QDG-17864TX49 MHz Walkie Talkie - TX

TALK THRU SKELTOR DOOR GREETER 17864 OPERATION INSTRUCTIONS INSTALLATION OF BATTERIES RECEIVER *Unscrew the battery cover *Insert 6 UM3 AA (1.5V) alkaline batteries with positive (+) and negative (-) ends placing in a proper direction as indicated (batteries are not included). *Close the cover. TRANSMITTER *Unscrew the battery cover *Insert one DC9V (6F22) battery *Close the cover. SAFTTY BATTERY USAGE *Use alkaline batteries for best performance. *Do not use rechargeable batteries *Non-rechargeable batteries are not to be recharged. *Different types of batteries, new and used batteries are not to be mixed. *Only batteries of same equivalent type as recommended are to be used. *Batteries are to be inserted with the correct polarity. *Exhausted batteries are to be removed from the unit. *The supply terminals are not to be short – circuited. *Do not dispose of batteries in fire; batteries may explode or leak. *Batteries should be replaced by adult. CARING FOR YOUR DEVICES *Your devices have been fully adjusted prior to shipment from the factory. Be sure not to touch the internal components other than replacing batteries. *After use the devices, always press the button to “OFF” position to avoid possibility of battery leakage. *Keep the sets in dry and clean place. QUICK START RECEIVER *Push ON / OFF button to turn on the Receiver *The skeltor’s eyes will shine, turn to red colour, and lower jar will move and release voice sound when received signal from transmitter TRANSMITTER *Push ON / OFF button to turn on the Transmitter *Talk directly at the MIC and located at the transmitter’s bottom *Change voice sound by pushing button. Four (4) different sound voices are available for selection. HELPFUL HINTS When the receiver fails to respond to the signal from the transmitter or release noise distortion, it may due to interference caused by other radio signals, mobile signals or computer. Try moving to different location outside the range of the interference and resume to play. If the problem persists, it is time to change the batteries. *IN MOST CASES, UNIT MALFUCNTION OCCUR BECAUSE OF WEAK BATTERIES. NOTES: - NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. - SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.

TIMCO TIMCOTIMCO TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: FAST PACE EAST LTD. FCC ID: QDG-17864TX REPORT #: F/FastPace_QDG\439HT2\439HT2TestReport.doc Page 1 of 11 Test Report Product Name: 49MHz WALKIE TALKIE - TRANSMITTER PORTION FCC ID: QDG-17864TX Applicant: FAST PACE EAST LTD. 27/F., KING KONG COMMERCIAL CENTRE 9 DES VOEUX ROAD WEST SHEUNG WAN HONG KONG Date Receipt: 5/9/02 Date Tested: 5/11/02 TIMCO TIMCOTIMCO TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: FAST PACE EAST LTD. FCC ID: QDG-17864TX REPORT #: F/FastPace_QDG\439HT2\439HT2TestReport.doc Page 2 of 11 TABLE OF CONTENTS LIST APPLICANT: FAST PACE EAST LTD. FCC ID: QDG-17864TX TEST REPORT CONTAINING: PAGE 1-4....TEST EQUIPMENT LIST PAGE 5......TEST PROCEDURE PAGE 6......RADIATION INTERFERENCE TEST DATA PAGE 7......OCCUPIED BANDWIDTH TEST DATA PAGE 8......OCCUPIED BANDWIDTH – LOUD VOICE PAGE 9......OCCUPIED BANDWIDTH - CW EXHIBITS CONTAINING: EXHIBIT 1............FCC ID LABEL & LABEL LOCATION EXHIBIT 2............BLOCK DIAGRAM EXHIBIT 3............SCHEMATIC EXHIBIT 4............INSTRUCTION MANUAL EXHIBIT 5............EXTERNAL PHOTO - FRONT SIDE EXHIBIT 6............EXTERNAL PHOTO - BACK SIDE EXHIBIT 7............INTERNAL PHOTO - COMPONENT SIDE EXHIBIT 8............INTERNAL PHOTO - COPPER SIDE EXHIBIT 9............CIRCUIT DESCRIPTION EXHIBIT 10...........TEST SETUP PHOTOGRAPH TIMCO TIMCOTIMCO TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: FAST PACE EAST LTD. FCC ID: QDG-17864TX REPORT #: F/FastPace_QDG\439HT2\439HT2TestReport.doc Page 3 of 11 Equipment List DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS X 3-Meter OATS TEI N/A N/A Listed 12/22/99 12/22/02 3/10-Meter OATS TEI N/A N/A Listed 3/26/01 3/26/04 X Receiver, Beige Tower X Spectrum Analyzer (Tan) HP 8566B Opt 462 3138A07786 3144A20661 CAL 8/31/01 8/31/02 X RF Preselector (Tan) HP 85685A 3221A01400 CAL 8/31/01 8/31/02 X Quasi-Peak Adapter (Tan) HP 85650A 3303A01690 CAL 8/31/01 8/31/02 Receiver, Blue Tower Spectrum Analyzer (Blue) HP 8568B 2928A04729 2848A18049 CHAR 10/22/01 10/22/02 RF Preselector (Blue) HP 85685A 2926A00983 CHAR 10/22/01 10/22/02 Quasi-Peak Adapter (Blue) HP 85650A 2811A01279 CHAR 10/22/01 10/22/02 Biconnical Antenna Electro-Metrics BIA-25 1171 CAL 4/26/01 4/26/03 X Biconnical Antenna Eaton 94455-1 1096 CAL 10/1/01 10/1/02 Biconnical Antenna Eaton 94455-1 1057 CHAR 3/15/00 3/15/01 BiconiLog Antenna EMCO 3143 9409-1043 X Log-Periodic Antenna Electro-Metrics LPA-25 1122 CAL 10/2/01 10/2/02 Log-Periodic Antenna Electro-Metrics EM-6950 632 CHAR 10/15/01 10/15/02 Log-Periodic Antenna Electro-Metrics LPA-30 409 CHAR 10/16/01 10/16/02 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 152 CAL 3/21/01 3/21/02 Dipole Antenna Kit Electro-Metrics TDA-30/1-4 153 CHAR 11/24/00 11/24/01 Double-Ridged Horn Antenna Electro-Metrics RGA-180 2319 CAL 12/19/01 12/19/02 Horn Antenna Electro-Metrics EM-6961 6246 CAL 3/21/01 3/21/02 TIMCO TIMCOTIMCO TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: FAST PACE EAST LTD. FCC ID: QDG-17864TX REPORT #: F/FastPace_QDG\439HT2\439HT2TestReport.doc Page 4 of 11 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Horn Antenna ATM 19-443-6R None No Cal Required Passive Loop Antenna EMC Test Systems EMCO 6512 9706-1211 CHAR 7/10/01 7/10/02 Line Impedance Stabilization . . . Electro-Metrics ANS-25/2 2604 CAL 10/9/01 10/9/02 Line Impedance Stabilization . . . Electro-Metrics EM-7820 2682 CAL 3/16/01 3/16/02 Termaline Wattmeter Bird Electronic Corporation 611 16405 CAL 5/25/99 (5/25/00) Termaline Wattmeter Bird Electronic Corporation 6104 1926 CAL 12/12/01 12/12/02 Oscilloscope Tektronix 2230 300572 CHAR 2/1/01 2/1/02 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 1/22/02 1/22/03 AC Voltmeter HP 400FL 2213A14499 CAL 10/9/01 10/9/02 AC Voltmeter HP 400FL 2213A14261 CHAR 10/15/01 10/15/02 AC Voltmeter HP 400FL 2213A14728 CHAR 10/15/01 10/15/02 X Digital Multimeter Fluke 77 35053830 CHAR 1/8/02 1/8/03 Digital Multimeter Fluke 77 43850817 CHAR 1/8/02 1/8/03 Digital Multimeter HP E2377A 2927J05849 CHAR 1/8/02 1/8/03 Multimeter Fluke FLUKE-77-3 79510405 CAL 9/26/01 9/26/02 Peak Power Meter HP 8900C 2131A00545 CHAR 1/26/01 1/26/02 Digital Thermometer Fluke 2166A 42032 CAL 1/16/02 1/16/03 Thermometer Traulsen SK-128 CHAR 1/22/02 1/22/03 X Temp/Humidity gauge EXTech 44577F E000901 CHAR 1/22/02 1/22/03 Frequency Counter HP 5352B 2632A00165 CAL 11/28/01 11/28/02 Power Sensor Agilent Technologies 84811A 2551A02705 CAL 1/26/01 1/26/02 TIMCO TIMCOTIMCO TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: FAST PACE EAST LTD. FCC ID: QDG-17864TX REPORT #: F/FastPace_QDG\439HT2\439HT2TestReport.doc Page 5 of 11 DEVICE MFGR MODEL SERNO CAL/CHAR DATE DUE DATE or STATUS Injection Probe Fischer Custom Communications F-120-9A 270 CAL 6/1/01 6/1/02 Service Monitor IFR FM/AM 500A 5182 CAL 11/22/00 11/22/01 Comm. Serv. Monitor IFR FM/AM 1200S 6593 CAL 11/12/99 11/12/00 Signal Generator HP 8640B 2308A21464 CAL 11/15/01 11/15/02 Modulation Analyzer HP 8901A 3435A06868 CAL 9/5/01 9/5/02 Power Line Coupling/ Decoupling Network Fischer Custom Communications FCC-801-M2- 16A 01048 CAL 8/29/01 8/29/02 Power Line Coupling/ Decoupling Network Fischer Custom Communications FCC-801-M3- 16A 01060 CAL 8/29/01 8/29/02 VHF/UHF Current Probe Fischer Custom Communications F-52 130 CAL 8/30/01 8/30/02 Passive Impedance Adapter Fischer Custom Communications FCC-801-150- 50-CDN 01117 & 01118 CAL 8/29/01 8/29/02 Radiating Field Coi…
