QI3BIL-AWDL0604G LTE Embedded Mini-Card Module

Billion Electric Co., Ltd.
4G LTE Embedded Mini-Card Module - FCC ID QI3BIL-AWDL060 - Billion Electric Co., Ltd.
Click to zoom

Application Details

Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant
Sep 07, 2013
Application Purpose
Original Equipment
Date of Application
Sep 07, 2013
Equipment Note
4G LTE Embedded Mini-Card Module
Frequency Range
704.00000000 - 711.00000000
Company
Billion Electric Co., Ltd.
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

8F., No.192, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.). TEL: + 886-2-2914-5665 FAX: + 886-2-2918-6731, +886-2-2918-2895 www.billion.com - 1 - WW-DL060 4G LTE Embedded Mini-Card Module Standard Version 0.4 Document release Date Modification Initials Approved Version 0.1 2013/06/10Initial version James Li Daniel Lee Verison 0.2 2013/07/09Spec update Daniel Daniel Verison 0.3 2013/07/09Add packing SOP Irene Lin Irene Lin Version 0.4 2013/07/29Update packing SOP Fiona Liang Fiona Liang 8F., No.192, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.). TEL: + 886-2-2914-5665 FAX: + 886-2-2918-6731, +886-2-2918-2895 www.billion.com - 2 - 1. General Description 1-1. Product Overview and Functional Description Billion Electric Co., Ltd. introduces the embedded mini-card for 4G LTE data communication – WW-DL060. The demands of data communication everywhere becomes more due to the great development of 4G LTE system. WW-DL060 adopts GCT GDM7240 solution. It provides up to 50 Mbps Downlink, up to 25 Mbps Uplink and RX antenna diversity etc. WW-DL060 is fast, reliable and easy to operate. Therefore, by WW-DL060 mobile user can experience the new features and surf the internet everywhere. FCC Caution <15.21 > ‧Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. ‧This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. FCC Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 8F., No.192, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.). TEL: + 886-2-2914-5665 FAX: + 886-2-2918-6731, +886-2-2918-2895 www.billion.com - 3 - RF exposure statements: Information to OEM integrator The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user manual of the end product. The user manual which is provided by OEM integrators for end users must include the following information in a prominent location. 1. To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co located or operating in conjunction with any other antenna or transmitter, except in accordance with ­ FCC multi transmitter product procedures.­ 2. Only those antennas with same type and lesser gain filed under this FCC ID number can be used with this device. 3. The regulatory label on the final system must include the statement: “Contains FCC ID: xxxx or using electronic labeling method as documented in KDB 784748. 4. The final system integrator must ensure there is no instruction provided in the user manual or customer documentation indicating how to install or remove the transmitter module except such device has implemented two ways authentication between module and the host system.­ This module can't be used on radio system and operation Individually. Using others antenna must be re-testing and certification. 8F., No.192, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.). TEL: + 886-2-2914-5665 FAX: + 886-2-2918-6731, +886-2-2918-2895 www.billion.com - 4 - 1-2. Antenna Description Type: Dipole Antenna A. Electrical Characteristics Frequency 700 ~ 960 MHz S.W.R. <= 3.5 @ 700 ~ 960 MHz Antenna Gain 1.37 dBi Polarization Linear Impedance 50 Ohm B. Material & Mechanical Characteristics Material of Radiator Cu Material of Plastic TPE & ABS Cable Type RG-178 Connecter Type SMA Male Pull Test >= 5 Kg C. Environmental Operation Temperature - 40 ̊C ~ + 65 ̊C Storage Temperature - 40 ̊C ~ + 80 ̊C 8F., No.192, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.). TEL: + 886-2-2914-5665 FAX: + 886-2-2918-6731, +886-2-2918-2895 www.billion.com - 5 - 1-2. Key Features Supporting Following Standards LTE : Long Term Evaluation (3GPP E-UTRA Release 8) E-UTRA: Evolved Universal Terrestrial Radio Access Supporting Following Service LTE packet data service Supporting Following Features FDD: Frequency Division Duplex RX diversity Uplink data rate up to 25 Mbps Downlink data rate up to 50 Mbps Mini PCI Express form factor, USB interface *Maximum data rate is subject to 4G services provided by network operators Operating Systems Supported Microsoft Windows XP ,Microsoft Vista , Microsoft Windows …

Text truncated - open the document above for the full version.

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 Date: 2013-08-07 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Billion Electric Co., Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): (Product description, model name) Product name: Brand: FCC ID: We affirm that between SIEMIC and Billion Electric Co., Ltd. , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities.

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Date :2013-08-07 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Tune up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application.

External Photos

Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 6, 2013 A1 - 1 / 4 Rev. 00 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 6, 2013 A1 - 2 / 4 Rev. 00 Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 6, 2013 A1 - 3 / 4 Rev. 00 Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 6, 2013 A1 - 4 Rev. 00

ID Label/Location Info

Label location Label

Internal Photos

Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 6, 2013 A1 - 1 / 4 Rev. 00 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 6, 2013 A1 - 2 / 4 Rev. 00 Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 6, 2013 A1 - 3 / 4 Rev. 00 Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 6, 2013 A1 - 4 Rev. 00

RF Exposure Info

Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 27, 2013 Page 1 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. APPENDIX I RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUT 4G LTE Embedded Mini-Card Module Model WW-DL060 Frequency band (Operating) LTE Band 12: 701.5MHz ~ 713.5MHz(Channel Bandwidth 5MHz) LTE Band 12: 704.0MHz ~ 711.0MHz(Channel Bandwidth 10MHz) Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational / Controlled exposure (S = 5mW/cm 2 ) General Population / Uncontrolled exposure Antenna Specification Dipole Antenna, Gain: 1.0 dBi ± 0.7 dBi @ low Band Average output power LTE Band 12 Channel Bandwidth 5MHz : QPSK : 24.26 dBm(266.686mW) 16QAM : 23.86 dBm(243.220mW) Channel Bandwidth 10MHz : QPSK : 23.10 dBm(204.174mW) 16QAM : 24.18 dBm(261.818mW) Tune up limit 23 ± 2.7 dBm Evaluation applied MPE Evaluation* SAR Evaluation N/A Remark: The maximum output power is 24.26 dBm (266.686 mW) at 713.5 MHz (with 1.48 numeric antenna gain.) Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 27, 2013 Page 2 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TEST RESULTS No non-compliance noted. Calculation Given d G P E    30 & 377 2 E S  Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 377 30 d G P S    Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields     2 2 0796 . 0 100 / 377 1000 / 30 d G P d G P S        Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Compliance Certification Services Inc. Report No.: T130717S02 Date of Issue: August 27, 2013 Page 3 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Maximum Permissible Exposure Substituting the MPE safe distance using d = 20 cm into Equation 1: G P S    000199 . 0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 LTE Band 12 Channel Bandwidth 5MHz QPSK: Measured Tune-up limit Measured Reported 23155 713.5 286.418 371.535 1.48 20 0.0844 0.1094 0.5 Limit (mW/cm 2 ) P (mW) Ch. Frequency (MHz) Gain (num.) D (cm) Power density in mW / cm 2 LTE Band 12 Channel Bandwidth 5MHz 16QAM : Measured Tune-up limit Measured Reported 23155 713.5 243.220 371.535 1.48 20 0.0716 0.1094 0.5 Limit (mW/cm 2 ) P (mW) Ch. Frequency (MHz) Gain (num.) D (cm) Power density in mW / cm 2 LTE Band 12 Channel Bandwidth 10MHz QPSK: Measured Tune-up limit MeasuredReported 23130711.0204.174371.5351.48200.06010.10940.5 Limit (mW/cm 2 ) P (mW) Ch. Frequency (MHz) Gain (num.)D (cm) Power density in mW / cm 2 LTE Band 12 Channel Bandwidth 10MHz 16QAM : Measured Tune-up limit MeasuredReported 23130711.0261.818371.5351.48200.07710.10940.5 Limit (mW/cm 2 ) P (mW) Ch. Frequency (MHz) Gain (num.)D (cm) Power density in mW / cm 2

Test Report

Compliance Certification Services Inc. FCC ID: QI3BIL-AWDL060 Report No.: T130717S02-RP1 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 67 Rev.00 FCC TEST REPORT and IC TEST REPORT For 4G LTE Embedded Mini-Card Module Model: WW-DL060 Trade Name: Billion Issued to Billion Electric Co., Ltd. 8F., No.192, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.) Issued by Compliance Certification Services Inc. No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: August 6, 2013 Compliance Certification Services Inc. FCC ID: QI3BIL-AWDL060 Report No.: T130717S02-RP1 Page 2 Rev. 00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 August 6, 2013 Initial Issue ALL Angel Cheng Compliance Certification Services Inc. FCC ID: QI3BIL-AWDL060 Report No.: T130717S02-RP1 Page 3 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ................................................................................................ 4 2. EUT DESCRIPTION ........................................................................................................................ 6 3. TEST METHODOLOGY ................................................................................................................. 7 3.1 DESCRIPTION OF TEST TYPE ....................................................................................................... 7 4. INSTRUMENT CALIBRATION .................................................................................................... 8 4.1 MEASURING INSTRUMENT CALIBRATION .............................................................................. 8 4.2 MEASUREMENT EQUIPMENT USED ........................................................................................... 8 4.3 MEASUREMENT UNCERTAINTY ................................................................................................. 9 5. FACILITIES AND ACCREDITATIONS ..................................................................................... 10 5.1 FACILITIES...................................................................................................................................... 10 5.2 EQUIPMENT .................................................................................................................................... 10 5.3 TABLE OF ACCREDITATIONS AND LISTINGS ........................................................................ 11 6. SETUP OF EQUIPMENT UNDER TEST ................................................................................... 12 6.1 SETUP CONFIGURATION OF EUT .............................................................................................. 12 6.2 SUPPORT EQUIPMENT ................................................................................................................. 12 7. TEST PROCEDURE AND RESULT ............................................................................................ 13 7.1 OUTPUT POWER MEASUREMENT ............................................................................................. 13 7.2 FREQUENCY STABILITY MEASUREMENT .............................................................................. 20 7.3 OCCUPIED BANDWIDTH MEASUREMENT .............................................................................. 23 7.4 BAND EDGE MEASUREMENT ..................................................................................................... 31 7.5 CONDUCTED SPURIOUS EMISSIONS ........................................................................................ 34 7.6 RADIATED EMISSION MEASUREMENT ................................................................................... 41 APPENDIX II PHOTOGRAPHS OF TEST SETUP ................................................................................ 66 Compliance Certification Services Inc. FCC ID: QI3BIL-AWDL060 Report No.: T130717S02-RP1 Page 4 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: Billion Electric Co., Ltd. 8F., No.192, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.) Equipment Under Test: 4G LTE Embedded Mini-Card Module Tr a d e N a m e : Billion Model: WW-DL060 Date of Test: July 26 ~ 29, 2013 FCC PART 27, SUBPART C, L, FCC PART 2 OPERATING BAND: 704~716 MHz Standard TEST TYPE AND LIMIT 2.1046 27.50(C)(10) Maximum Peak Output Power Limit: max. 3 watts e.r.p peak power 2.1055 27.54 Frequency Stability 2.1049 27.53(g) Occupied Bandwidth 27.50(d)(5) Peak to average ratio 27.53(g) Band Edge Measurements 2.1051 27.53(g) Conducted Spurious Emissions 2.1053 27.53(g) Radiated Spurious Emissions Note: 1. The test result judgment is decided by the limit of test standard 2. The information of measurement uncertainty is available upon the customer’s request. Compliance Certification Services Inc. FCC ID: QI3BIL-AWDL060 Report No.: T130717S02-RP1 Page 5 Rev. 00 Deviation from Applicable Standard None The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by Reviewed by Miller Lee Gina Lo Section Manager Section Manager Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. FCC ID: QI3BIL-AWDL060 Report No.: T130717S02-RP1 Page 6 Rev. 00 2. EUT DESCRIPTION Product 4G LTE Embedded Mini-Card Module Model Number WW-DL060 Model Discrepancy N/A Tr a d e Billion Received Date J…

Text truncated - open the document above for the full version.

Test Setup Photos

Compliance Certification Services Inc. FCC ID: ZJD-ARV5403FLLTE Report No.: T120917W01-RP1 Page 66 Rev. 00 APPENDIX II PHOTOGRAPHS OF TEST SETUP Conducted Emission Setup Photos Compliance Certification Services Inc. FCC ID: ZJD-ARV5403FLLTE Report No.: T120917W01-RP1 Page 67 Rev. 00 Radiated Emission Setup Photos

Contact Information

Applicant

Kevin Lien
[email protected]886-2-2914-5665Fax: 886-2-2918-2895

Test Firm

Compliance Certification Services Inc.Hank Lee
[email protected]886-2-22999720Fax: 886-2-22999721

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
427704 MHz - 711 MHz371.50 mW8M96W7D47 Hz
Modular Type
Single Modular Approval
Confidentiality
Long Term
Grant Notes
Modular approval for mobile host platform. Power listed is the maximum peak conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
