QF7INTERRAGATORINTERRAGATOR

Vermeer ® Interragator® II Ground Penetrating Radar (GPR) System ACS Interragator_II_o2_01Serial No. 178 - Order No. 105400T23Cabled No. 105400T24 Operator’s Manual This device complies with part 15 of the FCC Rules: Operation is subject to the following conditions: 1. This device many not cause harmful interference, and 2. This device must accept any interference received, Including interference that may cause undesired operation Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Operation of this device is restricted to law enforcement, fire and rescue officials, scientific research institutes, commercial mining companies, and construction companies. Operation by any other party is a violation of 47 U.S.C. § 301 and could subject the operator to serious legal penalties. Coordination Requirements. (a) UWB imaging systems require coordination through the FCC before the equipment may be used. The operator shall comply with any constraints on equipment usage resulting from this coordination. (b) The users of UWB imaging devices shall supply detailed operational areas to the FCC Office of Engineering and Technology who shall coordinate this information with the Federal Government through the National Telecommunications and Information Administration. The information provided by the UWB operator shall include the name, address and other pertinent contact information of the user, the desired geographical area of operation, and the FCC ID number and other nomenclature of the UWB device. This material shall be submitted to the following address: Frequency Coordination Branch., OET Federal Communications Commission 445 12 th Street, SW Washington, D.C. 20554 ATTN: UWB Coordination (d) Users of authorized, coordinated UWB systems may transfer them to other qualified users and to different locations upon coordination of change of ownership or location to the FCC and coordination with existing authorized operations. (e) The NTIA/FCC coordination report shall include any needed constraints that apply to day-to-day operations. Such constraints could specify prohibited areas of operations or areas located near authorized radio stations for which additional coordination is required before operation of the UWB equipment. If additional local coordination is required, a local coordination contact will be provided. (f) The coordination of routine UWB operations shall not take longer than 15 business days from the receipt of the coordination request by NTIA. Special temporary operations may be handled with an expedited turn-around time when circumstances warrant. The operation of UWB systems in emergency situations involving the safety of life or property may occur without coordination provided a notification procedure, similar to that contained in CFR47 Section 2.405(a)-(e), is followed by the UWB equipment user. -2 Interragator II GPR System I NTRODUCTION This manual contains operation instructions for the Interragator II Ground Penetrating Radar System. The instructions, illustrations, and specifications in this manual are based on the latest information available at time of publication. Your sys tem may have product improvements and options not yet contained in this manual. To provide a better view, certain photographs or illustrations in this manual may show the GPR system partially assembled. Never operate the system in this condition. Keep all shields in place.Do not attempt any maintenance on the GPR system. If you encounter a problem that you do not understand or cannot solve, contact your Vermeer dealer.A copy of this manual is supplied with each system. Keep this manual with the GPR system and available for reference at all times. Additional copies are available through your dealer. When ordering additional manuals, use the order number listed on th e front cover and the quantity needed. Vermeer Manufacturing Company reserves the right to make changes at any time without notice or obligation VERMEER®, VERMEER® Logo, INTERRAGATOR®, and ATLAS BORE PLANNER® are trademarks of Vermeer Manufacturing Company. PANASONIC TOUGHBOOK is a trademark of Matsushita Electric Industrial Co. Ltd. MICROSOFT is a trademark of Microsoft Corp. SMART TWO + is a trademark of Cadex Electronics Inc. SEIKO is a trademark of Seiko Instruments, Inc. RADAN NT is a trademark of Geophysical Survey Systems, Inc. LAPLINK is a trademark of Traveling Software, Inc. This Used Equipment Registration form must be completely filled out and returned to Vermeer Manufacturing Company. This will enable Vermeer to send you safety/product information if necessary. Type or legibly print in English. Send to Vermeer Mfg Co, Attn: Customer Data Center, PO Box 200, Pella, IA 50219, USA. If the card has been removed, call 641-628-3141 or 800-829-0051. Be prepared to supply the model & serial number of your machine. Mod el SN Vermeer Manufacturing Company Used Industrial Equipment Registration Form Customer Type Information: (Which of the following best describes you as a customer?)New Owner Information: (Please Print and Complete All Fields)Former Owner Information: Attachment Information ❏ Check to request OPERATOR’S MANUAL 18 Model: 19 Serial No.: 1a. Customer Type (check one):(also check 1b/1c for lined types*)❏ A. City/County/State ‹ ‹ ‹ ❏ B. Federal/Military ❏ C. Rental Center ❏ D. Golf Course ❏ E. Contractor ‹ ‹ ‹ ‹ ‹ ❏ F. Utility Company ‹ ‹ ‹ ‹ ❏ G. Nursery or T…

Text truncated - open the document above for the full version.

Vermeer ® Interragator® II Ground Penetrating Radar (GPR) System ACS Interragator_II_o2_01Serial No. 178 - Order No. 105400T23Cabled No. 105400T24 Operator’s Manual FCC NOTICES: This device complies with part 15 of the FCC Rules: Operation is subject to the following conditions: 1. This device many not cause harmful interference, and 2. This device must accept any interference received, Including interference that may cause undesired operation Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Operation of this device is restricted to law enforcement, fire and rescue officials, scientific research institutes, commercial mining companies, and construction companies. Operation by any other party is a violation of 47 U.S.C. § 301 and could subject the operator to serious legal penalties. Coordination Requirements. (a) UWB imaging systems require coordination through the FCC before the equipment may be used. The operator shall comply with any constraints on equipment usage resulting from this coordination. (b) The users of UWB imaging devices shall supply detailed operational areas to the FCC Office of Engineering and Technology who shall coordinate this information with the Federal Government through the National Telecommunications and Information Administration. The information provided by the UWB operator shall include the name, address and other pertinent contact information of the user, the desired geographical area of operation, and the FCC ID number and other nomenclature of the UWB device. This material shall be submitted to the following address: Frequency Coordination Branch., OET Federal Communications Commission 445 12 th Street, SW Washington, D.C. 20554 ATTN: UWB Coordination (d) Users of authorized, coordinated UWB systems may transfer them to other qualified users and to different locations upon coordination of change of ownership or location to the FCC and coordination with existing authorized operations. (e) The NTIA/FCC coordination report shall include any needed constraints that apply to day-to-day operations. Such constraints could specify prohibited areas of operations or areas located near authorized radio stations for which additional coordination is required before operation of the UWB equipment. If additional local coordination is required, a local coordination contact will be provided. (f) The coordination of routine UWB operations shall not take longer than 15 business days from the receipt of the coordination request by NTIA. Special temporary operations may be handled with an expedited turn-around time when circumstances warrant. The operation of UWB systems in emergency situations involving the safety of life or property may occur without coordination provided a notification procedure, similar to that contained in CFR47 Section 2.405(a)-(e), is followed by the UWB equipment user. NOTICE: Use of this device as a wall imaging system is prohibited by FCC regulations.

_____________________________________________________________________________________________________________ Geophysical Survey Systems, Inc. _____________________________________________________________________________________________________________ 13 Klein Drive - P.O. Box 97, North Salem, NH 03073-0097, U.S.A. / Telephone (603) 893-1109 Fax (603) 889-3984 website www.geophysical.com e-mail [email protected] July 2, 2002 Attention: Application Examiner Reviewing Engineer Re: Attestation Statement Applicant: Geophysical Survey Systems, Inc. FRN: 0007-2729-25 FCC ID: QF7-INTERRAGATOR To whom it may concern, The internal photographs submitted with this application are the same as was EMI tested. Sincerely, Dennis J. Johnson President, Geophysical Survey Systems, Inc.

_____________________________________________________________________________________________________________ Geophysical Survey Systems, Inc. _____________________________________________________________________________________________________________ 13 Klein Drive - P.O. Box 97, North Salem, NH 03073-0097, U.S.A. / Telephone (603) 893-1109 Fax (603) 889-3984 website www.geophysical.com e-mail [email protected] July 2, 2002 Attention: Application Examiner Reviewing Engineer Re: Request for confidentiality Applicant: Geophysical Survey Systems, Inc. FRN: 0007-2729-25 FCC ID: QF7-5100, QF7-5106 and QF7-INTERRAGATOR To whom it may concern, Request is hereby submitted by Geophysical Survey Systems, Inc., to withhold from public review certain portions of the application for equipment certification for the referenced FCC identifiers. In particular, the following sections of the application are requested to be kept confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description Rationale for request for confidentiality: Geophysical Survey Systems, Inc. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. The fee for confidentiality has been submitted along with the fee for certification. If you have questions or need further information, please contact the undersigned. Sincerely, Dennis J. Johnson President, Geophysical Survey Systems, Inc.

Letter of Agency I appoint Intertek Testing Services NA Inc. to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under the FCC rules until further notice. I further certify that no party (as defined in 1.2002 of CFR 47, 1995) to this application, including myself, is subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,853A. Equipment: __QF7-5100, QF7-5106 AND QF7-INTERRAGATOR ________________________________________________________________________ ________________________________________________________________________ Dated this __1st_day of_July, 2002___. _____________________________________ Signature Dennis J. Johnson______________________ Name President______________________________ Title Geophysical Survey Systems, Inc._________ Company 603-893-1109_________________________ Telephone

September 11, 2002 Page 1 of 3 Re: FCC ID QF7INTERRAGATOR Applicant: Geophysical Survey Systems, Inc. Correspondence Reference Number: 23858 731 Confirmation Number: EA363608 1) Please characterize the pulse. What is the pulse width? What is the frequency of the pulse? Or is the frequency of the pulse pseudorandom? A photo of the pulse is given below. The pulse width is approximately 3 ns. The PRF is a fixed 100 KHz. There is no randomizing. This picture has the antenna 1 meter above a reflective plate. The first pulse is the direct coupling between transmitter and receiver, and the second pulse is that reflected from the plate. The horizontal scale is in nanoseconds. September 11, 2002 Page 2 of 3 3) Upload a plot and table of data to show the -10 dB points. The plot should consist of max hold PEAK detector field strength level measured in any direction versus frequency. The field strength measurement for these points must account for non-linearities across the band that would be on the spectrum plot (ie: antenna and amplifier is not equal across the band). Ensure that the frequency range tested is wide enough to include the widest points of the electronic signature that are 10 dB down from the highest peak level. Do not use Horn antennas since Horn antennas are mounted 1 meter above the ground are directed above the EUT. All of our data has already been corrected for antenna, amplifier, cables, etc. The resulting spectrum is attached. As seen from the plot and table below, the peak is at 70.31 MHz, and the –10dB point is at 889.5 MHz. All of this data was taken with the log-periodic antenna. September 11, 2002 Page 3 of 3 QP<=1GHz f (MHz) EIRP 30.050 -67.863 35.500 -67.315 39.800 -66.681 44.660 -66.884 50.100 -62.914 57.200 -64.064 63.100 -63.255 70.310 -61.409 79.400 -63.282 89.420 -64.899 99.970 -61.603 112.000 -67.828 126.000 -62.644 141.000 -65.917 160.000 -64.195 178.000 -67.963 200.000 -64.658 224.000 -62.515 251.000 -63.522 282.000 -71.019 316.000 -71.708 355.000 -65.062 398.000 -67.085 447.000 -70.401 495.400 -64.950 562.300 -73.664 631.000 -69.830 708.000 -74.249 794.000 -73.676 889.500 -70.494 959.800 -72.927 5) Provide photo’s of the Sample board without the shielding. While photographing the sample board without the shield, it was discovered that one of the original photographs was mis-labeled. The complete set of all photographs is attached as INTERRAGATOR INTERNAL PHOTOS REV B.pdf. 7) Indicate compliance with 15.503(f). Attached are the first two pages of the user’s manual indicating compliance with 15.503(f).

To: Joe Dichoso FCC Application Processing Branch Re: FCC ID QF7INTERRAGATOR Applicant: Geophysical Survey Systems, Inc. Correspondence Reference Number: 23929 731 Confirmation Number: EA363608 1) The pulse has no carrier frequency. The pulse repetition frequency is fixed at 100kHz. A plot and description of the pulse width and repetition is provided by GSSI contained in new Cover Letter exhibit - file name “QF7Interragator questions 2.pdf” 2) Additional measurements were made in the frequency range of 960-1000MHz using a log periodic antenna. A revised test report has been uploaded with file name Interragator_Report_RevD.pdf (p14) 3) GSSI has verified the product frequency range as 30 – 889.5MHz in the new Cover Letter exhibit - file name “QF7Interragator questions 2.pdf” 4) The Interragator is designed to work only in contact with the ground, has a ‘dead-man’ switch and is shielded to direct the energy into the ground. A full description and photographs are contained in the new Cover Letter exhibit - file name “QF7Interragator questions 2.pdf” 5) A photograph of the label location is contained in the new Cover Letter exhibit - file name “QF7Interragator questions 2.pdf”

To: Alan Schutz, Geophysical Survey Systems Inc From: Joe Dichoso [email protected] FCC Application Processing Branch Re: FCC ID QF7INTERRAGATOR Applicant: Geophysical Survey Systems, Inc. Correspondence Reference Number: 23929 731 Confirmation Number: EA363608 1) What is the carrier frequency of the pulse? There is no carrier. It is a single cycle, whose center frequency is approximately 300 MHz. A photo of the pulse is given below. The pulse width is approximately 3 ns. The PRF is a fixed 100 KHz. There is no randomizing. This picture has the antenna 1 meter above a reflective plate. The first pulse is the direct coupling between transmitter and receiver, and the second pulse is that reflected from the plate. The horizontal scale is in nanoseconds. 2) Measurement from 960 -1 GHz with a log periodic antenna was requested due to the margin of compliance at 960 MHz which was 1 dB from the limit. When testing with a horn antenna, the horn antenna is focused 1 meter above your device and therefore it may not capture ground reflection as well as a log periodic antenna. Provide data at 960 MHz additional testing may be required depending on results or margin of compliance. 3) The requested frequency range will be changed to 30-889.5 MHz. Please verify. Yes, we agree. 4) With regard to compliance with 15.503(f), the device must be designed to operate when in contact with the ground and have shielding to direct emissions toward the ground. In addition, imaging systems must have a manual switch which causes the transmitter to cease within 10 seconds. Please address these 3 issues. The Interragator is a cart-like device that is rather heavy. It can only be used on the ground. The antenna is constructed as a five-sided metal box, with the antenna fans in the sixth side, on the ground side. The non-transmitting electronics is placed on the top of the shield. Another shield is placed over the electronics. There is a deadman switch on the handle. When the user steps away from the cart, the transmitter will cease operating after 10 seconds. A drawing of the deadman switch is given on the next page. 5) For compliance with 15.509(g), the label information must be on the device. Show where this label will be placed on the device.

INTERRAGATOR EXTERNAL PHOTOS Page 1 of 3 FRONT VIEW BACK VIEW INTERRAGATOR EXTERNAL PHOTOS Page 2 of 3 FRONT DETAIL SIDE VIEW INTERRAGATOR EXTERNAL PHOTOS Page 3 of 3 FCC LABEL TO BE LOCATED ON THE TOP OF THE ANTENNA NEAR THE CONNECTIONS. LABEL TO READ: This device complies with part 15 of the FCC Rules: Operation is subject to the following conditions: a. This device many not cause harmful interference, and b. This device must accept any interference received, Including interference that may cause undesired operation Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Operation of this device is restricted to law enforcement, fire and rescue officials, scientific research institutes, commercial mining companies, and construction companies. Operation by any other party is a violation of 47 U.S.C. § 301 and could subject the operator to serious legal penalties.

INTERRAGATOR FCC LABEL LOCATION LABEL TO READ: LABEL MATERIAL: THESE LABELS ARE PERMANENT FOR THE LIFE OF THE PRODUCT. THEY ARE REVERSE SCREEN-PRINTED ON 8 MIL POLYESTER FILM WITH PERMANENT ADHESIVE. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING 2 CONDITIONS: 1. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. 2. THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. MADE IN USA FCC ID. QF7INTERRAGATOR 1.25 " 3.5" FCC LABEL

INTERRAGATOR 2 FCC DOCUMENTATION Page 1 of 7 BOARDS SHOWN CLOCKWISE FROM UPPER LEFT: 1. POWER SUPPLY BOARD 2. DIFFERENTIAL SAMPLER (SHIELDED) 3. MULTI PLEXER 4. RADAR 5. ACCESSORY BOARD 6. FAN BOARDS (NOT SHOWN) LOCATED ON BACKSIDE SEE PAGE 7 FOR VIEW WITH SHIELD INSTALLED ON BOARDS. INTERRAGATOR 2 FCC DOCUMENTATION Page 2 of 7 1. POWER SUPPLY BOARD TOP BACK INTERRAGATOR 2 FCC DOCUMENTATION Page 3 of 7 2. DIFFERENTIAL SAMPLER TOP BOTTOM INTERRAGATOR 2 FCC DOCUMENTATION Page 4 of 7 3. MULTIPLEXER TOP (INSTALLED) BACK INTERRAGATOR 2 FCC DOCUMENTATION Page 5 of 7 4. RADAR TOP BACK INTERRAGATOR 2 FCC DOCUMENTATION Page 6 of 7 5. ACCESSORY BOARD TOP BACK INTERRAGATOR 2 FCC DOCUMENTATION Page 7 of 7 7. FAN BOARDS (2 PER UNIT) VIEW OF BOARDS WITH SHIELDS ATTACHED

INTERRAGATOR INTERNAL PHOTOS REV B Page 1 of 9 This is a revised document!!!! Wrong board was shown for #2 Differential Sample on page 3, which is now corrected. Board that was shown as Differential Sampler is actually #7 Impulse Generator, now shown on page 8. All changes are shown in RED. BOARDS SHOWN CLOCKWISE FROM UPPER LEFT: 1. POWER SUPPLY BOARD 2. DIFFERENTIAL SAMPLER (SHIELDED) 3. MULTI PLEXER 4. RADAR 5. ACCESSORY BOARD 6. FAN BOARDS (NOT SHOWN) LOCATED ON BACKSIDE 7. IMPULSE GENERATOR BOARD (NOT SHOWN) ATTACHES TO FAN BOARDS SEE PAGE 9 FOR VIEW WITH SHIELD INSTALLED ON BOARDS. INTERRAGATOR INTERNAL PHOTOS REV B Page 2 of 9 1. POWER SUPPLY BOARD TOP BACK INTERRAGATOR INTERNAL PHOTOS REV B Page 3 of 9 2. DIFFERENTIAL SAMPLER TOP BOTTOM INTERRAGATOR INTERNAL PHOTOS REV B Page 4 of 9 3. MULTIPLEXER TOP (INSTALLED) BACK INTERRAGATOR INTERNAL PHOTOS REV B Page 5 of 9 4. RADAR TOP BACK INTERRAGATOR INTERNAL PHOTOS REV B Page 6 of 9 5. ACCESSORY BOARD TOP BACK INTERRAGATOR INTERNAL PHOTOS REV B Page 7 of 9 6. FAN BOARDS (2 PER UNIT) IMPULSE GENERATOR BOARD SHOWN SOLDERED TO BACKSIDE OF FANS. INTERRAGATOR INTERNAL PHOTOS REV B Page 8 of 9 7. IMPULSE GENERATOR BOARD (2 PER UNIT) TOP WITHOUT SHIELDING CAN BACKSIDE INTERRAGATOR INTERNAL PHOTOS REV B Page 9 of 9 VIEW OF BOARDS WITH SHIELDS ATTACHED SIDE VIEW FAN PC BOARDS ARE LOCATED ON THE BOTTOM OF THE UNIT. IMPULSE GENERATOR BOARDS ARE ATTACHED TO FANS, ENCLOSED, INSERTED INTO SHIELDING FOAM (VISIBLE ALONG BOTTOM EDGE) AND CONNECTED TO BOARDS ON TOP.

2622.2 2820.7 3019.3 4013.4 509.4 607.3 707 807.8 908.8 1009.3 1108.7 1208 1307.8 1408.3 1509 1609.4 1709.4 18010 19010.4 20010.3 22511.4 25012.6 27512.9 30014.3 32515.1 35015.6 37516 40016.7 42516.6 45017.1 47517.8 50017.8 52518.8 55019 57519.3 60020 62521.3 65021 67521.9 70022.4 72522.4 75022.8 77523.1 80022.7 82522.8 85023 87523.8 90024 92523.9 95024.3 97524.4 100024.8 105025.1 110025.3 115026.2 120026.6 125026.1 130026.5 135028.1 140027.8 145027.5 150028.2 155029.6 160029.4 165029.9 170030.6 175031.7 180031.1 185031.1 190031.6 195031.2 200032.1

MM FCC Subpart 15FPage 1 of 27 Project Number: 3025094Report number Interragator_report_12_18.doc TEST REPORT Report Number: Interragator_report_12_18.doc Project Number: 3025094 Date: 12/18/02 Date(s) of Test: November 19-22, December 5-6, 2002 Evaluation of the Model number: Interragator To CFR 47 Part 15 Subpart F For Geophysical Survey Systems Test Performed by: Intertek Testing Services Test Authorized by: Geophysical Survey Systems 70 Codman Hill Rd. Boxborough, MA 01719 13 Klein Rd PO Box Salem, NH 03079 Prepared by: _______________________________Date: _______________________________ Robert F. Martin Reviewed by: _______________________________Date: _______________________________ Robert F. Martin Sr. Technical Manager All services undertaken are subject to the following general policy: Reports are submitted for exclusive use of the client to whom they are addressed. Their significance is subject to the adequacy and representative character of the samples and to the comprehensiveness of the tests, examinations or surveys made. No quotations from reports or use of Intertek Testing Services NA Inc. name is permitted except as expressly authorized by Intertek Testing Services NA Inc. in writing. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. AA FCC Subpart 15FPage 2 of 27 Project Number: 3025094Report number Interragator_report_12_18.doc EXECUTIVE SUMMARY............................................................................................................................................................................................4 1.INTRODUCTION..................................................................................................................................................................................................5 1.1.CLIENT INFORMATION...........................................................................................................................................5 1.2.TEST PLAN REFERENCE.........................................................................................................................................5 1.3.EQUIPMENT UNDER TEST (EUT)..........................................................................................................................5 1.3.1System Support Equipment.........................................................................................................................5 1.3.2System Block Diagram................................................................................................................................5 1.3.3Justification...................................................................................................................................................5 1.3.4Mode(s) of Operation...................................................................................................................................6 1.4.MODIFICATIONS REQUIRED FOR COMPLIANCE.....................................................................................................6 2.TEST ENVIRONMENT......................................................................................................................................................................................7 2.1.TEST FACILITY.......................................................................................................................................................7 2.2.TEST EQUIPMENT...................................................................................................................................................7 2.3.SAMPLE CALCULATIONS.......................................................................................................................................7 2.3.1Field Strength Calculation...........................................................................................................................7 2.3.2EIRP Calculation..........................................................................................................................................8 2.3.3RMS calculation...........................................................................................................................................8 2.4.MEASUREMENT UNCERTAINTY............................................................................................................................9 3.ULTRA WIDEBAND OPERATION...........................................................................................................................................................10 3.1.OPERATIONAL LIMITATIONS (SECTION 15.521)................................................................................................10 3.2.UWB BANDWIDTH (SECTION 15.503(A))..........................................................................................................10 3.2.1Requirement (low-frequency imaging systems).......................................................................................10 3.2.2Test Procedure............................................................................................................................................10 3.2.3Test Results.................................................................................................................................................10 3.3.CENTER FREQUENCY (SECTION 15.503(B)).......................................................................................................10 3.3.1Requirement................................................................................................................................................10 3.3.2Test Procedure............................................................................................................................................10 3.3.3Test Results.........................................................................................................................................…

Text truncated - open the document above for the full version.

Interragator Test Setup <1000MHz Interragator Test Setup 960 – 1000MHz RMS [picture not available – filed damaged] Interragator Test Setup >1000MHz
