QDJ-0307KON01900/1800/1900 TRIBANDS PHONE WITH GPRS10 AND BLUET

Konstanze User’s Guide PMG Phone Copyright Statement Copyright 2003 by CMCS. All rights reserved. No part of this publication may be reproduced, trans- mitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or other- wise, without the prior written permission of CMCS. Disclaimer CMCS makes no representations or warranties, either expressed or implied, with respect to the con- tents hereof and specifically disclaims any warranties, merchantability or fitness for any particular pur- pose. Further, CMCS reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of CMCS to notify any person of such revision or changes. ALL INFORMATION IS PROVIDED BY CMCS ON AN "AS IS" BASIS ONLY. CMCS PRO- VIDES NO REPRESENTATIONS AND WARRANTIES, EXPRESS OR IMPLIED, INCLUD- ING THE IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY AND NONINFRINGEMENT. Important Safety Precautions When using this product, the safety precautions below must be taken against possible legal issues and damages. SAFETY IN AIRCRAFT The interference would be caused by this product to an aircraft's navigation system and its network. In most countries, using this product on board an airplane is against the law. SAFETY FOR ENVIRONMENTS Do not use this product in gas stations. Also the use of this product is prohibited in fuel storehouse, chemical plants and locations containing explosives. SAFETY ON THE ROAD Vehicle drivers in motion are not permitted to use telephony services with the handheld device, except in the case of emergency. In some countries, using hand- free devices as an alternative is allowed. SAFETY ABOUT RADIATION This product should be operated in the suggested normal condition only to ensure the radiative performance and safety of the interference. SAFETY FOR MEDICAL EQUIPMENTS This product may cause malfunctions of medical equipments. In most hospital or medical centers, use of this product is forbidden. Attention CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Tips When Using • Avoid using the product near metal structures (for example, large metal furniture or steel frames of a building). The transmission and reception of signal can be effected by these objects. • Avoid using the product near strong electromagnetic sources, such as microwave ovens, sound speakers, TV and radio. • Avoid using the product right after dramatic change of temperature. There are no user serviceable parts inside this product. If this product appears to be broken, call a qualified service personnel or send this product to your original dealer. Do not attempt to disassemble or repair this product as it may result in electric shock or unrecoverable damage to the product itself. Keep this product out of reach of small children. Store this product in its protective case in a cool dry place. Do not throw the battery into fire or other heat source. Dispose of used batteries according to your local regulations. FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) this device may not cause harmful interference, and (2) this device must accept any interfer- ence received, including interference that may cause undesired operation. FCC ID: QDJ-0307KON01 Statement according to FCC part 15.21 Modifications not expressly approved by CMCS could void the user's authority to operate the equip- ment. Statement according to FCC part 15.105 This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ---Reorient or relocate the receiving antenna. ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. Regulatory information / Disclaimers Installation and use of this 900/ 1800/ 1900/ Bluetooth Mobile Handset device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution of the connecting cables and equipment other than manufacturer specified. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. Manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines. IMPORTANT NOTE (CO-LOCATION) FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunct…

Text truncated - open the document above for the full version.

The Main Menu Message 50 • Delete page: Delete current page. • Go to...: Move to one of the pages you are writing. • Preview: Preview the message you are writing. All inserted objects(includ- ing picture, animation, sound...etc.) will be displayed. • Remove object: Remove the inserted multimedia objects of the message. • View object: View all inserted multimedia objects of the message. • Set title: Set a title for the multimedia message. The title will appear when the message is received by recipient. • Detail info.: View the title, recipients, memory of the message. Viewing unsent multimedia messages The drafts of multimedia messages are automatically stored in the Outbox. To open the Outbox and check these messages: 1. In standby mode, press the left soft key, Select. 2. Scroll to Multimedia msgs. and press Select. 3. Scroll to Outbox and press Select. A list of multimedia message drafts with the iconin front of them will appear on the screen. 4. Scroll to a message and press Select. The message will be opened. 5. Press Options and you can also choose to perform the following operations to selected message. • Send: Send the message immediately. You will be prompted to enter the number of the recipients. You can also press Options, scroll to Add recipient and press Select. Scroll to Number and press Select to pick up one recipient from your Phone Book by pressing Names. Scroll to e-mail address and press Select to enter the recipient’s e-mail address. Scroll to Sending options and press Select to access the options below: Status report: Turn on/off a message delivery status report. • Each multimedia message size can not be over 30KB. • Each page of the multimedia message allows a maximum of 1,000 Latin characters or Chi- nese characters(including space and symbols). • You can add up to 5 pages into a multimedia message. • Your phone support the following multimedia objects formats: Picture: JPEG, GIF87,GIF89, BMP, WBMP, PNG. Sound: iMelody, MIDI, SP-MIDI, AMR. • Each page can only be inserted one picture and one sound if the memory is available. • The number of recipients of each message can be up to 10 persons. Note The Main Menu Message 51 Validity period: The valid period determines the duration of time the mes- sage is stored in the Outbox. • Erase: Erase current message. • Edit: Edit current message. • Objects: All inserted multimedia objects of the message will be listed here. Press Select, scroll to a desired object and press Select, you can view the object, save the object to the multimedia center or view the detail info. of the object. • Use address: Capture the address(numbers) in the message. The address (numbers) captured will appear on the screen. Scroll to an address (number) and press Select. You can call the number directly or save it in Phone Book. • Detail info.: View the detail info. of the message. Viewing received multimedia messages The messages you received are stored in the Inbox. To open Inbox and view received messages: 1. In standby mode, press the left soft key, Select. 2. Scroll to Multimedia msgs. and press Select. 3. Scroll to Inbox and press Select. 4. Scroll to a message you want to read and press Select. The contents of the message will be opened to the screen. 5. You can press Options to perform the following operations: • Reply: Reply to current message. Press Select to choose to reply to the sender of the message or to other recipients. • Forward: Send this message to other recipients. • Erase: Erase current message. • Edit: Edit current message. • Objects: All inserted multimedia objects of the message will be listed here. Press Select, scroll to a desired object and press Select, you can view the object, save the object to the multimedia center or view the detail info. of the object. • Use address: Capture the address(number) of the message. The address (number) captured will appear on the screen. Scroll to the address(number) and press Select. You can call the number directly or save it in Phone Book. The Main Menu Message 52 • Detail info.: View the detail info. of the message. Erasing all multimedia messages This function allows you to erase all messages in Inbox and Outbox. 1. In standby mode, press the left soft key, Select. 2. Scroll to Multimedia msgs. and press Select. 3. Scroll to Erase all and press Select. 4. Scroll to All inbox msgs. to erase all messages in Inbox. Scroll to All outbox msgs. to erase all messages in Onbox. Scroll to All msgs. to erase all mes- sages in Inbox and Outbox. Chatroom The Chatroom function allows you to chat on-line with multiple members via text messages. In a chat session, you can invite up to 4 members to your chat- room and talk to each other simultaneously. If someone else invites you to join his/her chatroom, you will be notified by a chat message. Press OK to join the chat. Accepting an invitation to join a chatroom If someone else invites you to join his/her chatroom, you will be notified by a chat message. 1. Press Detail, Select to enter the chatroom. 2. Press Options, scroll to Open chatroom, press Select, press OK. 3. Enter your nickname and press OK. 4. Enter your message and press Options, Select. On the screen, your chat messages follows the ">" symbol and your nickname, and the chat mes- sages from other chat members follow the "<" symbol and their nicknames. Opening a new chat session Multimedia messages, Voice recorder and Multimedia center share memory of total 504KB. It will be allocated automatically by your phone. Therefore, the number of the multimedia mes- sages that can be stored in Inbox and Outbox will depend on the memory size of the multime- dia messages you received(sent) and the remaining space of the Inbox/Outbox. When the memory is full, the icon will appear on the screen to remind you to delete some multime- Note The Main Menu Message 53 1. In standby mode, press the left soft key, Select. 2. Scroll to Chatroom and press Select. 3. Enter the number of chat member, or pick a m…

Text truncated - open the document above for the full version.

POWER OF ATTORNEY Date: October 7, 2003 We, the undersigned, hereby authorize Compliance Certification Services Inc. to act on our behalf in all matters relating to all processes related to FCC applications and communications issue. Any and all acts carried out by Compliance Certification Services Inc. on our behalf shall have the same effects as acts of our own. If you have any questions regarding this authorization, please don’t hesitate to contact us. Thank you. Sincerely yours, ------------------------------------------------------------------- Kara Liao / Engineer Chi Mei Communication Systems, Inc.

CMCS Proprietary & Confidential Version: Doc. No.: Antenna Specification Date: 2003/9/19 Copyright Statement Copyright 2002 by Chi Mei Communication Systems, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Chi Mei Communication Systems, Inc. Disclaimer Chi Mei Communication Systems, Inc. makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Further, Chi Mei Communication Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of Chi Mei Communication Systems, Inc. to notify any person of such revision or changes. ALL INFORMATION IS PROVIDED BY CMCS ON AN "AS IS" BASIS ONLY. CMCS PROVIDES NO REPRESENTATIONS AND WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY AND NONINFRINGEMENT. Antenna Specification History 2003-09-18 Submitted by BY Liu CMCS Proprietary & Confidential Antenna Specification Antenna Specification 1.1 Voltage Standing Wave Ration (VSWR) The VSWR will be below or equal to the value in table 1 Frequency(MHz)VSWR, free space GSM TX 880-915 4.5:1 GSM RX 925-960 4.5:1 DCS TX 1710-1785 4.5:1 DCS RX 1805-1880 4.5:1 PCS TX 1850-1910 4.5:1 PCS RX 1930-1990 4.5:1 bluetooth 2400-2483 2.5:1 Table 1 1.2 Antenna Efficiency The antenna efficiency is the average value over the specified frequency band for GSM, DCS, PCS and bluetooth . The antenna efficiency includes the reflection loss due to impedance mismatch at the antenna in free space. Frequency(MHz)Average efficiency GSM 880-960 26% DCS 1710-1880 39% CMCS Proprietary & Confidential Page 1 of 4 Antenna Specification PCS 11850-1990 45% bluetooth 2400-2483 60% Table 2 1.3 Antenna gain Band Max Peak gain (dBi) GSM900 -4 GSM1800 -1 GSM1900 -2 BT +1 1.4 Coupling between Antenna Element The coupling between the bluetooth antenna element and the antenna element for GSM, DCS and PCS=11dB or lower. Page 2 of 4 CMCS Proprietary & Confidential Antenna Specification 2. Antenna Dimension The Antenna of Konstanze mobile including GSM (Triple-Band) and Bluetooth in one, as the graph shows below, the top section (1) on the plane is BT antenna, and the bottom section (2) on the plane is GSM antenna, in the other world, the BT and GSM are coplanar. The antenna type of Konstanze is PIFA, and the dimension is 24mm×34mm. Konstanze Antenna ( GSM & BT ) CMCS Proprietary & Confidential Page 3 of 4

Steve Cheng From: [email protected] Sent: Wednesday, October 08, 2003 2:35 AM To: [email protected] Cc: [email protected]; [email protected]; [email protected]; [email protected]; [email protected] Subject: Re: AN03T3296-PCE-ChiMei-QDJ-0307 TCB question Page 1 of 3 10/10/2003 Hi, Steve, For the Q1, please refer to the one attached this time. Which is the most updated and just received from our client at this moment. FYI, and please discard the one we have sent you before. Thank you!! BR, Eric ----- ??? eric/ccsemc ? 2003/10/08 05:26 PM ----- Hi, Steve, Please find the replies for the PCE as follows, prepared per the your comments. PCE 1. Please refer to the revised tune up procedure attached. 2. Please refer to the revised POA attached. 3. Please refer to the revised test report attached. 4. Please refer to the revised user manual attached. 5. Please find the changes upon your comment on the revised Test report 6. The statement you'd requested is already shown on the report pg.6. eric ??? 2003/10/08 10:50 AM ???: [email protected] ????: lucy_tsai/ccsemc@ccsemc, jonson/ccsemc@ccsemc, miro/ccsemc@ccsemc, [email protected], [email protected] ??: Re: AN03T3296-PCE-ChiMei-QDJ-0307 TCB question 7. Please find the changes on the revised SAR report. 8. Please find the changes upon your comment on the revised SAR report. Replies for the DTS will be followed... Thank you!! Should you have any question, please don't hesitate to ask me. Best regards, Eric Wong Compliance Certification Services Inc. (Formerly C&C Laboratory Co., Ltd.) Tel.: +886-3-3240332 Ext.49 Add.: No.81-1, Lane 210, Ba-de 2nd Rd., Luchu Hsiang, Taoyuan Hsien 338, Taiwan, R.O.C. Email: [email protected] URL: http://www.ccsemc.com.tw ----- ??? lucy_tsai/ccsemc ? 2003/10/06 09:16 AM ----- RT for project: Question #1: Tune-up procedure does not has the required info, i.e. how to setup the required RF output power and spec. Please revise. Question #2: Need to revise POA, it refers to old agent name. Question #3: Test setup photos do not matching the DUT, please clarify. Question #4: User manual p9 stated that "For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used with an accessory that contains no metal and that position the antenna of the GSM phone a minimum of 1.5cm from the body. The SAR values of this GSM phone are 1.52mW/g (body) and 0.347mW/g (head). Use of other accessories may not ensure compliance with the FCC RF exposure guidelines." The specified SAR value is not consistent with measured vale in the SAR report. Please correct. Question #5: EMC test report p22, Please explain if this device has GPRS 10 to 15 classe and how it work. Steve Cheng <[email protected]> 2003/10/04 10:12 AM ???: "Lucy (E-mail)" <[email protected]>, "Jonson (E-mail)" <[email protected]> ????: Mike Kuo <[email protected]>, Scott Wang <[email protected]> ??: Re: AN03T3296-PCE-ChiMei-QDJ-0307 TCB question Page 2 of 3 10/10/2003 Figure 7-6 GSM Figure 7-7 GPRS (Class 10) Figure 7-8 GPRS (Class 11) Figure 7-9 GPRS (Class 12) Figure 7-10 GPRS (Class 13) Figure 7-11 GPRS (Class 14) Figure 7-12 GPRS (Class 15) Question #6: Please specify how DUT was set upped during the co-location test, i.e. which frequency GSM/GPRS was tuned to and what power level it outputted during the collocation test. Question #7: Some of the critical info from the calibration file is necessary during the review process. Please supply the complete calibration record for CAE, Dipole and measurement Probe. Question #8: SAR report p15 "IEEE P1528 Recommended Reference Value table" is not consistent with IEEE P1528 or FCC supplement C publishes value. And is not used in the test. Please explain how this related to the test. Review will continue when requested data uploaded. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best Regards Steve Cheng Compliance Certification Services 561F Monterey Road Morgan Hill, CA 95037 Tel:(408)463-0885 x:119 Fax:(408)463-0888 [email protected] http:\\www.ccsemc.com Page 3 of 3 10/10/2003

Compliance Certification Services Inc. Report No: B30715208 Page 1 of 8 EXTERNAL PHOTOGRPHS OF EUT EUT --- 1 EUT --- 2 Compliance Certification Services Inc. Report No: B30715208 Page 2 EUT --- 3 EUT --- 4 Compliance Certification Services Inc. Report No: B30715208 Page 3 EUT --- 5 Compliance Certification Services Inc. Report No: B30715208 Page 4 Adapter Battery

Label Location

Compliance Certification Services Inc. Report No: B30715208 Page 5 INTERNAL PHOTOGRPHS OF EUT Internal of EUT --- 1 Internal of EUT --- 2 Compliance Certification Services Inc. Report No: B30715208 Page 6 Internal of EUT --- 3 Internal of EUT --- 4 Compliance Certification Services Inc. Report No: B30715208 Page 7 Internal of EUT --- 5 Internal of EUT --- 6 Compliance Certification Services Inc. Report No: B30715208 Page 8 Internal of EUT --- 7 Internal of EUT --- 8

CMCS Proprietary & Confidential Version: Doc. No.: Operational Description Date: 2003/7/14 Copyright Statement Copyright 2002 by Chi Mei Communication Systems, Inc. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Chi Mei Communication Systems, Inc. Disclaimer Chi Mei Communication Systems, Inc. makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Further, Chi Mei Communication Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of Chi Mei Communication Systems, Inc. to notify any person of such revision or changes. ALL INFORMATION IS PROVIDED BY CMCS ON AN "AS IS" BASIS ONLY. CMCS PROVIDES NO REPRESENTATIONS AND WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY AND NONINFRINGEMENT. Tune Up Procedures History 2003-07-14 Created by Alex Chen CMCS Proprietary & Confidential Tune Up Procedures RF Functional Descriptions RF Block Diagram Triple Band PA T/R Switch Charge Pump PFD R 90 0 90 0 90 0 90 0 N N-fractional PLL 2 3 QRxP QRxN IRxP IRxN DCOC DCOC DCO C DCO C I MIX OUT Q MIX OUT VGA1 VGA1 Sallen Key Sallen Key GmC Filter GmC Filter GSM LNA DCS LNA VGA2 VGA2 Control Interface RXENA TXENA FEENA T/H LE DATA CLK Serial Interface SXENA GSM: 925~ 960 MHz 2805~2880 MHz GSM:42~50 MHz DCS:84~100 MHz TX GSM: 890~ 915 MHz DCS:1710~1785 MHz PCS :1850~1910MHz TCXO: 13 900~1008 MHz 450~504 MHz MHz 80~110 MHz DCS:1805~1880 MHz PCS:1930~1990 MHz PCS LNA PA Controller TCXO DCO C DCO C QTxP QTxN ITxP ITxN TXINP The whole RF block includes RF transceiver, LDO, T/R switch, PA controller, and TCXO. We used the 13MHz TCXO for system internal clock. The RF transceiver is a highly integrated device for GSM or GPRS applications. It includes receiver, transmitter and synthesizer features in single chip. The transmit path implements an offset phase lock loop with fully integrated transmit VCO. It consists of an I/Q modulator, phase-frequency detector (PFD), charge pump, mixer, programmable divider, and high power transmit VCO. The I,Q signal from baseband passed into the modulator and through OPLL architecture of TX path, we can get GMSK modulated signal from TXVCO output. Then triple band PA amplifies the signal and we use the PA controller to control the specified output power level. CMCS Proprietary & Confidential Page 1 of 7 Tune Up Procedures Synthesizer Electrical Characteristics Introduction The transceiver IC includes a single integrated fractional-N synthesizer, and a integrated frequency translation loop in the transmit path. The fractional-N synthesizer can phase lock the local oscillator used in both the transmit and the receive path to a precision frequency reference source, TCXO. It contains a fast phase frequency detector, charge pump, high frequency prescaler, divider, and fully integrated wideband Ultra High Frequency(UHF) VCO. Fractional-N operation offers low phase noise and fast settling times, allowing for multiple slot applications such as GPRS. Fractional-N synthesizer Translation TXÅ R X Page 2 of 7 CMCS Proprietary & Confidential Tune Up Procedures The frequency translation loop can minimize the post-PA filtering requirements and provide high output spectral purity. It contains a Phase Frequency Detector(PFD), charge pump, mixer, modulator, two programmable dividers, and two integrated high power transmit Voltage Controlled Oscillators (VCOs). Fractional-N synthesizer Translation CMCS Proprietary & Confidential Page 3 of 7 Tune Up Procedures Synthesizer electrical characterics The frequency synthesizer are controlled by a 3-wire input signals CLK, DATA, and LE . The division ratios and charge pump currents in the fractional-N (SX Register1 & SX Register2) and translation loop (RX/TX Control Register) can be programmed using 24-bit words. Rx section: Channel Rx Freq.LO Freq. GSM Band 62 947.4MHz1421.1MHz DCS Band 697 1842.2MHz1381.65MHz PCS Band 660 1959.8MHz1469.85MHz Tx section: Channel Tx Freq. LO Freq.(U201 pin53,pin54) GSM Band 62 902.4MHz1489MHz DCS Band 700 1747.8MHz1388MHz PCS Band 660 1879.8MHz1492.8MHz Page 4 of 7 CMCS Proprietary & Confidential

Compliance Certification Services Inc. REPORT NO: B30715208-SAR-FCC DATE: September 03, 2003 Page 1 of 29 in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C For 900/1800/1900/ Bluetooth Mobile Handset Model: Konstanze FCC ID: QDJ-0307KON01 Prepared for Chi Mei Communication Systems, Inc. 11F, No. 39, Chung Hua Road Sec. 1, Taipei 100, Taiwan, R.O.C. Prepared by Compliance Certification Services Inc. No. 181, Sec. 1, Tatung Rd., Hsijr City, Taipei Hsien, Taiwan TEL: (02) 8642-2071 FAX: (02) 8642-1150 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Compliance Certification Services Inc. REPORT NO: B30715208-SAR-FCC DATE: September 03, 2003 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION...................................................................................... 3 2. EUT DESCRIPTION.............................................................................................................. 4 3. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC............. 5 4. DOSIMETRIC ASSESSMENT SYSTEM ........................................................................... 6 4.1 MEASUREMENT SYSTEM DIAGRAM ....................................................................................7 4.2 SYSTEM COMPONENTS ...........................................................................................................8 5. EVALUATION PROCEDURE ........................................................................................... 10 5.1 DATA EVALUATION ...............................................................................................................10 5.2 SAR EVALUATION PROCEDURE..........................................................................................12 6. MEASUREMENT UNCERTAINTY .................................................................................. 13 7. EXPOSURE LIMIT.............................................................................................................. 14 8. MEASUREMENT RESULTS ............................................................................................. 15 8.1 SYSTEM VALIDATION............................................................................................................15 8.2 TEST LIQUID CONFIRMATION .............................................................................................16 8.3 EUT SETUP PHOTOS................................................................................................................19 8.4 SAR MEASUREMENT RESULT ..............................................................................................22 9. EUT EXTERNAL PHOTOS ............................................................................................... 24 10. EQUIPMENT LIST & CALIBRATION ............................................................................ 26 11. REFERENCES......................................................................................................................27 12. ATTACHMENT ................................................................................................................... 28 Compliance Certification Services Inc. REPORT NO: B30715208-SAR-FCC DATE: September 03, 2003 Page 3 1. TEST RESULT CERTIFICATION Applicant: Chi Mei Communication Systems, Inc. 11F, No. 39, Chung Hua Road Sec. 1, Taipei 100, Taiwan, R.O.C. Equipment Under Test: 900/1800/1900/ Bluetooth Mobile Handset Model: Konstanze FCC ID QDJ-0307KON01 Device Category: PORTABLE DEVICES Exposure Category: GENERAL POPULATION/UNCONTROLLED EXPOSURE Report Number: B30715208-SAR-FCC Date of Test: July 25, and Aug 04 - 27, 2003 Test Sample is a: 900/1800/1900/ Bluetooth Mobile Handset Modulation Type: GSM+GPRS Operating Mode: Maximum continuous output Tx Frequency: 1850.2 ~ 1909.8 MHz Max. O/P Power: 30.15dBm (GSM) (Conducted) 30.12dBm (GPRS) Max. SAR (1g): 0.603mW/g (Right Head -Touched mode) 0.639mW/g (GPRS mode) Application Type: Certification FCC Rule part(s): § 24 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1999 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement…

Text truncated - open the document above for the full version.
