QGGIPA243B16 user 3G Access Point operating in Bands 2 & 5

nano3G AP Installation Manual N3G_INST_300292_1.0 ip.access Ltd Building 2020 Cambourne Business Park Cambourne Cambridgeshire CB23 6DW United Kingdom www.ipaccess.com Notices This document is provided to you by or on behalf of ip.access Ltd ("ip.access"). © ip.access Limited 2012. The documentation and any software described herein and/or provided to you in conjunction with this documentation contain proprietary and confidential information of ip.access and may only be used subject to a license agreement containing restrictions on use and disclosure. They are also protected by copyright, patent rights and other intellectual and industrial property laws. The information contained in this document and any software described herein is subject to change without notice. If you find any problems in the documentation and/or the software please report them to us in writing. The document and/or the software are not warranted to be error-free. No right, title, license or interest in any physically or electronically distributed materials is transferred to you by such distribution. No part of this document and/or the software may be reproduced, displayed, copied, translated, adapted, downloaded, electronically transmitted, used or reproduced in any form including (without limitation) distribution or storage in a system for retrieval without our express written permission (which may be subject to conditions). The documentation and/or software may provide links to Web sites and access to content, products, and services from third parties. ip.access is not responsible for the availability of, or any content provided on, third-party Web sites. You bear all risks associated with the use of such content. If you choose to purchase any products or services from a third party, the relationship is directly between you and the third party. ip.access is not responsible for: (a) the quality of third-party products or services; or (b) fulfilling any of the terms of the agreement with the third party, including delivery of products or services and warranty obligations related to purchased products or services. ip.access is not responsible for any loss or damage of any sort that you may incur from dealing with any third party. ip.access is the owner of the "ip.access" trademark and all associated trade names, logos and devices unless indicated to the contrary. Any other trademarks, logos and names appearing on in this document may be the property of their respective owners. ip.access Limited is a Private Limited Company Registered in England and Wales Company No. 03400157 Registered Office: Building 2020 Cambourne Business Park Cambourne CB23 6DW UK Tel: +44 (0) 1954 713 700 Fax: +44 (0) 1954 713 799 Further company information may be found at www.ipaccess.com. Revision History Version Change SummaryDateAuthor 292_0.1 Draft for N3G_2.92 and S16 information22 Aug 2012CFB 292_0.2 Updated with S16 information14 Sep 2012CFB 292_1.0 Released for N3G_2.9218 Sep 2012CFB nano3G AP Installation Manual N3G_INST_300 v292_1.0 for N3G_2.92 © ip.access Limited 2012Page i Table of Contents 1Introduction............................................................................................ 1 1.1Overview ............................................................................................................ 1 1.2User Requirements ............................................................................................ 1 1.3Related Information............................................................................................ 2 1.4Licenses and Copyright Notices ........................................................................ 2 1.5Terminology ....................................................................................................... 2 2Installation Overview and Requirements............................................ 3 2.1Installation Tasks ............................................................................................... 3 2.1.1Pre-Provisioning ................................................................................................... 3 2.1.2Commissioning..................................................................................................... 3 2.1.3On Site Installation ............................................................................................... 4 2.2Requirements for All nano3G APs ..................................................................... 5 2.2.1General Requirements ......................................................................................... 5 2.2.2nano3G AP Cooling.............................................................................................. 7 2.2.3Information Required for Pre-Provisioning ........................................................... 7 2.2.4Parameters for Enterprise Deployments .............................................................. 8 2.2.5Parameters for Residential Deployments........................................................... 10 2.2.6Access Control ................................................................................................... 13 2.2.7Closed Access with CSG Parameter Broadcast ................................................ 15 2.2.8Closed Access in Legacy Mode ......................................................................... 16 2.2.9Pre-Prepared Configurations - Optional ............................................................. 17 2.2.10Information Required for Commissioning........................................................... 18 2.2.11Other Items for Commissioning.......................................................................... 19 2.3nano3G S8 AP Site Requirements .................................................................. 20 2.3.1nano3G S8 AP Power Requirements................................................................. 20 2.3.2nano3G S8 AP Physical Requirements...............................................…

Text truncated - open the document above for the full version.

ip.access ltd Tel +44 (0)1954 713700 Building 2020 Fax +44 (0)1954 713799 Cambourne Business Park www.ipaccess.com Cambourne Cambridge CB23 6DW United Kingdom Registered office: ip.access Building 2020, Cambourne Business Park, Cambridge, CB23 6DW Registered number 3400157 27 June 2012 TÜV SÜD BABT Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, ip.access Ltd hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation PCB Layouts The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Costa Panayi Product Design and Development Engineer Telephone Number: +44 (0)1954 713721 Email: [email protected]

IP.ACCESS LTD 243 S16 Access Point Top View Front View (with Stand) Rear View (with Stand) Side View (no Stand) Rear Sockets (no Stand)

IP Access 243 S16 LABEL POSITIONS Product Label Barcode Label FCC Label REAR VIEW OF CASEWORKS

20.0 40.0 25.0 8.0 R1 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. SEE NOTE 3 FCC ID: XXXXXXXXXX LAN 9VDC NOTES BACKING ADHESIVE TO BE 3M 467 OR SIMILAR1. ALL TEXT TO BE FONT 'ARIAL'2. ENTER FCC ID AS SHOWN BELOW:3. MODELFCC ID 237BQGGIPA237B 237BAQGGIPA237BA 237CQGGIPA237C 237CAQGGIPA237CA 243BQGGIPA243B 243BAQGGIPA243BA CP XA Size: All dimensions in mm Tolerances unless otherwise stated 2 DEC PLACES 0.10mm 1 DEC PLACE 0.20mm 0 DEC PLACE 0.50mm Angular 0.5 DO NOT SCALE www.ipaccess.com C This drawing is the property of ip.access ltd and must not be copied or disclosed without prior written consent A4 SCALE 2:1 Finish: N/A Material: SHEET 1 OF 1 243_044 nano3G-S8 Drawing Number: Drawn by: CP (25-09-2012) Weight: N/A Title: Third Angle CONFIDENTIAL Project: ISSUE DATECHANGE INTL 1 ABCDEFGHIJ 2 3 4 5 6 7 ABCDEFGH IJ 25-09-2012ECN XXXX FCC LABEL 7 6 5 4 3 2 1 MATT OR GLOSS WHITE POLYESTER INFO-MARK 336T-E1

IP.ACCESS LTD 243B PCB Top View Bottom View

Document 75918692 Report 07 Issue 1 September 2012 Report On RF Exposure Assessment of the ip.access Ltd 243B and 243BA nano3G S16 Access Point (Bands 2 & 5) FCC ID:QGGIPA243B TÜV SÜD Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk Document 75918692 Report 07 Issue 1 Page 1 of 13 REPORT ON RF Exposure Assessment of the ip.access Ltd 243B and 243BA nano3G S16 Access Point (Bands 2 & 5) Document 75918692 Report 07 Issue 1 September 2012 PREPARED FOR ip.access Ltd Building 2020 Cambourne Business Park Cambourne CB23 6DW PREPARED BY M Whiting Project Manager APPROVED BY M Jenkins Authorised Signatory DATED 25 September 2012 Document 75918692 Report 07 Issue 1 Page 2 of 13 CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Product Information ...................................................................................................................... 7 1.4 Summary ...................................................................................................................................... 7 2 TEST DETAILS ............................................................................................................................ 8 2.1 Rationale for Assessment of the RF Exposure ............................................................................ 9 2.2 Defined Limits ............................................................................................................................. 10 2.3 Establishing Wavelength and 1/4 Wavelength ........................................................................... 10 2.4 Far Field Calculations ................................................................................................................. 11 3 DISCLAIMERS AND COPYRIGHT ........................................................................................... 12 3.1 Disclaimers and Copyright .......................................................................................................... 13 Document 75918692 Report 07 Issue 1 Page 3 of 13 SECTION 1 REPORT SUMMARY RF Exposure Assessment of the ip.access Ltd 243B and 243BA nano3G S16 Access Point (Bands 2 & 5) Document 75918692 Report 07 Issue 1 Page 4 of 13 1.1 INTRODUCTION The information contained in this report is intended to show verification of the RF Exposure Assessment of the ip.access Ltd 243B and 243BA nano3G S16 Access Point (Bands 2 & 5) to the requirements of the applied test specifications. Objective To perform RF Exposure Assessment to determine the Equipment Under Test's (EUT’s) compliance of the applied rules. Applicant ip.access Ltd Manufacturer ip.access Ltd Manufacturing Description nano3G S16 Access Point (Bands 2 & 5) Model Number(s) 243B and 243BA Test Specification/Issue/Date EN 62311:2008 OET Bulletin 65 Edition 97-01 August 1997 RSS-102 Issue 4 March 2010 Radiocommunications (Electromagnetic Radiation – Human Exposure) Standard: 2003 Related Document(s) Council Recommendation 1999/519/EC:1999 FCC CFR 47 Part 1: 2011 FCC CFR 47 Part 2: 2011 Health Canada's Safety Code 6 ARPANSA ICNIRP 1998 National Council on Radiation Protection and Measurements (NRPC) - Report No. 86(1986) EN 50383:2002 IEEE Std C95.1-2005 Australian Standard 2772.2 – 1988 Document 75918692 Report 07 Issue 1 Page 5 of 13 1.2 BRIEF SUMMARY OF RESULTS 1.2.1 General Public Exposure Levels Antenna Gain (Numeric) Peak Output Power (mW) Field Calculated RF Exposure at 0.2 m (20cm) General Public Exposure Limit Application 1.000 100 S 0.20 W/m 2 9.662 W/m 2 ICNIRP S 0.020 mW/cm 2 1 mW/cm 2 FCC 47 CFR § 1.1310 S 0.20 W/m 2 10 W/m 2 Canada’s RF Safety Code 6 S 0.20 W/m 2 9.662 W/m 2 ARPANSA E 8.66 V/m 60.444 V/m ICNIRP E 8.66 V/m N/A V/m FCC 47 CFR § 1.1310 E 8.66 V/m 61.4 V/m Canada’s RF Safety Code 6 E 8.66 V/m 60.224 V/m ARPANSA H 0.02 A/m 0.163 A/m ICNIRP H 0.02 A/m N/A A/m FCC 47 CFR § 1.1310 H 0.02 A/m 0.163 A/m Canada’s RF Safety Code 6 H 0.02 A/m 0.160 A/m ARPANSA The calculations have shown that they meet the General Public Exposure Levels described in the ICNIRP Guidelines, FCC 47 CFR § 1.1310 Guidelines, Health Canada’s RF exposure guideline Safety Code 6 and the Australian ARPANSA limits at 20cm, the point of investigation. Document 75918692 Report 07 Issue 1 Page 6 of 13 1.2.2 Occupational Exposure Levels Antenna Gain (Numeric) Peak Output Power (mW) Field Calculated RF Exposure at 0.2 m (20cm) Occupational Exposure Limit Application 1.000 100 S 0.20 W/m 2 48.310 W/m 2 ICNIRP S 0.020 mW/cm 2 5 mW/cm 2 FCC 47 CFR § 1.1310 S 0.20 W/m 2 50 W/m 2 Canada’s RF Safety Code 6 S 0.20 W/m 2 48.310 W/m 2 ARPANSA E 8.66 V/m 131.877 V/m ICNIRP E 8.66 V/m N/A V/m FCC 47 CFR § 1.1310 E 8.66 V/m 137 V/m Canada’s RF Safety Code 6 E 8.66 V/m 134.954 V/m ARPANSA H 0.02 A/m 0.352 A/m ICNIRP H 0.02 A/m N/A A/m FCC 47 CFR § 1.1310 H 0.02 A/m 0.364 A/m Canada’s RF Safety Code 6 H 0.02 A/m 0.358 A/m ARPANSA The calculations have shown that they meet the Occupational Exposure Levels described in the ICNIRP Guidelines, FCC 47 CFR § 1.1310 Guidelines, Health Canada’s RF exposure guideline Safety Code 6 and the Australian ARPANSA limits at 20 cm, the point of investigation. Document 75918692 Report 07 Issue 1 Page 7 of 13 1.3 PRODUCT INFORMATION 1.3.1 Attestation The wireless device described within this report has been shown to be capable of compliance with the basic restrictions related to human exposure to electromagnetic fields (10 MHz - 300 MHz) - General public. The calculations shown in this report were made…

Text truncated - open the document above for the full version.

MPE / RF exposure information request: Product Description: nano3G S16 Access Point (Bands 2 & 5) Model number: 243B and 243BA Frequency Band 2: Antenna length (cm): N/A Centimetres (cm) Frequency range: Bottom frequency: 1932.4 MHz Middle frequency: 1960.0 MHz Top frequency: 1987.6 MHz Maximum power (input to the antenna): 0.1 W Antenna gain (or maximum gain allowed): 0 dBi Separation distance from antenna (if greater than 20cm) N/A cm (if greater than 20cm, distance will be calculated at 20cm) Duty Cycle: 100 % Frequency Band 5: Antenna length (cm): N/A Centimetres (cm) Frequency range: Bottom frequency: 871.4 MHz Middle frequency: 881.6 MHz Top frequency: 891.6 MHz Maximum power (input to the antenna): 0.1 W Antenna gain (or maximum gain allowed): 0 dBi Separation distance from antenna (if greater than 20cm) N/A cm (if greater than 20cm, distance will be calculated at 20cm) Duty Cycle: 100 %

Document 75918692 Report 02 Issue 1 September 2012 Report On FCC Testing of the ip.access Ltd 243B S16 3G AP (Bands 2 & 5) In accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 22 COMMERCIAL-IN-CONFIDENCE FCC ID: QGGIPA243B TÜV SÜD Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk COMMERCIAL-IN-CONFIDENCE Document 75918692 Report 02 Issue 1 Page 1 of 55 COMMERCIAL-IN-CONFIDENCE REPORT ON FCC Testing of the ip.access Ltd 243B S16 3G AP (Bands 2 & 5) In accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 22 Document 75918692 Report 02 Issue 1 September 2012 PREPARED FOR ip.access Ltd Building 2020 Cambourne Business Park Cambourne Cambridge CB23 6DW PREPARED BY Natalie Bennett Senior Administrator (Technical) APPROVED BY Mark Jenkins Authorised Signatory DATED 25 September 2012 ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47 Part 2 and FCC CFR 47 Part 22. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); M Russell G Lawler Document 75918692 Report 02 Issue 1 Page 2 of 55 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Application Form ........................................................................................................................... 6 1.4 Product Information ...................................................................................................................... 8 1.5 Test Conditions ............................................................................................................................. 8 1.6 Deviations from the Standard ....................................................................................................... 8 1.7 Modification Record ...................................................................................................................... 8 2 TEST DETAILS ............................................................................................................................ 9 2.1 Spurious Emissions at Band Edge ............................................................................................. 10 2.2 Effective Radiated Power ........................................................................................................... 13 2.3 Maximum Peak Output Power - Conducted ............................................................................... 20 2.4 Emission Limitations for Cellular Equipment .............................................................................. 22 2.5 Conducted Spurious Emissions .................................................................................................. 35 2.6 Occupied Bandwidth ................................................................................................................... 40 2.7 Modulation Characteristics ......................................................................................................... 44 2.8 Frequency Stability ..................................................................................................................... 45 3 TEST EQUIPMENT USED ......................................................................................................... 48 3.1 Test Equipment Used ................................................................................................................. 49 3.2 Measurement Uncertainty .......................................................................................................... 53 4 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 54 4.1 Accreditation, Disclaimers and Copyright ................................................................................... 55 Document 75918692 Report 02 Issue 1 Page 3 of 55 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY FCC Testing of the ip.access Ltd 243B S16 3G AP (Bands 2 & 5) In accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 22 Document 75918692 Report 02 Issue 1 Page 4 of 55 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.1 INTRODUCTION The information contained in this report is intended to show verification of the FCC Testing of the ip.access Ltd 243B S16 3G AP (Bands 2 & 5) to the requirements of FCC CFR 47 Part 2 and FCC CFR 47 Part 22. Objective To perform FCC Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer ip.access Ltd Model Number(s) 243B Serial Number(s) 000295-0000106246 Number of Samples Tested 1 Test Specification/Issue/Date FCC CFR 47 Part 2 (2011) FCC CFR 47 Part 22 (2011) Incoming Release Date Application Form 23 August 2012 Disposal Reference Number Date Held Pending Disposal Not Applicable Not Applicable Order Number Date PO30806 06 July 2012 Start of Test 22 August 2012 Finish of Test 29 August 2012 Name of Engineer(s) M Russell G Lawler Related Document(s) ANSI C63.4: 2009 Document 75918692 Report 02 Issue 1 Page 5 of 55 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.2 BRIEF SUMMARY OF RESULTS A brief summary of the tests carried out in accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 22 is shown below. Section Spec Clause Test Description Result Comments/Base Standard…

Text truncated - open the document above for the full version.

Document 75918692 Report 03 Issue 1 September 2012 Report On FCC Testing of the ip.access Ltd 243B S16 3G AP (Bands 2 & 5) In accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 24 COMMERCIAL-IN-CONFIDENCE FCC ID: QGGIPA243B TÜV SÜD Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk COMMERCIAL-IN-CONFIDENCE Document 75918692 Report 03 Issue 1 Page 1 of 58 COMMERCIAL-IN-CONFIDENCE REPORT ON FCC Testing of the ip.access Ltd 243B S16 3G AP (Bands 2 & 5) In accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 24 Document 75918692 Report 03 Issue 1 September 2012 PREPARED FOR ip.access Ltd Building 2020 Cambourne Business Park Cambourne Cambridge CB23 6DW PREPARED BY Natalie Bennett Senior Administrator (Technical) APPROVED BY Mark Jenkins Authorised Signatory DATED 25 September 2012 ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47 Part 2 and FCC CFR 47 Part 24. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); M Russell G Lawler Document 75918692 Report 03 Issue 1 Page 2 of 58 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Application Form ........................................................................................................................... 6 1.4 Product Information ...................................................................................................................... 8 1.5 Test Conditions ............................................................................................................................. 8 1.6 Deviations from the Standard ....................................................................................................... 8 1.7 Modification Record ...................................................................................................................... 8 2 TEST DETAILS ............................................................................................................................ 9 2.1 Frequency Stability ..................................................................................................................... 10 2.2 Spurious Emissions at Band Edge ............................................................................................. 12 2.3 Effective Isotropic Radiated Power ............................................................................................. 15 2.4 Maximum Peak Output Power - Conducted ............................................................................... 22 2.5 Modulation Characteristics ......................................................................................................... 24 2.6 Emission for Broadband PCS Equipment................................................................................... 25 2.7 Conducted Spurious Emissions .................................................................................................. 42 2.8 Occupied Bandwidth ................................................................................................................... 48 3 TEST EQUIPMENT USED ......................................................................................................... 52 3.1 Test Equipment Used ................................................................................................................. 53 3.2 Measurement Uncertainty .......................................................................................................... 56 4 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 57 4.1 Accreditation, Disclaimers and Copyright ................................................................................... 58 Document 75918692 Report 03 Issue 1 Page 3 of 58 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY FCC Testing of the ip.access Ltd 243B S16 3G AP (Bands 2 & 5) In accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 24 Document 75918692 Report 03 Issue 1 Page 4 of 58 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.1 INTRODUCTION The information contained in this report is intended to show verification of the FCC Testing of the ip.access Ltd 243B S16 3G AP (Bands 2 & 5) to the requirements of FCC CFR 47 Part 2 and FCC CFR 47 Part 24. Objective To perform FCC Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer ip.access Ltd Model Number(s) 243B Serial Number(s) 000295-0000106246 Number of Samples Tested 1 Test Specification/Issue/Date FCC CFR 47 Part 2 (2011) FCC CFR 47 Part 24 (2011) Incoming Release Date Application Form 23 August 2012 Disposal Reference Number Date Held Pending Disposal Not Applicable Not Applicable Order Number Date PO30806 06 July 2012 Start of Test 22 August 2012 Finish of Test 29 August 2012 Name of Engineer(s) M Russell G Lawler Related Document(s) ANSI C63.4: 2003 Document 75918692 Report 03 Issue 1 Page 5 of 58 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.2 BRIEF SUMMARY OF RESULTS A brief summary of the tests carried out in accordance with FCC CFR 47 Part 2 and FCC CFR 47 Part 24 is shown below. Section Spec Clause Test Description Result Comments/Base Standard Pt 2 P…

Text truncated - open the document above for the full version.

FCC ID: QGGIPA243B ip.access Ltd 243BA S16 3G AP (Bands 2 & 5) 2012 Not to be reproduced, except in its entirety, Page 1 of 4 without the Permission of TÜV SÜD Product Service Ltd Reference: 75918692 PHOTOGRAPHS OF TEST SET UP Radiated Emissions 30MHz-1GHz FCC ID: QGGIPA243B ip.access Ltd 243BA S16 3G AP (Bands 2 & 5) 2012 Not to be reproduced, except in its entirety, Page 2 of 4 without the Permission of TUV Product Service Ltd Reference: 75918692 Radiated Emissions 1GHz-18GHz FCC ID: QGGIPA243B ip.access Ltd 243BA S16 3G AP (Bands 2 & 5) 2012 Not to be reproduced, except in its entirety, Page 3 of 4 without the Permission of TUV Product Service Ltd Reference: 75918692 Radiated Emissions 18GHz-20GHz FCC ID: QGGIPA243B ip.access Ltd 243BA S16 3G AP (Bands 2 & 5) 2012 Not to be reproduced, except in its entirety, Page 4 of 4 without the Permission of TUV Product Service Ltd Reference: 75918692 Conducted Emissions
