page 6 of 19 No.: HM111513 1.3Equipment Under Test [EUT] Description of Sample Product:1:6 Radio Control M5 Stuart Tank Manufacturer:Kin Sun Industrial Ltd. Brand Name:Ultimate Solider Model Number:RC09037 Input Voltage:9Vd.c (“6F22” size battery x 1) 1.3.1Description of EUT Operation The Equipment Under Test (EUT) is an 21 st Century Toys HK Ltd., 1:6 Radio Control M5 Stuart Tank. The transmitter is a 2 button transmitter. The EUT continues to transmit while button is being pressed, Modulation by IC. and tape is pulses modulation. 1.4Date of Order 2003-08-21 1.5Submitted Sample(s): 2 Samples per model 1.6Test Duration 2003-09-01 1.7Country of Origin China Date: 2003-09-13 TEST REPORT Page 7 of 19 No.: HM111513 1.8Additional Information of EUT SubmittedNot Available User Manual Part List Circuit Diagram Printed Circuit Board [PCB] Layout Block diagram FCC ID Label Date: 2003-09-13 TEST REPORT Page 8 of 19 No.: HM111513 2.0Technical Details 2.1Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.4:2000 for FCC Certification. 2.2Test Standards and Results Summary Tables EMISSION Results Summary Test ConditionTest RequirementTest MethodClass /Test Result SeverityPassFailedN/A Field Strength of Fundamental Emissions & Spurious Emissions FCC 47CFR 15.227ANSI C63.4:2000N/A Radiated Emissions, 30MHz to 1GHz FCC 47CFR 15.209ANSI C63.4:2000Class B Conducted Emissions on AC, 0.15MHz to 30MHz FCC 47CFR 15.207ANSI C63.4:2000Class B Note: N/A - Not Applicable Date: 2003-09-13 TEST REPORT Page 9 of 19 No.: HM111513 3.0Test Results 3.1Emission 3.1.1Radiated Emissions (30 – 1000MHz) Test Requirement:FCC 47CFR 15.109 Class A Test Method:ANSI C63.4:2000 Test Date:2002-09-01 Mode of Operation:On mode Test Method: The sample was placed 0.8m above the ground plane on the OATS *. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. *:OATS [Open Area Test Site] located at HKSTC with a metal ground plane filed with the FCC pursuant to section 2.948 of the FCC rules, with Registration Number: 90657. Test Setup: EUT Pre-Amplifier Distance = 3m Receiver Turn Table Computer Ground Plane Date: 2003-09-13 TEST REPORT Page 10 of 19 No.: HM111513 Limits for Field Strength of Fundamental Emissions [FCC 47CFR 15.227]: Frequency Range of Fundamental Field Strength of Fundamental Emission [Peak] Field Strength of Fundamental Emission [Average] [MHz] [μV/m][μV/m] 26.96-27.28100,00010,000 Results: FrequencyCorrectionLimit @3mE-Field FactorPolarity MHz dB μ V/m μ V/m 27.1530.3022.352.6426.6100,000Vertical Field Strength of Fundamental Emissions Peak Value Measured Level @3m Field Strength μ V/mdB μ V/m Field Strength dB μ V/m FrequencyCorrectionLimit @3mE-Field FactorPolarity MHz dB μ V/m μ V/m 27.1522.522.344.8173.8100,00Vertical μ V/mdB μ V/m Field Strength dB μ V/m Field Strength of Fundamental Emissions Average Measured Level @3m Field Strength According to FCC 47CFR15.35, the limit on the radio frequency emissions as measured using instrumentation with a peak detector function, corresponding to 20dB above the maximum permitted average limit for the frequency being investigated unless a different peak emission limit is otherwise specified in the rules. Remarks: *: Adjusted by Duty Cycle = -7.8dB *:Linear interpolat…

Text truncated - open the document above for the full version.

TEST SET UP PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP
