TAKE OUT WHAT YOU NEED INSTALL THE PC CARD CLIENT ADAPTER INSTALL THE APPROPRIATE DRIVER AND UTILITIES 1 2 3 Quick Start Guide CISCO AIRONET 350 SERIES PC CARD C LIENT ADAPTERS Laptops with PC card client adapters Access Point 1 Take Out What You Need If any item is missing or damaged, contact your Cisco representative or reseller for support. Note: The integrated antenna on PC models of the Aironet PC Client Card Adapter is permanently attached; LM models are shipped with no antenna. Additional Requirements •A computing device (desktop personal computer, notebook, laptop computer, portable or hand-held device) equipped with an internal or external PC Card Type II or Type III slot. All drivers and supporting software (card and socket services) for the PC card slot must be loaded and configured. •The following information from your system administrator: —your wireless client name —the (case-sensitive) wireless service set identification (SSID) for your radio network —for Microsoft Windows networking, your computer name and workgroup name —the username and password for your network account —if you are not connected to a DHCP server, the IP address, default gateway address, and subnet mask of your computer —for Windows NT systems, an available IRQ number (interrupt address) in your system Cisco Aironet 350 Series PC Card Client Adapter (labeled Wireless LAN Adapter) Cisco Aironet 350 Series PC Card Client Adapter CDs for Windows 95 and Windows NT or Windows 98 and Windows 2000 with software and product documentation CISCO AIRONET 340 SERIES 11 Mbps WIRELESS LAN ADAPTER 2 Install the PC Card Client Adapter CautionThe following procedures and physical connections apply generally to normal and conventional PC card slots. In cases of custom or non-conventional equipment, be alert to possible differences in PC card slot configurations. 1 Before you begin, examine the PC card client adapter. One end is a dual-row, 68-pin PC card connector. The card is keyed so that it can be inserted only one way into the PC card slot. The slot in your computing device must be a PC card Type II slot (this includes slots that support both the Type II and Type III cards). Note: The PC card slot will be on the left or right side of the computer, depending on the model. 2 For Windows 95 and Windows 98 systems, remove any other PC card from the card slot. 3 For Windows 95 or Windows 98 systems, turn the computer on before inserting the PC card client adapter. For Windows NT systems, turn the computer off before inserting the client adapter. CautionNever force the PC card client adapter into the PC card slot. Forcing it will damage both the PC card and the slot. If the PC card does not easily insert, remove the card and re-insert it. 4 Hold the PC card client adapter with the logo facing up and insert the card into the slot, applying just enough pressure to make sure it is fully seated. Proceed to the appropriate driver installation for your operating system. 3 Note: The following procedures assume you are installing the driver from the CD provided. If your PC does not have a CD-ROM drive, download the driver from Cisco’s web site. Install the Appropriate Driver and Utilities Windows 98 Systems Note: The Windows 98 driver also works with the Windows 2000 operating system. In Windows 98 systems, after you have installed the PC card client adapter, the system automatically detects it, opens a New Hardware Found window, and starts collecting information for a driver database. 1 When the Add New Hardware Wizard dialog box opens, it is searching for new drivers. Click Next. 2 From the next dialog box, select Search for the best driver for your device (Recommended) and click Next. 3 Select CD-ROM drive, deselect all other options, insert the Cisco Aironet 350 Series Client Adapter CD for Windows 98, and click Next. 4 The hardware wizard will find the installation files on the CD and display the search results. When the PCMCIA adapter driver is displayed, click Next to copy the required files. 5 During driver installation, you may be prompted to enter a path to the required client adapter or Windows 98 files: (a) Windows 98 files installed on your PC are usually located in the folder C:\Windows\Options\Cabs. Click OK to install. (b) If the system prompts you for the Windows CD and the CD-ROM drive on your PC is drive D, the path should be D:\WIN98. Click OK to copy the required files. 6 The Add New Hardware Wizard window again opens indicating that the installation is complete. Click Finish. 7 Remove the CD and restart your laptop. 8 When the computer restarts, double-click My Computer, Control Panel, and Network. 9 Select the PCMCIA adapter and click Properties. 10 In the Properties window, click Advanced. 11 In the Advanced window, select Client Name and enter your computer’s unique name in the Value dialog box. 12 Select SSID. Enter your Access Point’s (case-sensitive) SSID in the Value dialog box. Click OK. 4 13 If you are not connected to a DHCP server, double-click My Computer, Control Panel, and Network. Click the Protocols tab and select TCP/IP and Properties. Select Specify an IP address and enter the IP Address, Subnet Mask, and Default Gateway address of your computer. Click OK. 14 In the Network window, click OK. 15 When prompted, click Ye s to reboot the laptop. Windows 95 Systems In Windows 95 systems, after you have installed the PC card client adapter, the system automatically detects it, opens a New Hardware Found window, and starts collecting information for a driver database. 1 The Update Device Driver Wizard dialog box opens and indicates that Windows will complete the installation of the PCMCIA adapter. 2 Insert the Client Adapter CD for Windows 95 and NT, and click Next. 3 When the Update Device Driver Wizard indicates that it is unable to locate a driver, click Other Locations. 4 In the Select other Location window, click Browse. 5 Select the CD-ROM drive and click OK. 6 In the Select other Location win…

Text truncated - open the document above for the full version.

Corporate Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 USA http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 526-4100 Cisco Aironet Access Point Software Configuration Guide 340 and 350 Series Software Release 11.21 Text Part Number: OL-0657-06 THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS. THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY. The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California. NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE. IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Cisco Aironet Access Point Software Configuration Guide Copyright © 2002, Cisco Systems, Inc. All rights reserved. CCIP, the Cisco Powered Network mark, the Cisco Systems Verified logo, Cisco Unity, Follow Me Browsing, FormShare, Internet Quotient, iQ Breakthrough, iQ Expertise, iQ FastTrack, the iQ Logo, iQ Net Readiness Scorecard, Networking Academy, ScriptShare, SMARTnet, TransPath, and Voice LAN are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn, Discover All That’s Possible, The Fastest Way to Increase Your Internet Quotient, and iQuick Study are service marks of Cisco Systems, Inc.; and Aironet, ASIST, BPX, Catalyst, CCDA, CCDP, CCIE, CCNA, CCNP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, the Cisco IOS logo, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Empowering the Internet Generation, Enterprise/Solver, EtherChannel, EtherSwitch, Fast Step, GigaStack, IOS, IP/TV, LightStream, MGX, MICA, the Networkers logo, Network Registrar, Pa cke t, PIX, Post-Routing, Pre-Routing, RateMUX, Registrar, SlideCast, StrataView Plus, Stratm, SwitchProbe, TeleRouter, and VCO are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. All other trademarks mentioned in this document or Web site are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (0203R) iii Cisco Aironet Access Point Software Configuration Guide OL-0657-07 CONTENTS Prefacexiii Audience and Scopexiv Organizationxiv Conventionsxv Related Publicationsxvi Obtaining Documentationxvi World Wide Webxvi Documentation CD-ROMxvii Ordering Documentationxvii Documentation Feedbackxvii Obtaining Technical Assistancexviii Cisco.comxviii Technical Assistance Centerxix Cisco TAC Web Sitexix Cisco TAC Escalation Centerxx CHAPTER 1Overview1-1 Key Features1-2 Management Options1-3 Roaming Client Devices1-3 Network Configuration Examples1-4 Root Unit on a Wired LAN1-4 Repeater Unit that Extends Wireless Range1-5 Central Unit in an All-Wireless Network1-6 Contents iv Cisco Aironet Access Point Software Configuration Guide OL-0657-07 CHAPTER 2Using the Management Interfaces2-1 Using the Web-Browser Interface2-2 Using the Web-Browser Interface for the First Time2-2 Using the Management Pages in the Web-Browser Interface2-2 Navigating Using the Map Windows2-4 Using the Command-Line Interface2-5 Preparing to Use a Terminal Emulator2-6 Connecting the Serial Cable2-6 Setting Up the Terminal Emulator2-7 Changing Settings with the CLI2-8 Selecting Pages and Settings2-9 Applying Changes to the Configuration2-9 Navigating the CLI2-10 Using a Telnet Session2-10 Using SNMP2-11 Supported MIBs2-11 CHAPTER 3Configuration3-1 Basic Settings3-2 Entering Basic Settings3-3 System Name3-3 Configuration Server Protocol3-3 Default IP Address3-4 Default IP Subnet Mask3-4 Default Gateway3-4 Radio Service Set ID (SSID)3-4 Role in Radio Network3-5 Radio Network Optimization (Optimize Radio Network For)3-7 Radio Network Compatibility (Ensure Compatibility With)3-7 v Cisco Aironet Access Point Software Configuration Guide OL-0657-07 Contents SNMP Admin. Community3-7 Filter Setup3-8 Protocol Filtering3-8 Creating a Protocol Filter3-9 Enabling a Protocol Filter3-12 MAC Address Filtering3-13 Creating a MAC Address Filter3-14 Radio Configuration3-18 Entering Identity Information3-18 Settings on the AP Radio Identification Page3-19 Entering Radio Hardware Information3-21 Settings on the AP Radio Hardware Page3-22 Entering Advanced Configuration Information3-30 Settings on the AP Radio Advanced Page3-31 Ethernet Configuration3-39 Entering Identity Information3-39 Settings on the Ethernet Identification Page3-40 Entering Ethernet Hardware Information3-42 Settings on the Ethernet Hardware Page3-43 Entering Advanced Configuration Information3-44 Settings on the Ethernet Advanced Page3-44 Server Setup3-46 Entering Time Server Settings3-47 Settings…

Text truncated - open the document above for the full version.

4-31 Cisco Aironet Access Point Software Configuration Guide OL-0657-07 Chapter 4 Security Setup Setting Up MAC-Based Authentication Step 4If you plan to create a MAC address list that will be checked by the authentication server, select Ye s for the option called Lookup MAC Address on Authentication Server if not in Existing Filter List. With this option enabled, the access point checks the authentication server’s MAC address list when a client device attempts to authenticate. Step 5Click Apply to save the list of MAC addresses in the access point management system. Step 6Click the Authentication Server link to go to the Authenticator Configuration page. Figure 4-11 shows the Authenticator Configuration page. Figure 4-11 Authenticator Configuration Page You can configure up to four servers for authentication services, so you can set up backup authenticators. If you set up more than one server for the same service, the server first in the list is the primary server for that service, and the others are used in list order when the previous server times out. Step 7Enter the name or IP address of the authentication server in the Server Name/IP entry field. Chapter 4 Security Setup Setting Up MAC-Based Authentication 4-32 Cisco Aironet Access Point Software Configuration Guide OL-0657-07 Step 8Enter the port number the server uses for authentication. The default setting, 1812, is the port setting for Cisco’s RADIUS server, the Cisco Secure Access Control Server (ACS), and for many other RADIUS servers. Check your server’s product documentation to find the correct port setting. Step 9Enter the shared secret used by the server in the Shared Secret entry field. The shared secret on the bridge must match the shared secret on the server. Step 10Enter the number of seconds the access point should try contacting the primary authentication server in the Timeout entry field. If the primary authentication server does not respond within this time, the access point tries to contact the backup authentication server if one is specified. Step 11Select MAC Address Authentication under the server. If you set up a backup authentication server, select MAC Address Authentication under the backup server, also. Step 12Click OK. You return automatically to the Setup page. Step 13Create a list of allowed MAC addresses for your authentication server. Enter the MAC addresses of all allowed clients as users in the server’s database. The “Enabling MAC-Based Authentication in Cisco Secure ACS” section on page 4-35 describes how to create a list of MAC addresses for your RADIUS server. NoteBe sure to include your own MAC address in the authentication server’s list. Step 14Click Advanced in the AP Radio row of the Network Ports section at the bottom of the Setup page. The AP Radio Advanced page appears. Figure 4-12 shows the AP Radio Advanced page. 4-33 Cisco Aironet Access Point Software Configuration Guide OL-0657-07 Chapter 4 Security Setup Setting Up MAC-Based Authentication Figure 4-12 AP Radio Advanced Page Step 15Select Disallowed from the pull-down menu for Default Unicast Address Filter for each authentication type requiring MAC-based authentication. For example, if the access point is configured for both open and Network-EAP authentication, you could set Default Unicast Address Filter under Open to Disallowed but leave Default Unicast Address Filter under Network-EAP set to Allowed. This configuration forces client devices using open authentication to authenticate using MAC addresses but does not force LEAP-enabled client devices to authenticate using MAC addresses. To force all client devices to authenticate using MAC addresses, select Disallowed for all the enabled authentication types. Chapter 4 Security Setup Setting Up MAC-Based Authentication 4-34 Cisco Aironet Access Point Software Configuration Guide OL-0657-07 When you set Default Unicast Address Filter to disallowed, the access point discards all unicast traffic except packets sent to the MAC addresses listed as allowed on the authentication server or on the access point’s Address Filters page. NoteClient devices associated to the access point are not immediately affected when you set Default Unicast Address Filter to disallowed. Step 16Click OK. You return automatically to the Setup page. Client devices that associate with the access point will not be allowed to authenticate unless their MAC addresses are included in the list of allowed addresses. Authenticating Client Devices Using MAC Addresses or EAP You can set up the access point to authenticate client devices using a combination of MAC-based and EAP authentication. When you enable this feature, client devices that associate to the access point using 802.11 open authentication first attempt MAC authentication. If MAC authentication succeeds, the client device joins the network; if the client is also using EAP authentication, it attempts to authenticate using EAP. If MAC authentication fails, the access point waits for the client device to attempt EAP authentication. Follow these steps to combine MAC-based and EAP authentication for client devices using 802.11 open authentication: Step 1Follow the steps in the “Setting Up EAP Authentication” section on page 4-19 to set up EAP. You must select Require EAP under Open authentication on the AP Radio Data Encryption page to force client devices to perform EAP athentication if they fail MAC authentication. If you do not select Require EAP, client devices that fail MAC authentication might be able to join the network without performing EAP authentication. Step 2Follow the steps in the “Setting Up MAC-Based Authentication” section on page 4-29 to set up MAC-based authentication. Step 3Follow this link path to reach the Address Filters page: a.On the Summary Status page, click Setup. b.On the Setup page, click Address Filters under Associations. 4-35 Cisco Aironet Access Point Software Configuration Guide OL-0657-07 Chapter 4 Security Setup Setting Up MAC-B…

Text truncated - open the document above for the full version.

Edward W. Suor, VPN Systems, Inc. Voice : (585) 624 - 8365 Managing Director 280 Cheese Factory Road Fax : (585) 624 - 4181 [email protected] Honeoye Falls, NY 14472 www.VPNSystems.com Specialists in Wireless Internetworking August 28, 2002 Federal Communications Commission Washington, DC 20554 Subject: VPN SYSTEMS INC. Submission for FCC Grant of Equipment Authorization Reference: VPN Systems Inc. Access Wireless Point Device To Whom It May Concern: VPN Systems Inc. hereby requests that certain sections, exhibits and the like, to our attached submission be treated by the FCC as confidential information. The sections that require confidentiality is, for the most part all of the Section entitled Block Diagrams and Schematics and includes the following technical information: • Detailed Theory of Operation • Any and all Block Diagrams and explanatory text • All Schematics The above technical information, which is explicitly characterized in our submission, describes in detail how our product is built and its theory of operation. This level of technical information, if disclosed outside the FCC, would cause irreparable harm to VPN Systems from a competitive standpoint. Therefore, we respectfully request that the technical information listed herein and fully described in our submission attached hereto be treated as confidential information and not be disclosed outside of the FCC. Sincerely, Edward W. Suor Managing Director

TEST SERVICES Parker Chomerics 77 Dragon Court Woburn, MA 01888 781-935-4850 FAX: 781-935-2758 January 16, 2003 Steve Dayhoff FCC Applications Processing Branch Reference FCC ID: QAX-VPN350 Dear Mr. Dayhoff: This correspondence is in response to your comment within FCC Correspondence Reference Number 24746 and 731 Confirmation Number EA257798. VPN is looking to certify two new antennas attached to the CISCO PCMCIA card. The original certification of the CISCO PCMCIA card can be found within FCC ID number LDK102035. For this certification, schematics and block diagrams are only needed for the PCMCIA card, which is the radio portion of the equipment. Use of the PCMCIA card within the CICSO Access Point device requires only Declaration of Conformity (DOC) testing. The PCMCIA card and the Access Point Device are purchased from CISCO as a package. The firmware within the Access Point will only recognize the CISCO PCMCIA radio. The Access Point with PCMCIA was received from CISCO pre- configured with a specific radio model. The CISCO model number ordered contains the specific radio model (PCMCIA Card). Dave Case from CISCO has helped clarify this issue. If you need any further information or have questions about the information I have provided please give me a call at (781) 939-4375 or e-mail at [email protected] . Sincerely; David C. Inman Manager, Chomerics Test Services

TEST SERVICES Parker Chomerics 77 Dragon Court Woburn, MA 01888 781-935-4850 FAX: 781-935-2758 February 19, 2003 Steve Dayhoff FCC Applications Processing Branch Reference FCC ID: QAX-VPN350 Dear Mr. Dayhoff: This correspondence is in response to your comment within FCC Correspondence Reference Number 24750 and 731 Confirmation Number EA257798. A.C line conducted data is not required for the following reason: The CISCO PCMCIA card is powered by the host CISCO Access Point Device. The Access Point Device is in turn powered through the Ethernet interface. This is referenced on Page 14 of the Access Point Hardware Manual. If you need any further information or have questions about the information I have provided please give me a call at (781) 939-4375 or e-mail at [email protected] . Sincerely; David C. Inman Manager, Chomerics Test Services

CISCO CONFIDENTIALMercury processing gainJ. Friedmann data ratesmodulation usedsymbol rateschip ratechip per bit 10 log (chip per bit) add 3dB if unique codes for I & Q (minus 1 dB for implementation) theoretical processing gain dB (add last two columns) measured processing gain 1 mb/sBPSK1 mbps11 mbps 11 (same code for I & Q)10.7 dB10.7 dB10.8 dB 2 mb/sQPSK1 mbps11 mbps 11 (same code for I & Q)10.7 dB10.7 dB10.8 dB 5.5 mb/sCCK1.375 mbps8 mbps 8 (8 for I & 8 for Q)9 dB2 dB11 dB10.7 dB 11 mb/sCCK1.375 mbps8 mbps 8 (8 for I & 8 for Q)9 dB2 dB11 dB10.6 dB 9/25/001PG_Mercury_th_writeup.xls

1-8 Cisco Aironet Access Point Hardware Installation Guide OL-0738-02 Chapter 1 Overview Access Point Specifications Access Point Specifications Table 1-1 lists specifications for the access point. Table 1-1Access Point Specifications CategorySpecification Physical Size6.30 in. (16 cm) W x 4.72 in. (12 cm) D x 1.45 in. (3.7 cm) H Status indicatorsThree indicators on the top panel: Ethernet traffic, status, and radio traffic ConnectorsOn the back panel: An RJ-45 jack for 10/100 Ethernet connections; a nine-pin serial connector; a power connector (plug-in AC adapter) for a regulated 5V input (340 series only) Voltage range24 to 60 VDC (regulated 5 VDC for 340 series only) Operating temperature range32 to 122 o F (0 to 50 o C) for 340 and 350 series –4 to 131 o F (–20 to 55 o C) for 350 series metal case 32 to 104 o F (0 to 40 o C) for power injectors WeightLess than 1 lb (0.45 kg) for 340 and 350 series 1.43 lbs (0.64 kg) for 350 series metal case Radio Power output100, 50, 30, 20, 5, or 1 mW for 350 series 30, 20, 5, or 1 mW for 340 series (Depending on the regulatory domain in which the access point is installed) Frequency2.400 to 2.497 GHz (Depending on the regulatory domain in which the access point is installed) RangeIndoor: 150 ft at 11 Mbps (100 ft for 340 series only) 350 ft at 1 Mbps (300 ft for 340 series only) Outdoor: 800 ft at 11 Mbps (400 ft for 340 series only) 2000 ft at 1 Mbps (1500 ft for 340 series only) ModulationDirect Sequence Spread Spectrum Data rates1, 2, 5.5, and 11 Mbps 1-9 Cisco Aironet Access Point Hardware Installation Guide OL-0738-02 Chapter 1 Overview Access Point Specifications AntennaTwo captured 2.2 dBi gain antennas or a diversity system with two reverse-TNC connectors (antennas for this model are sold separately). Some models in the 340 series have one 2.2 dBi gain antenna. ComplianceOperates license-free under FCC Part 15 and complies as a Class B computing device. Complies with DOC regulations. Complies with the following: ETS 300.328, FTZ 2100, MPT 1349, FCC Part 15.107 and 15.109 Class B, ICES-003 Class B (Canada), CISPR 22 Class B, AS/NZS 3548 Class B, VCCI Class B, EN 50082-1, UL1950, CSA 22.2 No. 950, EN 60950, IEC 60950, VCCI, and others (see Appendix B). 350 series metal case access point complies with UL 2043 for products installed in air handling spaces, such as above suspended ceilings. CautionCisco Aironet Power Injectors are not rated for UL 2043 and should not be placed in air handling spaces, such as above suspended ceilings. Table 1-1Access Point Specifications (continued) CategorySpecification

BOM-200-004994 This document includes the followin g assembl y variations: Variation Title Descri p tion -002 5V, A PHY, REV. A0 BDS. ONLY -006 5V, A PHY, LED MOD, PCI MOD -008 5V, B PHY, LED MOD, PCI MOD 05-May-00 BOM-200-004994 PAGE 1 OF 4 RUN PRODUCT ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 01-May-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2382 INCORPORATED ECN REVISIONS A PPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333 h a a a a NOTE: SEE SOURCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -002: 5V, A PHY, REV. A0 BDS. ONLY Doc Cell TESTED MECH. ASSY , PLUTO LM SERIES RADIO 5V , A PHY 421-004994-002 1 1 05-May-00 BOM-200-004994 PAGE 2 OF 4 RUN PRODUCT ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 01-May-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2382 INCORPORATED ECN REVISIONS A PPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333 h a a a a NOTE: SEE SOURCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -006: 5V, A PHY, LED MOD, PCI MOD Doc Cell TESTED MECH. ASSY , PLUTO LM SERIES RADIO 5V , A PHY , LED MOD , PCI M 421-004994-006 1 1 05-May-00 BOM-200-004994 PAGE 3 OF 4 RUN PRODUCT ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 01-May-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2382 INCORPORATED ECN REVISIONS A PPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333 h a a a a NOTE: SEE SOURCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -008: 5V, B PHY, LED MOD, PCI MOD Doc Cell TESTED MECH. ASSY , PLUTO LM SERIES RADIO 5V , B PHY , LED MOD , PCI M 421-004994-008 1 1 05-May-00 BOM-200-004994 PAGE 4 OF 4 RUN PRODUCT ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 01-May-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2382 INCORPORATED ECN REVISIONS A PPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333 h a a a a NOTE: SEE SOURCE CONTROL DRAWINGS FOR ORDERING INFORMATION. BOM-410-004994 This document includes the followin g assembl y variations: Variation Title Description -005 3V,HFA3861A,LED INV,PCI MOD INCORPORATED -006 5V,HFA3861A,LED INV,PCI MOD INCORPORATED -007 3V,HFA3861B,LED INV,PCI MOD INCORPORATED -008 5V,HFA3861B,LED INV,PCI MOD INCORPORATED 19-Jan-00 BOM-410-004994 PAGE 1 OF 17 RUN PCA, PLUTO LM, PCMCIA RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Nahra 18-Jan-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN B0 2262 PRODUCTION REL EASE REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -005: 3V,HFA3861A,LED INV,PCI MOD INCORPORATED Doc Cell PCB1 PCB , PLUTO LM , PCMCIA RADIO PCB 510-004994 B 1B0 1 SHLD1 SHIELD, POWER AMP SHIELD 530-004913 A1 1 2 SHIELD SHLD6 SHIELD, I/Q MODEM SHIELD 530-004919 A1 1 3 SHIELD SHLD3 SHIELD , RF/IF SHIELD 530-004939 B0 1 4 SHIELD SHLD2 SHIELD , 2GHZ VCO SHIELD 530-005061 A0 1 5 SHIELD SHLD8 SHIELD , TX BPF SHIELD 530-005062 B0 1 6 SHIELD U704 IC, UHS INVERTER, TINYLOGIC ( TM ) UHS SINGLE INV 601-004165 1 7 USV U500 U501 VOLTAGE REGULATOR , 150MA CMOS LDO TC1185-2.8VCT 601-004325-0280 2 8 SMV U700 IC , UHS BUFFER , TINYLOGIC ( TM ), GROUP IC , UHS BUFFER 601-004565 1 9 USV U400 IC , RF/IF CONVERTER & SYNTHESIZER 2.4GHZ HFA3683A 601-004748 1 10 LQFP64 U503 IC, I/Q MODULATOR/DEMOD & SYNTHESIZER HFA3783IN 601-004749 1 11 TQFP48 U101 IC , POWER AMPLIFIER & DETECTOR , 2.4GHZ HFA3983IV 601-004802 1 12 TSSP29 U401 IC , SILICON MMIC WIDEBAND AMP , 3V , 2.7GHZ UPC2745TB 601-004866 1 13 SMM6 U1 U100 IC , GAAS RF SWITCH , SPDT , 2.5GHZ AS179-92 601-004904 2 14 SOT363 U701 U705 U708 LMOS, 2-INPUT AND GATE TC7S08FU 604-002976 3 15 USV U600 IC,2MBIT BOTTOM SECT…
