QIFB47Bluetooth speaker

B47 FCC ID:QIFB47 2.1+EDR Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Rm. 401, Bldg. 13, Shenzhen Software Park, Keji Central 2nd Road, Nanshan District, Shenzhen, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 DATE 2015-06-30 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: QIFB47 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, My Music Group Limited Contact person: Bessie Luo Title: Manager

Rm. 401, Bldg. 13, Shenzhen Software Park, Keji Central 2nd Road, Nanshan District, Shenzhen, China Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 7/2/2015 Request for Confidentiality Company name: My Music Group Limited FCC ID: QIFB47 FCC Part 15 Certification Gentlemen, In accordance with CFR 47 § 0.459, My Music Group Limited hereby requests confidentiality of following attachments: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation These documents contain detailed system and equipment description and related information about the product which My Music Group Limited considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, My Music Group Limited considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Company Officer: Bessie Luo Company address： Room2026 , Global Logistics Service Center, China South City, Pinghu Town, Long Gang District, Shenzhen,China Email: [email protected]

External Photos TOTAL VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location Model: B47 FCC I D: QIFB47

FCC ID Label Location Model: B47 FCC I D: QIFB47

Internal Photos OPEN VIEW OF EUT INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 Antenna

Rm. 401, Bldg. 13, Shenzhen Software Park, Keji Central 2nd Road, Nanshan District, Shenzhen, China Declaration concerning Antenna Specification It is hereby declared that the product Model No.: B47 FCC ID: QIFB47 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for PCB antenna type described below: Model No. of antenna: N/A Type of antenna: PCB Antenna permanently attached Gain of the antenna: 0 dBi Frequency range: 2402-2480 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: My Music Group Limited Address: Room2026 , Global Logistics Service Center, China South City, Pinghu Town, Long Gang District, City: Shenzhen City ZIP / Postal code: 518111 Country: China Place: Shenzhen Date: 2015-06-30 Signature:

Part NameDescriptionQtyLocation ICPN25D04/SOP_8/ROHS1U6 ICBK8006/QFN56_7*7/ROHS1U1 ICM5158/SOP_8/ROHS1U2 RES.0.68Ω 1/10W 2010 J/ROHS1R11 RES.390Ω 1/16W 0603 J /ROHS1R1 RES.1KΩ 1/16W 0402 J /ROHS2 R17 R19 RES.1.2KΩ 1/16W 0402 J /ROHS2R4 R6 RES.4.7KΩ 1/16W 0603 J /ROHS1R18 RES.15KΩ 1/16W 0603 J /ROHS2R2,R3 RES.20KΩ 1/16W 0402 J /ROHS3R13 R14 R15 IND.4.7uH/0603/SMTROHS2L1 L2 CAP.2.7PF/50V 0402 /NPO/ROHS1C33 CAP. 15PF/50V 0402 /NPO/ROHS2C4 C18 CAP. 102PF/50V 0402 /X5R/ROHS1C20 CAP. 103PF/50V 0402 /X5R/ROHS1C8 CAP. 154/50V 0402 /Y5V/ROHS2C17 C19 CAP. 474/50V 0402 /Y5V/ROHS2C21 C25 CAP. 105/50V 0402 /Y5V/ROHS13 C1 C2 C5 C6 C7 C9 C10 C12 C14 C16 C27 C28 C30 diode1N4148/SMD-523 /ROHS1D3 diode1N5819/SMA /ROHS1D2 LEDBlue/0603/SMT/ROHS1D1 LEDred/0603/SMT/ROHS1D4 Triode9015/SMT/SOT-23/ROHS1Q4 switch4PIN/SMT/ROHS1K1 switchMSS22DC02G2/6PIN/SMT/ROHS1K2 crystalXTAL_3.2X2.5MM/26MHz/3225/±10ppm/9.3pF/ROHS1Y1 button3*4*3.5/SMT/4PIN1S1 MIC 38DB/0mm/ROHS 1MIC1 FCC ID: QIFB47

RF Exposure evaluation Product Description:Bluetooth Speaker Model Number: B47 FCC ID: QIFB47 According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation According to the follow transmitter output power（P t ）formula： P t =（E x d） 2 /（30 x g t ） P t =transmitter output power in watts g t =numeric gain of the transmitting antenna (unitess) E=electric field strength in V/m d=measurement distance in meters (m) According to the above test data, Emax=91.37dBuv/m=0.037V/m,d=3m,g t =1 P t =（E x d） 2 /（30 x g t ）=(0.037x3) 2 /(30x1)=0.000411W=0.41mW The result is rounded to one decimal place for comparison Worse case is as below: [2402MHz -0.41mW output power] (0.41mW /5mm) .[√2.402(GHz)]= 0.127<3.0 for 1-g SAR Then SAR evaluation is not required NOTE: For the maximum power, you can refer FCC test report.

Page 1 of 50 FCC Test Report Report No.: AGC00924150606FE03 FCC ID : QIFB47 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Bluetooth Speaker BRAND NAME : My Music MODEL NAME : B47 CLIENT : My Music Group Limited DATE OF ISSUE : June 29,2015 STANDARD(S) TEST PROCEDURE(S) : FCC Part 15 Rules REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC00924150606FE03 Page 2 of 50 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / June 29,2015 Valid Original Report Report No.: AGC00924150606FE03 Page 3 of 50 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY ...................................................................................... 4 2. GENERAL INFORMATION .................................................................................................. 5 2.1. PRODUCT DESCRIPTION ........................................................................................................... 5 2.2. TABLE OF CARRIER FREQUENCYS .......................................................................................... 5 3. MEASUREMENT UNCERTAINTY........................................................................................ 6 4. DESCRIPTION OF TEST MODES ........................................................................................ 6 5. SYSTEM TEST CONFIGURATION ...................................................................................... 7 5.1. CONFIGURATION OF EUT SYSTEM .......................................................................................... 7 5.2. EQUIPMENT USED IN EUT SYSTEM ......................................................................................... 7 5.3. SUMMARY OF TEST RESULTS .................................................................................................. 7 6. TEST FACILITY .................................................................................................................... 8 7 ALL TEST EQUIPMENT LIST ............................................................................................... 8 8. RADIATED EMISSION ......................................................................................................... 9 8.1TEST LIMIT ..................................................................................................................................... 9 8.2. MEASUREMENT PROCEDURE ................................................................................................ 10 8.3. TEST SETUP .............................................................................................................................. 12 8.4. TEST RESULT(Worst modulation:GFSK) ................................................................................... 14 9. BAND EDGE EMISSION .................................................................................................... 27 9.1. MEASUREMENT PROCEDURE ................................................................................................ 27 9.2 TEST SETUP ............................................................................................................................... 27 9.3 RADIATED TEST RESULT(Worst modulation:GFSK) ................................................................. 28 10. 20DB BANDWIDTH .......................................................................................................... 32 10.1. MEASUREMENT PROCEDURE .............................................................................................. 32 10.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ..................................................... 32 10.3. LIMITS AND MEASUREMENT RESULTS ................................................................................ 32 11. FCC LINE CONDUCTED EMISSION TEST ..................................................................... 39 11.1. LIMITS OF LINE CONDUCTED EMISSION TEST ................................................................... 39 11.2. BLOCK DIAGRAM OF LINE CONDUCTED EMISSION TEST ................................................. 39 11.3. PRELIMINARY PROCEDURE OF LINE CONDUCTED EMISSION TEST .............................. 40 11.4. FINAL PROCEDURE OF LINE CONDUCTED EMISSION TEST ............................................. 40 11.5. TEST RESULT OF LINE CONDUCTED EMISSION TEST ....................................................... 41 APPENDIX A: PHOTOGRAPHS OF TEST SETUP ............................................................... 43 APPENDIX B: PHOTOGRAPHS OF EUT .............................................................................. 45 Report No.: AGC00924150606FE03 Page 4 of 50 1. VERIFICATION OF CONFORMITY Applicant My Music Group Limited Address Room2026 , Global Logistics Service Center, China South City, Pinghu Town, Long Gang District, Shenzhen 518111, China Manufacturer Dongguan Fulun Electronic Co.,Limited Address 4F,Building A,Huangjinye Industrial Park,No.216Shaxin Road,Keyuan City,Tangxia, Dongguan.CN Product Designation Bluetooth Speaker Brand Name My Music Test Model B47 Date of test June 24,2015 to June 26,2015 Deviation None Condition of Test Sample Normal Report Template AGCRT-US-BR/RF We hereby certify that: The above equipment was tested by Compliance Certification Service(Shenzhen) Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with radiated emission limits of FCC Rules Part 15.249. Prepared By Time Huang June 29,2015 Checked By Forrest Lei June 29,2015 Authorized By Solger Zhang June 29,2015 Report No.: AGC00924150606FE03 Page 5 of 50 2. GENERAL INFORMATION 2.1. PRODUCT DESCRIP…

Text truncated - open the document above for the full version.

Test Setup Photos FCC LINE CONDUCTED EMISSION TEST SETUP FCC RADIATED EMISSION TEST SETUP
