FCC ID: QCW201866 Circuit Description The 307MHz LCR oscillator drives the base of Q4 the final/buffer amplifier. The modulation provided by IC (SM5212E). The output of Q4 has the matching network consisting of L2 and C3 that limit the harmonic content and effect the proper coupling of the antenna to the output stage. Antenna, Ground and Power Source There is no external antenna. There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by a 9 Volt (ā6F22ā size battery x 1) primary battery
Date: 2002-04-27 TEST REPORT Page 1 of 22 No.: HM106416 FCC PART 15 SUBPART C CERTIFICATION REPORT FOR LOW POWER TRANSMITTER TEST REPORT No.:HM106416 Equipment Under Test [EUT]:Instant Alert Model Number:201866 Applicant:C. Art Limited. FCC ID : Date: 2002-04-27 TEST REPORT Page 2 of 22 No.: HM106416 CONTENT: Cover Page 1 of 22 Content Page 2-3 of 22 Conclusion Page 4 of 22 1.0General Details 1.1Test Laboratory Page 5 of 22 1.2Applicant Details Page 5 of 22 Applicant HKSTC Code Number for Applicant Manufacturer 1.3Equipment Under Test [EUT] Page 6 of 22 Description of EUT operation 1.4Date of Order Page 6 of 22 1.5Submitted Sample Page 6 of 22 1.6Test Duration Page 6 of 22 1.7Country of Origin Page 6 of 22 1.8 Additional Information of EUT Page 7 of 22 2.0Technical Details 2.1Investigations Requested Page 8 of 22 2.2Test Standards and Results Summary Page 8 of 22 3.0Test Results 3.1Emission Page 9-13 of 22 3.2Bandwidth Measurement Page 14-15 of 22 Date: 2002-04-27 TEST REPORT Page 3 of 22 No.: HM106416 Appendix A List of Measurement Equipment Page 16 of 22 Appendix B Duty Cycle Correction During 100 msec Page 17-18 of 22 Appendix C Periodic Operation Page 19-22 of 22 Appendix D Photographs Page 19-22 of 22 Date: 2002-04-27 TEST REPORT Page 4 of 22 No.: HM106416 CONCLUSION The submitted product was deemed to have COMPLIED after modification by customer with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Verify byPatrick Wong for Chief Executive Date: 2002-04-27 TEST REPORT Page 5 of 22 No.: HM106416 1.0General Details 1.1Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong Telephone:852 2666 1888 Fax:852 2664 4353 1.2Applicant Details Applicant C. ART LIMITED. Unit Q, 10/F., Kaiser Estate, Phase 3, 11 Hok Yuen Street, Hunghom, Kowloon, Hong Kong. Telephone:852 2334 4455 Fax:852 2764 2432 HKSTC Code Number for ApplicantCAR001 Manufacturer C. ART LIMITED. Unit Q, 10/F., Kaiser Estate, Phase 3, 11 Hok Yuen Street, Hunghom, Kowloon, Hong Kong. Telephone:852 2334 4455 Fax:852 2764 2432 Date: 2002-04-27 TEST REPORT Page 6 of 22 No.: HM106416 1.3Equipment Under Test [EUT] Description of Sample Product:Instant Alert Manufacturer:C Art Ltd. Brand Name:N/A Model Number:201866 Input Voltage:9Vd.c (ā6F22ā size battery x 1) 1.3.1Description of EUT Operation The Equipment Under Test (EUT) is an C. Art Ltd., Instant Alert. The EUT is to transmit RF signal while each button is being, Modulation by Data Code tape is pulses modulation. 1.4Date of Order 2001-12-04 1.5Submitted Sample(s): 1 Sample per model 1.6Test Duration 2002-04-25 1.7Country of Origin China Date: 2002-04-27 TEST REPORT Page 7 of 22 No.: HM106416 1.8Additional Information of EUT SubmittedNot Available User Manual Part List Circuit Diagram Printed Circuit Board [PCB] Layout Block diagram FCC ID Label Date: 2002-04-27 TEST REPORT Page 8 of 22 No.: HM106416 2.0Technical Details 2.1Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.4:2000 for FCC Certification. 2.2Test Standards and Results Summary Tables EMISSION Results Summary Test ConditionTest RequirementTest MethodClass /Test Result SeverityPassFailedN/A Field Strength of Fundamental Emissions & Spurious Emissions FCC 47CFR 15.231aANSI C63.4:2000N/A Radiated Emissions, 30MHz to 1GHz FCC 47CFR 15.209ANSI C63.4:2000Class B Conducted Emissions on AC, 0.45MHz to 30MHz FCC 47CFR 15.207ANSI C63.4:2000Class B Note: N/A - Not Applicable Date: 2002-04-27 TEST REPORT Page 9 of 22 No.: HM106416 3.0Test Results 3.1Emission 3.1.1Radiated Emissions Test Requirement:FCC 47CFR 15.231a Test Method:ANSI C63.4:2000 Test Date:2002-04-25 Mode of Operation:On mode Test Method: The sample was placed 0.8m above the ground plane on the OATS *. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigate all operating modes, rotated about all 3 axis (X, Y & Z) to obtain worst position, manipulating interconnecting cables, rotating turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarization. The emissions worst-case are shown in Test Results of the following pages. *:OATS [Open Area Test Site] located at HKSTC with a metal ground plane on filed with the FCC pursuant to section 2.948 of the FCC rules, with Registration Number: 90657. Test Setup: EUT distance = 3m Pre -Amplifier Receiver Turn Table Computer Ground plane Date: 2002-04-27 TEST REPORT Page 10 of 22 No.: HM106416 Limits for Field Strength of Fundamental Emissions [FCC 47CFR 15.231a]: Frequency Range of Fundamental Field Strength of Fundamental Emission [Peak] Field Strength of Fundamental Emission [Average] [MHz][μV/m][μV/m] 40.66-40.701,000100 70-13050050 130-174500 to 1,500 *50 to 150 * 174-2601,500150 260-4701,500 to 5,000 *150 to 500 * Above 4705,000500 ** Linear interpolations Where F is the frequency in MHz, the formula for calculating the maximum permitted fundamental field strengths are as follows: for the band 130-174 MHz, μV/m at meters=56.81818(F)-6136.3636; for the band 260-470 MHz, μV/m at 3 meters =41.6667(F)-7083.3333. The maximum permissible unwanted emission level is 20dB below the maximum fundamental level. Results: CorrectionLimit **Antenna Factor @3mPolarity dB μ V/m μ V/m 307.4053.818.672.44168.757,250.1Horizontal μ V/m Field Strength of Fundamental Emissions Peak Value Frequency Level @3m Field Strength MHzdB μ V/m Field Strength Measured dB μ V/m CorrectionLimit @3mAntenna FactorPolarity dB μ V/m μ V/m 614.8032.724.557.2724.45,725.0Horizontal 922.2030.129.459.5944.15,725.0Vertical +1229.6021.132.253.3462.45,000.0Vertical +1537.00<1.015.9<ā¦
Text truncated - open the document above for the full version.
Marianne Bosley To:[email protected] Subject:C.Art Limited metrak #12398 Hi Alice, Technical review of the this and the application for Ngai has been completed. Ngai is fine and that grant should be forthcoming tomorrow. The RT for C. Art Limited is below, and as soon as you answer this, this too can be granted. 1. Page 20 of 22, Appendix C of the Test Report states that the EUT is a 2 button device. This is not the case- it is automatically activated by an IR Sensor. Please correct, and verify compliance with the 5 second limit for transmission of Section 15.231(a)(2). Marianne T. Bosley EMC Administrator 410-354-3300 X 412 [email protected]
