QASRA-T411-02Active RFID tag

9266-5777 Quebec inc. 501-1015 rue William Montreal, QC H3C 1P4 Canada Feuillet d’information RA-T411-02 Information Sheet Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Conformité Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Certification FCC ID: QASRA-T411-02 IC: 10707A-RAT41102 Page 1 of 1 Visit us online at http://reelyactive.com

9266-5777 Quebec inc. 501-1015 rue William Montreal, QC H3C 1P4 Canada Page 1 of 1 Visit us online at http://reelyactive.com Operational Description of RA-T411-02 The RA-T411-02 module is an active radio frequency identification device. The module allows the remote identification of people, places and things. The RA-T411-02 module is installed alone into an enclosure. The module is designed to reside inside a commercially-available OKW Minitec ES enclosure (shown below in the two possible configurations) (measuring approximately 5cm x 3cm x 1.5cm) which allows easy attachment to a keyring, clip or strap. For some applications, a custom enclosure may be required, for instance to facilitate attachment to a specific type of object. Custom enclosures will typically have similar size, materials and construction. The RA-T411-02 module's transmitter functionality serves to periodically transmit short messages containing several bytes of information: a unique identifier and optional sensor data or challenge responses. The receiver functionality serves to periodically listen for short messages containing instructions or a challenge. For many applications, the receiver functionality is permanently disabled in firmware. For almost all applications, the module's transceiver is disabled more than 99% of the time.

reelyActive RA‐R411‐02 component list ID Component Manufacturer Part Number BT1 Battery Panasonic CR2032 C1 Capacitor 22uF Murata GRM21BR60J226ME39L C2 Capacitor 0.1uF Yageo CC0603KRX7R9BB104 C3 Capacitor 1nF Yageo CC0603JRNPO8BN102 C4 Capacitor 8pF TDK C1608C0G1H8R2C C5 Capacitor 8pF TDK C1608C0G1H8R2C C6 Capacitor 1uF Murata GRM188R61E105KA12D C10 Capacitor 0.1uF Yageo CC0603KRX7R9BB104 C19 Capacitor 0.1uF Yageo CC0603KRX7R9BB104 C29 Capacitor 0.1uF Yageo CC0603KRX7R9BB104 E1 Antenna Johanson 0915AT43A0026E IC1 SoC TI (Chipcon) CC1110F32RSPR L1 Inductor 3.9nH Johanson L‐14C3N9SV4T L2 Inductor 8.2nH Johanson L‐14C8N2JV4T LC Balun Johanson 0915BM15A0001E LED1 Bi‐colour LED Kingbright APHBM2012SURKCGKC R1 Resistor 75 Yageo RC0603FR‐0775RL R2 Resistor 55 Yageo RC0603FR‐0754R9L R3 Resistor 2.7k Yageo RC0603FR‐072K7L R4 Resistor 56k Yageo RC0603JR‐0756KL X1 Crystal 26 MHz NDK NX3225SA‐26.000000MHZ

FCC 15.249.doc - Date: June, 2011 www.nemko.com Compliance test report ID 221407-1TRFWL Date of issue January 16, 2013 FCC 47 CFR Part 15 Subpart C, §15.249 Operation in the 902–928 MHz, 2400–2483.5 MHz, 5725–5875 MHz and 24.0–24.25 GHz RSS-210, Issue 8 Annex 2 Devices Operating in Frequency Bands for Any Application A2.9 Bands 902–928, 2400–2483.5 and 5725–5875 MHz Applicant 9266-5777 Quebec inc. Product reelyActive tag Model RA-T411-02 FCC ID QASRA-T411-02 IC Reg. 10707A-RAT41102 Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation SCC Accredited LAB LAB Accrédité CCN TM Report reference ID: 221407-1TRFWL Page 2 of 17 Test location Nemko Canada Inc. 303 River Road Ottawa, ON, K1V 1H2 Canada FCC test site registration number: 176392 and IC registered site number: 2040A-4 (3 m semi anechoic chamber) Telephone +1 613 737 9680 Facsimile +1 613 737 9691 Toll free +1 800 563 6336 Website www.nemko.com Tested by Andrey Adelberg, Senior Wireless/EMC Specialist Reviewed by January 16, 2013 Kevin Rose, Wireless/EMC Specialist Date Limits of responsibility Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. All results contain in this report are within Nemko Canada’s ISO/IEC 17025 accreditation. Copyright notification Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. © Nemko Canada Inc. Report reference ID: 221407-1TRFWL Page 3 of 17 Table of contents Section 1: Report summary ......................................................................................................................................................... 4 Section 2: Summary of test results ............................................................................................................................................. 5 Section 3: Equipment under test (EUT) details .......................................................................................................................... 6 Section 4: Engineering considerations ....................................................................................................................................... 7 Section 5: Test conditions ........................................................................................................................................................... 8 Section 6: Measurement uncertainty .......................................................................................................................................... 9 Section 7: Test equipment ......................................................................................................................................................... 10 Section 8: Testing data ............................................................................................................................................................... 11 8.1 FCC 15.215(c) and RSS-Gen 4.6.1 Emission bandwidth .......................................................................................... 11 8.2 FCC 15.249(a) and RSS-210 A2.9(a) Field strength of radiated emissions not in restricted bands .......................... 12 8.3 FCC 15.249(d) and RSS-210 A2.9(b) Spurious emissions (except for harmonics) ................................................... 14 Section 9: Block diagrams of test set-ups ................................................................................................................................ 15 Section 10: EUT photos .............................................................................................................................................................. 16 Section 1 Report summary Report reference ID: 221407-1TRFWL Page 4 of 17 Section 1: Report summary 1.1 Applicant 9266-5777 Quebec Inc. 501-1015 rue William Montreal, QC H3C 1P4 Canada 1.2 Manufacturer Digico Electronic Manufacturing Inc. 950 rue Bergar Laval, QC H7L 5A1 Canada 1.3 Test specifications FCC 47 CFR Part 15 Subpart C, §15.249 Operation in the 902–928 MHz, 2400–2483.5 MHz, 5725–5875 MHz and 24.0–24.25 GHz RSS-210, Issue 8 Annex 2 Devices Operating in Frequency Bands for Any Application A2.9 Bands 902–928, 2400–2483.5 and 5725–5875 MHz 1.4 Statement of compliance In the configuration tested, the EUT was found compliant. Testing was completed against all relevant requirements of the test standard. Results obtained indicate that the product under test complies in full with the requirements tested. The test results relate only to the items tested. See “Summary of test results” for full details. 1.5 Exclusions None 1.6 Test report revision history Revision # Details of changes made to test report TRF Original report issued Section 2: Summary of test results Report reference ID: 221407-1TRFWL Page 5 of 17 Section 2: Summary of test results 2.1 FCC Part 15 general requirements’ test results Part Test description Verdict §15.207(a) Conducted limits N/A §15.215(c) 20 dB bandwidth Pass Notes: The EUT is battery operated 2.2 FCC Part 15 Subpart C, 15.249 test results Part Test description Verdict §15.249(a) Radiated emissions not in restricted bands Pass §15.249(b) Fixed Point-to-Point operation in the 24.0–24.25 GHz band N/A §15.249(d) Spurious emissions (except harmonics) Pass Notes: The EUT operates within 902–928 MHz band 2.3 IC RS…
